Configuration guidelines
•
The gatekeeper identifies the type of a gateway by its area ID. The gatekeeper and gateways
reach an agreement on related gateway types in advance. For example, Area ID 1# represents
a voice gateway, and Area ID 2# represents a video gateway. Before a VoIP entity
communicates with the gatekeeper, the gatekeeper judges the gateway type by the received
area ID. At most 30 area IDs can be configured in GK-Client view.
•
Before you can configure a secondary gatekeeper, configure a primary gatekeeper with the
gk-id command.
•
Use the ras-on command to register with the gatekeeper only after you complete all required
basic voice gateway configurations.
Configuration procedure
To configure basic H.323 gateway functions:
Step
1. Enter system view.
2. Enter voice view.
3. Configure an H.323
descriptor.
4. Enter gateway view.
5. Assign an area ID to the
H.323 gateway.
6. Bind a source IP address
(typically the IP address of a
loopback interface) with the
H.323 gateway.
7. Configure a gateway alias.
8. Configure a primary
gatekeeper.
9. Configure a secondary
gatekeeper.
10. Enable the gatekeeper client
function to register with the
gatekeeper.
For more information about POTS and VoIP entities, see "Configuring voice entities."

Configuring registration password

You can configure the gateway to send a password with the RPQ message sent for registration with
the gatekeeper. When the gatekeeper receives this request, it compares the password with the one
configured on it for the gateway. The gatekeeper will accept the request and return an RCF only
when they are the same.
Command
system-view
voice-setup
voip h323-descriptor descriptor
gk-client
area-id string
gw-address ip-address
gw-id namestring
gk-id gk-name gk-addr
gk-ipaddress [ ras-port ]
gk-2nd-id gk-name gk-addr
gk-ipaddress [ ras-port ]
ras-on
222
Remarks
N/A
N/A
Optional.
The default is Wqldg0Hcwfydz.
If you want to change the
descriptor, make sure you
understand the impact of this
command before you use it.
N/A
Optional.
No area ID is assigned by default.
No source IP address is bound by
default.
No gateway alias is configured by
default. Each gateway can be
assigned only one alias.
No primary gatekeeper is
configured by default.
Optional.
No secondary gatekeeper is
configured by default.
Disabled by default.
