Configuring a number priority peer

Configuration prerequisites

The required basic configurations have been completed on POTS, VoIP, VoFR, and IVR entities.

Configuration procedure

To configure a number priority peer:
Step
1. Enter system view.
2. Enter voice view.
3. Enter voice dial program
view.
4. Configure a number priority
peer.
After the number-priority peer enable command is configured, a dialed number will match first
against a voice entity match template and then a service feature code. For example, if a service
feature code is *40*1234 and the match template *40 is configured for a voice entity, *40*1234 dialed
by a user will first match the number template *40 (*40 is dialed out as the called number), and the
feature corresponding to the service feature code *40*1234 will not be triggered.
For more information about the configuration of feature codes, see "Configuring call services."

Configuring a maximum-call-connection set

To control communication traffic, limit the total call connections for one or more voice entities
according to the network scale.
To configure a maximum-call-connection set:
1. Create a maximum-call-connection set. The parameters include a set label and the maximum
number of call connections.
2. Bind the maximum-call-connection set to voice entities.
By comparing the maximum number of call connections with the number of existing call connections
of voice entities in a set, the voice gateway determines whether these voice entities can establish
new calls.
Configuration prerequisites
The required basic configurations have been completed on POTS, VoIP, VoFR, and IVR entities.
Command
system-view
voice-setup
dial-program
number-priority peer enable
115
Remarks
N/A
N/A
N/A
Optional.
By default, a number starting with
an asterisk (*) or a pound sign (#)
will first match against a service
feature code.
