Task

Configuring basic parameters for an E1 voice interface

Configuring basic parameters for a T1 voice interface
Configuring the voice subscriber line for a TS set
Binding logical voice subscriber line to POTS entity
Configuring R2 signaling
Configuring PRI
Configuring digital E&M signaling
Configuring digital LGS signaling
Configuring AMD
Configuring reverse charging function
Enabling the router to treat DISCONNECT messages with PI 8 as
standard DISCONNECT messages
Mirroring PCM, RTP packets, or voice command data on a digital voice
subscriber line
Configuring basic parameters for an E1 voice
interface
This section describes the basic parameters and procedures for configuring an E1 voice interface.

Configuring a TDM clock source

Introduction to TDM clock source
When digital voice E1 interfaces perform time-division multiplexing (TDM) timeslot interchange, it is
important for them to achieve clock synchronization to prevent frame slips and bit errors.
Depending on your configurations on E1 interfaces, the system adopts different clocking approaches.
When there is a voice co-processing module (VCPM) on the main board, the clock distribution
principle is as follows:
•
If the clock mode is set to line for all interfaces, the clock on the interface with the lowest
number is adopted. If the interface goes down, the clock on the interface with the next lowest
number is adopted.
•
If the clock mode is set to line primary for one interface, the clock on the interface is adopted.
In one system, you can do this on only one interface.
•
If the line keyword is specified for one interface and the internal keyword for all others, the
clock on the interface is adopted.
•
Generally, you cannot set the clock source for all interfaces in a system to internal. This is to
prevent frame slips and bit errors. You can do this, however, if the remote E1 interfaces adopt
the line clock source.
Configuring basic R2 signaling parameters
Configuring R2 digital line signaling
Configuring R2 interregister signaling
63
Remarks
Optional.
Optional.
Required.
Required.
Optional.
Optional.
Optional.
Required.
Optional.
Optional.
Optional.
Optional.
Optional.
Optional.
