Configuring the connection mode for an R2 call
There are two connection modes for an R2 call: terminal-to-terminal (terminal) and
segment-to-segment (segment) mode.
•
In the terminal-to-terminal (terminal) mode, after the called number is received, the R2 protocol
module must wait for the real state (busy or idle) of the called party before returning the
corresponding register information to the originating side.
•
In the segment-to-segment (segment) mode, after the called number is received, the R2
protocol module directly returns the "called party idle" register signaling, without waiting for the
real state of the terminating side.
To configure the connection mode for an R2 call:
Step
1. Enter system view.
2. Enter E1/T1 interface view.
3. Create a TS set and enable
R2 signaling for it.
4. Enter R2 CAS view.
5. Configure the connection
mode for an R2 call.
Maintaining the circuits of a timeslot or a range of timeslots
Step
1. Enter system view.
2. Enter E1/T1 interface view.
3. Create a TS set and enable
R2 signaling for it.
4. Enter R2 CAS view.
5. Maintain the circuits of a
timeslot or a range of
timeslots.
Setting the length of called numbers that can be received
With an E1POS card installed, a point of sale (POS) terminal can access the network using R2
signaling. You can accelerate signaling exchange by setting the length of called numbers received
by the E1POS card. This will meet the real time transmission requirements of the POS terminal
access service.
To set the length of called numbers that can be received:
Step
1. Enter system view.
2. Enter E1 interface view.
3. Create a TS set and enable
R2 signaling for it.
4. Enter R2 CAS view.
Command
system-view
controller { e1 | t1 } slot-number
timeslot-set ts-set-number
timeslot-list timeslots-list signal r2
cas ts-set-number
callmode { terminal | segment }
Command
system-view
controller { e1 | t1 } slot-number
timeslot-set ts-set-number timeslot-list
timeslots-list signal r2
cas ts-set-number
ts { block | open | query | reset } timeslots
timeslots-list
Command
system-view
controller e1 slot-number
timeslot-set ts-set-number timeslot-list
timeslots-list signal r2
cas ts-set-number
78
Remarks
N/A
N/A
N/A
N/A
Optional.
By default, the
terminal-to-terminal
(terminal) mode is adopted.
Remarks
N/A
N/A
N/A
N/A
Optional.
Remarks
N/A
N/A
N/A
N/A
