Binding an FXS voice subscriber line to an FXO
voice subscriber line
The one-to-one binding between FXS voice subscriber lines and FXO voice subscriber lines
enhances the reliability of voice communication, which is particularly important for some industries.
After the binding, FXO voice subscriber lines can be used for communication over PSTN when the IP
network is unavailable.
The one-to-one binding between FXS voice subscriber lines and FXO voice subscriber lines
provides the following functions:
•
Dedicated FXO voice subscriber lines—The FXO voice subscriber lines are used only for the
bound FXS voice subscriber lines and PSTN-originated calls received over the FXO voice
subscriber lines are directly connected to the bound FXS voice subscriber lines.
•
Consistent state between bound FXS and FXO voice subscriber lines—The
on-hook/off-hook state of the bound FXS and FXO voice subscriber lines is consistent. If an
FXS voice subscriber line receives a PSTN-originated call when the corresponding FXS voice
subscriber line goes off-hook, the calling party will hear busy tones.

Configuration prerequisites

The router is equipped with FXO and FXS interface cards. The basic functions of FXO and FXS
voice subscriber lines are configured.

Configuration procedure

To bind one FXS voice subscriber line to one FXO voice subscriber line:
Step
1. Enter system view.
2. Enter FXO voice
subscriber line view.
3. Bind an FXS voice
subscriber line to the FXO
voice subscriber line.
4. Enable the automatic
dialing of the bound FXS
voice subscriber line.
5. Configure an interval
between on-hook and
off-hook.
6. Exit FXO voice subscriber
line view.
7. Enter voice view.
8. Enter voice dial program
view.
9. Create a POTS entity and
enter POTS entity view.
Command
system-view
subscriber-line line-number
hookoff-mode delay bind
fxs_subscriber_line
[ ring-immediately ]
private-line string
timer hookoff-interval milliseconds
quit
voice-setup
dial-program
entity entity-number pots
42
Remarks
N/A
N/A
By default, no FXS voice
subscriber line is bound.
Disabled by default.
Optional.
The default is 500 milliseconds.
N/A
N/A
N/A
N/A
