Step
1. Enter system view.
2. Enter E1/T1 interface view.
3. Bundle timeslots into a PRI
group.
4. Exit E1/T1 interface view.
5. Enter the view of the serial
interface created for the PRI
group.
6. Enable DSS1 or QSIG
signaling.
7. Configure a signaling
protocol mode.
For more information about the isdn protocol-type and isdn protocol-mode commands, see HPE
FlexNetwork MSR Router Series Comware 5 Layer 2—WAN Command Reference.
Enabling the transmission of QSIG signaling over a SIP
network
With the SIP for telephones (SIP-T) protocol, the ISDN signaling messages can be tunneled through
the SIP messages. The device only supports encapsulating QSIG messages within SIP messages.
For more information about the SIP-T protocol, see "Configuring SIP."
To configure the SIP tunneling function:
Step
1. Enter system view.
2. Enter E1/T1 interface view.
3. Bundle timeslots into a PRI
group.
4. Exit E1/T1 interface view.
5. Enter the view of the serial
interface created for the PRI
group.
6. Enable QSIG signaling.
7. Exit E1/T1 interface view.
8. Enter the view of the voice
subscriber line of the PRI
group.
9. Enable the QSIG tunneling
function.
Command
system-view
controller { e1 | t1 } slot-number
pri-set [ timeslot-list range ]
quit
interface serial number: { 15 |
23 }
isdn protocol-type { dss1 |
qsig }
isdn protocol-mode { network |
user }
Command
system-view
controller { e1 | t1 } slot-number
pri-set [ timeslot-list range ]
quit
interface serial number: { 15 |
23 }
isdn protocol-type qsig
quit
subscriber-line number: { 15 |
23 }
qsig-tunnel enable
82
Remarks
N/A
N/A
N/A
N/A
N/A
By default, DSS1 signaling is
enabled.
The default is user.
Remarks
N/A
N/A
N/A
N/A
N/A
By default, DSS1 signaling is
enabled.
N/A
N/A
Disabled by default.
