Configuring call backup
By default, the call backup function is enabled on the device.
The system supports two types of call backup:
•
Strict call backup
One of the following three conditions will trigger strict call backup:
The device does not receive any reply from the peer after sending out a call request.
The device fails to initiate a call to the IP network side.
The device fails to register on the voice server.
•
Loose call backup
Loose call backup is triggered if any of the above mentioned three conditions or the following
condition happens: the device receives a reject reply (with a number from 3xx to 6xx except 300,
301, 302, 305, 401, 407, and 422) after sending a call request.
To configure the call backup mode:
Step
1. Enter system view.
2. Enter voice view.
3. Specify the loose call
backup mode.
4. Set the time duration for call
backup.

Configuring hunt group

This section describes the procedures for enabling and configuring a hunt group.
Configuration prerequisites
The router is equipped with an FXS voice interface card.

Enabling hunt group

To enable hunt group:
Step
1. Enter system view.
2. Enter voice subscriber line
view.
Command
system-view
voice-setup
backup-rule loose
voip timer voip-to-pots time
Command
system-view
subscriber-line line-number
237
Remarks
N/A
N/A
Optional.
By default, strict call backup is
applied.
Optional.
Defaults to 5 seconds.
For more information about the
voip timer voip-to-pots
command, see HPE FlexNetwork
MSR Router Series Comware 5
Voice Command Reference.
Remarks
N/A
N/A
