Step
5. Bind a SIP trunk
account to the VoIP
voice entity.
6. Enable the SIP proxy
server.
7. Return to system
view.
8. Enter SIP client view.
9. Specify a SIP server
group to be used as
the proxy server.

Configuring call match rules

You can control call route selection by configuring the prefix of the source host name, prefix of the
destination host name, or the source IP address as the call match rule in VoIP voice entity view. If you
have configured several call match rules, only the callings that match all rules are permitted.
Configure the call match rules as follows:
•
Use the match source host-prefix command to specify the prefix of source host name as a
call match rule for a VoIP voice entity. The specified prefix of source host name is used to match
against the source host names of calls.
If the INVITE message received by the SIP trunk device carries the Remote-Party-ID
header, the calling information is abstracted from this header field.
If the INVITE message received by the SIP trunk device carries the Privacy header, the
source host name is abstracted from the P-Asserted-Identity or P-Preferred-Identity header
field.
If the INVITE message received by the SIP trunk device does not carry any of the previously
mentioned three header fields, the host name in the From header field of the INVITE
message is used as the source host name.
•
Use the match destination host-prefix command to specify the prefix of destination host
name as a call match rule for a VoIP voice entity. The specified prefix of destination host name
is used to match against the destination host names of calls. The host name in the To header
field of an INVITE message received by the SIP trunk device is used as the destination host
name.
•
Use the match source address command to specify the source address as a call match rule
for a VoIP voice entity.
To configure the call match rules:
Step
1. Enter system view.
2. Enter voice view.
3. Enter voice dial program
view.
4. Enter VoIP voice entity
view.
Command
bind sip-trunk account
account-index
address sip proxy
quit
sip
proxy { dns domain-name | ipv4
ip-address [ port port-number ] |
server-group group-number }
Command
system-view
voice-setup
dial-program
entity entity-number voip
205
Remarks
By default, no SIP trunk account is
bound to the VoIP voice entity.
Only an existing SIP trunk account can
be bound to a VoIP voice entity.
Not configured by default.
N/A
N/A
Not configured by default.
Remarks
N/A
N/A
N/A
N/A
