Replacing Memory Air Duct; Remove The Memory Air Duct - Oracle Sun Netra T5440 Service Manual

4.5

Replacing Memory Air Duct

Remove the Memory Air Duct

Prepare the server for memory air duct removal. See:
1.
"Power Off the Server" on page 59
■
"Remove the Server From the Rack" on page 60
■
■ "Perform Antistatic Measures" on page 61
"Remove the Top Cover" on page 62
■
Facing the server, carefully lift the rear of the air duct upward
2.
3. Lift the duct out of the chassis
Set it aside on an antistatic mat.
(Figure 4-7).
Chapter 4 • Replacing Motherboard Assembly Components
4.5 Replacing Memory Air Duct
(Figure 4-7).
83
