Install the SAS Drive Signal Cable

If you are removing a cable as part of another component's removal or installation
■
procedure, go to
Review this information, and complete these prerequisites in this order.
3.
"Remove a Fan Module" on page 132
■
"Remove the Fan Tray" on page 80
■
Disconnect the SAS drive signal cable from the drive backplane connector.
4.
See "System Cable Configuration" on page
5. Disconnect the SAS drive signal cable from the motherboard connector.
6. Set the cable aside.
7. Consider your next step.
If you removed a cable as part of a replacement operation, install a new cable.
■
See
If you removed a cable as part of another component's removal or installation procedure,
■
return to that procedure.
See
Related Information
"Install the SAS Drive Signal Cable" on page 158
■
"Component Locations (Storage, Power, and Fan Modules)" on page 14
■
"Preparing for Service" on page 61
■
"Returning the Server to Operation" on page 247
■
Install the SAS Drive Signal Cable
Installing a cable is a cold-service operation. You must power off the server before installing the
cable.
Consider your first step.
1.
If you are replacing a cable, remove the faulty or obsolete cable first, then return to this
■
procedure,
See
If you are installing a cable as part of another component's removal or installation
■
procedure, go to
2. Connect the SAS drive signal cable to the motherboard connector.
158 Netra Server X5-2 Service Manual • October 2016
Step 3.
"Install the SAS Drive Signal Cable" on page
"Component Service Task Reference" on page 65
Step 2.
"Remove the SAS Drive Signal Cable" on page
Step 2.
156.
158.
for assistance.
157.
