Performing Color Calibration
Color calibration improves color consistency by compensating for slight differences in how color appears
when printing due to individual variations or aging among the printers.
Executing color calibration will print a test pattern (built into the printer) that is then read automatically by the
By this operation, calibration adjustment values reflecting the print result of the test pattern are set
• To increase the color stability precision when executing color calibration, maintain a constant
temperature and humidity environment each time within the range of temperatures of 59 to 86°F (15 to
30°C) and within the range of humidities of 40 to 60%.
Executing color calibration under various temperature and humidity conditions may prevent the printer
from making the correct adjustments.
• Before color calibration, ensure the printer is not exposed to direct sunlight or other strong sources of
If the printer is exposed to strong sources of light, correct adjustment may not be possible.
Recommend Timing for Color Calibration
We recommend color calibration in the following situations.
• After initial printer installation
• After print head replacement
• If colors seem different from before, despite using the same printing environment, under the same
• To print with colors aligned from multiple printers
• When the execution guide is displayed
Executing Color Calibration
Execute color calibration using the following procedure.
1. You can confirm whether the paper to be loaded can be used in color calibration.
Paper Information List
2. Load the paper.
Loading Rolls on the Roll Holder
Loading the Upper Roll on the Printer
Loading the Lower Roll on the Roll Unit (Option)
Loading Sheets in the Printer
