Example Basket Configurations

Various positions are possible for the basket that collects the printed materials.
In this section, we present the following five positions as examples of using the basket. Switch the position
of the basket to suit to the media type and the print job.
• Using Without roll unit (Position 1)
• Using With roll unit (Position 2)
• Printing on Large-Format or Easily Damaged Paper (Position 3)
• Stacking Printed Materials (Position 4)
• Moving Printed Materials to Next Work Area Immediately (Position 5)
For instructions on switching the basket position, see
Important
• If replacing the roll paper or using the roll unit as a take-up device, you must store the basket. For
instructions on storing the basket, see
• If the printed materials collected are damaged or folded, select Eject cut in Cutting mode or use the
basket in a different position. (See
Note
• For details on the printer dimensions when using the basket, see "Specifications."
Using Without roll unit (Position 1)
You can use the basket in the following positions when not using the roll unit.
Important
• The number of sheets that can be collected in the basket is one. If printing multiple pages, print after
removing each sheet.
"Using the
"Storing the Basket."
"Specifying the Cutting Method for
109
Basket."
Rolls.")
