Table E-8 (Cont.) System Motherboard Components
Component Name IPMI Type
(Oracle ILOM CLI
Targets)
/SYS//SYS/MB/ State
RISER6/PCIE[6, 8]/ Sensor
P_ENABLE_STATE
/SYS/MB/ROT FRU
/SYS//SYS/MB/ROT/ Discrete
Sensor
PRSNT
/SYS/MB/ Threshold
T_IN_ZONE[0-3] sensor
Threshold
/SYS/MB/
T_OUT_ZONE[0-3] sensor
/SYS/SP FRU
/SYS/SP/OK Indicator
FRU
/SYS/SP/NET[0-1]

System Firmware Components

The following table lists the system firmware components.
Table E-9

System Firmware Components

Component IPMI
Name (Oracle Type
ILOM CLI
Targets)
/SYS/MB/BIOS FRU
/SYS/MB/CPLD FRU
Description
PCIe slots on Riser 6 Power Enable State
Root of Trust FRU
Optional card is present in slot 1 (only
supported slot)
Root of Trust is Present
Cooling zone input temperature sensor
Cooling zone output temperature sensor
Service processor FRU
SP Ethernet FRU
Description
BIOS FRU
Motherboard complex programmable logic device (CPLD)/field programmable gate
array (FPGA) firmware version
Appendix E
System Firmware Components
Values (if applicable)
02h-SLOT POWER ENABLED
01h-SLOT POWER DISABLED
01h-ENTITY_ABSENT
02h-ENTITY_PRESENT
Degrees Celsius
Degrees Celsius
SP OK LED
Color: Green
Location: Front panel
On: SP is operating.
Off: SP requires service.
