Server Components

These sections describe Exadata Server X10M component names, status, and indicator
states. The tables in this section identify the system components and describe the naming
conventions applied to the components of Exadata Server X10M. Each section corresponds
to an IPMI entity ID and lists sensors, indicators, and replaceable units related to that entity.
The tables contain the following fields:
• Component Name – Shows the user-visible component name used in management
interfaces to refer to a specific sensor, indicator, or replaceable unit. The IPMI name is a
shortened form of the component name, and is indicated by the boldface portion of the
component name.
• IPMI Type – Indicates the type of sensor, indicator, or replaceable unit represented.
• Description – Describes the particular component name reference.
• Values – Defines the states of the sensor, indicator, or replaceable unit entity, and any
specific units or values that are expected, if applicable.
This section includes information for the following server components.

System Chassis Components

The following table lists the system chassis components.
Table E-1

System Chassis Components

Component Name IPMI Type
(Oracle ILOM CLI
Targets)
/SYS FRU
/SYS/UUID FRU
State
/SYS/ACPI
sensor
/SYS/VPS Threshold
sensor
/SYS/VPS_CPUS Threshold
sensor
/SYS/VPS_MEMORY Threshold
sensor
Threshold
/SYS/VPS_FANS
sensor
/SYS/T_AMB Threshold
sensor
Description
Product information only
Unique system ID
Advanced Configuration and Power
Interface
Virtual power consumption sensor
Virtual power sensor - CPU power
consumption
Virtual power sensor - memory power
consumption
Virtual power sensor - fan power
consumption
Ambient temperature on system
motherboard
Values (if applicable)
Derived from host MAC address.
Used for PXE boot and licensing.
01h-ACPI_ON_WORKING
20h-ACPI_SOFT_OFF
Watts
Watts
Watts
Watts
Degrees Celsius
