Remove the Right LED/USB Indicator Module

Remove the Right LED/USB Indicator Module
1. Prepare the server for service.
a. Power off the server and disconnect the power cords from the power
supplies.
See
Extend the server into the maintenance position.
b.
See
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
c.
chassis.
See
d. Remove the server top cover.
See
Remove the server fan assembly door.
2.
See "Remove the Fan Assembly Door From the Server" on page
3. Remove the four remaining No. 2 Phillips screws (two on each side of the
chassis) that secure the disk cage assembly to the server chassis.
138 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
"Powering Down the Server" on page
"Extend the Server to the Maintenance Position" on page
"Take Antistatic Measures" on page
"Remove the Server Top Cover" on page
51.
55.
57.
58.
59.
