About Controls and Connectors

Note -
Storage drive configurations include a DVD drive (optional) and up to eight hard disk drives
■
(HDDs) or solid state drives (SSDs), with optional support for up to four PCIe-based NVMe
(non-volatile memory express) SSD drives.
Two hot-pluggable, redundant power supplies.
■
An on-board Oracle Integrated Lights Out Manager (Oracle ILOM) service processor (SP)
■
based on the Emulex Pilot3 chip.
About Controls and Connectors
The following sections describe the controls, indicators, connectors, and drives located on the
front and rear panels.
"Front Panel Controls and Indicators" on page 14
■
"Server Back Panel View" on page 16
■
Related Information
"About System Components" on page 17
■
"Illustrated Parts Breakdown" on page 17
■

Front Panel Controls and Indicators

The following figure shows the controls, status indicators (LEDs), connectors, and drives on the
front panel of the Oracle Server X6-2.
14 Oracle Server X6-2 Service Manual • June 2016
Ethernet ports NET2 and NET3 are nonfunctional on single-processor systems.
