Reviewing DLCI Configuration (Figure 7-4, Item C)

7-10
Frame Relay Port Parameters (screen 2 of 2)
* RLP: 0 Port: 0
* I/O: V.35
A Enable Outgoing Rate Control
B Enable Bandwidth Allocation
C Review DLCI Configuration
D Configure DLCI Parameters
E View Learned DLCIs
F For Backup Use Only
G Automatic DCE
Option:
Figure 7-4 Frame Relay Port Screen 2
To display the current configured DLCIs on the port, press
7-4. A screen similar to the following information will be displayed for each con-
figured DLCI.
RLP Port DLCI
(Primary Info)
0 2 16
0 2 50
PgUp, PgDn, F2:Review All DLCIs, F3:Exit
Figure 7-5 DLCI Configuration Review Screen
Link State:
Database
Y
Y
N
N
ICIR IBC IBE OCIR OBC OBE BECN Pri
Grp RRLP RPrt RDLCI SOT
0 0 0 0 0
0 0 0 0 0
1 0 0 50 25
Node Name=node_xyz
Linkup
System Memory
Y
Y
N
N
at the screen in Figure
[C]
Node Name=node_xyz
Proto
SBT TTH
0 0 0 N
0 0 0 N
0 20
