– is the total number of RIP and SAP packets transmitted on the local
Pkts Tx
interface.
– is the total number of successfully transmitted RIP and SAP
Tx Completions
packets that originated at the local node.
– is the total number of RIP and SAP packets received on the local
Pkts Rcv
interface.
– is the number of packets denied transmission because of a
Tx Pkts Filtered
filter configured on the interface.
– is the number of packets denied reception because of a filter
Rcv Pkts Filtered
configured on the interface.
– is self-explanatory.
Pkts Forwarded
– is the number of Echo Requests received on the interface.
Echo Requests Rcv
– is the number of replies to Echo Requests received on the
Echo Replies Rcv
interface.
– is the number of Novell error packets received on the
Err_Type Pkts Rcv
interface.
– is the number of packets discarded because the interface was
Pkts Discarded
down.
– is the number of packets received that exceeded the
Pkts_2_Large Rcv
Maximum Transmission Units configured for the interface. These packets are
discarded.
– are the version numbers of the IPX stack.
Major/Minor Version
– is the number of IPX packets received with incorrect header
Rcv Header Error
information. The header should be 30 bytes and contain network, node, and
socket addresses for source and destination.
– is the number of socket numbers received that could not be
Ukn Sockets Rcv
identified. Some socket numbers (assigned by Novell) are:
= NCP Process
0451
= RIP Process
0453
= Diagnostics Process
0456
through
Rcv BSys Discard
FRX4000/6000, but are included in the statistics list because it is part of the IPX
MIB. The statistics in the list between the above two are:
Local Rcv Pkts, Path_Not Found, Local Tx Pkts, Bad Local Tx Pkts, Tx BSys
Discard, Open Socket Fail, State Changes, Init Fail, Ms to Tx 1 Byte
– is the number of received RIP entries discarded due to a filter.
R-RIP Ent-Filter
– is the number of transmitted RIP entries discarded due to a
T-RIP Ent-Filter
filter.
– is the number of received SAP entries discarded due to a filter.
R-SAP Ent Filter
– is the number of transmitted SAP entries discarded due to a
T-SAP Ent-Filter
filter.
– is the number of received RIP packets discarded due to a RIP
R-RIP Pkt-Filter
router filter.
– is the number of transmitted RIP packets discarded due to a
T-RIP Pkt-Filter
RIP router filter.
= SAP Process
0452
= NetBIOS Process
0455
– are not monitored by the
R_Decomp Errors
FRX4000/FRX6000 4.0 User Guide, Rev 01
Bad Checksum Rcv,
