Getting Started
or
F4: Exit menu
Delete Record
—appears at the Main Menu, and exits to the Port Status display
Exit Menu
2-3). To return to the menu, you must enter the node's password. (This feature is
for security, to protect menu-level operations from unauthorized access.)
—initiates the deletion of the displayed record. A record for this
Delete Record
port number, containing all the default values, will remain in the database.
Deleting a port record for an existing port will immediately
disable the port.
—on statistics displays, clears the maximum/cumulative values
Clear Max Stats
from the display (restarting them at the current values).
—copies a Port record's database values to another port's record,
F5: Copy Record
which can be convenient if several records in a node will have identical (or almost
identical) configurations. After you perform this operation, the "copied to" record will
be displayed, with the new database values. (The original record is automatically
saved.) Press
to update the system memory values.
[F7]
You cannot copy a physical port's record to a logical port, or vice
versa.
—copies a Port record's database values to another port's record, then
F6: Move Record
deletes the original record. After you perform this operation, the "moved to" record
will be displayed, with the new database values. (The original record is automatically
saved.) Press
to update the system memory values.
[F7]
You cannot move a physical port's record to a logical port, or vice
versa.
—in Node Defaults or Physical/Logical Port configuration, copies
F7: On-line change
values to
Database
System Memory
described on
page 4-2
Filter Definitions and Applications, all changes made on the screen affect only system
memory, so
must be pressed to update the database.
[F7]
—terminates a remote control connection, gives you the option of
F9: Stop Remote
rebooting the remote node, and returns control to the local operator.
or
F10: Abort
Reboot Remote
—initiates a reboot of a local node.
Abort
—initiates a reboot of a remote node under local control. (You
Reboot Remote
must then press
[F9]
Before aborting or rebooting a node, notify all users that the
node will be going down.
or
Clear Max Stats
. (
Database
for Node Defaults and
:
to exit remote control.)
:
and
values are
System Memory
page 6-3
for Ports.) In IPX and Bridge
(Figure
2-9
