Configuring IP
IP Interface Configuration - Screen 2
Interface Number: 0
Secondary IP Address Configuration
A B
Seq Sec. IP Addr
1 1.0.0.0
Option:
Figure 13-3 LAN IP Interface – Secondary Address Configuration
Up to 15 secondary IP addresses can be configured on a LAN interface, providing
support for multiple IP subnets on the same physical LAN segment.
To configure a secondary address, press
in reverse video. To select a different address, press a number from
sponding to the sequence (
higher than the highest configured number will display a new entry for the next
sequential number after the highest configured number.)
When a secondary IP address (item B) is entered, default values will be displayed for
items C and D.
To delete an existing entry, press
higher sequence numbers will move up one to fill in the gap.
To delete a primary address (
deleting the group of associated secondary addresses, do this:
1.Select one of the secondary addresses to be the new primary.
2.Delete that secondary address.
3.Reconfigure the
was deleted.
Node Name=nodexyz
C D E
Net Mask Bcast Addr RMetric
223.255.255.0 0.0.0.255 0
. The selected address will be highlighted
[A]
) number of the entry. (Pressing any valid number
Seq
, then when asked to confirm. Any entries with
[G] [Y]
Source IP Address
to specify the secondary address that
Source IP Address
F G
RIP Support Del
0
, corre-
1–15
on the first screen) without
13-7
