Frame-level Statistics

Information in a Frame Relay Display:
Statistics Displays
Frame-level statistics are frame relay (if the port is configured for frame relay) or X.25
level 2 statistics (per second, multiplied by 10).
Frame Statistics Display
RLP: 0
Port: 1
Report Interval (sec): 5
Start Time: 4/21/1997 09:41:49
L2 State: Current
Information Transfer
CD FRAME TYPE
A SABM/sec (*10)
B UA/sec (*10)
C DISC/sec (*10)
D DM/sec (*10)
E FRMR/sec (*10)
F REJ/sec (*10)
G RR/sec (*10)
H RNR/sec (*10)
I INFO/sec (*10)
F2:Next F4:Clear Max F9: Stop Remote F10: Reboot Remote Others:Exit
Figure 20-5 Frame-level Statistics Display
This example shows an X.25 frame-level display. A frame relay display
will not include the two lines below
The information on those two lines includes the current and previous level
2 states, and the time in the current state.
– number of frames transmitted/received with the DE (Discard
DE/sec (*10)
Elgibility) bit set per second over the five-second reporting interval, multiplied
by 10.
– number of frames transmitted/received with the FECN
FECN/sec (*10)
(Forward Event Congestion Notification) bit set per second over the five-second
reporting interval, multiplied by 10.
– number of frames transmitted/received with the BECN
BECN/sec (*10)
(Backward Event Congestion Notification) bit set per second over the five-
second reporting interval, multiplied by 10.
– number of frames transmitted/received using LMI frame man-
LMI/sec (*10)
agement per second over the five-second reporting interval, multiplied by 10.
– number of frames transmitted/received using Annex D frame
ANXD/sec (*10)
management per second over the five-second reporting interval, multiplied by
10.
Previous Total Time in Current State
SABM Outstanding 0 Days 1 Hrs 4 Mins
Transmitted Received
CURR MAX CURR MAX
100 100 0 0
0 0 100 100
0 0 0 0
0 0 0 0
0 0 0 0
0 0 0 0
50 50 25 25
0 0 0 0
500 500 500 500
Start Time
Node Name=node_xyz
[E],[B],[F] from Main Menu
.
20-5
