Configuring Async PAD Profiles

PAD Profile Parameters

12-2
An async PAD profile is a specific set of X.3 parameters whose values define the oper-
ation of the device connected to an async PAD port on an FRX4000 or FRX6000. Dif-
ferent profiles contain the same parameters, but with difference(s) in the values.
To display a list of existing PAD profile names and descriptions, press
PAD Configuration Menu (or
database contains one profile,
minals to the PAD.
Changing a value in a profile in effect creates a new profile.
Unless you want to affect every device assigned that profile,
create a new profile instead of changing an existing one. Do not
change profile 90, since this is a CCITT standard.
To add or change a profile, press
the desired profile name (1–10 uppercase characters) to display the first of two screens
of parameters, listed in
second screen. Press
[PgUp]
return to the Node Configuration Menu.
When creating a new profile, be careful that you are not creating a duplicate
of an existing profile. When assigning a profile to a port, the software scans
the parameters of the specified profile and all other existing profiles, and if
there are duplicates, it loads the profile that was created first.
Table 12-1 Async PAD Profile Parameters
Parameter
Profile Description
01, PAD Recall
02, Echo
03, Data Forwarding Char
( sec)
04, Idle Timer Delay
05, Ancillary Device Control
06, PAD Service Signal
07, Receive Break Signal
08, Discard Output
09, Padding After <cr>
10, Line Folding
11, Speed
12, Flow Control
continued on next page
from the Main Menu). Note that the
[A], [A], [F], [A]
, which is a CCITT profile used for connecting ter-
90
at the Async PAD Configuration Menu and enter
[B]
Table 12-1. Press
[PgDn]
at the second screen to return to the first screen, or
Valid Values
1–31 uppercase chars.
0–126
0 (no) /
0–127
0–255
0–2
0–15
0–31
0 (no) /
0–255
0–255
n/a–determined in Port configration
0 (no) /
[A]
at the first screen to display the
Default Value
none
1
1 (yes)
1
126
0
1
1
2
1 (yes)
0
(characters)
0
0
1 (yes)
1
FRX4000/FRX6000 4.0 User Guide, Rev 01
at the Async
to
[F3]
