20-18
– is the number of RIP Nearest Queries transmitted on the
RIP N_Query Tx
interface.
– is the number of RIP General Responses (responses to General
RIP G_Resp Tx
Queries) transmitted on the interface.
– is the number of RIP Nearest Responses (responses to Nearest
RIP N_Resp Tx
Queries) transmitted on the interface.
– is the number of RIP packets received on the interface.
RIP Pkts Rcv
– is the number of RIP General Queries received on the
RIP G_Query Rcv
interface.
– is the number of RIP Nearest Queries received on the
RIP N_Query Rcv
interface.
– is the number of RIP General Responses (responses to
RIP G_Resp Rcv
General Queries) received on the interface.
– is the number of RIP Nearest Responses (responses to Nearest
RIP N_Resp Rcv
Queries) received on the interface.
– is the number of entries that have been deleted from the
RIP Aged Entries
routing information table, due to expiration of the
the IPX Interface record (described in
– is the number of periodic RIP messages broadcast from
RIP Prd_Broadcasts
this node advertising the available routes (from the routing table in the
FRX4000/6000).
– is the number of RIP messages broadcast from this node
RIP Upd_Broadcasts
to update the network with any changes in routes.
– is the number of RIP packets received with an invalid network
RIP INV Net Rcv
address (one that does not match the network address configured on the
interface). These packets will be discarded.
– is the number of RIP packets received containing routing
RIP Worse Rt Rcv
updates that are less efficient (worse) than the routes already in the routing
information table.
– is the number of RIP General Queries received with an
RIP Ukn G_Query
invalid packet size. These packets will be discarded.
– is the number of RIP Nearest Queries received with an
RIP Ukn N_Query
invalid packet size. These packets will be discarded.
– is the number of RIP General Responses received with an
RIP Ukn G_Resp
invalid packet size. These packets will be discarded.
– is the number of RIP Nearest Responses received with an
RIP Ukn N_Resp
invalid packet size. These packets will be discarded.
– is the number of SAP packets transmitted on the interface.
SAP Pkts Tx
– is the number of SAP General Queries transmitted on the
SAP G_Query Tx
interface.
– is the number of SAP Nearest Queries transmitted on the
SAP N_Query Tx
interface.
– is the number of SAP General Responses (responses to
SAP G_Resp Tx
General Queries) transmitted on the interface.
– is the number of SAP Nearest Responses (responses to Nearest
SAP N_Resp Tx
Queries) transmitted on the interface.
RIP Age Timer
Chapter 14).
FRX4000/FRX6000 4.0 User Guide, Rev 01
, configured in
