Table 3-13: IN_FIFO Input to Output Data Mapping in 4 x 4 Mode (Cont'd)
•
Table 3-14: IN_FIFO Input to Output Data Mapping in 4 x 8 Mode
Both modes support the FULL, EMPTY, ALMOSTFULL, and ALMOSTEMPTY flags.

IN_FIFO Primitive

The IN_FIFO primitive is shown in
7 Series FPGAs SelectIO Resources User Guide
UG471 (v1.10) May 8, 2018
Mapping
D5[3:0] → Q5[3:0]
D6[3:0] → Q6[3:0]
D7[3:0] → Q7[3:0]
D8[3:0] → Q8[3:0]
D9[3:0] → Q9[3:0]
D10[3:0] is D5[7:4] → Q5[7:4]
D11[3:0] is D6[7:4] → Q6[7:4]
4 x 8 mode – This mode configures the FIFO to have 10 4-bit wide data inputs (D) and
10 8-bit wide data outputs (Q). In 4 x 8 mode, the 4-bit input data is demultiplexed to
form the 8-bit output data width. 4 x 8 mode is generally used when the output clock
frequency is greater than one half the input clock frequency and thus output data is
twice the width of the input data.
Mapping
D0[3:0] → Q0[7:0]
D1[3:0] → Q1[7:0]
D2[3:0] → Q2[7:0]
D3[3:0] → Q3[7:0]
D4[3:0] → Q4[7:0]
D5[3:0] → Q5[7:0]
D6[3:0] → Q6[7:0]
D7[3:0] → Q7[7:0]
D8[3:0] → Q8[7:0]
D9[3:0] → Q9[7:0]
www.xilinx.com
Q7[7:4]
Q8[7:4]
Q9[7:4]
Table 3-14 shows the 4 x 8 mode mapping in detail.
Figure 3-20.
IO_FIFO Overview
Not Used
Not Used
