LVDCI_DV2

Table 1-17: Available I/O Bank Type
A controlled impedance driver with half impedance (source termination) can also provide
drivers with one half of the impedance of the reference resistors. This allows reference
resistors to be twice as large, thus reducing static power consumption through VRN/VRP.
The I/O standards supporting a controlled impedance driver with half impedance are:
LVDCI_DV2_15 and LVDCI_DV2_18.
driver with half impedance unidirectional topologies.
To match the drive impedance to Z
reference resistor R must be twice Z
7 Series FPGAs SelectIO Resources User Guide
UG471 (v1.10) May 8, 2018
IOB
LVDCI
R 0 = R VRN = R VRP = Z 0
Figure 1-41: Unidirectional Controlled Impedance Driver Topology
IOB
LVDCI
R 0 = R VRN = R VRP = Z 0
Figure 1-42: Bidirectional Controlled Impedance Driver Topology
HR HP
N/A Available
www.xilinx.com
Supported I/O Standards and Terminations
IOB
Z 0
IOB
Z 0
R 0 = R VRN = R VRP = Z 0
Figure 1-43 and Figure 1-44
when using a driver with half impedance, the
0
.
0
LVDCI
ug471_c1_31_011811
LVDCI
ug471_c1_32_011811
illustrate a controlled
