Chapter 1: SelectIO Resources
Differential HSTL can also be used for differential clock and DQS signals in memory
interface designs.

DIFF_HSTL_II_DCI and DIFF_HSTL_II_DCI_18

Table 1-28: Available I/O Bank Type
Differential HSTL class-II pairs complementary single-ended HSTL_II type drivers with a
differential receiver, including on-chip split-thevenin termination. Differential HSTL
class-II is intended to be used in bidirectional links. Differential HSTL can also be used for
differential clock and DQS signals in memory interface designs.

DIFF_HSTL_II_T_DCI and DIFF_HSTL_II_T_DCI_18

Table 1-29: Available I/O Bank Type
These standards are almost the same as the DIFF_HSTL_II_DCI and
DIFF_HSTL_II_DCI_18 standards except that the termination is only present when the
driver is 3-stated.

HSTL Class I (1.2V, 1.5V, or 1.8V)

Figure 1-46
the 1.2V, 1.5V, or 1.8V versions. In a specific circuit, all drivers and receivers must be at the
same voltage level (either 1.2V, 1.5V or 1.8V); they are not interchangeable. Only HP I/O
banks support the DCI standards.
62
Send Feedback
HR HP
N/A Available
HR HP
N/A Available
shows a sample circuit illustrating a termination technique for HSTL class-I for
