VCU110 Zynq-7000 AP SoC XC7Z010 System Controller

[Figure 1-2, callout 36]
The VCU110 XC7Z010 U111 system controller sub-system implements interfaces to:
• PMBus power system
• Programmable user clock
• Micro-SD card
• USB UART2
• Five directional user pushbutton switches
• Three GPIO connections to FPGA U1 Bank 65
• IIC bus MUXes
The system controller is delivered as a black-box design that communicates with on-board
programmable devices over an I2C interface. The Zynq-7000 AP SoC system controller IP is
not provided and is not available to end users for modification purposes.
The system controller is an ease-of-use feature that sets up or queries onboard resources
available to the XCVU190 UltraScale FPGA U1 on the VCU110. Programmable clocks, the
internal UltraScale FPGA system monitor block (SYSMON), and the Maxim power controllers
VCU110 Evaluation Board
UG1073 (v1.2) March 26, 2016
VCC12_SW
R318
1
10.0K
1/10W
2
1%
Q18
1
SI2300DS
1.7W
GND
Figure 1-31: Cooling Fan Circuit
