Table 1-47: I2C Devices (Cont'd)
I2C Device
HMC Si5328 clock
HMC I2C
FPGA SYSMON I2
PCA9544 4-channel bus switch
PMBus regulators
FMC HPC0 I2C
FMC HPC1 I2C
I2C EEPROM
Notes:
1. MAX15301: U4, U9, U30, U150, U156, U187; VT7701M: U166, U174, U175, U191, U192, U193 (See
Information about the TCA9548 and PCA9544 is available on the Texas Instruments
Semiconductor website at
For additional information on the Zynq-7000 AP SoC device I2C controller, see Zynq-7000
All Programmable SoC Overview (DS190)
Technical Reference Manual (UG585)

Status and User LEDs

[Figure 1-2, callout 23]
Table 1-48 defines VCU110 board status and user LEDs.
Table 1-48: VCU110 Board Status and User LEDs
Reference Designator
DS2
DS3
DS6
DS7
DS8
DS9
DS10
DS14
DS15
VCU110 Evaluation Board
UG1073 (v1.2) March 26, 2016
I2C Switch
Position
Binary Format
4
0b1101010
5
0b0010100
6
0b0110010
NA
0b1110101
0b0010000-0b0011000
0
0b1110000-0b1110110
1
0bXXXXX00
2
0bXXXXX00
3
0b1010000
[Ref 32].
[Ref 12]
[Ref 13].
Description
INIT
OR'D POWER GOOD
GPIO_LED_1
GPIO_LED_0
GPIO_LED_2
GPIO_LED_3
GPIO_LED_4
UTIL_3V3_PGOOD
MGTAVCC_PGOOD
www.xilinx.com
Chapter 1: VCU110 Evaluation Board Features
I2C Address
Hex Format
0x6A
0x14
0x32
0x75
0x10-x18
0x70-x76
0xXX
0xXX
0x50
and Zynq-7000 All Programmable SoC
Send Feedback
Device
U57 SI5328B
U160 HMC
U1 BANK 65
U80 PCA9544
(1)
MAXIM VREGs
J22 FMC HPC
J2 FMC LPC
U12 M24C08
Table 1-66 for details).
