Nortel Communication Server 1000
SIP DECT Fundamentals
Release: 6.0
Document Revision: 02.02
www.nortel.com
NN43120-123
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CS 1000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Nortel CS 1000

  • Page 1 Nortel Communication Server 1000 SIP DECT Fundamentals Release: 6.0 Document Revision: 02.02 www.nortel.com NN43120-123...
  • Page 2 While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are subject to change without notice.
  • Page 3: Table Of Contents

    Deployment terms 42 Deploying on a single floor 44 Deploying on multiple floors 59 Reengineer cells for high traffic areas 63 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 4 Configuration of Personal Call Assistant 156 Configuration of UEXT on the remote system 157 SIPL configuration Navigation 159 Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 159 Configuration using IP DECT Configurator 159 DAP manager configuration 173 SIP Line Gateway configuration 177...
  • Page 5 Synchronization Analyzer interface 226 Export and import SIP DECT system 233 Export a system 233 Import a system 234 DAP Controller deactivation 235 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 6 Mounting the cabinet on a wall 280 Mounting the cabinet on a pole 281 Third Party Software SRTP 283 TLS 284 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 7: New In This Release

    SIP DECT 4.2, and to support CS 1000 Release 6.0. January 2009 Standard 01.07. This document is up-issued for CS 1000 Release 5.5 with editorial changes. December Standard 01.06. This document is up-issued for CS 1000 2008 Release 5.5, in response to change requests for content related...
  • Page 8 February Standard 01.01. This is a new document issued to support 2008 CS 1000 Release 5.5. Some of the information in this new document was previously contained in the following document: DECT Fundamentals (NN43120-114). Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010...
  • Page 9: Product Overview

    • SIPL connections are available on CS 1000 Release 6.0 and later, and use SIP Line Gateway nodes to connect SIP clients to the Call Server. SIPL connections support SIP DECT handset registration, and require that you create a SIPL subtype of UEXT blocks on the Call Server.
  • Page 10 Transfer Protocol (TFTP) server unless you use a DAP configuration without DHCP or TFTP. You can configure the system to use two separate Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 11 TLAN network interface and an ELAN network interface. If the server you use cannot support all of these applications, you can use more than one server. You connect the DAP to the Communication Server 1000 (CS 1000) Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010...
  • Page 12: Universal Extension Support

    SIP Line Gateway Each DAP communicates with the subscribed DECT handsets in the coverage area, and each DAP interacts with the CS 1000 and with other configured DAPs in the company network. You can run SIP DECT on the following configurations: •...
  • Page 13 No Associated Telephone (AST) or Computer-Telephone Integration (CTI) capabilities are currently available for SIP DECT. Each DECT handset has a local Directory Number (DN) in CS 1000. Use this local DN to subscribe the corresponding DECT handsets on the SIP DECT system through DAP Manager.
  • Page 14: Dect Handset Features

    Press the star (*) key to start the conference. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 15: Callpilot And Message Waiting Indication Support

    Target DN on the UEXT corresponding to the DECT handset. CS 1000 supports only the Unsolicited MWI NOTIFY model. An external SIP UA cannot SUBSCRIBE to MWI NOTIFY messages and cannot request the current status of MWI for the DN from the system (by sending SUBSCRIBE messages).
  • Page 16: Sip Dect Capacity Limitations

    The number of DNs available for DECT handsets depends on the configured dialing plan and the availability of the Directory Number Expansion (DNXP) package (150). Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 17: Site Planning And Hardware Deployment

    • “DECT Access Points” (page 18) Call server, Signaling server, and SIP Line Gateway Before you install SIP DECT you must install and configure a CS 1000 system, as follows: • For SIPN configuration, install Call Server and Signaling Server.
  • Page 18: Pc (Dap Controller)

    Ensure that the G.711 codec is available in your system. It is not possible to make calls between the Nortel IP Softphone 2050 and DECT handsets when you select the I use a modem to connect to the network check box in the Audio settings for the softphone.
  • Page 19: Navigation

    • an outer circle in which sufficient signal strength exists for synchronization, but not enough for acceptable voice quality Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 20 DECT system. If the signals belong to the same DECT system, the DAPs synchronize according to user-configured rules. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 21 One or more DAPs act as a synchronization source to form the root of the hierarchical structure, as illustrated in Figure 3 "DAP synchronization hierarchy" (page 21). Figure 3 DAP synchronization hierarchy Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 22 6 dB lower. This means that at a minimum signal strength for good voice quality of --72 dBm and a distance X, the signal strength at the Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 23: Ip Network Configuration

    The IP network must be able to support SIP DECT; this section provides information about planning an IP network that is suitable for supporting SIP DECT. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 24 Long Range Ethernet equipment in the connection. Several manufacturers offer such a solution, which allows cable lengths of more than one kilometer (km). Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 25 The PABX is sometimes referred to as Gatekeeper or SIP proxy, depending on the type of PABX that is used. To facilitate network management, Nortel recommends that fixed IP addresses are also assigned by the DHCP server. Ensure that the DHCP server has the hardware MAC addresses of all servers to issue the proper (fixed) IP addresses to each individual server.
  • Page 26: Location Requirements

    0 C to 40 C. • Install DAPs in a vertical position. The radiation pattern differs between the horizontal and vertical positions. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 27 DAP to provide system redundancy. The power input providing the highest voltage is active. If one power input fails, the other takes over without service interruption. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 28: Types Of Sip Dect Configuration

    DAPs in the Campus network, through IP switches and the IP routers that connect the various subnets. For an illustration Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 29 For instance, if each subnet is defined by mask 255.255.255.0, then “aggregated” mask 255.255.248.0 covers up to four such subnets. • Branch Office Configuration Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 30 Routers must block IP multicast between Branch Offices (multicast TTL = 1, which means that IP multicast packets do not cross IP routers). Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 31 Multi Site Mobility Network (MSMN) Configuration makes it possible to use portable DECT handsets on various MCDN nodes where each node is a CS 1000 system plus the corresponding SIP DECT system. MSMN allows roaming between independent SIP DECT systems installed on separate Call Servers (connected by trunks).
  • Page 32: Site Planning

    Sensitive electronic equipment Check whether sensitive electronic equipment is present, for example, laboratory or medical equipment. Although the transmitted power of Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 33: Speech Quality

    “transmission errors hiding” system. This means that it tries to hide the transmission errors. The results of this mechanism are as follows: Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 34 If you agree with the customer on lower speech quality, then make sure that this is well documented and signed by the customer. If Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 35: Coverage Calculation

    Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 36 Ensure that outside the calculated range communication is possible but a good voice quality is no longer guaranteed. Figure 10 DECT range calculation chart Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 37 Ensure that DAPs are separated by at least 1 meter. • The presence of another unsynchronised DECT System, or any similar system in adjacent buildings, causes interference. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 38: Traffic Density Calculations

    This section describes the basics of SIP DECT system deployment. DECT Deployment Kit 2 The DECT Deployment Tool (deployment tool) determines cell centers and cell boundaries. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 39 , see “Deployment tool” (page 263). Figure 11 Deployment Kit 2 and carrying case The following figures shows the assembled kit. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 40 40 Site planning and hardware deployment Figure 12 Assembled Deployment Kit 2 and DeTeWe handsets Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 41 To enter Site Survey Mode on the handset, perform the following procedure. Access site survey mode. Procedure 1 Entering the site survey mode Step Action Press Menu. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 42: Deployment Terms

    Table 4 Deployment terms Term Definition Estimated number of handsets The average number of handsets expected in a particular cell. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 43: Nortel Communication Server

    The following figure illustrates some of the preceding terms. Figure 14 Example showing deployment terms Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 44: Deploying On A Single Floor

    Links can be made outside the cell boundary but the audio quality of the link is poor. The link drops if the handset and the basestation are too far apart. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 45 Set up the deployment tool basestation. Raise the deployment tool basestation as high as possible, or until it is at the height recommended for basestations. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 46 Figure 17 "Cell contour of the initial critical point" (page 46), P1 is the initial critical point. --End-- Figure 17 Cell contour of the initial critical point Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 47 --End-- Figure 18 Cell contour of the closest adjacent critical point to the initial critical point Locate the cell center. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 48 = the floor and n = is the cell number in sequence of the entire plan. Figure 19 "Example of a cell center" (page 49), IC1 is a cell center. --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 49 Find the cell boundary by measuring the range and marking it on the floor plan with a small x. Repeat steps Step 3 Step Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 50 Mark the cell contour on the floor plan by tracing a contour line through the Xs with a marker. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 51 Figure 21 "Example of new critical points (P8 and P9)" (page 52), the cell boundary area is IC1 and the new critical point is --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 52 Procedure 8 “Marking and labeling the cell boundary on the floor plan” (page 50). --End-- Mark new cell contours and a new cell boundary. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 53 Example of deployment for cell center 1C2 Mark cell contours, centers, and boundaries at the far end of the intended coverage area. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 54 Figure 24 "Identify new critical points (P11, P12, P13, P14, P15, P16, P17)" (page 55), where cell boundary area = IC2), Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 55 Procedure 10 “Marking and labeling new critical points” (page 52) as necessary to mark new cell boundaries at the middle of the building. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 56 Cell boundary 1C7 completes the floor plan. --End-- Figure 25 Contours formed by critical points P11, P13, and P16 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 57 Cell center 1C5 formed by critical points P11, P13, and P16 Figure 27 Cell boundary 1C5 formed by critical points P11, P13, and P16 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 58 58 Site planning and hardware deployment Figure 28 Example of critical point cell boundaries Figure 29 Example of cell center boundary 1C6 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 59: Deploying On Multiple Floors

    --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 60 For more information, see “Unusual conditions” (page 61) Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 61 Unusual conditions No precise steps exist to follow when you deploy in unusual condition, but you must consider several points. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 62 Follow safety codes, and be aware aesthetics. • Allow sufficient access to install basestations. • Provide clear installation instructions. • Test the coverage during post-deployment checks. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 63: Reengineer Cells For High Traffic Areas

    The calculation of expected telephone traffic includes an allowance for the user population in a cell and for the roaming user. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 64 If the traffic-handling capacity of the cells is not adequate, use 12-channel basestations and subdivide them into smaller cells to ensure the traffic is handled properly according to the instructions. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 65 --End-- Creating an estimate table Use the following table to estimate the number of handset users for each cell. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 66 Users inside the cell with an office Users with an office outside of a cell who walk into the cell Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 67 Users inside the cell with an office Users with an office outside of a cell who walk into the cell Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 68 3.2 walk-in users can be in cell 1C1. --End-- Table 8 Example of the table third row calculation Estimate for: Users inside the cell with an office Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 69 Users inside the cell with an office Users with an office outside of a cell who walk into the cell Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 70 (page 65), is entered into Table 10 "Example of a completed estimate table" (page 70). This Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 71 --End-- Table 12 Example of a completed estimate table Estimate for: Users inside the cell with an 21.0 14.7 office Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 72 (page 71). In the example H&W is the users with both a handset and a wired telephone. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 73 Telephone traffic generated by handset users equates to that of handset and wired users. Combine the two groups for cell size recalculation. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 74 Adjustment for users without wired telephones Estimated number of handsets for users Adjusted estimated number of handsets for without wired telephones each cell Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 75 Limit the anticipated number of handsets Limit the number of handsets you anticipate for each cell center to the limits shown in Table 14 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 76 Determine the number of handset users in the high-density handset cell. Count the number of users. Include users served by through-the-floor coverage of this cell. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 77 Repeat the anticipated handsets for each cell calculation to ensure that each smaller cell provides appropriate traffic coverage to the users in the area. --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 78 78 Site planning and hardware deployment Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 79: Software Requirements

    This document does not provide the steps you must follow to install the operating system. For information about installing Windows, see the documentation that accompanied the Windows software. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 80: Firewall Protection

    The DAP controller or manager runs as a service under Windows. Because the management interface is available through a Web interface, you must install the Web Server IIS. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 81 Procedure 28 Checking IIS on PC with Windows 2000 Step Action Open Internet Explorer on the PC where IIS is installed. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 82 The Add/Remove Programs window appears. Click Add/Remove Windows Components. In the Components window, double-click Application Server. In the Components window, check ASP.NET. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 83 The Internet Information Services (IIS) window appears. Select the check boxes for Internet Information Services Manager and Common Files. Do not change the remaining check boxes. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 84 Open Internet Explorer on the PC where IIS is installed. In the address bar in Internet Explorer, enter localhost/iisstart .htm. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 85 Click Start > Settings > Control Panel . Double-click Add/Remove Programs. The Add/Remove Programs window appears. Click Add/Remove Windows Components. Select Internet Information Services. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 86 Open Internet Explorer on the computer where you want to install the DAP manager. Enter the URL localhost/localstart.asp. Ensure that the Internet Information Services (IIS) page appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 87: Dhcp And Tftp Servers

    IP DECT Configurator. For more information about built-in DHCP and TFTP servers, see “Built-in DHCP and TFTP servers” (page 97). Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 88 PC that runs the TFTP server. The Microsoft DHCP server (Windows 2000 / 2003) is in the Microsoft Windows 2000 / 2003 Server CD-ROM package. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 89 Click OK. Click Next. Insert the Windows 2003 CD-ROM as prompted. Finish the procedure using the instructions in the dialog box. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 90 Click Next in the naming dialog box see the IP address range. The window New Scope Wizard—IP address range appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 91 Click Next. The Lease Duration window appears. Set the desired lease duration of the granted IP addresses to the desired value. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 92 The newly created scope appears with a new line called Scope Options. Right-click Scope Options, and select Configure Options. The Scope Options page appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 93 Select the Option 3 check box, and enter the Router or Default Gateway IP address, for example, 192.168.100.1, and click Add. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 94 A TFTP server must handle several accesses at the same time, because several accesses occur at the same time, when the DAPs start Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 95 Insert the Windows 2000 or Windows 2003 CD-ROM as prompted. Follow the instructions in the dialog box to complete the procedure. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 96 If you run Windows 2003, you must create the TFTP folder on drive C:, as shown in the following figure. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 97 Vendor Class Identification D(ECT) AP 49 from a DAP. You can configure built-in DHCP server using the Network Settings window of IP DECT Configurator. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 98 You can add DAPs to the list, delete DAPs from the list, or edit the addresses. Click Apply to save the changes, or Close to exit. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 99 You can perform DAP configuration without DHCP or TFTP only after you install the IP DECT Configurator. For more information, see “DAP Controller” (page 102). Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 100 Right-click Scope , and select Properties. The DHCP Administrative tools page appears. Select Unlimited for Lease duration for DHCP clients. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 101 Click the Advanced Tab, and select Both for Assign IP addresses dynamically to clients of and Unlimited for Lease duration for OOTP clients. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 102: Dap Controller

    CD. You must execute this procedure only once, and thereafter use the installation for any number of system configurations. You can change settings later. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 103 .NET Framework 2.0 Setup: Setup Complete page appears. Installation can take several minutes. The DAP controller - InstallShield Wizard indicates activity with a progress bar. Click OK. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 104 • Select Single System if plan to manage only one SIP DECT system with your PC. Nortel recommends this option unless you install DAP Controller on a laptop PC to be carried between SIP DECT systems, to manage them.
  • Page 105 Click Finish. The IP DECT Configurator starts automatically, so that you can configure your SIP DECT system. --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 106 106 Software requirements Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 107: Sipn Configuration

    This section contains information about creating a SIPN configuration. This is the SIP connection method used under Communication Server Release 5.5. Navigation • “Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway” (page 107) • “Routed Head Quarter configuration” (page 146) •...
  • Page 108: Configuration Using Ip Dect Configurator

    (page 119) • Procedure 52 “Saving the system” (page 119) • Procedure 53 “Enabling or re-enabling the DAPs” (page 120) Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 109 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 109 Procedure 43 Starting the IP DECT Configurator Step Action Select Start > Programs > DAP controller > DAP Applications > DAP Configurator. The IP DECT Configurator window appears. If your network card does not have a fixed IP address, the following error message appears after the application starts.
  • Page 110 --End-- Procedure 45 Configuring IP Settings Step Action On the Settings pane, click IP Settings. The IP Settings page appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 111 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 111 In the Multicast address field, enter 239.192.49.49. Enter the DAP controller Configuration: DC IP address, which is the IP address of the PC on which your DAP controller is installed.
  • Page 112 If you use a built-in TFTP server, select 3com TFTP server on this PC. Configure the DHCP server. • If you use a Microsoft Windows DHCP server, click Apply. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 113 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 113 • If you use a built-in DHCP server, see “Prerequisites” (page ATTENTION If you plan to create a configuration without DHCP and TFTP servers, “Configuration without DHCP or TFTP” (page 99).
  • Page 114 114 SIPN configuration The SIP Settings window appears. In the Predefined SIP Server configurations list, select Nortel. In the SIP Domain field, enter the domain name. The SIP domain you enter here must be the same as the SIP domain name you enter as the service domain in NRS in the procedure Procedure 71 “Creating service domain”...
  • Page 115 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 115 Ensure that the max_intern_dnr_len check box is selected, and select the maximum number of digits in the internal DNs. DNs that contain more digits than configured for this parameter are defined as external.
  • Page 116 PARI. Click Apply. --End-- Procedure 50 Configuring other settings—Performance/Email Settings Step Action Click Performance/Email Settings. The Performance/Email Settings window appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 117 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 117 In Performance Settings, under Performance Counters Configuration fill the field in Interval UPM generation every _____ minutes or accept the default of 1440 minutes, which equals one day. This interval specifies how often User Performance Measurement files are generated.
  • Page 118 Enter a value next to Email addresses with one or more destination email addresses. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 119 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 119 Select the days to receive archives, the date to stop sending archives, and the maximum size of the attached archive. Optionally, enter HTTP execution time out. HTTP execution time out (specified in seconds) is a guarding timer for the ASP scripts.
  • Page 120: Dap Manager Configuration

    • “Restarting DECT Access Points” (page 121) • “Adding number range” (page 122) • “Subscribing a DECT handset” (page 122) Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 121 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 121 Restarting DECT Access Points You must restart DECT Access Points (DAP) after software upgrades. Restart a DECT Access Point Procedure 54 Restarting DECT Access Points Step Action Start DAP manager by entering the following URL into an internet browser: localhost/cds The DAP manager IP DECT page appears.
  • Page 122 Procedure 56 Subscribing a DECT handset Step Action Select Subscriptions from the menu on the left. The Subscriptions page appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 123 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 123 Select the required available extension number or numbers. If the required number is not visible, select another page. The page number appears in the top and bottom rows of the subscriptions table.
  • Page 124: Configuration On Element Manager

    Use Element manager and follow the steps in the next procedure to create a new customer or modify information about an existing customer. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 125 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 125 Procedure 57 Creating a new customer or modifying information about an existing customer Step Action Select Customers from the menu on the left. Click Add on Customers list page.
  • Page 126 1 for ZONE. Select the Node ID of the signaling server for NODE. Select SIP for PCID. Select the ISDN check box. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 127 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 127 Select ISLD for MODE. Select the DCH created previously, for example, 5. Select SL1 for IFC and 1, for example, for the Private Network Identifier (PNI). Select the NCNA check box, and the INAC check box.
  • Page 128 The ESN Access Codes and the Basic Parameters page appears. Enter 10 for MXDM/MXRL/MXIX/MXFC/MXFS/MXLC/MXSC, 9 for AC1, 6 for ERDT, 0 for MXSD. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 129 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 129 Click Submit. --End-- Adding digit manipulation block Add digit manipulation block using Element manager. Procedure 64 Adding digit manipulation block Step Action On the ESN page, select Customer X > Network Control &...
  • Page 130 Configuring the signaling server Step Action Select System > IP Network > Nodes: Servers, Media Cards. Select the node to edit. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 131 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 131 The Node Configuration page appears. Click Gateway (SIPGw), and enter Signaling Server NRS IP address, for example, 192.168.100.104, for Proxy Or Redirect Server. Select UDP as Transport Protocol. Navigate to SIP URI Map , and enter the domain names.
  • Page 132 A Transfer prompt appears. Click Transfer Now. Verify that the component is active. Click Start Sync. Respond to subsequent prompts. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 133: Nrs Configuration

    Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 133 --End-- NRS configuration Log on to the Network Routing Service manager (NRS). Procedure 70 Logging on to NRS Step Action Log on to Unified Communications Management, and then log on to Element manager.
  • Page 134 SIP domain name you enter in Procedure 45 “Configuring IP Settings” (page 110). Click Save. --End-- Adding the UDP domain Add the UDP domain. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 135 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 135 Procedure 72 Adding the UDP domain Step Action Select Numbering Plans > Domains. The Domains page appears. Click the L1 Domains (UDP) tab. In the Filter by Domain field, enter an existing domain.
  • Page 136 Enter an endpoint description, for example, DECT Access Point. Select Static SIP Endpoint for SIP support. Select UDP for SIP Transport . Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 137 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 137 Enter the Static endpoint address (DAP IP address) 192.168.100.200. Click Save. If you plan to create a Branch Office Configuration, see "Perform configuration on NRS" (page 145) --End-- Configuring routing entries for DAP Redirect Server Configure routing entries for the DAP Redirect Server.
  • Page 138 DAP, for example, 44????. Click Save. If you plan to create a Branch Office Configuration, see "Perform configuration on NRS" (page 145) --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 139 0000-9999 for DN Prefix and 2 for Route cost. ATTENTION If you use a Trunk Steering Code (TSC) to make calls from CS 1000 to SIP DECT, the cost of the CDP routing entry for the Signaling Server must be higher than the cost of the CDP routing entry for DAP Redirect Server.
  • Page 140: Call Server Configuration

    LD 43 and restart your system. Table 17 LD 11: Add universal extension (UDP) Prompt Response Description Add new extension Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 141 Basic (simple) SIP DECT configuration with CS 1000 SIP Gateway 141 Prompt Response Description TYPE UEXT Universal Extension CUST n = customer number L s c u, for L = virtual superloop, s = shelf, example, 96 0 1 c = card, u = unit...
  • Page 142 Table 21 LD 15: Enable Message Center Prompt Response Description TYPE FTR_DATA CUST n = customer number Message Center included Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 143: Branch Office Configuration

    Select the SIP DECT system that you are running, and click System Configuration. Choose Main Site with Branch Office(s) for System configuration, as shown in the following figure. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 144 113), click Apply and continue configuring the SIP DECT system using Procedure 48 “Configuring SIP Settings” (page 113). Go to step 6. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 145 LOC 442 (or TSC 44) for handsets to be used in Branch Office 1, LOC 443 (or TSC 45) for handsets to be used in Branch Office 2. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 146: Routed Head Quarter Configuration

    Routed Head Configuration is the same as Simple configuration, but includes one more step. For information, see Procedure 46 “Configuring Network Settings” (page 112). Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 147: Configure Routed Head Quarter

    113), click Apply, and continue configuring the SIP DECT system using Procedure 48 “Configuring SIP Settings” (page 113). Go to step 7. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 148: Routed Head Quarter Configuration With Branch Office

    Office (including the Branch Office with Routed Head Quarter) behaves as isolated site of that SIP DECT system. Branch Office configuration Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 149 “Configuring System Settings” (page 113), click Apply and continue configuring the SIP DECT system with Procedure 48 “Configuring SIP Settings” (page 113). Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 150: Multi Site Mobility Network Configuration

    “Call server configuration to MSMN” (page 153) • “Configuration of Personal Call Assistant” (page 156) • “Configuration of UEXT on the remote system” (page 157) Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 151: Subscribe A Multiple-Site Dect Handset

    The status of the configuring subscription record changes from "Enabled" to "Subscribed". --End-- Import and export subscriptions Use the procedures in this section to import and export subscriptions. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 152: Configure Nrs For Multiple-Site Mobility Network

    Select Configuration from the tool bar at the top of the page. A dialog box indicating the status of Active and Standby database appears. Click OK. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 153: Call Server Configuration To Msmn

    MSMN SIP DECT system. • Codes on system 1 — Access Code: 9 — Location code to DAP: 442 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 154 Example of an MSMN SIP DECT system Use LD 15 to enable Personal Call Assistant before you configure the Personal Call Assistant. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 155 = <AC1+LOC+ subscribed DN on DAP> 94425001 Table 24 LD 11: Add universal extension (CDP) Prompt Response Description Add new extension TYPE UEXT Universal Extension Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 156: Configuration Of Personal Call Assistant

    = DN length (maximum length is 32) 1 HOT P 8 • yyyy = <AC1+LOC+ subscribed DN on DAP> 93355010 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 157: Configuration Of Uext On The Remote System

    = card, u = unit 96 0 1 10 UXTY SIPN UEXT subtype aaaa Designator. Optionally, enter a description. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 158 = DN length (maximum length is 32) 1 HOT P 6 335010 • yyyy = <TSC+ subscribed DN on DAP> Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 159: Sipl Configuration

    This section contains information about creating a SIP LINE (SIPL) configuration. This is the SIP connection method used under Communication Server Release 6.0. Navigation • “Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway” (page 159) • “Routed Head Quarter configuration” (page 182) •...
  • Page 160 Action Select Start > Programs > DAP controller > DAP Applications > DAP Configurator. The IP DECT Configurator window appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 161 Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 161 If your network card does not have a fixed IP address, the following error message appears after the application starts. To correct this error, assign a fixed IP Address to the network card in your DAP controller PC and restart the application.
  • Page 162 Use no special characters in your SIP DECT system name. The folder and the SIP DECT system share the same name. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 163 Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 163 In the General Settings window, enter the path to the firmware, the DAP package file, for example, C:\tftpdroot\4910b427.dwl. Click Apply. --End-- Procedure 88 Configuring IP Settings Step Action On the Settings pane, click IP Settings.
  • Page 164 If you use a built-in DHCP server, see Built-in DHCP server. ATTENTION If you plan to create a configuration without DHCP and TFTP servers, see Configuration without DHCP or TFTP. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 165 Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 165 Optionally, select the Monitor TFTP server check box to monitor the TFTP activity of the built-in TFTP server. The results appear in the System Status window, which appears when you click Activate / Deactivate / System Status.
  • Page 166 166 SIPL configuration In the Predefined SIP Server configurations list, select Nortel. In the SIP Domain field, enter the domain name. The SIP domain you enter here must be the same as the SIP domain name you enter as the domain in SIP LINE Gateway, in “SIP Line Gateway configuration”...
  • Page 167 Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 167 Click Apply. --End-- Table 28 Job aid Value Description The DN to which a handset is subscribed. If you enter %s as the user password, SIP DECT uses the handset DN for user authentication.
  • Page 168 The following procedure applies to SIPL configurations only. Procedure 93 Configuring other settings—PBX Settings Step Action In the Settings pane, click PBX Settings. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 169 Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 169 The PBX Settings window appears. In Conference ID field, enter conference. In the Conference IP address field, enter the SIP Line Gateway Node IP address. Click Apply. --End-- Procedure 94 Configuring other settings—Performance/Email Settings...
  • Page 170 Fill in the two boxes after Channel Occupation. In the Threshold box, specify the percentage. In the Time box, specify a time in seconds. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 171 Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 171 Channel Occupation defines the conditions for generating an email on DAP channel occupation. If the channel occupation is higher than the percentage of the available channels for a specified time period, an email is generated.
  • Page 172 In the System Control pane in the left of the IP DECT Configurator main window, click Activate/Deactivate/System Status. The Activate/Deactivate/System Status window appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 173: Dap Manager Configuration

    Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 173 --End-- Procedure 97 Enabling or re-enabling the DAPs Step Action To enable or re-enable the DAPs, start the DAPs. --End-- DAP manager configuration The following procedures are described in this section.
  • Page 174 Reboot All—Select this option to restart all DAPs in the list. • Delete—Select this option to remove a DAP from the list. The DAP takes a few minutes to restart. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 175 Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 175 Confirm the DAP is active by checking the status of the device under the Working column. Active DAPs have Yes in this column. --End-- Adding number range Add a Number Range.
  • Page 176 Sometimes you must enter PARK code first. The PARK code appears on the left at the bottom of the Subscriptions page. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 177: Sip Line Gateway Configuration

    Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 177 You must enter the PIN within 16 minutes, otherwise the subscription mode terminates for that specific extension number, and you must restart the subscription process from the beginning.
  • Page 178 LD 11: Add universal extension (UDP) Prompt Response Description Add new extension TYPE UEXT Universal Extension CUST n = customer number Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 179 Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway 179 Prompt Response Description L s c u, for where L = virtual superloop, s = shelf, example, 96 0 1 c = card, u = unit UXTY SIPL...
  • Page 180: Branch Office Configuration

    To configure Branch Office, see “Basic (simple) SIP DECT configuration with CS 1000 SIP Line Gateway” (page 159). Use the information in this section when you require information about Branch Office configuration. Select a Branch Office configuration.
  • Page 181 Subnet - the first address in the subnet range. For instance, 192.168.32.0. • Subnet mask - mask to specify the subnet boundaries. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 182: Routed Head Quarter Configuration

    • Aggregated Subnet mask—The aggregated subnet mask is the subnet mask for the DAPs to determine the network boundaries for Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 183: Configure Routed Head Quarter

    Choose Routed Head Quarter Configuration for System configuration. Enter a Time To Live Value greater than 1 to have the Router forward multicast packages. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 184 165), click Apply, and continue configuring the SIP DECT system using Procedure 91 “Configuring SIP Settings” (page 165). Go to step 7. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 185: Routed Head Quarter Configuration With Branch Office

    Branch Office (including the Branch Office with Routed Head Quarter) behaves as isolated site of that SIP DECT system. Branch Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 186 “Configuring System Settings” (page 165), click Apply and continue configuring the SIP DECT system with Procedure 91 “Configuring SIP Settings” (page 165). Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 187: Multiple-Site Mobility Network Configuration

    “Import and export subscriptions” (page 188) • “Personal Call Assistant configuration” (page 189) Subscribe a multi-site DECT handset Subscribe a multi-site DECT handset. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 188: Import And Export Subscriptions

    The status of the configuring subscription record changes from Enabled to Subscribed. --End-- Import and export subscriptions Use the procedures in this section to import and export subscriptions. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 189: Personal Call Assistant Configuration

    (for CDP) or access and location codes (for UDP) to the remote system. PCA and UEXT are configured using LD 11. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 190: Sip Dect Fundamentals Nn43120-123 02.02 30 March

    = DN length (maximum length is 32) 1 HOT P 8 • yyyy = <AC1+LOC+ SIP DECT handset DN on the 93355010 remote system> Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 191: System Administration

    To start DAP manager, open Internet Explorer and enter the following URL in the address field: localhost/cds. The DAP Manager appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 192 Pack Up & Go Use this section to prepare subscription data for use in another system and to export multi-site subscriptions. Task list Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 193: Subscription Management

    DNs available on the system, see “Add a DN range” (page 202). • You also must configure the Communication Server 1000 (CS 1000) system to which the SIP DECT system is connected. For information, see “Call server configuration” (page 140).
  • Page 194: Edit A Subscription Rpn

    The DAP manager IP DECT page appears. Select Subscriptions from the menu on the left in the DAP manager IP DECT page. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 195: Disable A Subscription

    Subscribed to Black Listed. When the SIP DECT system manages to delete the subscription record from the handset, the status changes to Free. --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 196: Removing A Subscription

    Remove subscription data from the system only. This procedure does not clear the subscription from the handset. ATTENTION Nortel recommends that you use the following procedure only if a handset was lost or damaged beyond repair. Procedure 110 Removing a subscription from the system...
  • Page 197: Use The Filter

    Select Subscriptions. Select the Use DNR filter check box at the top of the Subscriptions page. The Filters page appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 198: Handset Status

    If the extension number is activated for subscription, the status is changed to Enabled and you must follow the procedure to subscribe the handset. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 199 SIP DECT system and cannot be used to make calls. ATTENTION For SIPN configurations, the CS 1000 system is not aware of the status of the handset, and attempts to send calls to the handset even if the handset is absent.
  • Page 200: Dap Management

    The DAP manager IP DECT page appears. Click Access points . The DECT Access Points page appears. Select the DAP to edit. Click Edit. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 201: Restarting A Dap

    Restart all the DAPs in a system. This can be required if you are upgrading software, or if the DAPs are not functioning properly. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 202: Deleting A Dap

    Open Internet Explorer and enter the following URL in the address field: localhost/cds. The DAP manager IP DECT page appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 203: Importing A Dn Range From A .Csv File

    A dialog appears. Browse to the .csv file that contains the extension numbers (phone book). Click OK. The file contents is imported. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 204 Access tool with an .xls file, you can convert this xls file to .csv format by using Microsoft Office Excel. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 205: System Backup

    Subscription export and import 205 System backup Nortel recommends that you back up the SIP DECT system whenever you make changes to the system configuration. Procedure 119 Backing up a system Step Action Open Internet Explorer, and enter the following URL in the address field: localhost/cds.
  • Page 206 If you are exporting multi-site subscriptions, enter the SARI of the remote system. Click OK. Click Add Number Range. The Add Number Range page appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 207 The status of the configuring subscription record changes from "Enabled" to "Subscribed". Click Export (Prepared). The Export page appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 208: Import Subscriptions

    Navigate to the folder where the file to be imported is stored. Select the file to be imported. Click OK. --End-- You must also configure the CS 1000 system to which the SIP DECT system is connected. For information, see “Call server configuration” (page 140).
  • Page 209: System Archive

    Use the procedure in this section to create an archive file containing various system settings, third line maintenance data, and performance data. The Nortel help desk can request this information if you experience certain types of problems with your SIP DECT system.
  • Page 210: Handset Firmware Update

    Click the menu Handset Firmware Update in the Main Window. The Handset Firmware Update window appears. Click the option Configuration. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 211 In the table Define Update Periods, specify the days of the week and the time period updates are to occur. Nortel recommends that you have the system perform updates during out-of-office periods. The handset functions during firmware updating; however firmware updating reduces the number of available channels on a radio.
  • Page 212 In the right pane, click the package, and then click Select. In the menu, click Add Handsets. The Add handsets window appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 213 The update starts according to the time schedule you defined. The status of the update process appears in the Update handsets window, as shown in the following figure. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 214: Central Directory Access Tool

    Central Directory, you cannot use Central Directory on that handset type. Consult your SIP DECT supplier to find the handset types that support Central Directory dialling. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 215: Supported Database Types

    Central directory access tool 215 Supported database types Nortel supports using Flat Excel database as a database type for a Central directory access tool. Create an Excel file for the central database You can create a an Excel sheet to contain your central database. When you install the Central directory access tool, specify the path to the Excel file and the file name.
  • Page 216: Installation

    After Microsoft Office Access database engine 2007 is installed on your PC, the Install Shield window appears. Click Next. The Database Type page appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 217: Configure Sip Dect For Central Directory Access

    Nortel AccessService • Nortel DirectoryService Ensure that Nortel AccessService and Nortel DirectoryService are present in the list, and have a Status of Started. --End-- Configure SIP DECT for Central directory access You must configure SIP DECT to reach the Central directory access services.
  • Page 218 Click Apply. Click Save System. Click Activate / Deactivate / System Status. Restart the DDS service and restart all DAPs. --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 219: System Maintenance

    However, you cannot change or modify the data using the Web interface. View DAP configuration information using the Web interface. Procedure 128 Viewing DAP configuration information Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 220 • Click Network status to see network-related information. Optionally, click Home Page to return to the general settings page. --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 221: Dap Led Indications

    You must update the firmware for all DAPs in the system at the same time. Ensure that all DAPs are running, and can have their firmware updated. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 222 DAP package file, and click Open. The new firmware information appears in the 4710 Package: field. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 223: Remove And Replace A Dap (If A New Dap Is Available)

    ID) is uploaded successfully. --End-- Remove and replace a DAP (if a new DAP is available) Remove and replace a DAP. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 224: Remove And Replace A Dap (If A New Dap Is Not Available)

    Replace a failed DAP. Procedure 131 Replacing a DAP Step Action Open the DAP Manager Web interface. Click Access Points. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 225: System Synchronization Analysis

    You can also use it to detect potential problems in the synchronization structure. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 226: Synchronization Analyzer Interface

    Synchronization Analyzer main page The main page of the Synchronization Analyzer, as shown in the following figure, has four panes. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 227 DAP in the tree view. Meaning Symbol + Red The current level of an RPN is higher that the one in the compared file. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 228 Synchronization Analyzer Location page Use the Location page to display a visual representation of the DAP locations in the system. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 229 After a DAP is selected, other DAPs that the selected DAP can communicate with change color and the corresponding node in the tree view is highlighted. The following controls are available: Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 230 Click Start > All programs > DAP controller > DAP Applications > IPDECT Performance Manager to open the DAP Performance Management Interface. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 231 Navigate to the directory C:\..\PM\ on the DAP controller or manager PC, and choose the file pmtbc.dat. The Portable Tracking page appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 232 Click Start > All programs > DAP controller > DAP Applications > DAP Sync Analyzer. From the menu, choose File > Open. A file requestor appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 233: Export And Import Sip Dect System

    DAP controller or manager PC. Export a system Export a system configuration. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 234: Import A System

    Open. Click Activate / Deactivate / System status to activate the imported system. --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 235: Dap Controller Deactivation

    In the IP DECT Configurator main window, click Activate/Deac tivate/System Status. Click Deactivate All (indicated in the following figure) to stop all enabled services and programs. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 236: Uninstalling Dap Controller Software

    Click Activate/Deactivate/System Status. Click Deactivate all. Close the IP DECT Configurator tool. Click Start > Settings > Control Panel. Double-click Add/Remove Programs. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 237: Dap Controller Software Update

    Install a new version of the DAP Controller. For more information, see “DAP Controller” (page 102), and restart your PC if required. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 238: Troubleshooting

    IP address range is added • the scope options are configured • the scope is activated • Microsoft Windows DHCP Server is running Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 239: If You Cannot Make Calls From A Dect Handset To An Ip/Tdm Telephone On The Call Server (Sipn Configuration)

    • Ensure that the DECT handset is subscribed. For more information, “DAP manager configuration” (page 120). • For DAP Manager Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 240: If You Cannot Make Calls Between Dect Handsets (Sipn Configuration)

    "Call flow for a call from DECT handset to DECT handset" (page 242) for a simplified call flow), ensure the following are properly configured. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 241 • Service domain name is the same as SIP domain, configured on the signaling server and the IP DECT Configurator. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 242: If You Cannot Make Calls To Or From A Dect Handset With Sipl Configuration

    If you cannot make calls to or from a DECT handset with SIPL configuration Perform the following steps if you cannot make calls. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 243 = sip line gateway node ID sipu = SIP DECT user DN scpw = password is entered according to settings in SIP Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 244: If You Have Problems

    If you cannot resolve the issue, collect the necessary information including a system survey, system archive, and network traces. Describe the issue and contact the Nortel help desk. System survey Complete a system survey for your SIP DECT configuration. Provide the information outlined in the following sections to describe your hardware, IP addresses, software version, configuration, and numbering plan.
  • Page 245: Dap Information File

    CallPilot in use (yes or no): DAP information file The DAP information file contains the main configuration parameters for the current DAP; the Nortel help desk can use it for detailed access. For more information, see Procedure 128 “Viewing DAP configuration information”...
  • Page 246: Network Packet Capture Traces

    246 System maintenance Network packet capture traces The Nortel help desk may ask you to collect network traces if some call scenarios fail on your SIP DECT system. Traces contain SIP messages and RTP packets sent over the Ethernet. You can collect traces from a computer connected to the network (when hubs are in use or if port mirroring is configured on IP switches).
  • Page 247: Location Builder Tool

    Start > All programs > DAP controller > DAP Applications > Location Builder. The Location builder window appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 248 • Use the DAP list view mode pane to select the view mode for the DAP list: Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 249: Create A Location File

    Start > All programs > DAP controller > DAP Applications > Location Builder. The Location builder window appears. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 250 The size values used in the location builder do not correspond to real-world units, such as meters or feet. However, Nortel recommends that you consistently enter values that equal the measurements in meters to make your location map easy to understand.
  • Page 251 • In the w field, define the width (x size) of the building. Nortel recommends that you enter the actual width of the building in meters. • In the h field, define the depth (y size) of the building.
  • Page 252 Ensure that Update DAPs already located is not checked, and click OK. A list of DAPs appears on the left side of the program window. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 253 Info field data in the Edit box pane, titled Current DAP. Continue placing the DAPs until the DAP list is empty. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 254: Maintenance

    • You can make minor configuration changes, excluding RPNadm data. To make minor changes in the configuration, you can import Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 255 RPNs changed in the DAP manager, but the radios are still identical, thus having identical MAC addresses. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 256 256 Location builder tool Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 257: Site Survey Example

    “Gather survey items” (page 258) • “Identify site contacts” (page 258) • “Obtain site plans” (page 258) • “Gather building information” (page 259) Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 258 The scale is in the form of a measured line so it remains in proportion to the floor plan through reduction copiers. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 259 Record the type facilities, such as office, hotel, factory, store. Record the number of floors in the building. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 260 Assessing radio coverage Step Action Record areas where radio coverage is required. Record areas where radio coverage is not required. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 261 Determine and record which users have a wired IP phone in their office. Determine and record the locations of user offices. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 262 --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 263: Deployment Tool

    If you have the Deployment tool shown in the following figure, read the instructions in this section. Figure 37 Deployment tool carrying case and packing details Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 264: Prepare The Tool For Deployment

    Preparing the tool for deployment involves the following activities: • “Charging the deployment tool battery” (page 265) • “Charging the deployment handset battery” (page 266) Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 265: Charging The Deployment Tool Battery

    Charge the deployment tool battery for at least six hours before using. CAUTION Equipment Damage Use the Nortel battery charger. This charger is a separately ordered item. Failure to use an automatic shutoff battery charger can damage the battery. Do not use the battery supplied with the CT2 deployment tool.
  • Page 266: Charging The Deployment Handset Battery

    Connect the charger cord to the charging stand. Connect the charger cord to the AC mains. Place the handset into the Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 267: Assembling The Deployment Tool

    • g--telescopic extension • h--Allen key • i--basestation attaching thumb screw • j--basestation • Figure 41 Deployment tool extension details Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 268 • f--thumb screw nut • g--power cord • h--power cord receptacle • i--tripod Figure 42 Deployment tool battery details Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 269 Pull the release pin on the bracket back and slide the battery grooves on to the bracket. Ensure the bracket pin locks into the battery. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 270: Testing The Deployment Handset

    To turn the handset on, press the Shift key and press the ON/OFF button. DECT HANDSET appears on the handset display. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 271: How The Deployment Tool Works

    After a link is established, the handset emits a continuous 1.4 kHz tone and displays an RSSI value. Figure 44 Deployment handset link display Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 272: Using The Deployment Tool

    However, keep the following in mind: • Some environments can cause poor tone at a RSSI meter reading of 7 to 10. In this case, contact the Nortel Help desk for assistance. • The tone stops after the radio link is lost.
  • Page 273: Handset Tones Interpretation

    If an outdoor critical point cannot be reached, inform the customer. --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 274 274 Deployment tool Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 275: External Housing Installation

    Connect the incoming cable to the connection box that is delivered with the outdoor cabinet. Connect the CAT5 cable that is inside the outdoor cabinet to the connector box. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 276 276 External housing installation Place the foam below the foam blocks. Connect the Ethernet CAT5 to the basestation as shown. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 277 Installing a C4710 basestation in an external housing 277 Push the basestation into the foam. Place the cover foam into position. Close and lock the cabinet. --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 278: Installing A C4710E Basestation In An External Housing With An External Antenna

    Connect the antenna cables to the connectors on the printed circuit board. Secure the nuts with an SMA Torque Wrench. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 279 Connect the Ethernet CAT5 cable to the C4710E basestation. Place the basestation in the outdoor cabinet and install the foam. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 280: Mounting The Cabinet On A Wall

    Mount the cabinet to the wall. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 281: Mounting The Cabinet On A Pole

    Ensure that the cabinet is at the desired height, and tighten the metal strip around the pole by twisting the bolt. Secure the metal strip with the lock-nuts. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 282 282 External housing installation --End-- Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 283: Third Party Software

    USE, DATA, OR PROFITS; OR BUSINESS INTERRUPTION) HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY, WHETHER IN CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING NEGLIGENCE Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 284: Tls

    EXEMPLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR BUSINESS Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 285: Nortel Communication Server

    All advertising materials mentioning features or use of this software must display the following acknowledgement: "This product includes cryptographic software written by Eric Young (eay@cryptsoft.com)" Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 286: Sip Dect Fundamentals Nn43120-123 02.02 30 March

    GNU Public Licence. Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 287 Checking IIS on a PC with Windows information services 80 2003 84 DAP management 200 Choice of system configuration 147, 183 DAP manager configuration 120, 173 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 288 IP DECT configuration tools 9 Site survey process 257 Software deinstallation 236 Software requirements 79 Maintenance 254 Software requirements, call server software 79 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 289 TFTP server 94 Universal extension support 12 Using the filter 197 Using the location builder tool 247 Zone configuration 125 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 290 Nortel Communication Server 1000 SIP DECT Fundamentals NN43120-123 02.02 30 March 2010 Copyright © 2008-2010 Nortel Networks. All Rights Reserved.
  • Page 292 While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are subject to change without notice.

Table of Contents

Save PDF
