Title page
Nortel Communication Server 1000
Nortel Communication Server 1000 Release 5.0
Communication Server 1000E
Installation and Commissioning
Document Number: NN43041-310
Document Release: Standard 01.11
Date: October 2008
Year Publish FCC TM
Copyright © 2008, Nortel Networks. All rights reserved.
Produced in Canada
The information in this document is subject to change without notice. The statements, configurations, technical
data, and recommendations in this document are believed to be accurate and reliable, but are presented
without express or implied warranty. Users must take full responsibility for their applications of any products
specified in this document. The information in this document is proprietary to Nortel Networks.
Nortel, Nortel (Logo), the Globemark, SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.

Advertisement

Table of Contents
loading

Related Manuals for Nortel 1000

Summary of Contents for Nortel 1000

  • Page 1 Users must take full responsibility for their applications of any products specified in this document. The information in this document is proprietary to Nortel Networks. Nortel, Nortel (Logo), the Globemark, SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.

  • Page 3: Table Of Contents

    How to get help ......Getting help from the Nortel Web site ......
  • Page 4 Page 4 of 466 Contents Using telephones ......... . Installation summary .
  • Page 5 Contents Page 5 of 466 Rack-mounting a Media Gateway or Media Gateway Expander ..Rack-mounting a Terminal Server ......Rack-mounting a BayStack 470 Switch .
  • Page 6 Installing the Signaling Server software ......First boot of a new Nortel CP PM Signaling Server ....
  • Page 7 Contents Page 7 of 466 Verifying a successful configuration ......Testing the Leader Signaling Server ......Configuring the IPMG .
  • Page 8 Page 8 of 466 Contents Configuring a terminal and SDI ports ..279 Contents ..........Introduction ..
  • Page 9 Contents Page 9 of 466 Saving configuration changes ....... . Installing a CompactFlash ..
  • Page 10 Configuring virtual superloops ....... Configuring a Nortel IP Phone using LD 11 ....
  • Page 11 Contents Page 11 of 466 Installing and cross-connecting a Power Fail Transfer Unit ..... 437 Contents ..........Introduction .
  • Page 12 Page 12 of 466 Contents NN43041-310 Standard 01.11 October 2008...

  • Page 13: List Of Procedures

    Page 13 of 466 List of Procedures Procedure 1 Removing the cover ......... 84 Procedure 2 Rack-mounting a Media Gateway or Media Gateway Expander .
  • Page 14 Page 14 of 466 List of Procedures Procedure 14 Inserting a Shielded 50-pin to Serial/ELAN/TLAN adapter ..113 Procedure 15 Connecting a Media Card to the ELAN subnet ....114 Procedure 16 Connecting a Media Card to the TLAN subnet .
  • Page 15 Performing a datadump using Element Manager ....170 Procedure 38 Connecting a Nortel CP PM Signaling Server ..... 182 Procedure 39 Connecting a CP PM Signaling Server to the ELAN and TLAN subnets of a CS 1000E system .
  • Page 16 Page 16 of 466 List of Procedures Procedure 49 Configure conference TDS (CLI) ....... 244 Procedure 50 Configuring conference TDS (Element Manager) .
  • Page 17 List of Procedures Page 17 of 466 Procedure 67 Adding a Voice Gateway Media Card to an IP telephony node ..319 Procedure 68 Adding voice gateway channels using Element Manager ... 323 Procedure 69 Configuring voice gateway channels using LD 14 .
  • Page 18 IP Telephone Installer ........414 Procedure 97 Installing Nortel IP Phone hardware components ....417 Procedure 98 Entering IP Telephone boot parameters using manual configuration .
  • Page 19 List of Procedures Page 19 of 466 Procedure 102 Configuring the IP Softphone 2050 ......433 Procedure 103 Installing the USB Headset Kit .

  • Page 20: Procedure

    Page 20 of 466 List of Procedures NN43041-310 Standard 01.11 October 2008...

  • Page 21: Revision History

    Page 21 of 466 Revision history October 2008 Standard 01.11. This document is up-issued to reflect changes in technical content for CR Q01945162. October 2008 Standard 01.10. This document is up-issued to reflect changes in digital trunk cards and system components sections. October 2008 Standard 01.09.
  • Page 22 Standard 01.02. This document is up-issued with corrections from CR Q001646756. May 2007 Standard 01.01. This document is up-issued for Communication Server 1000 Release 5.0. This document contains information previously contained in the following legacy document, now retired: Communication Server 1000E: Installation and Configuration (553-3041-210).

  • Page 23: How To Get Help

    Center If you don’t find the information you require on the Nortel Technical Support Web site, and have a Nortel support contract, you can also get help over the phone from a Nortel Solutions Center. In North America, call 1-800-4NORTEL (1-800-466-7835).

  • Page 24: Getting Help From A Specialist By Using An Express Routing Code

    To access some Nortel Technical Solutions Centers, you can use an Express Routing Code (ERC) to quickly route your call to a specialist in your Nortel product or service. To locate the ERC for your product or service, go to: www.nortel.com/erc...

  • Page 25: Finding The Latest Updates

    The content of this documentation was current at the time the product was released. To check for updates to the latest documentation and software for CS 1000 Release 5.0, click one of the links below. Latest Software Takes you directly to the Nortel page for CS 1000 Release 5.0...
  • Page 26 Page 26 of 466 Finding the latest updates on the Nortel web site NN43041-310 Standard 01.11 October 2008...

  • Page 27: System Information

    Page 27 of 466 System information This document is a global document. Contact your system supplier or your Nortel representative to verify that the hardware and software described are supported in your area. Subject This document provides the information necessary to install and configure a Nortel Networks Communication Server 1000E system.

  • Page 28: Applicable Systems

    Page 28 of 466 System information Technical Documentation link under Support & Training on the Nortel home page: www.nortel.com Applicable systems This document applies to the Communication Server 1000E (CS 1000E) system. Note: When upgrading software, memory upgrades may be required on the Signaling Server, the Call Server, or both.
  • Page 29 Nordex BIX documentation • Krone documentation Online To access Nortel documentation online, click the Technical Documentation link under Support & Training on the Nortel home page: www.nortel.com CD-ROM To obtain Nortel documentation on CD-ROM, contact your Nortel customer representative. Communication Server 1000E...
  • Page 30 Page 30 of 466 System information NN43041-310 Standard 01.11 October 2008...

  • Page 31: Safety Instructions

    Page 31 of 466 Safety instructions Contents This section contains information on the following topics: Introduction ..........Lifting system equipment .

  • Page 32: Lifting System Equipment

    Page 32 of 466 Safety instructions Lifting system equipment Care should be exercised when lifting system components. If necessary, get assistance to lift a component or install a component in a rack. The weight of the system component can be found in the component profiles in “System components”...

  • Page 33: Installing Telephones

    Safety instructions Page 33 of 466 Installing telephones Follow these safety instructions when installing telephone equipment: • Never install telephone wiring during a lightning storm. • Never install a telephone jack in wet locations unless the jack is designed for wet locations. •...
  • Page 34 Page 34 of 466 Safety instructions • Some equipment has a three-wire grounding plug. This type of plug has a third grounding pin. As a safety feature, the plug only fits into an isolated ground outlet. If you cannot insert the plug completely into the outlet, contact your electrician to replace the outlet.

  • Page 35: Installation Summary

    Page 35 of 466 Installation summary Contents This section contains information on the following topics: Introduction ..........Installation tasks .

  • Page 36: Installation Tasks

    Page 36 of 466 Installation summary the CS 1000E system, see “Installing and configuring Nortel IP Phones” on page 391. Installation tasks Table 1 lists the tasks involved with the installation of a CS 1000E system. Table 1 List of required installation tasks (Part 1 of 2)
  • Page 37 Installation summary Page 37 of 466 Table 1 List of required installation tasks (Part 2 of 2) Task Go to page Installing and cross-connecting a Power Fail Transfer Unit Installing and cross-connecting an external alarm from a PFTU Basic system telephony configuration Configuring IP Peer Networking and managing the Gatekeeper database Communication Server 1000E...
  • Page 38 Page 38 of 466 Installation summary NN43041-310 Standard 01.11 October 2008...

  • Page 39: System Components

    Page 39 of 466 System components Contents This section contains information on the following topics: Introduction ..........CS 1000E Common Processor Pentium Mobile Call Server .

  • Page 40: Introduction

    Page 40 of 466 System components Introduction Supported configurations The following CS 1000E system configurations for CS 1000 Release 5.0 are supported: • CS 1000E Standard Availability (non redundant) • CS 1000E High Availability (redundant) • CS 1000E CP PIV processor option •...
  • Page 41 System components Page 41 of 466 • 19-inch rack • Uninterruptible Power Supply (UPS) CS 1000E High Availability (redundant) The CS 1000E High Availability system consists of the following components: • Dual CP PM Call Servers • Dual CP PM Signaling Servers •...
  • Page 42 Page 42 of 466 System components • Media Gateway Expander • BayStack 470 Switch • MRV Terminal Server • System cables The system uses the following customer-supplied components: • BayStack 460 Layer 2 switch • 19-inch rack • Uninterruptible Power Supply (UPS) Note: You must order the power cord specified for your region CS 1000E Cabinet option The CS 1000E Cabinet system consists of the following components:...

  • Page 43: Cs 1000E Common Processor Pentium Mobile Call Server

    Call Server or a Signaling Server in a CS 1000E system. There are two CP PM types available for CS 1000 Release 5.0: NTDW61BA and NTDW66AAE5. The NTDW61BA is used in the MG 1000E as either a Call Server or a Signaling Server, while the NTDW66AAE5 is used strictly as a Signaling Server in the CS 1000M SG or CS 1000M MG.
  • Page 44 Page 44 of 466 System components Figure 1 CS 1000E CP PM Call Server NN43041-310 Standard 01.11 October 2008...
  • Page 45 An MG 1000E performs functions under the control of the CS 1000E Core CP PM Call Server. Traditionally, in CS 1000 Release 4.5, this core CP PM Call Server was a CP PII or CP PIV processor in its own Call Server chassis.
  • Page 46 Page 46 of 466 System components For CS 1000 Release 5.0, the CP PM call server processor sits in one of the slots in the MG1000E chassis. The CP PM Call Server processor connects to the MG 1000E Media Gateway Controllers via Ethernet and therefore does not require backplane connectivity (other than power and slot ID).
  • Page 47 System components Page 47 of 466 Figure 3 CS 1000E CP PM Call Server system overview CP-PM Faceplate Components The following section details the CP PM faceplate. Refer to Figure 4 on page Status LED • Red: Hardware /BIOS • Flashing Red: Bootrom and OS (before Sysload Phase1) •...
  • Page 48 Page 48 of 466 System components • Green: Normal Operation • Flashing Green: SL1 Loading (on Active Core only) • Off No Power Call Server Redundancy LED • Green: Redundant Mode, Active • Flashing Green: Split Mode, Active • Yellow: Redundant Mode, Standby •...
  • Page 49 • Off: 10 Mbps • Yellow: 100 Mbps • Green: 1000 Mbps Compact Flash/ Hard Disk LEDs • CF - Flashing Green shows activity on RMD • HD/CF – Flashing Green shows activity on FMD (or HD for CP PM...
  • Page 50 Page 50 of 466 System components Figure 4 CS 1000E CP PM Call Server CP PM CS Serial Data Interface (SDI) The CP PM Call Server features two standard RS232 DTE serial ports, port 0 and port 1. These ports are accessible through a cable that attaches to the chassis or cabinet MDF port.
  • Page 51 The CP-PM Signaling Server switch S5 must be set to position 2 to indicate that a hard disk is used for the FMD. CP PM Call Server software The CP PM Call Server software features the following enhancements for CS 1000 Release 5.0: • software is large-system based •...

  • Page 52: Signaling Server

    Page 52 of 466 System components IMPORTANT! The RMD used for installation must be created specifically for CP PM using the mkbootrmd utility provided in the CP PM Call Server install zip file. An RMD created using the CP PIV mkbootrmd utility will not work on a CP PM Call Server installation.
  • Page 53 System components Page 53 of 466 The ISP1100 Signaling Server, as shown in Figure 5 and described in Table 2, provides signaling interfaces to the network using software components that run on a real-time operating system. You can install ISP1100 Signaling Servers in a load-sharing redundant configuration for higher scalability and reliability.
  • Page 54 Page 54 of 466 System components Table 2 ISP1100 Signaling Server profile (Part 2 of 3) Property Description Power • Power status indicator (green LED) is located on the unit’s faceplate. • Power cord connector is located on the left-hand corner on the back of the unit.
  • Page 55 System components Page 55 of 466 Table 2 ISP1100 Signaling Server profile (Part 3 of 3) Property Description Connectors • The DB-9 serial port, the CD-ROM and floppy (front) drives are located on the unit’s faceplate. • The DB-9 serial port can support a login session for Command Line Interface (CLI) management.
  • Page 56 Page 56 of 466 System components Figure 6 Connectors on the front of the ISP1100 Signaling Server and floppy Maintenance port CD-ROM drives NN43041-310 Standard 01.11 October 2008...
  • Page 57 System components Page 57 of 466 Figure 7 Connectors at the back of the ISP1100 Signaling Server TLAN (P2) not used Universal AC Maintenance/ ELAN (P1) not used not used power cord Admin port connector CP PM Signaling Server The CP PM Signaling Server is in the form of a circuit card and comes in two distinct models, NTDW61 and NTDW66.

  • Page 58: Media Gateway Controller

    Page 58 of 466 System components Keying will prevent the NTDW61 circuit card from being inserted into this slot. CAUTION — Equipment Damage Do not insert the NTDW61 model of the CP PM Signaling Server circuit card into any slot of an IPE cube. Doing so may cause electrical shorts on adjacent circuit cards.

  • Page 59: Mc32S Media Card

    System components Page 59 of 466 daughterboard. These daughterboards provide DSP resources for connecting IP and TDM devices, eliminating the need for installing Voice Gateway Media Cards on the CS 1000E Media Gateways. However, Voice Gateway Media Cards are still supported in CS 1000E. MC32S Media Card The MC32S is a 32-channel Voice Gateway Media Card that provides 32 Digital Signal Processor (DSP) ports to facilitate connectivity between IP and...
  • Page 60 Page 60 of 466 System components Table 3 Media Card profile (Part 2 of 2) Property Description Cooling • Provided by the Media Gateway or Media Gateway Expander. Connectors • The PC Card slot can be used to deliver software (front) or for additional storage.

  • Page 61: Media Gateway

    System components Page 61 of 466 Figure 8 Media Card PC Card slot Maintenance port Media Gateway The media gateway is shown in Figure 9 on page 62 and described Table 4 on page Communication Server 1000E Installation and Commissioning...
  • Page 62 Page 62 of 466 System components Figure 9 5-pair Cable Connectors on the Media Gateway 25-pair connectors CAUTION — Damage to Equipment Do not block equipment ventilation openings. Table 4 Media Gateway profile (Part 1 of 3) Property Description Product Code •...
  • Page 63 Media Gateway profile (Part 2 of 3) Property Description Power • Power status indicator (Nortel logo) is located on the unit faceplate. • Power cord connector is located on the right rear when viewed from the front. • Power On/Off switch is located behind the faceplate.
  • Page 64 Page 64 of 466 System components Table 4 Media Gateway profile (Part 3 of 3) Property Description Connectors • The 25-pair cable connectors at the back panel (rear) (see Figure 9 on page 62) provide access to the cross-connect terminal (Main Distribution Frame). •...
  • Page 65 System components Page 65 of 466 Figure 7 Connectors at the back of the Media Gateway Universal AC power Call Server to Media Gateway link cord connector DS-30X Port Port 2 CE-MUX Communication Server 1000E Installation and Commissioning...
  • Page 66 Page 66 of 466 System components Figure 10 Front of the Media Gateway Power Power status switch DIP switch indicators settings Bulkhead connectors NN43041-310 Standard 01.11 October 2008...

  • Page 67: Media Gateway Expander

    System components Page 67 of 466 Media Gateway Expander Figure 11 on page 67 shows the Media Gateway Expander and Table 5 on page 67 describes the expander. Figure 11 Media Gateway Expander Slot 10 Slot 9 Slot 8 Slot 7 553-CSE9032 Table 5 Media Gateway Expander profile (Part 1 of 3)
  • Page 68 Media Gateway Expander profile (Part 2 of 3) Property Description Power • Power status indicator (Nortel logo) is located on the unit’s faceplate. • Power cord connector is located on the right rear when viewed from the front. • Power On/Off switch is located behind the faceplate.
  • Page 69 System components Page 69 of 466 Table 5 Media Gateway Expander profile (Part 3 of 3) Property Description Card slots • Four usable universal card slots: 7 to 10. See Figure 11 on page • Logical slots 5 and 6 are not supported. •...

  • Page 70: 19-Inch Rack Mount Kit

    Page 70 of 466 System components Figure 12 Connectors at the back of the Media Gateway Expander CE-MUX Universal AC power DS-30X cord connector 25-pair connectors 19-inch Rack Mount Kit A 19-inch Rack Mount Kit (NTTK09AA) is available for mounting a Media Gateway and Media Gateway Expander in a 19-inch rack.

  • Page 71: Baystack 470 Switch

    System components Page 71 of 466 Table 6 NTTK09AA installation Order Code Description P0906672 Left Shelf Mounting Bracket U/O P097F813 Screw, .216- 24 X .500 STL 289A P0719943 Sems, Ext Tooth Washer Pan Head, CR Type1A, 0.164- 32 X P0906671 Right Shelf Mounting Bracket U/O P0719587 Sems, Ext Tooth Washer Pan Head, CR Type...
  • Page 72 Page 72 of 466 System components Table 7 BayStack 470 Switch profile (Part 2 of 2) Property Description Cooling • Forced air cooling with side-to-side air flow. • The three fans run whenever the unit is on. Card slots • None Connectors •...

  • Page 73: Baystack 460 Layer 2 Switch

    System components Page 73 of 466 A third-party data network switch can be used with the system. For more information, refer to Converging the Data Network with VoIP (NN43001-260). BayStack 460 Layer 2 switch The BayStack 460 Layer 2 switch, shown in Figure 14 on page 73, adds power in addition to data communications over standard Category 5 LAN...
  • Page 74 Page 74 of 466 System components The Terminal Server is configured to automatically log in to the active Core CP PM Call Server upon start-up. It always connects to the Active CPU IP address. The CS 1000E can configure up to 16 serial ports for applications within the configuration Data Block.

  • Page 75: 19-Inch Rack

    System components Page 75 of 466 Table 8 MRV IR-8020M Terminal Server profile (Part 2 of 2) Property Description Power • Power cord connector is located on the left-hand corner on the unit’s backplane. • Power supplies are factory installed and not customer replaceable.
  • Page 76 Page 76 of 466 System components Table 9 CS 1000E cables (Part 1 of 2) Cables & Component Descriptions Cable Kits Accessories Quantity Qty of 2 MRV Terminal Server cables for connecting NTDU6302 COM port 1 of the CP PM Call Server to the Terminal Server HS cross-over cable used to connect the two call NTRC17BA...
  • Page 77 System components Page 77 of 466 Table 9 CS 1000E cables (Part 2 of 2) Cables & Component Descriptions Cable Kits Accessories Quantity 100BaseT Connection Signaling Servers, Layer two switch (BS 470), Carrier CAT5 Cables Cards, ELAN on Gateways MRV Terminal Server RJ45 to 9-pin female RS232, 25 feet long, for NTVW01iX connecting terminal equipment to the MRV Terminal...

  • Page 78: Miscellaneous System Components

    Page 78 of 466 System components Miscellaneous system components Table 10 contains a list of miscellaneous items that can be used with the CS 1000E system installation. Table 10 Miscellaneous components Order Code Description Purpose QUA6A Power Failure To transfer trunk lines during a power failure Transfer Unit NTBK80BA Ground bar...
  • Page 79 System components Page 79 of 466 A UPS provides a continuous AC power supply. Refer to Communication Server 1000E: Planning and Engineering (NN43041-220) for calculating power consumption requirements. Install the UPS unit according to the manufacturer’s instructions. Communication Server 1000E Installation and Commissioning...
  • Page 80 Page 80 of 466 System components NN43041-310 Standard 01.11 October 2008...

  • Page 81: Rack-Mounting The Components

    Page 81 of 466 Rack-mounting the components Contents This section contains information on the following topics: Introduction ..........Lifting system components .

  • Page 82: Lifting System Components

    Exercise care when lifting system components. If necessary, get assistance to lift a component or install components in a rack. Table 11 on page 82 lists the CS 1000E system components provided by Nortel and the weight of each component. Consult the manufacturer’s documentation for the weight of other components installed during the CS 1000E system installation.

  • Page 83: Guidelines For Component Placement In A Rack

    Rack-mounting the components Page 83 of 466 Table 11 Weight of CS 1000E system components (Part 2 of 2) Component Media Gateway Expander — without cards — with 4 cards 13.5 BayStack 470 Switch 14.7 BayStack 460 Power over Ethernet Switch 12.76 MRV Terminal Server Guidelines for component placement in a rack...

  • Page 84: Rack-Mounting A Media Gateway Or Media Gateway Expander

    Page 84 of 466 Rack-mounting the components Rack-mounting a Media Gateway or Media Gateway Expander References to the Media Gateway in this section also apply to the Media Gateway Expander. The Media Gateway Expander can be mounted either above or below the Media Gateway. The following items are required to mount each Media Gateway or Media Gateway Expander in a 19-inch rack: •...
  • Page 85 Rack-mounting the components Page 85 of 466 upward to remove it from the Media Gateway. Refer to Figure 16 on page Note: The bottom of the front cover is supported by, but not secured to, the Media Gateway. Do not drop it. Figure 15 Unlock the latches Communication Server 1000E...

  • Page 86: Rack-Mounting A Media Gateway Or Media Gateway Expander

    Page 86 of 466 Rack-mounting the components Figure 16 Unlock the cover End of Procedure Procedure 2 Rack-mounting a Media Gateway or Media Gateway Expander Fasten the right guide bracket to the right rack support. Insert two #10-32 machine screws into the two middle slots in the guide bracket and into the respective holes in the right rack support.
  • Page 87 Rack-mounting the components Page 87 of 466 Figure 17 Guide bracket installed in a rack #10-32 Fasten the left guide bracket to the left rack support. Insert two #10-32 machine screws into the two middle slots in the bracket and into the respective holes in the left rack support. Fasten the screws.
  • Page 88 Page 88 of 466 Rack-mounting the components Figure 18 Right ear bracket on a Media Gateway Bracket flange marked with an “R”. Attach this ear bracket to the right- hand side of the Media Gateway. Attach the ear bracket to these holes.

  • Page 89: Procedure

    Rack-mounting the components Page 89 of 466 Use two #8-32 machine screws. Position the ear bracket so the four holes on the bracket flange are closer to the rear of the Media Gateway. Note: To determine the front of the bracket, locate the “L” on the bracket. The “L”...

  • Page 90: Rack-Mounting A Terminal Server

    Page 90 of 466 Rack-mounting the components Rack-mounting a Terminal Server Follow the manufacturer’s instructions to rack-mount this equipment. Rack-mounting a BayStack 470 Switch Follow the manufacturer’s instructions to rack-mount this equipment. Rack-mounting a BayStack 460 Power over Ethernet unit Follow the manufacturer’s instructions to rack-mount this equipment.

  • Page 91: Installing System Grounds

    Page 91 of 466 Installing system grounds Contents This section contains information on the following topics: Introduction ..........Installing a ground bar.

  • Page 92: Installing A Ground Bar

    Page 92 of 466 Installing system grounds Refer to your grounding plan for additional information. WARNING Correct grounding is very important. Failure to complete the grounding procedures could result in a system that is unsafe for the personnel using the equipment. CAUTION —...

  • Page 93: Installing An Ntbk80 Ground Bar

    Installing system grounds Page 93 of 466 Follow Procedure 3 to install a ground bar. Procedure 3 Installing an NTBK80 Ground Bar Place the ground bar near the equipment. Note: The ground bar is a bridging point for ground wires from up to six components.

  • Page 94: Installing An Ntdu6201 Ground Bar

    Page 94 of 466 Installing system grounds Figure 20 NTBK80 Ground Bar End of Procedure Follow Procedure 4 to install an Ground Bar. NTDU6201 Procedure 4 Installing an NTDU6201 Ground Bar Place the NTDU6201 Ground Bar near the equipment. Note: The ground bar is a bridging point for ground wires from up to 48 components.

  • Page 95: Grounding An Isp1100 Signaling Server

    Installing system grounds Page 95 of 466 Connect the NTDU6201 Ground Bar to the ground bus in the AC electrical panel, or to TGB for an ANSI/EIA/TIA 607 installation using #6 AWG wire. See Table 12 on page 93 for region-specific grounding requirements. WARNING A qualified technician or electrician must make the connection in the AC electrical panel.

  • Page 96: Grounding Media Gateways Powered By The Same Electrical Panel

    Page 96 of 466 Installing system grounds Procedure 5 Grounding Media Gateways powered by the same electrical panel Disconnect the AC power cord from the power outlet. Install a #6 AWG ground wire from the ground lug, as shown in Figure 21 page 96, at the back of the Media Gateway to the ground bar.

  • Page 97: Grounding A Media Gateway Powered By Multiple Electrical Panels

    Installing system grounds Page 97 of 466 Test the ground. End of Procedure Grounding a Media Gateway powered by multiple electrical panels Follow Procedure 6 on page 97 to ground multiple Media Gateway that are powered by multiple electrical panels. Procedure 6 Grounding Media Gateways powered by multiple electrical panels Disconnect the AC power cord from the power outlet.

  • Page 98: Grounding Other Rack-Mounted Components

    Page 98 of 466 Installing system grounds IMPORTANT! Power each Media Gateway and Media Gateway Expander pair from the same electrical panel. Follow Procedure 7 to ground a Media Gateway Expander. Procedure 7 Grounding a Media Gateway Expander Disconnect the AC power cord from the power outlet. Install a #6 AWG ground wire from the ground lug on the rear of the Media Gateway Expander to the Media Gateway.
  • Page 99 Installing system grounds Page 99 of 466 Figure 22 Grounding multiple pieces of equipment in a rack Terminal Server Signaling Server CS 1000E Call Server Media Gateway Chassis Grounding lug on back of chassis Media Gateway Chassis Expansion Other data communications equipment with grounding lug...

  • Page 100: Grounding Equipment In The Uk

    Page 100 of 466 Installing system grounds Grounding equipment in the UK Follow Procedure 8 to ground equipment in the UK. Procedure 8 Grounding equipment in the UK Connect a protective and functional ground wire from the grounding strip on the Krone Test Jack Frame to the ground at the building entry point. Use a green/yellow wire no thinner than 10 mm Consider each Media Gateway and Media Gateway Expander pair as one ground.

  • Page 101: Installing And Connecting Cs 1000E Hardware

    Page 101 of 466 Installing and connecting CS 1000E hardware Contents This section contains information on the following topics: Introduction ..........Connecting CP PM Call Server 0 to CP PM Call Server 1.

  • Page 102: Connecting Cp Pm Call Server 0 To Cp Pm Call Server 1

    Layer 2 switching products, in addition to the BayStack 470. The distance depends upon network parameter limitations specified in Communication Server 1000: System Redundancy (NN43001-507). To separate the redundant CP PM Call Servers, the ELAN subnet and the subnet of the High Speed Pipe (HSP) can be extended between the two processors with an Ethernet switch, using Layer 2 protocol.

  • Page 103: Connecting Co-Located Cp Pm Call Servers

    Page 103 of 466 For detailed information on Campus Redundancy, refer to Communication Server 1000: System Redundancy (NN43001-507). The Layer 2 switch allows the ELAN subnet and the subnet of the High Speed Pipe (HSP) to be extended between the two processors. The BayStack 470-24T provides full duplex wire-speed 100BaseT with no significant packet loss (less than 0.001%) and delays of less than 100 usec.

  • Page 104: Installing The Cards

    Page 104 of 466 Installing and connecting CS 1000E hardware information, see Communication Server 1000: System Redundancy (NN43001-507). Procedure 10 Connecting Campus Redundant CP PM Call Servers Connect the CAT5E RJ-45 LAN 2 port of Call Server 0 to a 100BaseT ELAN network interface on the local Baystack 470-24T switch.

  • Page 105: Installing A Dsp Daughterboard

    You must ensure that all dongles (for both MGC and CP PM cards) are correctly identified. You must destroy or return the SSC dongle to your local Nortel Repairs/Returns center. For the CP PM call server you must use the dongle provided with the software kit.

  • Page 106: Installing The Cp Pm Card

    Page 106 of 466 Installing and connecting CS 1000E hardware The existing 3-port SDI cable (NTBK48AA) is reused. It connects to the SDI port on the Chassis. This chassis, the main chassis in the system, will now become known as IPMG 00.

  • Page 107: Cabling The Cards

    Installing and connecting CS 1000E hardware Page 107 of 466 Figure 23 2-port SDI cable (NTAK19EC) cable End of Procedure Cabling the cards The following sections describe the process required to cable the MGC and CP PM cards. Cabling the MGC The existing 3-port SDI cable (NTBK48AA) is reused.
  • Page 108 Page 108 of 466 Installing and connecting CS 1000E hardware port of the call server, while the CT connects to the TLAN port of the call server. The 1E and 2T ports must be attached to the layer 2 switch. MGC Ethernet Capabilities An MGC features six Ethernet interfaces set to auto-negotiate by default: four on the faceplate (see Figure 24 on...
  • Page 109 Installing and connecting CS 1000E hardware Page 109 of 466 Figure 24 MGC faceplate 1E: ELAN CE: ELAN Dual homed with Dedicated for CPPM-CS Backplane E CT: TLAN 2T: TLAN Dedicated for Dual homed with CPPM-CS Backplane T Note: The MG1000E can be connected directly to the CS1000E ELAN subnet, or it can be connected to the ELAN subnet through a Layer 2 switch.
  • Page 110 Page 110 of 466 Installing and connecting CS 1000E hardware Figure 25 Elan connection (CP PM Call Server) NN43041-310 Standard 01.11 October 2008...
  • Page 111 Installing and connecting CS 1000E hardware Page 111 of 466 Figure 26 Elan connections (MGC) Communication Server 1000E Installation and Commissioning...

  • Page 112: Inserting A Shielded 50-Pin To Serial/Elan/Tlan

    Page 112 of 466 Installing and connecting CS 1000E hardware Figure 27 Ethernet connections for CP PM Signaling Server Note: Refer to Figure 26 on page 111 for a visual representation of MGC card cabling (from port 1E and 2T) out to the layer 2 switch. Inserting a Shielded 50-pin to Serial/ELAN/TLAN adapter onto a Media Card The Shielded 50-pin to Serial/ELAN/TLAN adapter shown in Figure 28...
  • Page 113 Installing and connecting CS 1000E hardware Page 113 of 466 • TLAN (telephony) network interface • one RS-232 (local console) port Figure 28 Shielded 50-pin to Serial/ELAN/TLAN adapter TLAN RJ-45 ELAN RJ-45 RS-232 Connector LAN socket LAN socket Voice Gateway Media Card maintenance port 50-pin connector Identification Label...

  • Page 114: Connecting A Media Card To The Elan Subnet

    Page 114 of 466 Installing and connecting CS 1000E hardware Connecting a Media Card to the ELAN subnet Follow Procedure 15 to connect a Media Card to the ELAN. Procedure 15 Connecting a Media Card to the ELAN subnet Connect a standard CAT5 patch cable to the ELAN network interface on the Adaptor (Figure 29 on page 114).

  • Page 115: Connecting A Media Card To The Tlan Subnet

    Installing and connecting CS 1000E hardware Page 115 of 466 Connecting a Media Card to the TLAN subnet Follow Procedure 16 to connect a Media Card to the TLAN subnet. Procedure 16 Connecting a Media Card to the TLAN subnet Connect a standard CAT5 patch cable to the TLAN network interface on the adaptor (see Figure 29 on page...
  • Page 116 Page 116 of 466 Installing and connecting CS 1000E hardware Figure 30 Media Gateway and Media Gateway Expander connections NTDK95 cables CE-MUX DS-30X connector connector End of Procedure NN43041-310 Standard 01.11 October 2008...

  • Page 117: Installing Software On The Cs 1000E

    Page 117 of 466 Installing software on the CS 1000E Contents This section contains information on the following topics: Introduction ..........Installing the software .

  • Page 118: Installing The Software

    Installing the software This section provides the steps involved in installing CS 1000 Release 5.0 for CP PM. Procedure 18 Installing the software on the CP PM Call Server Connect the terminal to port 0 with the NTAK19EC cable.
  • Page 119 Installing software on the CS 1000E Page 119 of 466 The VxWorks banner screen appears (see Figure 32 on page 119): Figure 32 VxWorks banner Enter y for both software warnings to proceed with the upgrade. Note: PE/EPE is not applicable for this upgrade as it only applies to large systems.
  • Page 120 Page 120 of 466 Installing software on the CS 1000E The Software Installation Tool Main Menu appears (see Figure 33 on page 120). Note: If the keycode files reside on a separate CF card, remove the software CF card and insert the CF card containing the keycode files. The keycode normally resides in the keycode folder of the OS CF card.
  • Page 121 Note: If the CF card was exchanged, insert the CF card containing CS 1000 Release 5.0. Enter <CR> or y to confirm that the keycode matches the system software on the RMD (see Figure 35 on page 121).
  • Page 122 Page 122 of 466 Installing software on the CS 1000E The Install Menu appears (see Figure 36 on page 122). Enter b to install the software, database, and CP-BOOTROM. Figure 36 Install Menu The following screen appears (see Figure 37 on page 122): 10 Enter <CR>...
  • Page 123 Figure 38 Call processor location 12 If not already present in the CF drive, insert the CF card containing CS 1000 Release 5.0 (see Figure 39). Figure 39 Insert RMD 13 Enter <CR> or y to confirm that you have the correct software version...
  • Page 124 Page 124 of 466 Installing software on the CS 1000E Figure 40 Confirm software version 14 Enter <CR> or y to install dependency lists and continue with the upgrade (see Figure 41 on page 124). Figure 41 Install Dependency Lists 15 Enter <CR>...
  • Page 125 Installing software on the CS 1000E Page 125 of 466 Figure 42 Centralized Software Upgrade 16 Set the CSU feature to Sequential by entering either <CR> or y (see Figure 43). Figure 43 Automatic Centralized Software Upgrade Mode The Installation Status Summary screen appears (see Figure 44 on page 126).
  • Page 126 Page 126 of 466 Installing software on the CS 1000E Figure 44 Installation Status Summary 17 Enter <CR> or y to begin the installation (see Figure 45). Figure 45 Install Tool NN43041-310 Standard 01.11 October 2008...
  • Page 127 Installing software on the CS 1000E Page 127 of 466 18 A prompt appears warning you that old system files will be deleted as a result of the installation. Enter <CR> or y to continue with the installation. 19 The PSDL Installation Menu appears (see Figure 46). Select the appropriate location based on your geographical location.
  • Page 128 Page 128 of 466 Installing software on the CS 1000E Figure 48 Database installation 22 Enter a. 23 The Installation Status Summary screen appears, indicating that the installation was a success (see Figure 49). Enter <CR> to continue. NN43041-310 Standard 01.11 October 2008...
  • Page 129 Installing software on the CS 1000E Page 129 of 466 Figure 49 Installation Status Summary 24 The Install Menu appears (see Figure 50 on page 130). Enter q to quit the Install Tool. Communication Server 1000E Installation and Commissioning...
  • Page 130 Page 130 of 466 Installing software on the CS 1000E Figure 50 Install Menu 25 Enter <CR> or y to confirm your selection (see Figure 51). Figure 51 Quit Install Tool NN43041-310 Standard 01.11 October 2008...
  • Page 131 Installing software on the CS 1000E Page 131 of 466 26 Enter <CR> or y to reboot the system (see Figure 52). Once the system has completed its reboot, remove the CF from the faceplate. Figure 52 System reboot Communication Server 1000E Installation and Commissioning...

  • Page 132: Reconfiguring I/O Ports And Call Registers

    Reconfiguring I/O ports and call registers Evaluate the number of call registers and 500 telephone buffers that are configured for the system (suggested minimum values are 4500 and 1000 respectively). If changes are required, reconfigure the values in LD 17:...

  • Page 133: Testing The Cp Pm Call Server

    Installing software on the CS 1000E Page 133 of 466 Test the CP PM Call Server Procedure 21 Testing the CP PM Call Server Verify that the CP PM Call Server is active. LD 135 Load program STAT CPU Get the status of the CPUs Check dial-tone.

  • Page 134: Making The System Redundant

    Page 134 of 466 Installing software on the CS 1000E Verifying CP PM Call Server 0 is active Use the following commands to verify that CP PM Call Server 0 is active. LD 135 Load program STAT CPU Get the status of the CPUs Make the system redundant At this point, Core/Net 0 is ready to be synchronized with Core/Net 1.
  • Page 135 Installing software on the CS 1000E Page 135 of 466 .stat cpu cp 0 16 PASS -- STDBY TRUE REDUNDANT DISK STATE = REDUNDANT HEALTH = 20 VERSION = Mar 3 2005, 16:26:40 Side = 0, DRAM SIZE = 512 MBytes cp 1 16 PASS -- ENBL TRUE REDUNDANT DISK STATE = REDUNDANT...
  • Page 136 Page 136 of 466 Installing software on the CS 1000E .stat health Local (Side 0, Active, Redundant): Components without TIER 1 Health contribution: ================================================= disp 0 15 1:In Service sio2 0 15 1:In Service cp 0 16:In Service ipb 0:In Service TIER 1 Health Count Breakdown: ===================================== sio8 0 16 1: 0002...
  • Page 137 Installing software on the CS 1000E Page 137 of 466 TIER 2 Health Count Breakdown: ======================================= ELAN 16 IP : 47.11.138.150 Health = 2 ELAN 17 IP : 47.11.138.153 Health = 2 Local AML over ELAN Total Health:4 Local Total IPL Health = 6 IPL connection history:3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 Local TIER 2 Health Total:10...
  • Page 138 Page 138 of 466 Installing software on the CS 1000E TIER 2 Health Count Breakdown: ======================================= ELAN 16 IP : 47.11.138.150 Health = 2 ELAN 17 IP : 47.11.138.153 Health = 2 Remote AML over ELAN Total Health:4 Remote Total IPL health = 6 Remote TIER 2 Health Total:10 Get status of links to the Media Gateways (STAT IPL).

  • Page 139: Testing Cp Pm Call Server 0

    Installing software on the CS 1000E Page 139 of 466 Complete the CP PM installation Testing the CP PM Call Servers Procedure 24 Testing CP PM Call Server 0 At this point in the installation, CP PM Call Server 0 is tested from active CP PM Call Server 1.

  • Page 140: Switching Call Processing

    Page 140 of 466 Installing software on the CS 1000E Test system redundancy and media devices: LD 137 Load program TEST RDUN Test redundancy DATA RDUN Test database integrity STAT FMD Status of one or both Fixed Media Devices (FMD) STAT RMD Status of one or both Removable Media Devices (RMD)

  • Page 141: Testing Cp Pm Call Server 1

    Installing software on the CS 1000E Page 141 of 466 Procedure 26 Testing CP PM Call Server 1 From active CP PM Call Server 0, perform these tests on CP PM Call Server Perform a redundancy sanity test: LD 135 Load program STAT CPU Get status of CPU and memory...
  • Page 142 Page 142 of 466 Installing software on the CS 1000E STAT RMD Status of one or both Removable Media Devices (RMD) **** Exit the program Clear the display and minor alarms on both CP PM Call Servers: LD 135 Load program CDSP Clear the displays on the CP PM Call Servers CMAJ...

  • Page 143: Configuring Initial Ip Configuration Data On Mgc

    Installing software on the CS 1000E Page 143 of 466 Perform a customer backup data dump (installation release) Procedure 28 Performing a data dump to backup the customer database: Log in to the system. Insert a CF card into the active CP PM Call Server RMD slot to back up the database.

  • Page 144: Configuring The Mgc On The Call Server

    Page 144 of 466 Installing software on the CS 1000E The MGC must be given a superloop and shelf reference on the Call Server (see Table 13) Table 13 MGC superloop configuration Loop Shelf IPMG # Procedure 29 Configuring the MGC on the Call Server Note: Initial configuration of the MGC is command line ONLY.
  • Page 145 Installing software on the CS 1000E Page 145 of 466 The MGC Shells can be accessed using the following commands: • <CTRL>O<CTRL>A<CTRL>M, (provide OAM username and password to access OAM shell) • <CTRL>L<CTRL>D<CTRL>B, (provide LDB username and password to access LDB) Enter network IP information at the MGC setup menu: Please define the data networking parameters for this MG 1000E now.
  • Page 146 Page 146 of 466 Installing software on the CS 1000E Enter port and security parameters, if required: Change MGC advanced parameters? (y/[n]) : y TLAN is set to auto negotiate, change? (y/[n]) : y Note: Turning off auto negotiate on the TLAN : will default it to 100Mbps full duplex.
  • Page 147 Installing software on the CS 1000E Page 147 of 466 TLAN set to auto negotiate. ELAN set to auto negotiate. ELAN security Enabled, level is Optimized Security Is this correct? (y/n/[a]bort) : y IP changes require a reboot. Enter “y” at the prompt. Do you want to continue? (y/n/[a]bort) : y reboot(-1) has been called...
  • Page 148 Page 148 of 466 Installing software on the CS 1000E IPMG ---- -- - - -- - - ------------ ------------ IPMG ---- -- - - -- - - ------------ ---------- IPMG ---- -- - - -- - - ------------ ------------ 096 ---- ---- VIRTUAL -- - - --- --- - --- ---------- 100 ---- ---- VIRTUAL -- - -...
  • Page 149 Installing software on the CS 1000E Page 149 of 466 Rebooting the MGC The MGC reboots and registers with the Call Server. Found device : INTEL 82365SL Engcode:NTDW60BA REL 08 ELAN mac address is:00:13:65:ff:ee:ed TLAN mac address is:00:13:65:ff:ee:ec RESET reason: Hard Reset. Daughter board 1:NTDW62AA R02 00:13:65:ff:f8:fd.
  • Page 150 Page 150 of 466 Installing software on the CS 1000E -> Received an upgrade request. Preparing MGC for upgrade. Auto commit option has been enabled. Upgrade of CSP loadware initiated. OMM: IP link is UP between Primary Call Server and MGC 1 Upgrade of MSP loadware initiated.

  • Page 151: Configuring The Cs 1000E Cp Pm

    Page 151 of 466 Configuring the CS 1000E CP PM Call Server Contents This section contains information on the following topics: Introduction ..........Configuring login IDs and passwords.

  • Page 152: Introduction

    Page 152 of 466 Configuring the CS 1000E CP PM Call Server Introduction The CS 1000E system requires the configuration of an IP telephony node. The configuration data is stored in the BOOTP.TAB and CONFIG.INI files on the CS 1000E. Copies of both files are maintained on each node component (Signaling Server and Media Card).

  • Page 153: Configuring Login Ids And Passwords

    Configuring the CS 1000E CP PM Call Server Page 153 of 466 Configuring login IDs and passwords Note: You must be logged in as a user with admin2 level privileges in order to change the default username and password. For increased security: •...
  • Page 154 Page 154 of 466 Configuring the CS 1000E CP PM Call Server LOCK <enter to accept default or set to required setting> FLTA <enter to accept default or set to required setting> AUDT <enter to accept default or set to required setting> LLID <enter to accept default or set to required setting>...
  • Page 155 Configuring the CS 1000E CP PM Call Server Page 155 of 466 15 Enter the command: PASSWORD (userpassword) 16 Enter the command: CONFIRM (confirm password) 17 Enter the command: OVLA 10 11 18 Enter the command: OVLA all 19 Enter the command: OVLA 20 Enter the command: Cust 0...

  • Page 156: Enabling The Multi-User Option

    Page 156 of 466 Configuring the CS 1000E CP PM Call Server Enabling the multi-user option Follow Procedure 31 to enable the multi-user option. Procedure 31 Enabling the multi-user option Enter the command: LD 17 System response: CFN000 MEM AVAIL: (U/P): 1015918 USED U P: 138773 24956 TOT: 1179647 DISK RECS AVAIL: 486 TMDI D-CHANNELS AVAIL: 0 USED: 0 TOT: 0...

  • Page 157: Configuring Pseudo-Terminals (Ptys)

    PORT prompt. If no input is entered for the PORT prompt, the default value is the same as the TTY number. Nortel recommends using the default value for easy management. When an rlogin session is initiated with a user ID, the Call Server searches for a free PTY with a matching user ID.
  • Page 158 Page 158 of 466 Configuring the CS 1000E CP PM Call Server System response: CFN000 MEM AVAIL:(U/P):1019254 USED U P:138012 22381 TOT:1179647 DISK RECS AVAIL: 491 TMDI D-CHANNELS AVAIL: 0 USED: 0 TOT: 0 DCH AVAIL: 80 USED: 0 TOT: 80 AML AVAIL: 15 USED: 1 TOT: 16 Enter the command: REQ CHG...

  • Page 159: Checking Pty Status

    Configuring the CS 1000E CP PM Call Server Page 159 of 466 10 Enter the command: TTYLOG NO 11 Enter the command: BANR YES System response: MEM AVAIL: (U/P):1019130 USED U P: 138064 22453 TOT: 3555327 DISK RECS AVAIL: 491 TMDI D-CHANNELS AVAIL: 0 USED: 0 TOT: 0 DCH AVAIL: 80 USED: 0 TOT: 80 AML AVAIL: 15 USED: 1 TOT: 16...

  • Page 160: Configuring Virtual Tone And Conference Circuits

    MG 1000E. Use LD 17 to add MGTDS and MG Conference loops. The Virtual Tone and Conference Circuits in the same MG 1000E must occupy contiguous double loops. For easy management, Nortel recommends to start the MGTDS and MG Conference loops from a loop number high enough (for example, 60) to leave enough superloop number for all MG 1000E superloops.

  • Page 161: Configuring The Mg 1000E Bandwidth Management Zones

    Configuring the CS 1000E CP PM Call Server Page 161 of 466 Configuring the MG 1000E Bandwidth Management Zones Follow Procedure 34 for configuring bandwidth management zones. Procedure 34 Configuring MG 1000E Bandwidth Management Zone Enter LD 117 and press <cr>. Enter NEW ZONE 0, to create a new zone with default parameters.
  • Page 162 Page 162 of 466 Configuring the CS 1000E CP PM Call Server LD 117 – Bandwidth management zone commands Command Description NEW ZONE xxx p1 p2 p3 p4 p5 Create a new zone, where: xxx = zone number = (0) - 255. p1 = Intrazone available bandwidth = 0 - (10 000) - 100 000 (Kbps) p2 = Intrazone preferred strategy...

  • Page 163: Configuring The Mg 1000E Ports

    Configuring the CS 1000E CP PM Call Server Page 163 of 466 The type of any Bandwidth Management Zone for MG 1000E with conference resources configured must be shared. Distortion in Music is expected when G.729AB codec is used. Hence the Interzone and the Intrazone policies for an MG 1000E Bandwidth Management Zone should have Best Quality to give preference to G711 codec to minimize of occurrence of music distortion.

  • Page 164: Configuring Digitone Receivers

    Page 164 of 466 Configuring the CS 1000E CP PM Call Server Configuring Digitone Receivers Digitone Receivers must be configured in each MG 1000E if any analog terminals or trunks are equipped. The loop of the Digitone Receivers is the superloop of the MG 1000E.

  • Page 165: Configuring Tone Detectors

    Configuring the CS 1000E CP PM Call Server Page 165 of 466 Configuring Tone Detectors Tone Detectors, when required, are configured in a manner similar to that for Digitone Receivers. The SSC card in the MG 1000E provides four units of Multifrequency Senders and Receivers.

  • Page 166: Launching Element Manager

    Page 166 of 466 Configuring the CS 1000E CP PM Call Server Note: This procedure requires Service Pack 1 and Java Runtime environment. Procedure 35 Launching Element Manager Open the web browser. Enter the Signaling Server Node IP address in the Address Bar of the browser window, and press Enter on the keyboard.
  • Page 167 Configuring the CS 1000E CP PM Call Server Page 167 of 466 Figure 53 The Element Manager login End of Procedure Communication Server 1000E Installation and Commissioning...

  • Page 168: Importing Preconfigured Ip Telephony Files

    Page 168 of 466 Configuring the CS 1000E CP PM Call Server Importing preconfigured IP telephony files Follow Procedure 36 to import the preconfigured IP telephony files from the Signaling Server. Procedure 36 Importing an existing node Figure 54 displays the Element Manager System Information home page. Figure 54 Element Manager –...
  • Page 169 Configuring the CS 1000E CP PM Call Server Page 169 of 466 Select System > IP Network > Nodes: Servers, Media Cards from the navigator. The Node Configuration web page appears. No nodes are defined. Import the Node files from the leader Signaling Server. Click Import Node Files on the Node Configuration web page.

  • Page 170: Reviewing And Submitting Ip Telephony Node Configuration Files

    Page 170 of 466 Configuring the CS 1000E CP PM Call Server Reviewing and submitting IP telephony node configuration files To review and submit IP telephony node configuration files, please refer to IP Line: Description, Installation, and Operation (NN43100-500). Adding a Follower Signaling Server to an IP telephony node To add a follower signaling server to an IP telephony node, follow the procedure as given in Signaling Server: Installation and Commissioning...
  • Page 171 Configuring the CS 1000E CP PM Call Server Page 171 of 466 Figure 56 Call Server Backup and Restore web page Select Backup. The Call Server Backup web page appears (see Figure 57 on page 172). Communication Server 1000E Installation and Commissioning...
  • Page 172 Page 172 of 466 Configuring the CS 1000E CP PM Call Server Figure 57 CS 1000E Backup Select Backup from the Action drop-down list box. Click Submit. The message displays indicating “Backup in progress. Please wait...” Click OK in the EDD complete dialog box. The Backup function then displays information in a tabular form, indicating the actions that were performed.

  • Page 173: Installing A Signaling Server

    Installing the Signaling Server software ......First boot of a new Nortel CP PM Signaling Server ....

  • Page 174: Introduction

    Installing a Signaling Server Introduction This chapter contains general instructions to install a Nortel CP PM server and detailed instructions to install a legacy Nortel ISP1100 server. This chapter contains no instructions to install an IBM X306m or HP DL320-G4 COTS 1U server.

  • Page 175: Readiness Checklist

    IBM xSeries 306m Types 8848 and 8491 User Guide or the HP ProLiant DL320 Generation 4 Server User Guide shipped with the server. Readiness checklist Before installing a Signaling Server in a CS 1000 system, complete the following checklist. WARNING Do not modify or use a supplied AC-power...
  • Page 176 Have you: Read all safety instructions in Communication Server 1000E: Installation and Commissioning (NN43041-310) or Communication Server 1000M and Meridian 1 Large System Installation and Configuration (NN43021-310), as appropriate for your CS 1000 system? Received all equipment and peripherals? For a Nortel ISP1100 (NTDU27AA), IBM X306m (NTDU99AAE5), and HP DL320-G4 (NTDU97AA) Signaling Servers: •...

  • Page 177: Installing The Cp Pm Signaling Server Hardware

    Installing the CP PM Signaling Server hardware The Nortel CP PM server is a circuit card, and thus is not mounted in a rack. This section contains instructions for installing a Nortel CP PM Signaling Server in a CS 1000E and a CS 1000M system.
  • Page 178 CP PM Signaling Server circuit cards only. Installation in a CS 1000E system The NTDW61BAE5 model of the Nortel CP PM server is designed for use in a CS 1000E system. The first task that must be performed is to install the hard drive shipped with the server.

  • Page 179: Connections

    Obtained a serial cable (DTE-DTE null modem cable) to connect the server to a maintenance terminal? Obtained the NTAK19EC cable (if you are connecting a Nortel CP PM server)? This cable adapts the 50-pin MDF connector on the back of the shelf of the Media Gateway, Universal Equipment Module, or 11C cabinet to a 25-pin DB connector.
  • Page 180 The NTDW66AAE5 model of the Nortel CP PM Signaling Server was designed for use in a CS 1000M system. Figure 58 shows the faceplates of the two models of the Nortel CP PM Signaling Server with labeling for all components (NTDW61BAE5 on the left and NTDW66AAE5 on the right).
  • Page 181 Installing a Signaling Server Page 181 of 466 Figure 58 Faceplates of the Nortel CP PM server Communication Server 1000E Installation and Commissioning...

  • Page 182: Connecting A Nortel Cp Pm Signaling Server

    Page 182 of 466 Installing a Signaling Server Procedure 38 Connecting a Nortel CP PM Signaling Server Note: Refer to Figure 58 when performing the following procedure. Establish a maintenance terminal connection at the back of the shelf of the IPMG. The com (SDI) port of the CP PM circuit card Signaling Server is routed through the backplane of the shelf to the 50 pin MDF connector on the back of the shelf.

  • Page 183: System

    9600 Bit/s. Other available speeds are 19 200, 38 400, and 115 200 Bits. You can change the port speed using the maintenance terminal. To verify or change the baud rate on a Nortel CP PM Signaling Server, see Signaling Server: Installation and Commissioning (NN43001-312).
  • Page 184 Signaling Server directly to the ELAN and TLAN Ethernet switches from the faceplate ELAN and TLAN Ethernet ports. Complete Procedure 40 to connect a Nortel CP PM Signaling Server (model NTDW66AAE5) to the ELAN and TLAN subnets of a CS 1000M system. IMPORTANT! Connecting a Nortel CP PM Signaling Server to the ELAN and TLAN subnets of a CS 1000M system causes a service disruption.
  • Page 185 TLAN Ethernet switch. End of Procedure Verify or change the baud rate To verify or change the baud rate on a Nortel CP PM Signaling Server, see Signaling Server: Installation and Commissioning (NN43001-312). Connecting an IBM X306m Signaling Server...

  • Page 186: Connecting An Ibm X306M Signaling Server

    Page 186 of 466 Installing a Signaling Server Figure 59 IBM X306m Signaling Server (rear view) Note: Refer to Figure 59 when performing the following procedure. Procedure 41 Connecting an IBM X306m Signaling Server Connect the Signaling Server to the TLAN subnet. Insert the RJ-45 CAT5 (or better) cable into Port 1 (TLAN network interface) on the back of the Signaling Server.
  • Page 187 End of Procedure Connecting an HP DL320-G4 Signaling Server In geographic regions that are susceptible to electrical storms, Nortel recommends that you plug the HP DL320-G4 Signaling Server into an AC surge suppressor. Figure 60 shows the rear view of the HP DL320-G4 Signaling Server.

  • Page 188: Connecting An Hp Dl320-G4 Signaling Server

    Page 188 of 466 Installing a Signaling Server Procedure 42 Connecting an HP DL320-G4 Signaling Server Connect the Signaling Server to the TLAN subnet. Insert the RJ-45 CAT5 (or better) cable labeled with the number 5 into the port (TLAN network interface) on the back of the Signaling Server.

  • Page 189: Installing The Signaling Server Software

    Signaling Server software prior to CS 1000 Release 5.0. IMPORTANT! CS 1000 Release 5.0 Signaling Server software does not need to be installed on the CP PM Signaling Server. It is delivered with the Signaling Server software, operating system, applications and web files pre-loaded onto the hard drive.

  • Page 190: Installing Signaling Server Software

    Server to boot from the CD. • For a Nortel CP PM Signaling Server, insert the CS 1000 Release 5.0 Signaling Server Software CF card into the faceplate CF drive and press the RST button on the faceplate of the Signaling Server to trigger a cold boot.
  • Page 191 Installing a Signaling Server Page 191 of 466 Figure 61 Nortel CP PM system BIOS configuration • The VxWorksTM banner screen appears (see Figure 62) followed by system messages indicating that the Signaling Server Software Installation Tool is being loaded from either the Signaling Server Software CD or CF Card.
  • Page 192 Page 192 of 466 Installing a Signaling Server Figure 62 VxWorks system banner When the Install Tool banner appears (Figure 63), press <CR> to perform system checks and begin software installation. NN43041-310 Standard 01.11 October 2008...
  • Page 193 Installing a Signaling Server Page 193 of 466 Figure 63 Install Tool banner screen CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== ##### ######### ######## ########`` `############# ######## `############# #######` ######```#### ####### ######`` `### NORTEL NETWORKS ####### #####`` ####...
  • Page 194 Upon failure, the menu in Figure 64 appears. Figure 64 File systems verification failure CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== The filesystems verification failed! (This is normal for a new system.) The hard disk must be (re)partitioned and (re)initialized. This will erase all data on the hard disk.
  • Page 195 Page 195 of 466 Figure 65 Date and time CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ==================================================================== You should ensure the system date and time are correct prior to installation, since all files copied or created during install will be time-stamped.
  • Page 196 Page 196 of 466 Installing a Signaling Server Figure 66 System Summary CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== ------------------------------------------ SYSTEM INFORMATION ------------------------------------------ +================================================================+ Hostname: SS_Node276_Ldr S/W Ver: x.xx.xx Role: Leader Set TPS: Disabled Node ID: Vtrk TPS: Disabled...
  • Page 197 Installing a Signaling Server Page 197 of 466 Figure 67 Install Tool Main Menu CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== M A I N M E N U The Install Tool will install Signaling Server software and related files.
  • Page 198 Page 198 of 466 Installing a Signaling Server The Dependency Lists installation screen appears (Figure 68). Figure 68 Dependency lists installation Press <CR> or enter y to install the dependency lists. The Installation Status Summary screen appears: The Installation status screen appears (Figure 69 on page 199).
  • Page 199 Installing a Signaling Server Page 199 of 466 Figure 69 Installation Status Enter y to start the installation. The screens shown in Figures 70 to 76, which start on page 200, appear. Communication Server 1000E Installation and Commissioning...
  • Page 200 Page 200 of 466 Installing a Signaling Server Figure 70 Installation output CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== You have selected to install version x.xx.xx on the system. As this is a new install, all necessary directories and files will be created on the hard disk.
  • Page 201 Installing a Signaling Server Page 201 of 466 Figure 72 IP Phone firmware CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== The installation source contains multiple Internet Telephone firmware files. Copying /cd0/0603Bxx.bin” to “/u/fw/0603Bxx.bin”. Copying “/cd0/0602Bxx.bin” to “/u/fw/0602Bxx.bin”. Copying “/cd0/0604Dxx.bin” to “/u/fw/0604Dxx.bin”.
  • Page 202 Page 202 of 466 Installing a Signaling Server Figure 74 Restore IP configuration Do one of the following: • If you are migrating a Leader Signaling Server (see "Signaling Server migration" in Signaling Server: Installation and Commissioning (NN43001-312),insert the Removable Media Device (RMD) into the appropriate drive, and press <CR>...
  • Page 203 Installing a Signaling Server Page 203 of 466 Figure 75 IP telephony parameter confirmation If you are installing a new Signaling Server, or you are migrating a Follower or Standalone Signaling Server (see "Signaling Server migration" in Signaling Server: Installation and Commissioning (NN43001-312)), select b to bypass the restoration of IP configuration data.
  • Page 204 Page 204 of 466 Installing a Signaling Server Figure 76 Signaling Server role selection CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Note: This step will over-write all existing configuration parameters on this Signaling Server. Please select the role of this Signaling Server.
  • Page 205 Installing a Signaling Server Page 205 of 466 Figure 77 Follower Signaling Server configuration CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ======================================================================= This Follower Signaling Server will obtain its data network and IP telephony configuration from the Leader Signaling Server at boot.
  • Page 206 NRS - Coresident Signaling Server screen or the NRS - Standalone Signaling Server screen appears. Figure 79 Network Routing Service (NRS) — co-resident Signaling Server CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please select the Network Routing Service (NRS) configuration for this Signaling Server.
  • Page 207 Installing a Signaling Server Page 207 of 466 Figure 80 Network Routing Service (NRS) — stand-alone Signaling Server CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please select the Network Routing Service (NRS) configuration for this Signaling Server. Please enter: <CR>...
  • Page 208 Page 208 of 466 Installing a Signaling Server Figure 81 NRS type — co-resident Signaling Server CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please select the type of Network Routing Service (NRS) for this Signaling Server. Please enter: <CR>...
  • Page 209 (Figure 83) or the Standalone Signaling Server configuration screen (Figure 84) appears. Figure 83 Leader Signaling Server configuration CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please enter the data networking and IP Telephony parameters for this Leader Signaling Server.
  • Page 210 Page 210 of 466 Installing a Signaling Server Figure 84 Stand-alone Signaling Server configuration CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please define the data networking parameters for this Standalone Signaling Server. Note that the ELAN parameters are necessary for management access (e.g.
  • Page 211 Alternate NRS IP address screen, or both (in succession) appear. Both screens appear in succession for a Standalone Signaling Server. Figure 85 Primary NRS IP address CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please enter the Primary NRS IP Address: Primary NRS IP Figure 86 Alternate NRS IP address CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx)
  • Page 212 The Gatekeeper configuration can be updated later using Element Manager. The IP Telephony parameter confirmation screen appears (Figure 87). Figure 87 IP Telephony parameter configuration CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== You have entered the following parameters for this Leader Signaling Server: Node ID...
  • Page 213 Installing a Signaling Server Page 213 of 466 16 Enter <CR> or y to confirm the parameters. The example in Figure 87 on page 212 is for a Leader Signaling Server configured with an Alternate H.323 and SIP NRS. The confirmation screens for a Follower and stand-alone Signaling Server are similar, showing the same list of parameters, specifically: •...
  • Page 214 Page 214 of 466 Installing a Signaling Server Figure 88 Installation Status Summary 18 Press <CR> to exit to the Main Menu (see Figure 89 on page 215). Enter q at the Main Menu to quit the installation process. Figure 90 on page 215 appears.
  • Page 215 Installing a Signaling Server Page 215 of 466 Figure 89 Install Tool Main Menu CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== M A I N M E N U The Install Tool will install Signaling Server software and related files.

  • Page 216: First Boot Of A New Nortel Cp Pm Signaling Server

    Nortel CP PM Signaling Servers have CS 1000 Release 5.0 software, applications, operating system, and web files preloaded on the hard drive when they are shipped. On the first boot of a Nortel CP PM Signaling Server, the Signaling Server Software Installation Tool prompts you to enter basic system configuration parameters.

  • Page 217: Entering Basic System Configuration Parameters

    Press the RST button on the faceplate of the CP PM Signaling Server. This cold-reboots the Signaling Server and triggers the Install Tool on the hard drive (see Figure 91) Figure 91 Install Tool banner screen CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== ##### ######### ########...
  • Page 218 Page 218 of 466 Installing a Signaling Server Press <CR> to continue with the configuration. The Restore IP configuration screen appears (Figure 92). Figure 92 Restore IP configuration Enter b at the prompt to bypass the restore of IP configuration data. The CP PM board location screen appears (Figure 93).
  • Page 219 The Leader/Follower configuration screen appears (Figure 94). Figure 94 Leader/Follower Signaling Server configuration CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Note: This step will over-write all existing configuration parameters on this Signaling Server. Please select the role of this Signaling Server.
  • Page 220 Page 220 of 466 Installing a Signaling Server Figure 95 Follower Signaling Server configuration CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ======================================================================= This Follower Signaling Server will obtain its data network and IP telephony configuration from the Leader Signaling Server at boot.
  • Page 221 Signaling Server as a Standalone Signaling Server - NRS. Figure 96 Application configuration CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please select the application configuration for this Signaling Server. Please enter: <CR>...
  • Page 222 Page 222 of 466 Installing a Signaling Server Figure 97 Standalone Signaling Server - NRS CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please select the Network Routing Service (NRS) configuration for this Signaling Server. Please enter: <CR> -> <a> - H.323 Gatekeeper and SIP Redirect/Proxy Server.
  • Page 223 (Figure 100) or the Stand-alone Signaling Server configuration screen (Figure 101) appears. Figure 99 Leader Signaling Server configuration CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please enter the data networking and IP Telephony parameters for this Leader Signaling Server.
  • Page 224 Page 224 of 466 Installing a Signaling Server Figure 101 Stand-alone Signaling Server configuration CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please define the data networking parameters for this Standalone Signaling Server. Note that the ELAN parameters are necessary for management access (e.g.
  • Page 225 Installing a Signaling Server Page 225 of 466 Figure 102 IP Telephony parameter configuration • Proceed to step 16 on page 213. • If this is a stand-alone Signaling Server and not associated with a Call Server (that is, b was selected in step 11 on page 206), enter the TLAN subnet parameters as required.
  • Page 226 103), the Alternate NRS IP address screen (Figure 104), or both in succession (for a Stand-alone Signaling Server) appear. Figure 103 Primary NRS IP address CS 1000 Signaling Server Software Install Tool (sse-x.xx.xx) ===================================================================== Please enter the Primary NRS IP Address: Primary NRS IP...
  • Page 227 Installing a Signaling Server Page 227 of 466 — If you did enter the address of the Primary NRS, enter the address of the Alternate NRS (also optional). The Gatekeeper configuration can be updated later using Element Manager. The IP telephony parameter configuration screen appears (Figure 105).
  • Page 228 Page 228 of 466 Installing a Signaling Server 12 Press <CR> or enter y to confirm all parameters entered, n to re-enter all parameters, or a letter a through l to change the value of the corresponding system parameter. The configuration screens for a Follower and Standalone Signaling Server - NRS are similar, showing the same list of parameters, specifically: •...
  • Page 229 Installing a Signaling Server Page 229 of 466 Figure 106 Install tool 13 Enter q to quit the Install Tool. Confirm to reboot the system. The Installation Tool quit confirmation screen appears (Figure 107). Communication Server 1000E Installation and Commissioning...
  • Page 230 Page 230 of 466 Installing a Signaling Server Figure 107 Installation Tool quit confirmation 14 Enter q to close/terminate the Installation Tool and reboot the Signaling Server. End of Procedure Adding a follower Signaling Server After configuration and reboot, a Follower Signaling Server sends out BOOTP requests and waits for a response.
  • Page 231 Installing a Signaling Server Page 231 of 466 Procedure 45 Adding a Follower Signaling Server to an IP Telephony node Note: The first time the Follower Signaling Server is installed, it cannot obtain the system login and password, and does not have the current CONFIG.INI file with the Call Server IP address, therefore the FTP fails.
  • Page 232 Page 232 of 466 Installing a Signaling Server Figure 108 Node Configuration web page Click Edit next to the node to which the Follower Signaling Server is to be added. The Edit web page opens, as shown in Figure 109. NN43041-310 Standard 01.11 October 2008...
  • Page 233 Installing a Signaling Server Page 233 of 466 Figure 109 Edit web page Click Add next to Signaling Servers.The section expands to show a list of Signaling Servers and a blank template for entering Signaling Server xxx.xxx.xxx.xxx properties, as shown in Figure 110. Communication Server 1000E Installation and Commissioning...
  • Page 234 Page 234 of 466 Installing a Signaling Server Figure 110 Signaling Server properties template Enter the information corresponding to the Follower Signaling Server. The Role field will automatically revert to Follower once the Follower Signaling Server has been added. NN43041-310 Standard 01.11 October 2008...

  • Page 235: Unpacking Help Files For Virtual Terminal Emulator

    Signaling Server software is installed. To unpack the files, refer to Signaling Server: Installation and Commissioning (NN43001-312). IMPORTANT! Unpacking the Help files takes approximately 20 to 30 minutes. Nortel recommends that you unpack the files during a service outage. Refer to Element Manager: System Administration (NN43001-632) for more information on Element Manager and the Virtual Terminal Emulator.
  • Page 236 Page 236 of 466 Installing a Signaling Server Procedure 46 Logging in to the Signaling Server Before you begin, make sure the DTE–DTE null modem cable (supplied with the Signaling Server) runs between the serial port on the back of the Signaling Server and the maintenance terminal.

  • Page 237: Verifying A Successful Configuration

    Installing a Signaling Server Page 237 of 466 Verifying a successful configuration To ensure that the Signaling Server Ethernet connections (for the ELAN and TLAN subnets) are configured correctly, perform a ping test to one or more of the other devices connected to the network, particularly the Call Server. Procedure 47 Verifying the Signaling Server Ethernet connection Log in to the Signaling Server, using Procedure 46 on...
  • Page 238 Page 238 of 466 Installing a Signaling Server NN43041-310 Standard 01.11 October 2008...

  • Page 239: Configuring The Ipmg

    Page 239 of 466 Configuring the IPMG Contents This section contains information on the following topics: Configuring the IPMG in Element Manager..... Configuring conference TDS .
  • Page 240 Page 240 of 466 Configuring the IPMG Procedure 48 Configuring the IPMG (Element Manager) In Element Manager, select IP Network > Media Gateways. Select the appropriate Superloop Number and Shelf. Click Add. Figure 111 Add IPMG The preceding screen appears (see Figure 111). Enter the IP address, zone number, and the Media Gateway type (in this case, a Media Gateway Controller).
  • Page 241 Configuring the IPMG Page 241 of 466 Figure 112 IPMG MGC configuration Once configuration of the MGC is complete, click Add. The following screen appears (see Figure 113 on page 242): The Media Gateways screen lists the superloop and shelf numbers, IP address, zone, and type of the recently configured MGC.
  • Page 242 Page 242 of 466 Configuring the IPMG Figure 113 Media Gateways The following screen appears (see Figure 114): In this screen, select the number of required channels, the Terminal Number (the superloop and shelf numbers of the MGC, the card number, and the unit).

  • Page 243: Configuring Conference Tds

    Configuring the IPMG Page 243 of 466 The following screen appears (Figure 115): The MGC has been added to the list. Figure 115 VGW Channels - IPMG End of Procedure Configuring conference TDS Procedure 49 on page 244 describes how to configure conference TDS for an IPMG using the CLI.

  • Page 244: Configure Conference Tds (Cli)

    Page 244 of 466 Configuring the IPMG Procedure 49 Configure conference TDS (CLI) Enter LD 17. >LD 17 CFN000 MEM AVAIL: (U/P): 99278047 USED U P: 4965412 26361 TOT: 104269820 DISK SPACE NEEDED: 20 KBYTES AVAIL: USED: TOT: AVAIL: USED: TOT: TYPE cequ7 MPED...

  • Page 245: Configuring Conference Tds (Element Manager)

    Configuring the IPMG Page 245 of 466 Procedure 50 describes how to configure conference TDS for IPMG using Element Manager. Procedure 50 Configuring conference TDS (Element Manager) In the Element Manager screen, select IP Network > Nodes: Media Gateways. The Media Gateway Configuration page appears. Select the IPMG superloop (see Figure 116).
  • Page 246 Page 246 of 466 Configuring the IPMG Figure 117 Loop configuration The TDS loop configuration page appears (see Figure 118). Enter the TDS loop number (0 – 255). Figure 118 TDS Loop configuration NN43041-310 Standard 01.11 October 2008...
  • Page 247 Configuring the IPMG Page 247 of 466 Click Save. It does not become available until a loop number has been entered and TAB has been used to move the cursor. The following message box appears: Figure 119 Confirmation Click OK to complete the configuration. The updated loop configuration page appears (see Figure 120).

  • Page 248: Configuring Dsp Daughterboard Voice Gateway Channels

    Page 248 of 466 Configuring the IPMG Configuring DSP Daughterboard Voice gateway channels Procedure 51 describes how to configure DSP Daughterboard Voice gateway channels using the CLI. To configure DSP Daughterboard Voice gateway channels using Element Manager see Procedure 50 on page 245.
  • Page 249 Configuring the IPMG Page 249 of 466 ZONE 004 End of Procedure Communication Server 1000E Installation and Commissioning...
  • Page 250 Page 250 of 466 Configuring the IPMG NN43041-310 Standard 01.11 October 2008...

  • Page 251: Connecting An Ir-8020M-101

    Page 251 of 466 Connecting an IR-8020M-101 Terminal Server Contents This section contains information on the following topics: Introduction ..........Configuring a Terminal Server .
  • Page 252 Page 252 of 466 Connecting an IR-8020M-101 Terminal Server information on connecting the MRV LX8020S-102AC-R, see “Connecting an MRV LX8020S-102AC-R Terminal Server” on page 265. As the Terminal Server is configured to automatically log in to the active Call Server upon start-up, only one Terminal Server is required for the system. It can be located anywhere on the LAN.

  • Page 253: Configuring A Terminal Server

    Connecting an IR-8020M-101 Terminal Server Page 253 of 466 This chapter contains the following procedures: • Procedure 52: "Connecting a Terminal Server to the system" page 254 • Procedure 53: "Configure IP address for the Terminal Server" page 255 • Procedure 54: "Run telnet from PC"...

  • Page 254: Connecting A Terminal Server To The System

    Page 254 of 466 Connecting an IR-8020M-101 Terminal Server Customer-made cables with the following pin out (as NTDU6302) can also be used. See Table 17. Table 17 Customer made cable pin out Pins on DB9 Female Pins on RJ45 Male (MRV Terminal Server) DSR/DCD S GND TxD GND...

  • Page 255: Configure Ip Address For The Terminal Server

    Connecting an IR-8020M-101 Terminal Server Page 255 of 466 Configure HyperTerminal to communicate with the Terminal Server’s management port: Set baud rate to 9600. Set data bits to 8. Set parity to none. Set stop bit to 1. Set flow control to “None”. Set Terminal Emulation to VT100.

  • Page 256: Telnet Terminal Server Virtual Management Port

    Page 256 of 466 Connecting an IR-8020M-101 Terminal Server Configure the Terminal Server’s IP primary gateway address. Enter: define server ip primary gateway address [ip address] Check Terminal Server configuration. Enter: list server ip Example commands: define server ip address 172.16.3.50 define server ip subnet mask 255.255.255.0 define server ip primary gateway address 172.16.3.1 End of Procedure...

  • Page 257: Telnet Cs 1000E Com Port From A Pc

    Connecting an IR-8020M-101 Terminal Server Page 257 of 466 Telnet CS 1000E COM port from a PC Connect port xx (xx = 1 - 19) of the Terminal Server to COM1 port of the CS 1000E Call Server. Follow Procedure 55 to establish access to a Call Server from a PC through telnet Terminal Server.

  • Page 258: Configuring A Transparent Rlogin Port

    Page 258 of 466 Connecting an IR-8020M-101 Terminal Server Enter the Input telnet command. Enter the command: TELNET xxx.xx.x.xx xxxx Where: xxx.xx.x.xx = Terminal Server IP Address xxxx = telnet port (for port 1 to 19) Note: The value of the target telnet port, xxxx, is determined using the following formula: TELNET PORT = 2 000 + (port number ×...
  • Page 259 Connecting an IR-8020M-101 Terminal Server Page 259 of 466 Where: xx = port number Enable a dedicated service using rlogin. Enter the command: DEFINE PORT XX RLOGIN DEDICATED SERVICE xx.xx.xx.xx Where: xx = port number xx.xx.xx.xx = port IP address Enable the port to be accessible only by local command and from a serial connection only.
  • Page 260 Page 260 of 466 Connecting an IR-8020M-101 Terminal Server Enable autoconnect for the port. Enter the command: DEFINE PORT xx AUTOCONNECT ENABLED Where: xx = port number Enable autodedicate for the port. Enter the command: DEFINE PORT xx AUTODEDICATED ENABLED Where: xx = port number Define a user name for the port.

  • Page 261: Configuring A Transparent Rlogin Port

    Connecting an IR-8020M-101 Terminal Server Page 261 of 466 Check port configuration. Enter the command: LIST PORT xx LIST PORT xx ALTERNATE CHARA Where: xx = port number End of Procedure Configuring a transparent rlogin port with sample data Sample data has been incorporated into Procedure 57. This configuration shows that a device connected to MRV Port 2 will rlogin 47.11.166.76 through pty 10.

  • Page 262: Accessing An Mrv Console Port Through The On-Board Modem

    Page 262 of 466 Connecting an IR-8020M-101 Terminal Server Define a user name for the port. Enter the command: DEFINE PORT 2 USERNAME “pty7” Note: When typing the letters “pty”, they must be lower case letters. The number must equal the pty number configured on the system. Log out of the port.

  • Page 263: Cs 1000E Com Port Types

    Connecting an IR-8020M-101 Terminal Server Page 263 of 466 CS 1000E COM port types Table 19 lists various components of the CS 1000E system and their COM port types. Table 19 System components and COM port type System component COM port type Baystack 460 9-pin DCE (male) Baystack 470...
  • Page 264 Page 264 of 466 Connecting an IR-8020M-101 Terminal Server NN43041-310 Standard 01.11 October 2008...

  • Page 265: Connecting An Mrv Lx8020S-102Ac-R Terminal

    Page 265 of 466 Connecting an MRV LX8020S-102AC-R Terminal Server Contents This section contains information on the following topics: Introduction ..........Configuring a Terminal Server .
  • Page 266 Page 266 of 466 Connecting an MRV LX8020S-102AC-R Terminal Server For information on connecting the IR-8020M-101, see “Connecting an IR-8020M-101 Terminal Server” on page 251. Differences between the two Terminal Servers include: • The IR-8020M-101 Management port is port 20. The LX8020S-102AC-R contains a Diag Port at the front.
  • Page 267 Connecting an MRV LX8020S-102AC-R Terminal Server Page 267 of 466 mask address and gateway address. The 20 Ports at the rear can be configured for Serial Data Interface for CS 1000E system components. IMPORTANT! Before connecting the Terminal Server to another component of the CS 1000E system, read and understand the documentation provided by the Terminal Server’s manufacturer including the Quick Start Guide for MRV server, LX Series Configuration Guide and MRV LX Series...

  • Page 268: Configuring A Terminal Server

    Page 268 of 466 Connecting an MRV LX8020S-102AC-R Terminal Server Configuring a Terminal Server Follow Procedure 59 to connect a Terminal Server with a CS 1000E system. Table 20 lists the MRV cables required to install the LX8020S-102AC-R Terminal Server in a CS 1000E system. Table 20 Required MRV serial cables and connectors Order Code...

  • Page 269: Connecting A Terminal Server To The System

    Connecting an MRV LX8020S-102AC-R Terminal Server Page 269 of 466 Table 21 Customer made cable pin out (same as NTDU6302) Pins on DB9 Female Pins on RJ-45 Male (MRV Terminal Server) Procedure 59 Connecting a Terminal Server to the system Connect the above mentioned MRV serial cable from the Terminal Server Diag port at the front of the Terminal Server to the PC COM port.

  • Page 270: Configure Ip Address For The Terminal Server

    Page 270 of 466 Connecting an MRV LX8020S-102AC-R Terminal Server System End of Procedure Configuring the Terminal Server IP address Procedure 60 Configure IP address for the Terminal Server Note: The IP address can be configured or changed only from the local Management/ DIAG port.

  • Page 271: Telnet Terminal Server Virtual Management Port

    Connecting an MRV LX8020S-102AC-R Terminal Server Page 271 of 466 Telnet Terminal Server virtual management port Connect the Terminal Server ethernet port to the ELAN subnet using a CAT5 ethernet cable. The virtual management port 0 is accessible from an online PC using a telnet session.

  • Page 272: Accessing A Cs 1000E From A Pc Through Telnet Terminal Server

    Page 272 of 466 Connecting an MRV LX8020S-102AC-R Terminal Server Follow Procedure 62 to establish access to a Call Server from a PC through telnet Terminal Server. Use the same port number for each procedure step. Procedure 62 Accessing a CS 1000E from a PC through telnet Terminal Server Connect to the management port or virtual management port as shown in Procedure 61 on page 271...

  • Page 273: Configuring An Rlogin Port For Various Applications

    Connecting an MRV LX8020S-102AC-R Terminal Server Page 273 of 466 xxx.xx.x.xx = Terminal Server IP Address xxxx = telnet port (for port 1 to 20) Note: The value of the target telnet port, xxxx, is determined using the following formula: TELNET PORT = 2 000 + (port number xx ×...
  • Page 274 Page 274 of 466 Connecting an MRV LX8020S-102AC-R Terminal Server Connect to the management port or virtual management port At the InReach: 0>> prompt, type shell. The shell window opens. InReach: 0 >>shell BusyBox v1.1.3 (2006.10.20-12:27+0000) Built-in shell (ash) It will then go to the LX prompt as shown below. Type the below command to start editing.
  • Page 275 Connecting an MRV LX8020S-102AC-R Terminal Server Page 275 of 466 InReach:0>>configure rlogin enable. Configure the rlogin port for various applications. InReach: 0>> config port async xx connect command rlogin -l user_name host_ip_address InReach: 0 >>config port async 1 connect command rlogin -l pty8 47.11.244.101 Here PTY8 is the user name.It is the port no.

  • Page 276: Accessing An Mrv Console Port Through The On-Board Modem

    Page 276 of 466 Connecting an MRV LX8020S-102AC-R Terminal Server Note 1: It is not advisable to use putty software while trying to do rlogin Note 2: MRV definition of autoconnect: In Procedure 62 on page 272 and Procedure 63 on page 273 this feature of autoconnect is required.

  • Page 277: Cs 1000E Com Port Types

    Connecting an MRV LX8020S-102AC-R Terminal Server Page 277 of 466 Login Log in to the LX-series Element Manager using the default password, (see steps 4,5,6,and 7 in Procedure 59 on page 269). Once logged into the onboard modem, it is possible to telnet to ports 1-20.It is also possible to rlogin to different IPs.
  • Page 278 Page 278 of 466 Connecting an MRV LX8020S-102AC-R Terminal Server Table 22 System components and COM port type (Part 2 of 2) System component COM port type P0609205 MIRAN L-adapter 9-pin DTE (male) NTDU14 Gateway 9-pin DTE (male) (modified to isolate pins 6, 7, and 8) Use PORT 0 of NTBK48AA 3-port SDI cable.

  • Page 279: Configuring A Terminal And Sdi Ports

    Page 279 of 466 Configuring a terminal and SDI ports Contents This section contains information on the following topics: Introduction ..........Setting the TTY terminal port .

  • Page 280: Setting The Tty Terminal Port

    Page 280 of 466 Configuring a terminal and SDI ports Setting the TTY terminal port A TTY terminal can be any standard PC running terminal software, (for example, HyperTerminal). The TTY terminal port must be configured as: • Bits per second - Baud rate must be the same as the speed of SDI port. •...

  • Page 281: Cs 1000E Cp Pm Call Server Com Port Connections

    Configuring a terminal and SDI ports Page 281 of 466 Figure 121 VT220 setup values Global Set-Up On Line Comm1=RS232 Sessions on Comm1 70Hz CRT Saver Printer Shared Display Set-Up 80 Columns Light Text, Dark Screen Interpret Controls Cursor Auto Wrap Block Style Cursor Jump Scroll General Set-up...

  • Page 282: Mg 1000E Sdi Connection

    Page 282 of 466 Configuring a terminal and SDI ports • Parity - none • Flow control - none The baudrate setting can be changed in Overlay 17, however changing this setting is not recommended since it will only used when SL1 is loaded. Note that only the Port 0 serial port displays the boot sequence from BIOS, Bootrom &...
  • Page 283 Configuring a terminal and SDI ports Page 283 of 466 SDI2 is not available during the MGC bootup, it cannot be used to access the installation menus. All of the SDI ports on the MGC are configured via software. There are no DIP switches on the MGC for configuring the baud rate of SDI0.

  • Page 284: Connecting Sdi Ports On The Media Gateways

    Page 284 of 466 Configuring a terminal and SDI ports Procedure 65 Connecting SDI ports on the Media Gateways Connect the NTBK48 3-port SDI cable to the 9-pin SDI port (RS-232) at the rear of the Media Gateways (see Figure 122). Figure 122 SDI port access to the Media Gateway SSC card port...

  • Page 285: Baystack 470 Sdi Connection

    Configuring a terminal and SDI ports Page 285 of 466 BayStack 470 SDI connection The SDI port on the Bay Stack 470 can be used for basic configuration and maintenance. The SDI port is located on the faceplate. It is a DCE port with a default speed of 9600 bps.
  • Page 286 Page 286 of 466 Configuring a terminal and SDI ports to Serial/ELAN/TLAN adapter provides an alternative to the faceplate maintenance port. Both are DTE ports with a speed of 9600 bit/s. CAUTION — Service Interruption Do not connect maintenance terminals or modems to the faceplate and I/O panel DB-9 male serial maintenance port at the same time.

  • Page 287: Introduction

    Page 287 of 466 Installing and cross-connecting a trunk card Contents This section contains information on the following topics: Introduction ..........Circuit card options .
  • Page 288 Page 288 of 466 Installing and cross-connecting a trunk card IMPORTANT! Digital Trunk cards can be installed only in slots 1 to 4 of the Media Gateway. Figure 124 shows the circuit card slots in a Media Gateway. To view the circuit card slots available in a Media Gateway Expander, see Figure 125 on page 289.
  • Page 289 Installing and cross-connecting a trunk card Page 289 of 466 Figure 125 Circuit card assignments in the Media Gateway Expander Slot 10 Slot 9 Slot 8 Slot 7 553-CSE9032 WARNING Use caution when installing or modifying telephone lines. Avoid installing telephone wiring during a lightning storm. Do not install telephone jacks in wet locations unless the jacks are designed for wet locations.
  • Page 290 Page 290 of 466 Installing and cross-connecting a trunk card Before you proceed, install the cable from the slot that contains the Line card associated with the telephone being connected. Refer to “Installing the Main Distribution Frame” on page 349, if you require additional cable installation. DANGER OF ELECTRIC SHOCK Always use caution when installing or modifying telephone lines.

  • Page 291: Circuit Card Options

    Installing and cross-connecting a trunk card Page 291 of 466 Figure 126 Antistatic wrist strap Antistatic wrist strap Circuit card options A circuit card that has a switch symbol on its faceplate is equipped with option switches, strapping plugs, or both. Ensure that the option switches or strapping plugs are set correctly.

  • Page 292: Connecting A Trunk

    Page 292 of 466 Installing and cross-connecting a trunk card • NTRB21 TMDI 1.5 Mbit DTI/PRI • NT6D70 SILC • NT6D71 UILC Note: Now NT6D70 SILC and NT6D71 UILC Digital trunk cards can be installed in slots 7 to 10 in a Media Gateway Expander. For additional information about installing Digital trunk cards, refer to the following documents: •...

  • Page 293: Universal Trunk Card Connections

    Installing and cross-connecting a trunk card Page 293 of 466 Note: See “Installing and cross-connecting a Power Fail Transfer Unit” page 437 for connecting trunks with the PFTU. End of Procedure Universal Trunk card connections The Universal Trunk card (NT8D14) provides eight Analog trunks that can function in the modes identified in Table 24.
  • Page 294 Page 294 of 466 Installing and cross-connecting a trunk card Table 25 NT8D14 Universal Trunk connections (Part 1 of 2) Paging All other Cable from equipment Unit mode mode modes Pair Color Designations W-BL BL-W W-BR BR-W R-BL BL-R R-BR BR-R BK-BL BL-BK...
  • Page 295 Installing and cross-connecting a trunk card Page 295 of 466 Table 25 NT8D14 Universal Trunk connections (Part 2 of 2) Paging All other Cable from equipment Unit mode mode modes Pair Color Designations BK-G G-BK BK-BR BR-BK BK-S S-BK Y-BL BL-Y Note: Remaining pairs are spare.

  • Page 296: E&M Trunk Card Connections

    Page 296 of 466 Installing and cross-connecting a trunk card E&M Trunk card connections Table 26 lists the connections required by the E&M Trunk card (NT8D15). Table 26 NT8D15 E&M Trunk card (Part 1 of 2) Cables Card 1 through Card 10 from Paging Type 1...
  • Page 297 Installing and cross-connecting a trunk card Page 297 of 466 Table 26 NT8D15 E&M Trunk card (Part 2 of 2) Cables Card 1 through Card 10 from Paging Type 1 Type 1 Type 2 equipment Unit mode mode mode mode Pair Color Designations...

  • Page 298: Trunk Connections (Europe)

    Page 298 of 466 Installing and cross-connecting a trunk card Trunk connections (Europe) Trunk connections for Europe are provided in the following tables: • Table 27: “E&M TIE trunk card (2-Wire)” on page 298 • Table 28: “E&M 2-wire Type 2” on page 299 •...
  • Page 299 Installing and cross-connecting a trunk card Page 299 of 466 Table 27 E&M TIE trunk card (2-Wire) (Part 2 of 2) Column 3 Cables Card 1 through Card 10 Column 1 Column 2 Type 5 from equipment Paging Paging (BPO) BK-O SIGB O-BK...
  • Page 300 Page 300 of 466 Installing and cross-connecting a trunk card Table 28 E&M 2-wire Type 2 (Part 2 of 2) BK-BL BL-BK BK-O O-BK BK-BR BR-BK BK-S S-BK Y-BL BL-Y Table 29 E&M TIE Trunk card (4-Wire) (Part 1 of 2) Cables Card 1 through Column 1 Column 2...
  • Page 301 Installing and cross-connecting a trunk card Page 301 of 466 Table 29 E&M TIE Trunk card (4-Wire) (Part 2 of 2) Cables Card 1 through Column 1 Column 2 Card 10 from equipment Type 1 & 5 Type 1 & 5 R-BL BL-R R-BR...
  • Page 302 Page 302 of 466 Installing and cross-connecting a trunk card Table 30 E&M TIE Trunk card (Part 1 of 2) Cables Card 1 through Column 1 Column 2 Card 10 from equipment Type 2 Type 2 Unit Pair Color Pins Lead Designations W-BL BL-W...
  • Page 303 Installing and cross-connecting a trunk card Page 303 of 466 Table 30 E&M TIE Trunk card (Part 2 of 2) Cables Card 1 through Column 1 Column 2 Card 10 from equipment Type 2 Type 2 BK-G G-BK BK-BR BR-BK BK-S S-BK Y-BL...
  • Page 304 Page 304 of 466 Installing and cross-connecting a trunk card Table 31 E&M 2280 Hz TIE Trunk connections (Part 2 of 2) R-BR BR-R BK-G G-BK BK-BR BR-BK Table 32 E&M 2-wire Recorded Announcement Trunk connections Lead designations Pins Pair color Unit number W-BL BL-W...
  • Page 305 Installing and cross-connecting a trunk card Page 305 of 466 Table 33 E&M 2-wire Music Trunk connections Lead designations Pins Pair color Unit number W-BL BL-W R-BR BR-R BK-G G-BK Table 34 Central Office & Direct Dial Inward Trunk connections (Part 1 of 2) Cable from equipment Column 1...
  • Page 306 Page 306 of 466 Installing and cross-connecting a trunk card Table 34 Central Office & Direct Dial Inward Trunk connections (Part 2 of 2) Cable from equipment Column 1 Column 2 Column 3 Pair Color Unit Pins Lead designations PPM3 —...
  • Page 307 Installing and cross-connecting a trunk card Page 307 of 466 Table 35 Central Office Trunk connections (Part 1 of 2) Cable from equipment Pair Color Unit Pins Lead designations W-BL BL-W W-BR BR-W R-BL BL-R R-BR BR-R BK-BL BL-BK BK-O O-BK Communication Server 1000E Installation and Commissioning...

  • Page 308: Trunk Connections (Uk)

    Page 308 of 466 Installing and cross-connecting a trunk card Table 35 Central Office Trunk connections (Part 2 of 2) Cable from equipment Pair Color Unit Pins Lead designations BK-G G-BK BK-BR BR-BK BK-S S-BK Y-BL BL-Y Trunk connections (UK) Trunk connections for the UK are provided in the following tables: •...
  • Page 309 Installing and cross-connecting a trunk card Page 309 of 466 Table 36 NT5K17 Direct Inward Dial card terminations (Part 1 of 2) Pair Pins Pair color Unit W-BL BL-W W-BR BR-W R-BL BL-R R-BR BR-R BK-BL BL-BK BK-O O-BK BK-G G-BK Communication Server 1000E Installation and Commissioning...
  • Page 310 Page 310 of 466 Installing and cross-connecting a trunk card Table 36 NT5K17 Direct Inward Dial card terminations (Part 2 of 2) Pair Pins Pair color Unit BK-BR BR-BK BK-S S-BK Y-BL BL-Y Note: The connections on the NT5K18 Exchange Line Trunk card are polarity-sensitive.
  • Page 311 Installing and cross-connecting a trunk card Page 311 of 466 Table 37 NT5K18 Exchange line trunk card cross-connect terminations (Part 2 of 2) Pair Pins Pair color Unit R-BR BR-R BK-BL BL-BK BK-O O-BK BK-G G-BK BK-BR BR-BK BK-S S-BK Y-BL BL-Y Communication Server 1000E...
  • Page 312 Page 312 of 466 Installing and cross-connecting a trunk card Note: The speech pairs on the NT5K19 card are polarity-insensitive. The E&M signaling pairs, however, are polarity-sensitive. Make sure the ground side of the trunk is connected to the A leg of the NT5K19 circuit. Make sure the -50 Volt side of the trunk is connected to the B leg.
  • Page 313 Installing and cross-connecting a trunk card Page 313 of 466 Table 39 NT5K19 2W Type 1 mode terminations (Part 2 of 2) Pair Pins Pair color Unit R-BL BL-R & BK-BL BL-BK BK-BR BR-BK BK-S S-BK Communication Server 1000E Installation and Commissioning...
  • Page 314 Page 314 of 466 Installing and cross-connecting a trunk card Table 40 NT5K19 4W Type 1 mode terminations Pair Pins Pair color Unit W-BL BL-W R-BL BL-R R-BR BR-R BK-BL BL-BK BK-G G-BK BK-BR BR-BK BK-S S-BK NN43041-310 Standard 01.11 October 2008...
  • Page 315 Installing and cross-connecting a trunk card Page 315 of 466 Table 41 NT5K19 AC15 mode pair terminations Pair Pins Pair color Unit W-BL BL-W R-BL BL-R R-BR BR-R BK-G G-BK BK-BR BR-BK Communication Server 1000E Installation and Commissioning...

  • Page 316: Verifying Trunk Functionality

    Page 316 of 466 Installing and cross-connecting a trunk card Table 42 NT5K19 Recorded Announcement mode pair terminations Pair Pins Pair color Unit W-BL BL-W SIG B W-BR SIG A BR-W SIG B SIG A R-BR BR-R SIG B BK-O SIG A O-BK BK-G...

  • Page 317: Voice Gateway Media Card

    Page 317 of 466 Installing and configuring a Voice Gateway Media Card Contents This section contains information on the following topics: Introduction ..........Configuring a card.

  • Page 318: Introduction

    Page 318 of 466 Installing and configuring a Voice Gateway Media Card Introduction The Voice Gateway Media Card provides access to the voice gateway and functions as a Follower to the Signaling Server, which is the node Leader and which, by default, acts as a Master for the node. In the absence of the Signaling Server a Voice Gateway Media Card may be an active Leader, a backup Leader, or a Follower.

  • Page 319: Configuring A Card

    Installing and configuring a Voice Gateway Media Card Page 319 of 466 • Procedure 74: "Displaying the status of Voice Gateway Media Card units" on page 341 • Procedure 75: "Displaying the status of one unit on a Voice Gateway Media Card"...
  • Page 320 Page 320 of 466 Installing and configuring a Voice Gateway Media Card Figure 127 Node Configuration web page Click Edit next to the Node to which the Voice Gateway Media Card is to be added. The Edit web page opens, as shown in Figure 128 on page 321.
  • Page 321 Installing and configuring a Voice Gateway Media Card Page 321 of 466 Figure 128 Edit web page Click Add next to the Cards tab. The Cards tab expands (see Figure 129 on page 322). Enter your data for this Voice Gateway Media Card. The ELAN MAC address is on a faceplate sticker.

  • Page 322: Configuring A Card As A Node Leader

    Page 322 of 466 Installing and configuring a Voice Gateway Media Card Figure 129 Cards Save the node. Click Save and Transfer at the bottom of the Edit web page Click OK to save this node. End of Procedure Configuring a card as a node Leader A Voice Gateway Media Card remains at the default “Follower”...

  • Page 323: Configuring Voice Gateway Channels Using Element Manager

    Installing and configuring a Voice Gateway Media Card Page 323 of 466 Description, Installation, and Operation (NN43100-500) for a detailed configuration procedure. Configuring voice gateway channels using Element Manager The voice gateway channels are also called “DSP channels” or the card’s “physical TNs”.
  • Page 324 Page 324 of 466 Installing and configuring a Voice Gateway Media Card The Add VGW channels web page opens, as shown in Figure 131. Figure 131 Add VGW channels Enter the appropriate parameters to configure the VGW channels. The TN is the logical TN of the first Voice Gateway Media Card unit. Note: The Media Card has 8 or 32 channels.

  • Page 325: Configuring Voice Gateway Channels Using Ld 14

    Installing and configuring a Voice Gateway Media Card Page 325 of 466 Figure 132 VGW channels list End of Procedure Configuring voice gateway channels using LD 14 The voice gateway channels are also called “DSP channels” or the card’s “physical TNs.” Follow Procedure 69 on page 326 to configure the voice gateway channels using LD 14.

  • Page 326: Configuring Voice Gateway Channels Using Ld 14

    Page 326 of 466 Installing and configuring a Voice Gateway Media Card Procedure 69 Configuring voice gateway channels using LD 14 Log in to the CS 1000E. Enter the command: LOGI System response: PASS? Enter the default password: 0000 Access LD 14. Enter the command: LD 14 Enter responses shown in Table 43.

  • Page 327: Saving Configuration Changes

    Installing and configuring a Voice Gateway Media Card Page 327 of 466 Table 43 LD 14 – Configure physical TNs (Part 2 of 2) Prompt Response Description MAXU 32 is the maximum number of voice Media Gateway channels on the Media Card. 24 is the maximum number of voice Media Gateway channels on the ITG-P Line card.

  • Page 328: Installing A Compactflash

    Page 328 of 466 Installing and configuring a Voice Gateway Media Card Installing a CompactFlash The Voice Gateway Media Card requires a CompactFlash card to operate. The CompactFlash card contains the IP Line 3.1 software. CAUTION WITH ESDS DEVICES Wear an antistatic device to avoid damage to the Voice Gateway Media Card.
  • Page 329 Installing and configuring a Voice Gateway Media Card Page 329 of 466 Figure 133 CompactFlash card location CompactFlash card Figure 134 shows the CompactFlash card and Retaining Pin. Figure 134 CompactFlash card and Retaining Pin Communication Server 1000E Installation and Commissioning...

  • Page 330: Installing The Compactflash

    Page 330 of 466 Installing and configuring a Voice Gateway Media Card Procedure 70 Installing the CompactFlash Remove the Media Card, CompactFlash card, and Retaining Pin from the packaging. Locate the CompactFlash socket in the lower left-hand corner of the Voice Gateway Media Card (see Figure 135).
  • Page 331 Installing and configuring a Voice Gateway Media Card Page 331 of 466 Insert the CompactFlash card in the socket. Press firmly until it is fully seated and the Eject button extends (see Figure 137). Figure 137 Insert CompactFlash to extend Eject button Eject button Turn the Voice Gateway Media Card over to view the back of the card.
  • Page 332 Page 332 of 466 Installing and configuring a Voice Gateway Media Card Press the Retaining Pin into the hole until the pin clicks as it locks into position (labeled 2 in Figure 139). The underside of the head of the Retaining Pin should be flat against the card.

  • Page 333: Installing A Card In A Media Gateway

    Installing and configuring a Voice Gateway Media Card Page 333 of 466 Installing a card in a Media Gateway A Voice Gateway Media Card can be installed in a Media Gateway or a Media Gateway Expander slot. See Figure 141 on page 333 and Figure 142 page 334...
  • Page 334 Media Gateway Expander card slot location Slot 10 Slot 9 Slot 8 Slot 7 553-CSE9032 Table 44 on page 335 shows the TN assignments for the MG 1000E. Communication Server 1000 Release 5.0 supports up to 30 MG 1000E. NN43041-310 Standard 01.11 October 2008...

  • Page 335: Installing A Voice Gateway Media Card In A Card Slot

    Installing and configuring a Voice Gateway Media Card Page 335 of 466 Table 44 TN assignments for MG 1000E MG 1000E MG 1000E Expander Slots l s c l s c l s c l s c l s c l s c l s c l s c...

  • Page 336: Verifying A Card

    Page 336 of 466 Installing and configuring a Voice Gateway Media Card Hook the locking devices. Note: The Voice Gateway Media Card boots automatically. If the Voice Gateway Media Card is a Follower, then it retrieves the node configuration files from the IP telephony node Leader. If it is a Leader, then you must configure it.
  • Page 337 Installing and configuring a Voice Gateway Media Card Page 337 of 466 Figure 143 Node Maintenance and Reports web page Open the desired node by clicking on the + next to the Node ID. This displays the Signaling Servers and Voice Gateway Media Cards belonging to the node, as shown in Figure 144 on page 337.

  • Page 338: Displaying The Voice Gateway Status For All Voice Gateway Channels

    Page 338 of 466 Installing and configuring a Voice Gateway Media Card Where xx.xxx.xxx.xxx is the ELAN IP address of the Voice Gateway Media Card and the meaning of the status is: • Disabled – The card is configured but out-of-service. •...
  • Page 339 Installing and configuring a Voice Gateway Media Card Page 339 of 466 Figure 145 General Commands From the Group drop-down list, select Vgw. From the Command drop-down list, select vgwShowAll. Click RUN. Figure 146 on page 340 shows the General Commands web page with the output from the vgwShowAll command.
  • Page 340 Page 340 of 466 Installing and configuring a Voice Gateway Media Card Figure 146 vgwShowAll result The following information is provided for each VGW channel: • Chan – Channel number • ChanState – State of channel (Idle/Busy/Disabled/Unequipped) • DspMode – Mode DSP is in (Voice/Closed) •...

  • Page 341: Displaying The Status Of Voice Gateway Media Card Units

    Installing and configuring a Voice Gateway Media Card Page 341 of 466 Procedure 74 Displaying the status of Voice Gateway Media Card units Select System > Maintenance from the navigator. The Maintenance web page opens as shown in Figure 147. This page allows you to perform maintenance using overlays or using a selected functionality.
  • Page 342 Page 342 of 466 Installing and configuring a Voice Gateway Media Card Figure 148 Maintenance (by functionality) web page Select Network & Peripheral Equipment Diagnostics from the list in Figure 148. The Network and Peripheral Diagnostics web page opens, as shown in Figure 149 on page 343.
  • Page 343 Installing and configuring a Voice Gateway Media Card Page 343 of 466 Figure 149 Network & Peripheral Diagnostics web page Choose the STAT — Get card status command from the Card Commands drop-down list. Enter the card number in the corresponding Command Parameter text box.

  • Page 344: Disabling A Card

    Page 344 of 466 Installing and configuring a Voice Gateway Media Card Procedure 75 Displaying the status of one unit on a Voice Gateway Media Card Select System > Maintenance from the navigator. The Maintenance web page opens as shown in Figure 147 on page 341.

  • Page 345: Disabling A Card Unit

    Installing and configuring a Voice Gateway Media Card Page 345 of 466 The list in the web page changes to show a list of diagnostics you can use, as shown in Figure 148 on page 342. Select Network & Peripheral Equipment Diagnostics from the list in Figure 148 on page 342.

  • Page 346: Enabling A Card

    Page 346 of 466 Installing and configuring a Voice Gateway Media Card The Network and Peripheral Diagnostics web page opens, as shown in Figure 149 on page 343. Select the DISU – Disable unit command from the Unit Commands drop-down list. Enter the card number and unit number in the corresponding Command Parameter text box.

  • Page 347: Enabling A Card Unit

    Installing and configuring a Voice Gateway Media Card Page 347 of 466 The output from this command is shown in the text box in the lower half of the web page. End of Procedure Enabling a card unit Follow Procedure 79 to enable a Voice Gateway Media Card unit using Element Manager.

  • Page 348: Verifying Functionality

    Page 348 of 466 Installing and configuring a Voice Gateway Media Card Verifying functionality You can now use the Voice Gateway Media Card to transcode voice data between IP and TDM. To test the voice gateway channels (DSPs), perform a variety of analog or digital calls to IP Phones and vice-versa.

  • Page 349: Installing The Main Distribution Frame

    Page 349 of 466 Installing the Main Distribution Frame Contents This section contains information on the following topics: Introduction ..........Terminal block requirements .

  • Page 350: Terminal Block Requirements

    Page 350 of 466 Installing the Main Distribution Frame Terminal block requirements The cross-connect terminal requires enough connecting blocks to terminate up to four 25 pair cables for each Media Gateway and each Media Gateway Expander. When Ethernet connections are used instead of traditional cabling, the Media Card Input/Output adapter is used: •...
  • Page 351 Installing the Main Distribution Frame Page 351 of 466 Attach labels on the cross-connect terminal to indicate the terminal blocks assigned to the following: • 25-pair cables from the system • AUX wiring • PFTUs • Telephones and consoles • Trunks •...

  • Page 352: Installing A Krone Test Jack Frame For The Uk

    Page 352 of 466 Installing the Main Distribution Frame Installing a Krone Test Jack Frame for the UK The Krone Test Jack Frame provides terminating strips that hold ten pairs of cable. Generally, only eight of ten pairs are used. As a result, one 25-pair cable requires three terminating strips (8 pairs/strip x 3 strips = 24 pairs).
  • Page 353 Installing the Main Distribution Frame Page 353 of 466 Figure 151 25-pair cable on three Krone strips Pair Pin Number Wire Colour Krone Strip W-BL BL-W W-BR BR-W R-BL BL-R R-BR BR-R BK-BL BL-BK BK-O O-BK BK-G G-BK BK-BR BR-BK BK-S S-BK Y-BL...

  • Page 354: Installing The Krone Test Jack Frame (Uk)

    Page 354 of 466 Installing the Main Distribution Frame Procedure 81 describes how to install the Krone Test Jack Frame for the UK. For detailed information, refer to the Krone documentation. Procedure 81 Installing the Krone Test Jack Frame (UK) Refer to the equipment layout plan to determine where to place the cross-connect terminal.
  • Page 355 Installing the Main Distribution Frame Page 355 of 466 Figure 152 Typical Krone cross-connect terminal layout (UK) Pair Pair Spare PFTU termination Other AUX cable equipment Grounding block Card 10 Card 9 Media Gateway Expansion Card 8 Card 7 Card 4 Card 3 Media Gateway Card 2...

  • Page 356: Connecting The Cables To The Media Gateways

    Page 356 of 466 Installing the Main Distribution Frame Connecting the cables to the Media Gateways DANGER Always use caution when installing or modifying telephone lines. Do not install telephone wiring during a lightning storm. Never touch uninsulated telephone wiring unless the line is disconnected at the network interface.
  • Page 357 Installing the Main Distribution Frame Page 357 of 466 Figure 153 Cable connectors at the back of the Media Gateway 25-pair connectors Figure 154 Cable connectors at the back of the Media Gateway Expander 25-pair connectors Communication Server 1000E Installation and Commissioning...
  • Page 358 Page 358 of 466 Installing the Main Distribution Frame Tighten the velcro straps when you have connected each cable to the system. Terminate all the 25-pair cables installed at the cross-connect terminal. Label all the cables at the cross-connect terminal blocks according to the card slot assignment plan.
  • Page 359 Installing the Main Distribution Frame Page 359 of 466 When auxiliary power is required from the QUA6 PFTU, terminate the AUX cable at the PFTU cross-connect terminal, according to Table 45. Table 45 AUX cable termination information Color Wire number Designation Connection W-BL...
  • Page 360 Page 360 of 466 Installing the Main Distribution Frame NN43041-310 Standard 01.11 October 2008...

  • Page 361: Configuring An Ip Telephony Node

    A node has only one Leader Signaling Server. All other Signaling Servers and Voice Gateway Media Cards are defined as Followers. An IP Telephony node must be configured to make a CS 1000 system operational. For more information about IP Telephony nodes and their configuration, refer to IP Line: Description, Installation, and Operation (553-3001-365).

  • Page 362: Before You Begin

    Page 362 of 466 Configuring an IP telephony node The preconfigured IP telephony configuration files from the leader Signaling Server must be imported. These files are saved on the CS 1000E as: • c:/u/db/node/nodex.cfg where x is the node number •...

  • Page 363: Configuring Ms Internet Explorer

    Configuring an IP telephony node Page 363 of 466 Limited Access to Overlays, see Features and Services (NN43001-106) and Software Input/Output: Administration (NN43001-611). Configuring MS Internet Explorer Element Manager is available to configure IP telephony parameters on the system. It is accessed by pointing MS Internet Explorer (version 6.0.2600 or higher) to the ELAN subnet, TLAN subnet, or node IP address of the Signaling Server.
  • Page 364 Page 364 of 466 Configuring an IP telephony node Figure 156 Internet Explorer – Internet Options On the General tab, under the Temporary Internet files section, click Settings. The Settings window opens (see Figure 157 on page 365). NN43041-310 Standard 01.11 October 2008...
  • Page 365 Configuring an IP telephony node Page 365 of 466 Figure 157 Temporary Internet files – Settings window Click Every visit to the page. This checks for new versions of stored pages on every visit to the web page. Click OK in the Settings window. Click OK in the Internet Options window.
  • Page 366 Page 366 of 466 Configuring an IP telephony node Logging in to Element Manager Follow Procedure 84 to log in to Element Manager. Procedure 84 Logging in to Element Manager Open the web browser. Enter the Signaling Server Node IP address in the Address Bar of the browser window, and press Enter on the keyboard.
  • Page 367 Configuring an IP telephony node Page 367 of 466 Figure 158 Element Manager login End of Procedure Communication Server 1000E Installation and Commissioning...

  • Page 368: Importing Preconfigured Ip Telephony Files

    Page 368 of 466 Configuring an IP telephony node Importing preconfigured IP telephony files Follow Procedure 85 to import the preconfigured IP telephony files from the Signaling Server. Procedure 85 Importing an existing node Figure 159 displays the Element Manager System Information home page. Figure 159 Element Manager –...
  • Page 369 Configuring an IP telephony node Page 369 of 466 Select IP Network > Node: Servers, Media Cards from the navigator. The Node Configuration web page opens, as shown in Figure 160. If this is the first node to be added, the “No nodes are configured” message is displayed.

  • Page 370: Reviewing And Submitting Ip Telephony Node Configuration Files

    Page 370 of 466 Configuring an IP telephony node Figure 161 Import Node Files web page Click Import. Click OK in the dialog when the operation is complete. The Node Summary web page is re-displayed showing the new node. End of Procedure Reviewing and submitting IP telephony node configuration files Follow Procedure 86 to review and submit IP telephony node configuration...
  • Page 371 Configuring an IP telephony node Page 371 of 466 Note 1: Clicking Transfer / Status displays the Transfer / Status web page (see Figure 165 on page 373). This sends the node configuration files to all IP Telephony components in the node. •...
  • Page 372 Page 372 of 466 Configuring an IP telephony node Figure 162 Transfer Progress – Starting Figure 163 Transfer Progress – Transferring When the file transfer is complete, the Transfer Progress web page displays a status of complete (see Figure 164 on page 373).
  • Page 373 Configuring an IP telephony node Page 373 of 466 Figure 164 Transfer Progress – Complete Click OK in the dialog box. The Transfer / Status web page displays. Note: The Transfer / Status web page (see Figure 165) can also be displayed from the Node Summary web page by clicking Transfer / Status.

  • Page 374: Adding A Follower Signaling Server To An Ip Telephony Node

    Page 374 of 466 Configuring an IP telephony node The previous status of the node displays, and the failure reason is displayed for elements in nodes that failed to get configuration files (BOOTP.TAB and CONFIG.INI) from the CS 1000E. The Transfer / Status web page has five buttons: •...
  • Page 375 Configuring an IP telephony node Page 375 of 466 In Element Manager: Click Edit on the Node Configuration web page (see Figure 160 on page 369). Click Add beside the Signaling Server row. Enter the Follower Signaling Server data to an IP telephony node. Include the ELAN MAC address (used to answer BootP requests).

  • Page 376: Performing A Datadump Using Element Manager

    Page 376 of 466 Configuring an IP telephony node datadump backs up new IP Telephony node files on the CS 1000E at the same time that it backs up the customer database. Procedure 88 Performing a datadump using Element Manager From within Element Manager (see Figure 84 on page 366 for details on...
  • Page 377 Configuring an IP telephony node Page 377 of 466 End of Procedure Communication Server 1000E Installation and Commissioning...
  • Page 378 Page 378 of 466 Configuring an IP telephony node NN43041-310 Standard 01.11 October 2008...

  • Page 379: Introduction

    Page 379 of 466 Installing Line cards and cross-connecting telephones Contents This section contains information on the following topics: Introduction ..........Card placement in a Media Gateway or a Media Gateway Expansion .
  • Page 380 Page 380 of 466 Installing Line cards and cross-connecting telephones Before you proceed, install the cable from the slot that contains the Line card associated with the telephone being connected. Refer to “Installing the Main Distribution Frame” on page 349, if you require additional cable installation. DANGER OF ELECTRIC SHOCK Always use caution when installing or modifying telephone lines.
  • Page 381 Installing Line cards and cross-connecting telephones Page 381 of 466 Figure 167 Circuit card assignments in a Media Gateway Slot 4 Slot 3 Slot 2 Slot 1 Slot 0 - SSC 553-CSE9025 Figure 168 Circuit card assignments in a Media Gateway Expander Slot 10 Slot 9 Slot 8...

  • Page 382: Card Placement In A Media Gateway Or A Media Gateway Expansion

    Page 382 of 466 Installing Line cards and cross-connecting telephones Circuit cards features If a circuit card has a switch symbol on its faceplate, it is equipped with option switches, strapping plugs, or both. Make sure that the circuit cards with option switches or strapping plugs are set correctly.
  • Page 383 Installing Line cards and cross-connecting telephones Page 383 of 466 Figure 169 NE-500/2500-type telephone cross connections Lead Cable pairs designation Line Cross connect Pack terminal Unit W-BL To 500/2500-type BL-W telephone Unit To 500/2500-type telephone Unit To 500/2500-type telephone Unit W-BR To 500/2500-type BR-W...

  • Page 384: Connecting A Telephone Without A Pftu

    Page 384 of 466 Installing Line cards and cross-connecting telephones Figure 170 Digital telephone cross connections Pack Telephone connecting connector block, or connector PE shelf Line Cross connect block pack Line cord W-BL to telephone Unit 0 BL-W For Power Supply leads Unit 1 to telephone...

  • Page 385: Connecting An Off-Premise Telephone

    Installing Line cards and cross-connecting telephones Page 385 of 466 Procedure 90 Connecting a telephone without a PFTU Locate the telephone terminations on the cross-connect terminal. Connect one end of the cross-connect wire to the leads of the telephone. Locate the Line card terminations on the cross-connect terminal. Connect the other end of the cross-connect wire to the assigned TN terminal block.

  • Page 386: Procedure 91: "Connecting An Off-Premise Telephone

    Page 386 of 466 Installing Line cards and cross-connecting telephones Procedure 91 Connecting an off-premise telephone Install the NTAK92BA Off-Premise Protection Module on the wall using four #10 1/2-in (minimum) screws. Connect a #6 AWG from the grounding lug at the bottom of the NTAK92AA Off-Premise Protection Module to the system ground.

  • Page 387: Connecting An Attendant Console

    Installing Line cards and cross-connecting telephones Page 387 of 466 Figure 171 NTAK92BA Off-Premise Protection Module connections Cross-connect terminal block BL - 1W BL - 2W O - 1W O - 2W To off-premise G - 1W telephones G - 2W BR - 1W BR - 2W NTAK92AA...
  • Page 388 Page 388 of 466 Installing Line cards and cross-connecting telephones Figure 172 Attendant console connections Console Cross-connect connector block W-BL To 1st TN BL-W To 2nd TN ASM/ To 3rd TN To +15 AUX + AUX (W-G 1 dot wire) Console power on AUX cable from AUX...
  • Page 389 Installing Line cards and cross-connecting telephones Page 389 of 466 Table 46 Color combinations of cable pairs W-Bl W-BR R-BL Color Bl-W BR-W BL-R Unit R-BR BK-BL BK-O BK-G BK-BR BK-S Color BR-R BL-BK O-BK G-BK BR-BK S-BK Unit End of Procedure Communication Server 1000E Installation and Commissioning...
  • Page 390 Page 390 of 466 Installing Line cards and cross-connecting telephones NN43041-310 Standard 01.11 October 2008...

  • Page 391: Installing And Configuring Nortel Ip Phones

    Installing the IP Softphone 2050......Verifying Nortel IP Phone functionality ......

  • Page 392: Introduction

    The system must be configured before the Nortel IP Phones can be installed. The configuration includes: • The Nortel IP Phone TN blocks must be defined on the Call Server (See “Configuring VoIP bandwidth management zones” on page 406 “Using Set-Based Installation” on page 430).

  • Page 393: Package Components For The Nortel Ip Phones

    Installing and configuring Nortel IP Phones Page 393 of 466 Package components for the Nortel IP Phones Table 47 lists the Nortel IP Phone 2001 package components and product codes. Table 47 Nortel IP Phone 2001 components list (Part 1 of 2) Nortel IP Phone 2001 package contents include: •...
  • Page 394 Table 47 Nortel IP Phone 2001 components list (Part 2 of 2) Handset, Charcoal A0758634 Handset cord, Ethergray; for Nortel IP Phone 2004 and Nortel IP A088682 Phone 2001 Handset cord, Charcoal; for Nortel IP Phone 2004 and Nortel IP...
  • Page 395 Installing and configuring Nortel IP Phones Page 395 of 466 Table 48 lists the Nortel IP Phone 2002 package components and product codes. Table 48 Nortel IP Phone 2002 components list (Part 1 of 2) Nortel IP Phone 2002 package contents include: •...
  • Page 396 Page 396 of 466 Installing and configuring Nortel IP Phones Table 48 Nortel IP Phone 2002 components list (Part 2 of 2) Handset cord, Ethergray A0897725 Handset cord, Charcoal N0000763 Footstand, Charcoal (used for Ethergray and Charcoal models) A0891619 IP Phone 2001/2002/2004 Power Adaptors...
  • Page 397 Installing and configuring Nortel IP Phones Page 397 of 466 Table 49 lists the Nortel IP Phone 2004 package components and product codes. Table 49 IP Phone 2004 component list (Part 1 of 2) IP Phone 2004package contents includes • IP Phone 2004 •...
  • Page 398 Page 398 of 466 Installing and configuring Nortel IP Phones Table 49 IP Phone 2004 component list (Part 2 of 2) Replacement parts 7 ft. Ethernet Cat5 cable A0648375 Handset (Ethergray) A0788874 Handset (Charcoal) A0758634 Handset cord (Ethergray) A0788682 Handset cord (Charcoal)
  • Page 399 Installing and configuring Nortel IP Phones Page 399 of 466 Table 50 lists the Nortel IP Phone 2007 package components and product codes. Table 50 Nortel IP Phone 2007 component list (Part 1 of 2) Nortel IP Phone 2007 package contents includes NTDU96AB70 •...
  • Page 400 Pakistan, Brunei, Sri Lanka Option 11C Denmark Power Cord Kit, 9.9 ft. 125Vac NTTK22AB Denmark Table 51 lists the Nortel IP Phone ACP 2033 package components and product codes. Table 51 Nortel IP Audio Conference Phone 2033 components list IP Audio Conference Phone 2033 package contents include: •...
  • Page 401 WLAN Handset 2210 Battery Pack NTTQ4050/A0548446 WLAN Handset 2210 Desktop Charger NTTQ4060/A0548447 WLAN 2210/2211 Charger & Nortel Application Gateway 2246-64 NTTQ4101/A0548449 Power Supply for North America Global kit is the same as the North American kit without the power supply...
  • Page 402 NTTQ5131/A0548944 WLAN Handset 2211 carrying case, yellow NTTQ5121/A0548943 WLAN Handset 2211 carrying case, (key cover) yellow NTTQ5141/A0548945 Nortel WLAN IP Telephony Manager 2245, a minimum of one NTTQ60AA/A048950 Telephony Manager is required per system order NN43041-310 Standard 01.11 October 2008...
  • Page 403 Installing and configuring Nortel IP Phones Page 403 of 466 Table 52 WLAN Handset component list (Part 3 of 4) WLAN Application Gateway 2246 64 users NTTQ65AB/N0023211 128 users NTTQ65BA/A0548971 256 users NTTQ65CA/A0548972 512 users NTTQ65DA/A0548973 1,024 users NTTQ65EA/A0548974 10,000+ users...
  • Page 404 Page 404 of 466 Installing and configuring Nortel IP Phones Table 52 WLAN Handset component list (Part 4 of 4) Power supplies — WLAN Handset 2211 Gang Charger: • North America NTTQ4301/A0548951 • Europe NTTQ4311/A0548952 • UK-HK NTTQ4321/A0548953 • Switzerland NTTQ4331/A0548954 •...

  • Page 405: Setting Passwords For The Administrator And Temporary

    PC. • a local power supply appropriate for the voltage in the area or a Power over LAN unit. (The Nortel IP Phone 2002 comes with a built-in 3-port switch and is ready for LAN powering.) Installation and configuration procedures This chapter contains the following procedures: •...

  • Page 406: Configuring Voip Bandwidth Management Zones

    Page 406 of 466 Installing and configuring Nortel IP Phones • Procedure 105: "Displaying registered IP Phones in Element Manager" page 436 Configuring VoIP bandwidth management zones Follow Procedure 93 to configure the VoIP bandwidth management zones. For more details on bandwidth management zones, see IP Line: Description, Installation, and Operation (NN43100-500).
  • Page 407 Installing and configuring Nortel IP Phones Page 407 of 466 Exit from LD 117. Enter the command: **** Table 53 Bandwidth management zones configuration commands in LD 117 Command Description NEW ZONE xxx p1 p2 p3 p4 p5 Create a new zone, where: xxx = zone number = (0) - 255.

  • Page 408: Configuring Virtual Superloops

    Exit from LD 97. Enter the command: **** End of Procedure Configuring a Nortel IP Phone using LD 11 Follow Procedure 95 to configure a Nortel IP Phone. The configuration can be completed using either OTM or CLI. NN43041-310 Standard 01.11...

  • Page 409: Configuring The Ip Phones

    Configuring the IP Phones Access LD 11. Enter the command: LD 11 Enter the appropriate responses shown in Table 55. Table 55 LD 11 – Configure a Nortel IP Phone (Part 1 of 4) Prompt Response Description REQ: NEW CHG...
  • Page 410 Page 410 of 466 Installing and configuring Nortel IP Phones Table 55 LD 11 – Configure a Nortel IP Phone (Part 2 of 4) Prompt Response Description Class of Service ADD - Automatic Digit Display, (default for Nortel IP Phone) For a complete list of responses, refer to Software Input/ Output: Administration (NN43001-611).
  • Page 411 Installing and configuring Nortel IP Phones Page 411 of 466 Table 55 LD 11 – Configure a Nortel IP Phone (Part 3 of 4) Prompt Response Description Key number limits that can be assigned are as follows: 0-7 for Meridian Communications Adapter (MCA)
  • Page 412 Page 412 of 466 Installing and configuring Nortel IP Phones Table 55 LD 11 – Configure a Nortel IP Phone (Part 4 of 4) Prompt Response Description On the M3903, keys 4-15 are blocked. No feature assignment is accepted for keys 2-15.
  • Page 413 Installing and configuring Nortel IP Phones Page 413 of 466 Configure the dedicated soft keys, as shown in Table 56. Table 56 Nortel IP Phone dedicated soft key assignment (Part 1 of 2) Nortel IP Phone key number Response(s) Allowed...

  • Page 414: Setting Administrator And Temporary Ip Telephone Installer Passwords

    Nortel IP Phone Installer Passwords, see IP Line: Description, Installation, and Operation (NN43100-500). The Nortel IP Phone Installer Passwords are configured on either a Signaling Server or a Media Card in a node. The passwords then apply to all components in the node.
  • Page 415 Installing and configuring Nortel IP Phones Page 415 of 466 Click the desired node to expand it. Click GEN CMD for the chosen Signaling Server or Media Card. The General Commands web page opens, as shown in Figure 173. Figure 173 General Commands Select NodePwd from the Group drop-down list.
  • Page 416 Page 416 of 466 Installing and configuring Nortel IP Phones Enter the administrator Nortel IP Phone Installer Password in the Node Password box (see Figure 174). Figure 174 Node Password Note: The entered password appears as asterisks. The valid characters are 0-9 * #.

  • Page 417: Installing Nortel Ip Phone Hardware Components

    418, when installing the following: Footstand 3-Port Switch only on the Nortel IP Phone 2004, required if a single Ethernet connection is shared with a PC Ethernet cable from the set to the 3-Port Switch Power Transformer or Power Splitter for Power over LAN unit...
  • Page 418 Page 418 of 466 Installing and configuring Nortel IP Phones Handset cord Figure 176 Nortel IP Phone 2004 components Three Port Switch Power Transformer connection Power Splitter connection (power over LAN) CAT5 line cable NN43041-310 Standard 01.11 October 2008...
  • Page 419 Power the Nortel IP Phone with one of the following methods: Using a 16V AC power adaptor, plug the AC power transformer into the nearest power outlet. Check the Nortel IP Phone User Guide for country-specific parameters. Using a Power over LAN unit, connect the Power over LAN unit as...
  • Page 420 Page 420 of 466 Installing and configuring Nortel IP Phones Figure 177 Nortel IP Phone connections End of Procedure NN43041-310 Standard 01.11 October 2008...

  • Page 421: Configuring The Nortel Ip Phone Boot Parameters

    Partial Dynamic Host Configuration Protocol (DHCP) mode — Works with standard DHCP server. The DHCP server automatically provides the Nortel IP Phone with an IP address; the remainder of the Nortel IP Phone's boot parameters are statically configured at the Nortel IP Phone.

  • Page 422: Entering Nortel Ip Phone Boot Parameters Using Manual Configuration

    Power the Nortel IP Phone. Within four seconds, the Nortel logo appears. When the Nortel logo appears on the display, you have one second to press the four feature keys at the bottom of the display in sequence, from left to right.
  • Page 423 VLAN?(0-No,1-Ma,2-Au)0 13 Choose one of the following: Enter 0 to configure no VLAN. The Nortel IP Phone displays: Locating server... After several seconds, the Nortel IP Phone prompts: Connect Svc Node: x TN: x.x Go to step 14 on page 424.
  • Page 424 Nortel IP Phone prompts: Node: x TN: x.x 15 Enter the node number and the Nortel IP Phone's (virtual) TN, then go to Step 18. If you configured an Nortel IP Phone Installer Password, the Nortel IP...

  • Page 425: Entering Nortel Ip Phone Boot Parameters Using Full Dhcp Parameters

    Installing and configuring Nortel IP Phones Page 425 of 466 17 Enter the Nortel IP Phone’s (virtual) TN. The Nortel IP Phone displays the logo, the date and time, and the DN keys. 18 Check for dial tone and the correct DN above the display.
  • Page 426 If you did not configure an Nortel IP Phone Installer Password, after several seconds, the Nortel IP Phone prompts: Node: x TN: x.x Enter the node number and the Nortel IP Phone's (virtual) TN, and then go to step 11 on page 427.

  • Page 427: Entering Boot Parameters Using Partial Dhcp Parameters

    The Nortel IP Phone prompts: TN: x.x 10 Enter the Nortel IP Phone’s (virtual) TN. The Nortel IP Phone displays the logo, the date and time, and the DN keys. 11 Check for dial tone and the correct DN above the display.
  • Page 428 Page 428 of 466 Installing and configuring Nortel IP Phones Press the OK key to accept your selection. The Nortel IP Phone prompts: DHCP? (0-No, 1-Yes): 0 Enter 1 to use DHCP. The Nortel IP Phone prompts: DHCP:0-Full, 1-Partial:0 Enter the 1 to use Partial DHCP.
  • Page 429 Nortel IP Phone prompts: Node: x TN: x.x 13 Enter the node number and the Nortel IP Phone's (virtual) TN then go to step 16. If you configured a Nortel IP Phone Installer Password, the Nortel IP...

  • Page 430: Using Set-Based Installation

    The Nortel IP Phone prompts: TN: x.x 15 Enter the Nortel IP Phone’s (virtual) TN. The Nortel IP Phone displays the logo, the date and time, and the DN keys. 16 Check for dial tone and the correct DN above the display.
  • Page 431 Installing and configuring Nortel IP Phones Page 431 of 466 Node: x TN: x.x Enter the node number and the Nortel IP Phone's (virtual) TN, then go to Step 4. If you configured a Nortel IP Phone Installer Password, the Nortel IP Phone prompts:...

  • Page 432: Installing The Ip Softphone 2050

    Page 432 of 466 Installing and configuring Nortel IP Phones The system response, displayed on the Nortel IP Phone, is as follows: OK, EXTENSION? 2244 10 Press the # key to select the default DN, or enter a DN and press #.

  • Page 433: Configuring The Ip Softphone 2050

    Installing and configuring Nortel IP Phones Page 433 of 466 Procedure 102 Configuring the IP Softphone 2050 Access LD 11. Enter the command: LD 11 Enter appropriate responses shown in Table 57. Table 57 LD 11 – Configure the IP Softphone 2050...

  • Page 434: Installing The Usb Headset Kit

    Page 434 of 466 Installing and configuring Nortel IP Phones installed, you can still choose it as the audio device from the Configuration Utility. Procedure 103 Installing the USB Headset Kit Connect the coiled lower cord to the headset cord with the Quick Disconnect connector.
  • Page 435 Running the IP Softphone 2050 for the first time Installation places the IP Softphone 2050 in the Windows Start menu at Start > Programs > Nortel > IP Softphone 2050. The Configuration Utility is placed in the Windows Control Panel.

  • Page 436: Verifying Nortel Ip Phone Functionality

    Page 436 of 466 Installing and configuring Nortel IP Phones Verifying Nortel IP Phone functionality You can now use the IP Phones. To test the telephones, make Nortel IP Phone-to-Nortel IP Phone calls. Displaying registered IP Phones Follow Procedure 105 to display the IP Phones registered on a Signaling Server or Voice Gateway Media Card.

  • Page 437: Power Fail Transfer Unit

    Page 437 of 466 Installing and cross-connecting a Power Fail Transfer Unit Contents This section contains information on the following topics: Introduction ..........Installing and connecting a QUA6 PFTU .

  • Page 438: Installing And Connecting A Qua6 Pftu

    Page 438 of 466 Installing and cross-connecting a Power Fail Transfer Unit The following procedures are provided in this chapter: Procedure 106: "Installing and connecting a QUA6 PFTU" on page 438 Procedure 107: "Connecting an analog (500/2500-type) telephone to a PFTU"...
  • Page 439 Installing and cross-connecting a Power Fail Transfer Unit Page 439 of 466 Connect the PFTU power and control connections to the AUX connector on the Media Gateway. See Figure 179 on page 439 and Figure 180 on page 440, Table 58 on page 440, and Figure 181 on page...
  • Page 440 Page 440 of 466 Installing and cross-connecting a Power Fail Transfer Unit Figure 180 AUX cable connector on Media Gateway Table 58 Control and power connections on cable J1 (Part 1 of 2) J1 Cable from QUA6 Function Pair Number Pair Color Connects to Cross-connects to...
  • Page 441 Installing and cross-connecting a Power Fail Transfer Unit Page 441 of 466 Table 58 Control and power connections on cable J1 (Part 2 of 2) J1 Cable from QUA6 Function Pair Number Pair Color Connects to Cross-connects to (TC) Console transfer switch. See console connections.
  • Page 442 Page 442 of 466 Installing and cross-connecting a Power Fail Transfer Unit Figure 181 Power fail transfer QUA6A PFTU XFER TR 2 3 4 PFT1 NTAK1104 553-CSE8343 End of Procedure NN43041-310 Standard 01.11 October 2008...

  • Page 443: Installing And Connecting A Third-Party Pftu

    Installing and cross-connecting a Power Fail Transfer Unit Page 443 of 466 Installing and connecting a third-party PFTU Follow the equipment manufacturer’s instructions for installing the PFTU. Use the information in Table 59 to connect a third-party PFTU. Table 59 PFTU control lead signals Lead State NTAK1104 AUX...

  • Page 444: Connecting An Analog (500/2500-Type) Telephone To A Pftu

    Page 444 of 466 Installing and cross-connecting a Power Fail Transfer Unit Connecting an analog (500/2500-type) telephone to a PFTU Ensure that the cable from the appropriate Line card slot has been connected to the telephone. Refer to “Installing the Main Distribution Frame” on page 349.
  • Page 445 Installing and cross-connecting a Power Fail Transfer Unit Page 445 of 466 Figure 182 Analog Line card cable distribution Lead Cable pairs designation Line Cross connect Pack terminal Unit W-BL To 500/2500-type BL-W telephone Unit To 500/2500-type telephone Unit To 500/2500-type telephone Unit W-BR...

  • Page 446: Connecting An Analog (500/2500-Type) Telephone To A Pftu

    Page 446 of 466 Installing and cross-connecting a Power Fail Transfer Unit Procedure 107 Connecting an analog (500/2500-type) telephone to a PFTU Locate the telephone terminations on the cross-connect terminal. Connect one end of the cross-connect wire to the leads of the telephone. Locate the PFTU connections (unit PFTU 1 through PFTU 5) assigned to this telephone at the cross-connect terminal.
  • Page 447 Installing and cross-connecting a Power Fail Transfer Unit Page 447 of 466 Table 60 Power Fail Transfer Unit connections (Part 2 of 3) QUA6 J1 Cable Function Pair Color Connects to: R-BR Telephone BR-R Telephone Line card PFT 2 BK-BL Central Office Trunk BL-BK BK-O...

  • Page 448: Connecting A Trunk To A Pftu

    Page 448 of 466 Installing and cross-connecting a Power Fail Transfer Unit Table 60 Power Fail Transfer Unit connections (Part 3 of 3) QUA6 J1 Cable Function Pair Color Connects to: V-BL Telephone BL-V Telephone Line card PFT 5 Central Office Trunk V-BR Trunk Line card BR-V...

  • Page 449: Installing And Cross-Connecting

    Installing and cross-connecting a Power Fail Transfer Unit Page 449 of 466 Repeat for each trunk assigned to the PFTU. Table 61 Power Fail Transfer Unit connections (Part 1 of 2) QUA6 J1 cable Function Pair Color Connects to: Connects to: Telephone —...
  • Page 450 Page 450 of 466 Installing and cross-connecting a Power Fail Transfer Unit Table 61 Power Fail Transfer Unit connections (Part 2 of 2) QUA6 J1 cable Function Pair Color Connects to: Connects to: Telephone — Telephone Line card TN assigned to the telephone Y-BR Central office trunk —...

  • Page 451: An External Alarm From A Pftu

    Page 451 of 466 Installing and cross-connecting an external alarm from a PFTU Contents This section contains information on the following topics: Introduction ..........Installing an alarm using an alarm port assigned in LD 15.

  • Page 452: Installing An Alarm Using An Alarm Port Assigned In Ld 15

    LD 15. Procedure 109 Installing an alarm using an alarm port assigned in LD 15 Install an analog (500/2500-type) line as described in “Installing and configuring Nortel IP Phones” on page 391. Connect an analog (500/2500-type) telephone, or another similar alerting device used as an alarm, to the line.

  • Page 453: Installing An Alarm Through Qua6 Pftu Connections

    Installing and cross-connecting an external alarm from a PFTU Page 453 of 466 Installing an alarm through QUA6 PFTU connections A QUA6 PFTU can be used to connect an external alarm through normally open or normally closed contacts of one of its units. The contacts operate under the same conditions as the PFTU and can support the capacities listed in Table 63.
  • Page 454 Page 454 of 466 Installing and cross-connecting an external alarm from a PFTU Figure 183 Contacts in PFTU PFT 1 on PFTU 8T (R-G) Normally 7T (R-O) connected Normally to a connected trunk line card to a 8R (G-R) CO trunk 7R (O-R) 6T (R-BL) Normally...
  • Page 455 Installing and cross-connecting an external alarm from a PFTU Page 455 of 466 Table 64 PFTU connections (Part 2 of 3) Unit Pair Color Normal mode Failure mode R-BR Makes with 10T and Opens 10T and 10R BR-R Makes with 11T and 11R Makes with 9T and 9R Open BK-BL...
  • Page 456 Page 456 of 466 Installing and cross-connecting an external alarm from a PFTU Table 64 PFTU connections (Part 3 of 3) Unit Pair Color Normal mode Failure mode V-BL Makes with 22T and Opens 22T and 22R BL-V Makes with 23T and 23R Makes with 21T and Open Makes with 24T and...

  • Page 457: Basic System Telephony Configuration

    Page 457 of 466 Basic system telephony configuration Contents This section contains information on the following topics: Introduction ..........Basic system configuration .

  • Page 458: Configuring The Basic System

    Page 458 of 466 Basic system telephony configuration See Software Input/Output: Administration (NN43001-611) for information about overlays. Flow charts Figure 184 on page 459 shows the programming overlay (LD) sequence for a new system. The Data-entry-sequence flowchart does not show all possible administration overlays.
  • Page 459 Basic system telephony configuration Page 459 of 466 Figure 184 Data-entry-sequence for new systems Communication Server 1000E Installation and Commissioning...
  • Page 460 Page 460 of 466 Basic system telephony configuration Figure 185 Configuration Record NN43041-310 Standard 01.11 October 2008...
  • Page 461 Basic system telephony configuration Page 461 of 466 Figure 186 Customer Data Block Communication Server 1000E Installation and Commissioning...

  • Page 462: Tn Assignment

    Page 462 of 466 Basic system telephony configuration TN assignment Table 65 shows the TN assignments for the MG 1000E. Table 65 TN assignments for MG 1000E MG 1000E MG 1000E Expander Slots l s c l s c l s c l s c l s c l s c...

  • Page 463: Managing The Gatekeeper Database

    Page 463 of 466 Configuring IP Peer Networking and managing the Gatekeeper database Contents This section contains information on the following topics: Introduction ..........Implementation summary .
  • Page 464 Page 464 of 466 Configuring IP Peer Networking and managing the Gatekeeper database You must configure the following data when setting up a CS 1000E IP network: Configure the Virtual Trunk routes using Element Manager or the Command Line Interface (LD 16). Configure the Route Data Blocks and associate the Virtual Trunk routes with the IP network by configuring the following parameters: route information...
  • Page 465 Configuring IP Peer Networking and managing the Gatekeeper database Page 465 of 466 Configure the Gatekeeper database to provide a central database of addresses that are required to route calls across the network, using the Gatekeeper web pages in Element Manager. Log in to the Gatekeeper web pages in Element Manager.
  • Page 466 Page 466 of 466 Configuring IP Peer Networking and managing the Gatekeeper database NN43041-310 Standard 01.11 October 2008...
  • Page 468 Users must take full responsibility for their applications of any products specified in this document. The information in this document is proprietary to Nortel Networks. Nortel, Nortel (Logo), the Globemark, SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.

This manual is also suitable for:

1000eCommunication server 1000Communication server 1000e

Table of Contents
