Nortel Communication Server 1000

Fiber Remote Multi-IPE

Interface Fundamentals

Release: 6.0

Document Revision: 03.01

www.nortel.com

NN43021-556

Table of Contents

Summary of Contents for Nortel Communication Server 1000 Series

Page 1 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals Release: 6.0 Document Revision: 03.01 www.nortel.com NN43021-556...
Page 2 While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are subject to change without notice.
Page 3: Table Of Contents
Intended audience 8 Conventions 8 Related information 9 Getting help from the Nortel web site 9 Getting Help over the phone from a Nortel Solutions Center 10 Getting Help through a Nortel distributor or reseller 10 Product description Contents 11...
Page 4 Peripheral Controller HEX codes and cable connection diagrams Peripheral Controller hexadecimal codes 149 Fiber Remote Multi-IPE Interface units connection diagrams 150 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 5: New In This Release
This document contains information previously contained in the following legacy document, now retired: Fiber Remote Multi-IPE Interface: Description, Installation, and Maintenance (553-3001-022) () . Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 7: Introduction
Introduction This document is a global document. Contact your system supplier or your Nortel representative to verify that the hardware and software described are supported in your area. Subject This Nortel technical publication (NTP) provides information specific to the implementation of fiber-optic links that connect a local system to multiple Remote IPE modules using a pair of Fiber Remote Multi-IPE Interface units.
Page 8: Intended Audience
The following systems are referred to generically as "Small System": • Meridian 1 PBX 11C Chassis • Meridian 1 PBX 11C Cabinet Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 9: Related Information
To obtain Nortel documentation on CD-ROM, contact your Nortel customer representative. How to get help Getting help from the Nortel web site The best source of support for Nortel products is the Nortel Support Web site: www.nortel.com Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01...
Page 10: Getting Help Over The Phone From A Nortel Solutions Center
Getting Help over the phone from a Nortel Solutions Center If you have a Nortel support contract and cannot find the information you require on the Nortel Support Web site, you can get help over the phone from a Nortel Solutions Center.
Page 11: Product Description
This document focuses on the Fiber Remote Multi-IPE Interface equipment specifically designed to provide fiber-optic links between the network functions in the local system and the peripheral controller functions in Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 12: System Description
Multi-IPE Interface units are connected by a fiber-optic link at a distance of up to 15 miles over a single-mode optical fiber. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 13 J1 and the Remote IPE site with the superloop extended from the faceplate connector J2 at the same time. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 14 NT8D04 #2 NT8D01BC #1 per other superloop Note: NT8D01BC Controller -4 replaces both NT8D01AC Controller-4 and NT8D01DC Controller-2 for new installations. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 15 Fiber Remote Multi-IPE Interface and the fiber-optic link to two Remote IPE modules. Minimal blocking for the first four segments in one IPE Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 16 A 30 foot shielded cable connects the local network I/O Remote Multi-IPE panel 24-pin Centronics connector to a Fiber Remote Interface Cable Multi-IPE Interface unit SUPERLOOP 37-pin D Shell connector. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 17 Connects the 6-pin modular jack J5 on the Fiber Remote System Monitor Multi-IPE I/O panel to the system monitor jack J6 in the Serial Link Cable pedestal. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 18 IPE Modules supported at the remote site. A maximum of four IPE Modules can be supported using a pair of Fiber Remote Multi-IPE Interface units. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 19 30.48 cm.). This enclosure can be mounted on the wall. Up to six of these enclosures can be installed in a 19-inch rack-mounted shelf. The Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 20 The motherboard can then be accessed to install the daughterboard or to set configuration switches. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 21 SDI port, the MMI terminal, the modem, the external alarms, and the power. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 22 Remote IPE. It can be connected at the local and at the remote site. DB-9 male Connects to external alarm devices. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 23 The Fiber Remote Multi-IPE Interface links multiple Remote IPE sites with the local system over single-mode or multi-mode optical fibers. With a multi-mode fiber-optic link, the maximum distance between the Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 24 Each superloop supports 120 timeslots for voice and data. Eight additional timeslots are used to carry out-of-band signaling and messaging information across the fiber-optic link. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 25 Fiber Remote Multi-IPE Interface at the local or remote sites for maintenance Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 26 IN modular jack of the other unit in the chain. Only one Fiber Remote Multi-IPE Interface unit 6-pin XSM IN (J5) modular jack is connected to Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 28 External alarm indicators. The Fiber Remote Multi-IPE Interface unit I/O panel contains the DB-9 female ALM connector which connects the external alarms to the Fiber Remote Multi-IPE Interface unit. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 29 External alarm inputs and outputs LED indicators. The LED indicators are located on the faceplate of each Fiber Remote Multi-IPE Interface unit. These LEDs are: Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 30: Engineering Guidelines
One IPE module supports up to 16 line cards, or 256 ports if each line card has 16 ports (other IPE cards may have Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 31 When planning a fiber-optic link, you must consider the transmit and receivesignal power and the signal attenuation of each component in the link to determine total signal attenuation. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 32 Note: XMIT A and RCV A connector pairs on the faceplate do not count when calculating the attenuation across the link. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 33 Fiber Remote Multi-IPE Interface: 10 dB • dB loss per km of fiber: 1.5 dB • dB loss per splice: 0.5 dB Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 34 Fiber Remote Multi-IPE Interface: 15 dB • dB loss per km of fiber: 1.0 dB • dB loss per splice: 0.2 dB Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 35 256 ports (different IPE cards provide different number of ports). This column can be expanded by adding more IPE modules to support Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 36 Multi-IPE Interface unit to provide the required power for the Fiber Remote Multi-IPE Interface unit. This power converter is wall-mounted next to the Fiber Remote Multi-IPE Interface unit. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 37 Remote IPE column. This source is usually available if the system is DC-powered or has a DC backup power source. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 39: Installation And Configuration
Take inventory of the equipment by comparing the received equipment against the shipping documents. Refer to Table 2 in the Product Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 40 Remote Multi-IPE Interface units” (page 66) — “Connecting the fiber-optic link” (page 68) At the remote site, install the Remote IPE equipment. Refer to the following: Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 41: Installation Overview
Fiber Remote Multi-IPE Interface units and the local system and between remote Fiber Remote Multi-IPE Interface units and the Remote IPEs. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 42 MMI terminal cables at the remote site • connecting the fiber-optic link to the Fiber Remote Multi-IPE Interface at the Remote IPE site Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 43: Preinstallation Preparation
Use antistatic spray if the site is carpeted. • Observe grounding precautions before handling any equipment. • Remove equipment carefully from its packaging. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 44 Remote Multi-IPE Interface units and, if it can, at what distance between the local system and the Remote IPE. Consult the Nortel distributor to learn how to verify that the existing fiber-optic link is suitable for the Fiber Remote IPE application and what equipment to use to do so.
Page 45 RCV B at the local site, and RCV B at the remote site as XMIT B at the local site as shown in Figure 6 "Fiber-optic link" (page 45). Figure 6 Fiber-optic link Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 46: Fiber-Optic Equipment Installation
Remote IPE sites, and linking the local system with remote sites using single or redundant fiber-optic links. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 47 LED on the card as it performs self-tests. The LED should blink three times and then stay ON until enabled by software. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 48 Use longer screws supplied in the kit with the cable assembly. Repeat steps 2 through 4 for each superloop connection required in your application. --End-- Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 49 Remote Multi-IPE Interface unit in a daisy-chain and the system monitor address. Each Fiber Remote Multi-IPE Interface must have a unique address from 0 to 63. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 50 Fiber Remote Multi-IPE Interface and system monitor address selection table Address S1 Pos 3 S1 Pos 4 S1 Pos 5 S1 Pos 6 S1 Pos 7 S1 Pos 8 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 51 Fiber-optic equipment installation 51 Address S1 Pos 3 S1 Pos 4 S1 Pos 5 S1 Pos 6 S1 Pos 7 S1 Pos 8 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 52 "Daisy-chaining of multiple Fiber Remote Multi-IPE Interface units" (page 68). It also defines the system monitor address at the remote site. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 53 SDI port in the local system and the MAINT connector connects to the SDI connector on the next Fiber Remote Multi-IPE Interface in the daisy-chain. Set dip-switch Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 54 Refer Figure 7 "Installing the redundant fiber-optic link option" (page 56) installation details. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 55 Figure 7 "Installing the redundant fiber-optic link option" (page shows the installation of the daughterboard onto the motherboard of the Fiber Remote Multi-IPE Interface unit. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 56 This is normally used at the local site, where the possibility of having multiple units is much greater. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 57 Figure 8 "The Fiber Remote Multi-IPE Interface unit installation methods" (page 58) illustrates the installation of the Fiber Remote Multi-IPE Interface units on the wall and into a rack-mounted shelf. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 58 Figure 9 "Wall-mounting the Fiber Remote Multi-IPE Interface unit" (page and follow the steps in Procedure 7 “Installing the Fiber Remote Multi-IPE Interface unit onto the wall” (page 59). Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 59 Figure 9 "Wall-mounting the Fiber Remote Multi-IPE Interface unit" (page illustrates the installation of the Fiber Remote Multi-IPE Interface unit onto the wall. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 60 Use the superloop connection plan that you completed based on the traffic blocking criteria for Remote IPE segments and Table 2 "Superloop connection configurations" (page 14). Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 61 Interface unit to the system monitor at the local site, follow the steps in Procedure 9 “Connecting a single Fiber Remote Multi-IPE Interface to the system monitor” (page 62). Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 62 Plug one end of the NT8D46AL cable 6-pin modular plug into the second Fiber Remote Multi-IPE Interface unit 6-pin modular jack XSM OUT (J6). Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 63 Fiber Remote Multi-IPE Interface units at the local site. Figure 10 System monitor daisy-chain connections at the local site Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 64 Plug the other end of the NT7R66AA SDI Cable Kit into the modem connector. Use the enclosed adapter gender changer, if required. --End-- Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 65 Plug the DB-25 male connector of the NT7R66AA SDI Cable Kit into the DB-25 female SDI connector on the I/O panel. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 66 Plug the other end of the A0634497 Maintenance Interface cable into the DB-9 female SDI connector on the Fiber Remote Multi-IPE Interface unit #2. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 67 Interface units in a daisy-chain to provide MMI and SDI connections for all Fiber Remote Multi-IPE Interface units and through them to their respective Remote IPE sites. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 68 “Engineering the fiber-optic link” (page 31). Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 69 Repeat steps 2 and 3 for the XMIT B and RCV B if there is a redundant link. Route and secure the fiber-optic cable to prevent excessive bending and other physical damage. --End-- Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 70 Observe the wire color codes and their corresponding pin assignments at the connector when wiring the external alarm devices to the cable. --End-- Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 71 Multi-IPE Interface unit I/O panel, as shown in Figure 12 "DC power connection of the Fiber Remote Multi-IPE Interface unit" (page 73). Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 72 Figure 12 "DC power connection of the Fiber Remote Multi-IPE Interface unit" (page 73) shows the power connection of the Fiber Remote Multi-IPE Interface unit to the local DC power source. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 73 Figure 13 "DC system power source connection to the Fiber Remote Multi-IPE Interface unit" (page 75) for an illustration of this power source connection. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 74 Figure 13 "DC system power source connection to the Fiber Remote Multi-IPE Interface unit" (page 75) illustrates the POWER connector on the I/O panel of the Fiber Remote Multi-IPE Interface unit. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 75: Remote Ipe Installation
If the Remote IPE column is not assembled in the factory, follow the instructions in Communication Server 1000M and Meridian 1 Large System Installation and Commissioning (NN43011-310) () . It describes Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 76 Repeat steps 2 and 3 for each NT8D92AB cable connecting SL1, SL2, and SL3 backplane connectors, if these are required. Replace the back cover on the Remote IPE module. --End-- Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 77 Table 13 "System monitor address selection" (page 78) shows S1 switch position 3-5 that represent the system monitor address numbers from 0 to 63 at the remote site. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 78 System monitor address selection Address S1 Pos 3 S1 Pos 4 S1 Pos 5 S1 Pos 6 S1 Pos 7 S1 Pos 8 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 79 Remote IPE installation 79 Address S1 Pos 3 S1 Pos 4 S1 Pos 5 S1 Pos 6 S1 Pos 7 S1 Pos 8 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 80 80 Installation and configuration Address S1 Pos 3 S1 Pos 4 S1 Pos 5 S1 Pos 6 S1 Pos 7 S1 Pos 8 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 81 Fiber Remote Multi-IPE Interface unit as shown in Figure 9 "Wall-mounting the Fiber Remote Multi-IPE Interface unit" (page 60). Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 82 Refer to Figure 17 "Remote site single Fiber Remote Multi-IPE Interface unit cable connection diagram" (page 154) for the connection diagram. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 83 Set Fiber Remote Multi-IPE Interface unit S1 positions 3-8 for the new system monitor address at the remote site, refer Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 84 Plug the DB-9 female connector of the NT7R66BA MMI Cable into the DB-9 male MAINT connector on the Fiber Remote Multi-IPE Interface unit. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 85 Plug the other end of the A0634497 Maintenance Interface cable into the SDI connector on the Fiber Remote Multi-IPE Interface unit #2. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 86 For details on how to engineer and handle the fiber-optic link and the fiber-optic connectors, refer to “Engineering the fiber-optic link” (page Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 87 RCV A. Repeat steps 2 and 3 for the XMIT B and RCV B if there is a redundant link. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 88 Step Action Plug the cable DB-9 male connector into the DB-9 female ALM connector on the Fiber Remote Multi-IPE Interface unit. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 89: Configuring The Equipment
Table 15 "Factory default parameter settings" (page 89): Table 15 Factory default parameter settings Parameter Default setting Time Central Standard Time Date Current Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 90 Print Program LD 22. Table 16 Request CFN printout Prompt Response Description Print request TYPE CEQU Configuration data PKG PSWV Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 91 After the new Peripheral Controller is defined, define the superloop for the Superloop Network card designated to support the Remote IPE. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 92 Table 22 To enable the superloop sl Command Response Comment ENLL sl OK = op Enables specified superloop sl eration is successful. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 93: Configuring The Fiber Remote Multi-Ipe Interface Unit
MMI terminal modes • setting modem parameters • configuring fiber-optic link performance criteria • performing maintenance functions • conducting test and diagnostic functions Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 94 Entering password. After logging in, the password is prompted. The password is FIBER and it must be entered in all capital (upper-case) letters. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 95 Host Busy. Barge In (Y or N) Y May want to barge in but the connection may be denied if another terminal is active in the Host SDI mode. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 96 Use a terminal or put the computer into the terminal mode and connect it to the modem to be able to configure the modem. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 97 The three modes are Initial, MMI, and SDI. The words shown along the paths must be entered on the terminal to go from one mode to the next. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 98 Commands affecting the far-end can be executed only when the far-end is communicating and the Microlink is up. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 99 Current Dip Switch Settings (S1...S8) ON ON OFF OFF OFF OFF OFF OFF 2400 Baud Single Terminal Mode Multidrop Address 0 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 100 To change link IDs ID for Superloop 1 004 1 Superloop and shelf number ID for Superloop 2 008 1 Superloop and shelf number Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 101 HOST. Enter password in all capital letters. Log in to the MMI terminal for one Fiber Remote Multi-IPE Interface. The password is FIBER. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 102 1 to 98 minutes. By entering 0, the tests run one time. To stop testing, enter STOP. Terminates the terminal connection. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 103: Remote Ipe Acceptance Testing
Acceptance testing verifies the operation of local system functions and features at the remote site equipped with Fiber Remote Multi-IPE Interface units and the Remote IPE. Acceptance testing consists of: Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 104: Checking The System
It may be able possible to use the system as configured at the site according to the customer requirements and not have to modify the configuration to perform the acceptance testing. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 105: Performing Acceptance Testing
Placing a call to the remote site To perform a call test, follow the steps in Procedure 29 “Performing a call test” (page 106). Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 106 Now, place an outgoing call from the telephone at the remote site by dialing an idle telephone located at the local site. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 107 This command is sent over the fiber-optic link to the Peripheral Controller card for execution. Check the response to this command for the local and remote sites. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 108 Fiber Remote Multi-IPE Interface faceplate XMIT A connector. Verify that the call is still established over the secondary link. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 109 Multi-IPE Interface units after the loss of power at one end. To perform this test, follow the steps in Procedure 34 “Perform a fault recovery test” (page 110). Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 110 If the actual customer configuration was used to perform these tests, it is not necessary to change or remove the setup. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 111 For more information on traffic reports, refer to the Traffic control program LD 02 in Software Input Output Administration (NN43001-611) () and Traffic Measurement Format and Output Reference (NN43001-750 () . Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 113: Remote Ipe Maintenance
A problem may have more than one cause. To isolate the cause, a knowledge of Remote IPE operation is required. This information can be found in “Product description” (page 11). Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 114: Diagnostic Tools
Optional equipment: • 1300 nm light source (LED or laser) • visual fault locator (high power visible light source) Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 115 Table 5 "Fiber-optic transmit and receive signal levels" (page 32). Measure the transmitter power level using a good patch cable and the power meter. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 116 The Fiber Remote Multi-IPE Interface unit provides LED indicators to show the power status and the alarm status of the Fiber Remote Multi-IPE Interface unit and the fiber-optic link. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 117 System monitoring units continuously monitor the environmental and power status of the system and the individual system modules including the Remote IPE equipment. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 118 Remote IPE equipment • error messages listed under ERR that indicate hardware faults and under BUG that indicate software faults Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 119 These programs test the entire system and print a report that lists the test results. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 120 Test Card-LAN operation and queries superloop, peripheral controller, and IPE cards. Returns part numbers and serial numbers of cards. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 121 Display error distant. Displays far-end error log, which contains the previous minute and the last 30 days of the fiber-optic link error statistics. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 122 Test duration can be set from 1 to 98 minutes. By entering 0, the tests run one time. To stop testing enter STOP. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 124 Procedure 36 “isolating Remote IPE faults” (page 125) describe how to isolate Remote IPE faults using the diagnostic tools described in this section. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 125 Check the symptoms listed in Table 29 "Remote IPE equipment problems" (page 126) that are related to problems with a newly installed Remote IPE. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 126: Remote Ipe Fault Isolation And Correction
Then go to Procedure 43 “Testing the superloops and the fiber-optic link” (page 137) to test the superloop and the fiber-optic link. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 127 If the problem cannot be resolved after exhausting all available diagnostic tools and test procedures, make a list of the symptoms and contact the field service representative. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 128 (the Superloop Network card is not installed). If the Superloop Network card is manually disabled using LD 30, the response can be: Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 129 Step Action To perform the self-test, follow the steps below: Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 130 Superloop Network card is missing, not configured, and so on. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 131 SL0 C1—Controller is locked on the network superloop connected to SL1 C2—Controller is locked on the network superloop connected to SL2 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 132 Type XPCT x and press the Enter key to start the self-test, where x is the Peripheral Controller card specified for self-test. If the response is: TEST PASSED Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 133 This procedure uses MMI commands to display the superloop and the fiber-optic link performance history. Log in on the MMI maintenance terminal.: Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 134 DISTANT) to display far-end superloop and fiber-optic link error history. The [P] or pause, allows you to display a full screen of events at the time. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 135 Example: FII::>D S Fiber Remote IPE S/N 25002-R3 Software Version 2.05 04/15/96 9:25 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 136 To perform these tests, execute the (TEST ALL) T A command. This test interferes with normal traffic; therefore all superloops should be disabled. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 137 DS-30A Frame 1 PASSED DS-30A Frame 2 PASSED DS-30A Frame Test Completed DS-30A Clock 1 PASSED DS-30A Clock 2 PASSED DS-30A Clock Test Completed Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 138 Then execute the DISL sl command to disable the superloop sl. Place the MMI terminal into the MMI mode by entering @@@. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 139 Remote Multi-IPE Interface at both ends of the link and the fiber-optic link itself. If a redundant link is configured, this test checks both links. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 140 Distant-Fiber A Threshold Exceeded Fiber Link Restored (after correcting the fault) Distant-No Activity Super Loop 1 Distant-Activity On Super Loop 1 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 141 If the problem with the fiber-optic link has been corrected, reinstall the link connectors into the Fiber Remote Multi-IPE Interface ST faceplate connectors and execute the T FI command again. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 142: Replacing Remote Ipe Equipment
Keep cards in their antistatic bags until ready to install them. Do not stack them on top of each other. Install cards. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 143 Set the ENL/DIS switch on the Superloop Network card to ENL. The Superloop Network card automatically starts the self-test. Observe the red LED on the front panel during self-test. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 144 Hold the replacement card by the card locking devices and insert it partially into the card guides in the module. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 145 Log in on the TTY or the MMI maintenance terminal. Disable the Superloop Network card by loading the Network and Intelligent Peripheral Equipment Diagnostic Program LD 32, and Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 146 Procedure 50 “Removing and replacing the card in the Fiber Remote Multi-IPE Interface unit” (page 147) replaces just the motherboard and faceplate combination. The enclosure remains installed and connected. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 147 Procedure 51 Reinstalling covers Step Action Reinstall the covers on the local module. Reinstall the cover on the Remote IPE module. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 148 If using the MMI terminal, log out to complete the test and troubleshooting session. --End-- Packing and shipping defective cards To ship a defective card to a Nortel repair center, follow the steps in Procedure 52 “Packing and shipping defective cards” (page 148). Procedure 52...
Page 149: Peripheral Controller Hex Codes And Cable Connection Diagrams
DUART port B A31 #1 external buffer A31 #1 internal context memory (phase A) A31 #1 internal context memory (phase B) Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 150: Fiber Remote Multi-Ipe Interface Units Connection Diagrams
Figure 15 "Local site single Fiber Remote Multi-IPE Interface unit cable connection diagram" (page 152) shows a network of Superloop Network cards, including: Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 151 SUPERLOOP #4 is not equipped in this example. — Shows the MMI terminal connection, the system monitor connection, and the fiber-optic link connection. Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 152 152 Peripheral Controller HEX codes and cable connection diagrams Figure 15 Local site single Fiber Remote Multi-IPE Interface unit cable connection diagram Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 153 Fiber Remote Multi-IPE Interface units connection diagrams 153 Figure 16 Local site multiple Fiber Remote Multi-IPE Interface units cable connection diagram Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 154 154 Peripheral Controller HEX codes and cable connection diagrams Figure 17 Remote site single Fiber Remote Multi-IPE Interface unit cable connection diagram Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 155 Background Network and IPE Conﬁguration Record Program 119 Diagnostics LD 32 program 120 conﬁgure MMI mode 94 using MMI terminal 98 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 156 91 ﬁber-optic link functional architecture ﬁber-optic link loss 32 Fiber Remote Multi-IPE Interface 23 ﬁber-optic links 31 environmental requirements 36 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 157 35 network superloop 120 Remote IPE MMI 121 maintenance display codes labelling described 117 ﬁber-optic link 45 overview 118 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 158 Remote IPE capacity 30 attenuator 114 removing 143–146 power light source 114 local system cards 117 power meter 114 Remote IPE cards 143 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 159 111 Superloop Network card transmit continuity tests 120 signal levels 32 fault isolation/correction 128 signal power 31 installing 47 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 160 142 verifying local system operation 46 Remote IPE operation 103 voice call acceptance testing 105 yellow alarms overview 117–118 Nortel Communication Server 1000 Fiber Remote Multi-IPE Interface Fundamentals NN43021-556 03.01 11 May 2009 Copyright © 2007-2009 Nortel Networks...
Page 162: Nortel Communication Server 1000
While the information in this document is believed to be accurate and reliable, except as otherwise expressly agreed to in writing NORTEL PROVIDES THIS DOCUMENT "AS IS" WITHOUT WARRANTY OR CONDITION OF ANY KIND, EITHER EXPRESS OR IMPLIED. The information and/or products described in this document are subject to change without notice.

This manual is also suitable for:

Communication server 1000e cp piiCommunication server 1000e cp pivCommunication server 1000e cp pmCommunication server 1000m single group cp pii Communication server 1000m single group cp pivCommunication server 1000m multi group cp pii ... Show all

Nortel Communication Server 1000 Series Manual

Quick Links

Related Manuals for Nortel Communication Server 1000 Series

Summary of Contents for Nortel Communication Server 1000 Series

This manual is also suitable for:

Table of Contents
