Title page
Nortel Networks Communication Server 1000
Nortel Networks Communication Server 1000 Release 4.0
ISDN Primary Rate Interface
Installation and Configuration
Document Number: 553-3001-201
Document Release: Standard 2.00
Date: September 2004
Year Publish FCC TM
Copyright © 2003—2004 Nortel Networks
All Rights Reserved
Produced in Canada
Information is subject to change without notice. Nortel Networks reserves the right to make changes in design
or components as progress in engineering and manufacturing may warrant.
SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Communication Server 1000S and is the answer not in the manual?

Questions and answers

Related Manuals for Nortel Communication Server 1000S

Summary of Contents for Nortel Communication Server 1000S

  • Page 1 All Rights Reserved Produced in Canada Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant. SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.
  • Page 3 Page 3 of 394 Revision history September 2004 Standard 2.00. This document is up-issued for Communication Server 1000 Release 4.0. October 2003 Standard 1.00. This document is a new NTP for Succession 3.0. It was created to support a restructuring of the Documentation Library, which resulted in the merging of multiple legacy NTPs.
  • Page 4 Page 4 of 394 Revision history 553-3001-201 Standard 2.00 September 2004...

  • Page 5: Table Of Contents

    Page 5 of 394 Contents About this document ..... . . Subject ..........Applicable systems .
  • Page 6 Page 6 of 394 Contents NT5D12 Dual-port DTI/PRI ....... . . DCH installation .
  • Page 7 Contents Page 7 of 394 Install an additional network shelf ......NT5D97 Dual-port DTI2/PRI2 installation and removal .
  • Page 8 Page 8 of 394 Contents Installation procedures ........ISL installation .
  • Page 9 Contents Page 9 of 394 Install DTI hardware ........Software enable the DTI/PRI cards ..
  • Page 10 Page 10 of 394 Contents Non-standard cables ..... . . 383 Contents ..........Introduction ..

  • Page 11: About This Document

    Page 11 of 394 About this document This document is a global document. Contact your system supplier or your Nortel Networks representative to verify that the hardware and software described is supported in your area. Subject This document describes the basic hardware and the associated installation procedures needed to equip ISDN Primary Rate Interface (PRI) on CS 1000M, CS 1000S, and Meridian 1 systems.
  • Page 12 Page 12 of 394 About this document • Communication Server 1000M Multi Group (CS 1000M MG) • Communication Server 1000E (CS 1000E) • Meridian 1 PBX 11C Chassis (Meridian 1 PBX 11C Chassis) • Meridian 1 PBX 11C Cabinet (Meridian 1 PBX 11C Cabinet) •...

  • Page 13: Intended Audience

    Communication Server 1000M and Meridian 1: Small System Upgrade Procedures (553-3011-258) • Communication Server 1000M and Meridian 1: Large System Upgrade Procedures (553-3021-258) • Communication Server 1000S: Upgrade Procedures (553-3031-258) Intended audience This document is intended for individuals responsible for installing and configuring ISDN PRI. Conventions Terminology In this document, the following systems are referred to generically as “system”:...
  • Page 14 Page 14 of 394 About this document • Meridian 1 PBX 11C Chassis (Meridian 1 PBX 11C Chassis) • Meridian 1 PBX 11C Cabinet (Meridian 1 PBX 11C Cabinet) The following systems are referred to generically as “Large System”: • Communication Server 1000M Half Group (CS 1000M HG) •...

  • Page 15: Related Information

    Communication Server 1000M and Meridian 1: Small System Planning and Engineering (553-3011-120) Online To access Nortel Networks documentation online, click the Technical Documentation link under Support on the Nortel Networks home page: http://www.nortelnetworks.com/ CD-ROM To obtain Nortel Networks documentation on CD-ROM, contact your Nortel Networks customer representative.
  • Page 16 Page 16 of 394 About this document 553-3001-201 Standard 2.00 September 2004...

  • Page 17: Isdn Primary Rate Interface Equipment Overview

    Page 17 of 394 ISDN Primary Rate Interface equipment overview Contents The section contains information on the following topics: Introduction ..........Primary Rate Interface (PRI) hardware requirements.
  • Page 18 Page 18 of 394 ISDN Primary Rate Interface equipment overview Power requirements ........NT8D72 faceplate .

  • Page 19: Introduction

    Note: The NTRB53 Clock Controller cannot be combined with a QPC775 or a QPC471 card in one system Additional hardware is also required for PRI capability and applications. Installation instructions are given in other Nortel Networks publications, or supplied by the manufacturer. This additional hardware includes: •...
  • Page 20 Page 20 of 394 ISDN Primary Rate Interface equipment overview • Echo canceller • ROM circuit card requirements: — the QPC939A for a CS 1000M HG — the QPC939A for CS 1000M SG Note: CS 1000M MG ROM requirements are fulfilled by the NT6D66 Call Processor (CP) card.

  • Page 21: Isdn Signaling Link (Isl) Hardware

    ISDN Primary Rate Interface equipment overview Page 21 of 394 Figure 1 PRI hardware (shown without downloadable PRI and DCH cards) Clock Controllers Interface to the external digital CEPT carrier (2Mb/s PCM carrier) DCHI Loop QPC414 DCHI Network Card 553-7332 ISDN Signaling Link (ISL) hardware The following hardware is required for ISDN Signaling Link (ISL) capability and applications.
  • Page 22 Smart Modems from power spikes and noisy lines. To increase the reliability on this configuration, use a constant power source when powering the modems. Also, verify that TIE lines meet data grade specifications. Nortel Networks takes no responsibility for ISL D-Channel outages due to modem lockup. •...

  • Page 23: D-Channel Handler Description

    ISDN Primary Rate Interface equipment overview Page 23 of 394 Equipment required for dedicated mode using a DTI/DTI2 trunk: • NT6D11(AB/AE/AF) D-Channel (DCH) card (for 2.0 Mb PRI) • QPC757 D-channel (DCH) for (1.5 Mb PRI) • NT6D80 Multipurpose Serial Data Link (MSDL) card •...

  • Page 24: Dch/Pri Interface

    Page 24 of 394 ISDN Primary Rate Interface equipment overview DCH/PRI interface The NT6D11AB/AE/AF DCHs connect to the PRI2 cards by means of a special RS422 cable, the QCAD328A, which is a special RS422 cable; refer to “QCAD328” on page 389 of the Cabling chapter for more details.
  • Page 25 ISDN Primary Rate Interface equipment overview Page 25 of 394 Figure 2 NT6D11 DCH faceplate layout Status LED The DCHI LED indicates the statusof both ports on the DCHI card. If both ports are configured, the LED is lit only when both ports are disabled.

  • Page 26: Qpc757 Dch

    Page 26 of 394 ISDN Primary Rate Interface equipment overview QPC757 DCH Power requirements The power requirements for the QPC757 DCH are: • +5 volts at 3 amperes • +12 volts at 50 milliamperes • –12 volts at 50 milliamperes DCH/PRI interface The QPC757 DCH connects to the QPC720 PRI via a RS-422 cable.
  • Page 27 ISDN Primary Rate Interface equipment overview Page 27 of 394 Note: A QPC757 vintage C is required if the ISL Revert to Conventional Signaling feature is configured. The QPC757 vintage D is recommended for combination ISL/PRI networks using NACD or Network Message Services and ISL networks using modems.

  • Page 28: Nt6D80 Msdl

    Page 28 of 394 ISDN Primary Rate Interface equipment overview NT6D80 MSDL The NT6D80 MSDL card can be used in conjunction with, or independent of, the QPC757, or NT6D11AB/AE/AF DCH. Power requirements The NT6D80 MSDL power requirements are: Voltage Current Power Heat (VAC)
  • Page 29 ISDN Primary Rate Interface equipment overview Page 29 of 394 Figure 4 NT6D80 MSDL faceplate layout Care Locking Device Card Address Select Switches Ones Tens S9 S10 Setting for an RS-232 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 9 10 interface DTE/DCE are Port 0 software configured...

  • Page 30: Ntbk51 Downloadable D-Channel Daughterboard

    Page 30 of 394 ISDN Primary Rate Interface equipment overview NTBK51 Downloadable D-Channel Daughterboard The NTBK51 is a two port Downloadable D-Channel Daughterboard (DDCH) that has been introduced as an option to the NT6D80 MSDL, the NT5D97 dual-port DTI2/PRI2 card, or the NT5D12 dual-port 1.5 Mb DTI/PRI card.

  • Page 31: Nt8D72 Pri2

    ISDN Primary Rate Interface equipment overview Page 31 of 394 NT8D72 PRI2 Power requirements The NT8D72AB and NT8D72BA PRI use power and ground connections from the backplane. Power requirements are: +5 volts at 4 amperes +12 volts at 50 milliamperes -12 volts at 50 milliamperes NT8D72 faceplate The NT8D72 contains five LEDs and six external connectors.
  • Page 32 Page 32 of 394 ISDN Primary Rate Interface equipment overview Figure 5 NT8D72 PRI faceplate layout OOS: Card is out of service ACT: Card is enabled LOCAL: Local alarm - local card or transmission fault RAI: Remote alarm - far end fault LBK: Loop -back test - see PRI tests RCV MON: Access point to regenerated CEPT signal from the external network...

  • Page 33: Cable Requirements

    ISDN Primary Rate Interface equipment overview Page 33 of 394 Table 2 gives information about the external connectors located on the NT8D72 PRI2 faceplate. Table 2 NT8D72 PRI External connectors Faceplate Destination Type Description 9-pin female, D-connector Reference Clock 0 interface 9-pin female, D-connector Reference Clock 1 interface 36-pin connector...

  • Page 34: Carrier Interface

    Page 34 of 394 ISDN Primary Rate Interface equipment overview Table 3 NT8D72AB and NT8D72BA PRI: Cables and cable lengths (Part 2 of 2) QCAD328B PRI card DCH card QCAD328C PRI card DCH card 10.67 QCAD328D PRI card DCH card 15.24 NTND26AA PRI card...

  • Page 35: Qmt21 High Speed Data Module

    ISDN Primary Rate Interface equipment overview Page 35 of 394 QMT21 High Speed Data Module The QMT21 High Speed Data Module supports the 64K Clear Data feature. (It allows data terminating equipment (DTE) to send and receive 64-Kb/s clear data.) The QMT21B is required for Large System to Large System configurations.
  • Page 36 Page 36 of 394 ISDN Primary Rate Interface equipment overview Figure 6 Clock controller primary and secondary tracking Clock Controller 0 Primary Primary REF 1 clocking Primary source Reference Primary REF 2 Clock Controller Backup Secondary Secondary REF 1 clocking Secondary Clock source...
  • Page 37 ISDN Primary Rate Interface equipment overview Page 37 of 394 Reference clock errors The system software checks at intervals of 1 to 15 minutes to see if a clock controller or reference-clock error has occurred. (The interval of this check can be configured in LD 73.) In tracking mode, at any one time, there is one active clock controller which is tracking on one reference clock.

  • Page 38: Qpc720 Pri

    Page 38 of 394 ISDN Primary Rate Interface equipment overview Automatic clock switching If the EREF command is selected in LD 60, tracking on the primary or secondary reference clock is automatically switched in the following manner: If software is unable to track on the assigned primary reference clock, it switches to the secondary reference clock and sends appropriate DTC maintenance messages.
  • Page 39 ISDN Primary Rate Interface equipment overview Page 39 of 394 Figure 7 QPC720 PRI faceplate layout DIS: Card is disabled ACT: Card is enabled RED: Red alarm (local alarm)-card or transmission fault YEL: Yellow alarm (remote alarm)-far end fault LBK: Loop -back test - see PRI tests RCV MON: Access point to regenerated DS-1 signal from the external network XMT MON: Access pont to DS-1 signal being transmitted...

  • Page 40: Qpc720 Cable Requirements

    Page 40 of 394 ISDN Primary Rate Interface equipment overview Faceplate destination Type 15-pin male, D-connector 15-pin male, D-connector 15-pin female, D-connector RCV MON Miniature bantam jack XMT MON Miniature bantam jack QPC720 Cable requirements Table 5 on page 41 lists the types of cable used and the lengths required for external QPC720 PRI connections.

  • Page 41: Echo Canceller Interface

    ISDN Primary Rate Interface equipment overview Page 41 of 394 In the U.S.A., FCC Part 68 regulations require Network Channel Terminating Equipment (for example, the NT QRY551 Channel Service Unit) installed at of the point of connection between a system and a registered common carrier trunk.

  • Page 42: Disk Drive Hardware

    Page 42 of 394 ISDN Primary Rate Interface equipment overview Table 5 QPC720 PRI cables and cable lengths (Part 2 of 2) Maximum Maximum length Cable type From length (feet) (meters) QCAD328B QPC720 QPC757 DCHI QCAD328C QPC720 QPC757 DCHI 10.67 QCAD328D QPC720 QPC757 DCHI...

  • Page 43: Nt5D97 Dual-Port Dti2/Pri2 Card

    ISDN Primary Rate Interface equipment overview Page 43 of 394 NT5D97 Dual-port DTI2/PRI2 card The NT5D97 is a dual-port 2.0 Mb DTI2/PRI2 card (the DDP2 firmware functions in DTI2 or PRI2 mode, depending on DIP switch settings) that integrates the functionality of two NT8D72BA PRI2 cards, and one QPC414 ENET card into a single CE card.

  • Page 44: External D-Channel Interface Dch Or Msdl

    Page 44 of 394 ISDN Primary Rate Interface equipment overview External D-Channel Interface DCH or MSDL The connection between the DDP2 card and the external DCH or MSDL is through a 26 pin female D type connector. The data signals conform to the electrical characteristics of the EIA standard RS-422.

  • Page 45: Nt5D97 Faceplate

    ISDN Primary Rate Interface equipment overview Page 45 of 394 NT5D97 faceplate Figure 8 on page 46 illustrates the faceplate layout for the NT5D97 DDP card. The faceplate contains an enable/disable switch; a DDCH status LED; 6 x 2 trunk port status LEDs; and six external connectors. Table 7 on page 47 shows the name of each connector, its designation with respect to the faceplate and the name and description of the card it is connected to.
  • Page 46 Page 46 of 394 ISDN Primary Rate Interface equipment overview Figure 8 NT5D97 faceplate D-Channel LED ENET LED Trunk Disable LED Trunk Out of Service LED Near End Alarm LED Far End Alarm LED Loop Back LED Recovered Clock0#1 Recovered Clock0#2 Recovered Clock1#1 Recovered Clock1#2 Trunk0 / Trunk1...
  • Page 47 ISDN Primary Rate Interface equipment overview Page 47 of 394 Table 7 External connectors and LEDs Faceplate Function Designator Type Description Switch ENB/DIS Plastic, ESD protected Card Enable/disable switch Connectors Unit 0 Clock 0 RJ11 Connector Connects reference clock 0 to Clock Controller card 0 Unit 0 Clock 1 RJ11 Connector...
  • Page 48 Page 48 of 394 ISDN Primary Rate Interface equipment overview The following is a brief description of each element on the faceplate. Enable/Disable Switch This switch is used to disable the card prior to insertion or removal from the network shelf. While this switch is in disable position, the card will not respond to the system CPU.
  • Page 49 ISDN Primary Rate Interface equipment overview Page 49 of 394 LBK LEDs Two yellow LEDs indicate if a remote loopback test is being performed on trunk port 0 or trunk port 1. The loopback indication is active when the digital trunk is in remote loopback mode.

  • Page 50: System Capacity And Performance

    Page 50 of 394 ISDN Primary Rate Interface equipment overview System capacity and performance Physical capacity Each NT5D97 DDP2 card occupies one slot on the network shelf. Each card supports two digital trunk circuits and two network loops. The total number of DDP2 cards per system is limited by the number of network loops, physical capacity of the shelf, number of DTI2/PRI2 interfaces allowed by the software and the range of DCH addresses.

  • Page 51: Testability And Diagnostics

    ISDN Primary Rate Interface equipment overview Page 51 of 394 Table 8 NT5D97 DDP2 power requirements Voltage Source Current DDP2 DDP2 (without (with NTBK51AA) NTBK51AA) Backplane 3.8A +12V Backplane 25mA 75mA -12V Backplane 25mA 75mA Total Power (Maximum) 15.6W 20.8W Testability and diagnostics The DDP2 card supports testing and maintenance functions through the following procedures:...
  • Page 52 Page 52 of 394 ISDN Primary Rate Interface equipment overview DDP2 cable assemblies include: • E1 carrier cables — NTCK45AA (A0407956) — NT8D7217 (A0617192) — NTCK78AA (A0618294) — NTCK79AA (A0618296) • DDP2 to QPC471/QPC775 Clock Controller Cables — NTCG03AA — NTCG03AB —...
  • Page 53 ISDN Primary Rate Interface equipment overview Page 53 of 394 E1 carrier cables NTCK45AA (A0407956) The NTCK45AA (8 ft.) is an 120Ω cable for systems equipped with an I/O filter panel, connecting the TRK port (P1, D-type 9 pin male) on the DDP2 faceplate to the I/O filter (P2, P3 D-type 9 pin males).
  • Page 54 Page 54 of 394 ISDN Primary Rate Interface equipment overview Table 9 NTCK45AA cable pins (Part 2 of 2) DDP2 I/O Panel Cable Name Description Color pins pins R-PRI1TX Trunk 1 Transmit Ring P1-6 P3-7 T-PRI1RX Trunk 1 Receive Tip Black P1-7 P3-2...
  • Page 55 ISDN Primary Rate Interface equipment overview Page 55 of 394 Table 10 which follows lists the pin attributes for the NT8D7217 cable. Table 10 NT8D7217 cable pins DDP2 I/O Panel Cable Name Description Color pins pins T-PRI0TX Trunk 0 Transmit Tip Black P1-6 P2-6...
  • Page 56 Page 56 of 394 ISDN Primary Rate Interface equipment overview Figure 11 NTCK78AA D-type D-type 9 pin, males 15 pin, males 553-7385 Table 11 lists the pin attributes for the NTCK78AA cable. Table 11 NTCK78AA cable pins DDP2 Cable Name Description Color pins...
  • Page 57 ISDN Primary Rate Interface equipment overview Page 57 of 394 NTCK79AA (A0618296) The NTCK79AA (40 ft) is a 75Ω coaxial cable for connecting the TRK port on the DDP2 faceplate (P1, D-type 9 pin male) to the Line Terminating Unit (LTU) (P2, P3, P4, P5 BNC males).
  • Page 58 Page 58 of 394 ISDN Primary Rate Interface equipment overview Table 12 NTCK79AA cable pins (Part 2 of 2) DDP2 Cable Name Description Color pins NCTE pins R-PRI1RX Trunk 1 Receive Ring Green P1-8 P5 shield Outer metalized PVC Bare P1 Case shield 3 stranded wire...
  • Page 59 ISDN Primary Rate Interface equipment overview Page 59 of 394 • NTCK46AB (18 ft.) - DDP2 to DCH cable • NTCK46AC (35 ft.) - DDP2 to DCH cable • NTCK46AD (50 ft.) - DDP2 to DCH cable Figure 14 NTCK46AA/AB/AC/AD D-type 9 pin, males D-type...

  • Page 60: Cable Diagrams

    Page 60 of 394 ISDN Primary Rate Interface equipment overview Cable diagrams Figure 16 on page 61 and Figure 17 on page 62 provide examples of typical cabling configurations for the DDP2. Figure 16 on page 61 shows a typical DDP2 cabling for a system with an I/O panel, with the connection between the I/O panel and a Network Channel Terminating Equipment (NCTE).
  • Page 61 ISDN Primary Rate Interface equipment overview Page 61 of 394 Figure 16 DDP2 cable for systems with an I/O panel Switch Clock Controllers LEDs clk0 Port 0 clk1 clk0 NCTE Port 1 NCTE (MDF or LTU) clk1 NT8D7217 cable Trunk NTCK78AA/NTCK79AA cable NT8D7217 cable NTCK80 cable to MSDL or...
  • Page 62 Page 62 of 394 ISDN Primary Rate Interface equipment overview Figure 17 DDP2 cable for systems without an I/O panel Switch Clock Controllers NTCG03 cables LED's clk0 Unit 0 clk1 NCTE clk0 Unit 1 (MDF or LTU) clk1 Trunk NTCK78AA/NTCK79AA cable NTCK80 cable to MSDL or NTCK48 cable to DCHI NT6D80 MSDL or...

  • Page 63: Clock For The Nt5D97

    ISDN Primary Rate Interface equipment overview Page 63 of 394 Clock for the NT5D97 Clock operation There are two types of clock operation — tracking mode and free-run mode. Tracking mode In tracking mode, the DDP2 loop supplies an external clock reference to a clock controller.
  • Page 64 Page 64 of 394 ISDN Primary Rate Interface equipment overview Figure 18 Clock Controller primary and secondary tracking Clock Controller 0 Primary Primary REF 1 clocking Primary source Reference Primary REF 2 Clock Controller Backup Secondary Secondary REF 1 clocking Secondary Clock source...
  • Page 65 ISDN Primary Rate Interface equipment overview Page 65 of 394 Reference clock errors The system software checks at intervals of 1 to 15 minutes to see if a clock controller or reference-clock error has occurred. (The interval of this check can be configured in LD 73).
  • Page 66 Page 66 of 394 ISDN Primary Rate Interface equipment overview Automatic clock switching If the EREF command is selected in LD 60, tracking on the primary or secondary reference clock is automatically switched in the following manner: • If software is unable to track on the assigned primary reference clock, it switches to the secondary reference clock and sends appropriate DTC maintenance messages.
  • Page 67 ISDN Primary Rate Interface equipment overview Page 67 of 394 Table 13 summarizes the clocking options. Table 14 on page 68 explains the options in more detail. Table 13 Clock Controller options - summary CC Option CPU Type Notes Option 1 Single Ref from P0 on Clk0 Ref from P1 on Clk0...
  • Page 68 Page 68 of 394 ISDN Primary Rate Interface equipment overview Table 14 Clock Controller options - description Clock Notes Option Option 1 This option provides a single CPU system with 2 clock sources derived from the 2 ports of the DDP2. Connector Clk0 provides a clock source from Unit 0.
  • Page 69 ISDN Primary Rate Interface equipment overview Page 69 of 394 Figure 19 Clock Controller – Option 1 Clock Controller 0 Primary Primary REF 1 clocking Primary source Reference Primary REF 2 Clock Controller Backup Secondary Secondary REF 1 clocking Secondary Clock source Reference...
  • Page 70 Page 70 of 394 ISDN Primary Rate Interface equipment overview Figure 20 Clock Controller – Option 2 Clock Controller for CPU 0 J1 Sec. DDP2 Primary Ref 1 Primary clk 0 J2 Prim. Reference Port 0 Primary Ref 2 clk 1 Clk0 Port 1 Secondary Ref 1...
  • Page 71 ISDN Primary Rate Interface equipment overview Page 71 of 394 Figure 21 Clock Controller – Option 3 DDP2 clk 0 Clock Controller Port 0 for CPU 0 clk 1 J1 Sec. Primary Ref 1 Primary Clk0 J2 Prim. Reference Port 1 Primary Ref 2 Clk1 Secondary Ref 1...

  • Page 72: Nt5D12 Dual-Port Dti/Pri

    Page 72 of 394 ISDN Primary Rate Interface equipment overview Figure 22 Clock Controller – Option 4 Clock Controller for CPU 0 DDP2 J1 Sec. Primary Ref 1 Primary clk 0 J2 Prim. Reference Port 0 Primary Ref 2 clk 1 Secondary Ref 1 Clock Controller Secondary...

  • Page 73: D-Channel And Msdl Interface

    ISDN Primary Rate Interface equipment overview Page 73 of 394 The NT5D12 DDP card supports all features (except the echo canceller and protocol conversion) of the QPC720. In addition, it maintains the backward compatibility of QPC720. The NT5D12 DDP card hardware design uses a B57 ASIC E1/T1 framer. The carrier specifications comply with the ANSI TI.403 specification.
  • Page 74 Page 74 of 394 ISDN Primary Rate Interface equipment overview Table 15 indicates how the RR control signal operates with regard to the DDP status. Table 15 DCHI/MSDL Receiver Ready control signals RR State Condition D-Channel data rate selected at 64 Kbps or 56 Kbps or 64 Kbps inverted PRI loop is enabled PRI link is not in RED alarm mode state...

  • Page 75: Nt5D12 Faceplate

    ISDN Primary Rate Interface equipment overview Page 75 of 394 NT5D12 faceplate Figure 23 on page 76 and Figure 24 on page 77 illustrate the faceplate layout for the NT5D12 DDP card. The faceplate contains an enable/disable switch; a DDCH status LED; 6 x 2 trunk port status LEDs; and six external connectors.
  • Page 76 Page 76 of 394 ISDN Primary Rate Interface equipment overview Figure 23 NT5D12 faceplate - general view Dual PRI clk0 Port 0 clk1 clk0 Port 1 clk1 NT5D12AA Rlse 01 P0 P1 Loop Loop DCH DCH 553-3001-201 Standard 2.00 September 2004...
  • Page 77 ISDN Primary Rate Interface equipment overview Page 77 of 394 Figure 24 DDP faceplate - detailed view Dual PRI D-Channel LED Card Enable / Disable Switch P0 P1 Port Out Of Service LED Trunk Port Disable LED Trunk Port Active LED Red Alarm LED Yellow Alarm LED Loop Back LED...
  • Page 78 Page 78 of 394 ISDN Primary Rate Interface equipment overview Table 16 External connectors and LEDs Faceplate Function Designator Type Description Switch ENB/DIS Plastic, ESD Card Enable/disable switch protected Port 0 Clock 0 RJ11 Connector Connects reference clock to Clock Controller card Port 0 Clock 1 RJ11 Connector Connects reference clock to...
  • Page 79 ISDN Primary Rate Interface equipment overview Page 79 of 394 Faceplate Function Designator Type Description 2 Red LEDs ENET 0 or ENET 1 disabled 2 Red LEDs Trunk 0 or Trunk 1 disabled 2 Green LEDs Trunk 0 or Trunk 1 lines active 2 Red LEDs Red Alarm on Trunk 0 or...
  • Page 80 Page 80 of 394 ISDN Primary Rate Interface equipment overview Trunk Port Disable LEDs Two red LEDs indicate if the “trunk port 0” and “trunk port 1” portion of the card are disabled. These LEDs are turned on in the following cases: •...

  • Page 81: System Capacity And Performance

    ISDN Primary Rate Interface equipment overview Page 81 of 394 Port 0 Clk Connectors Two RJ11 connectors for connecting: • Digital trunk port 0 recovered clock to primary or secondary reference source on clock controller card 0. • Digital trunk port 0 recovered clock to primary or secondary reference source on clock controller card 1.

  • Page 82: Power Requirements

    Page 82 of 394 ISDN Primary Rate Interface equipment overview D-Channel capacity The software configuration for the NTBK51AA DDCH is similar to the MSDL. It is both physical and logical, and supports D-Channel functionality only. The system has a total capacity of 16 addresses (Device Addresses or DNUM) that can be reserved for DCHI card, MSDL card or DDCH card.

  • Page 83: Testability And Diagnostics

    ISDN Primary Rate Interface equipment overview Page 83 of 394 Table 17 DDP power requirements Voltage Source Current DDP (without DDP (with NTBK51AA) NTBK51AA) Backplane 3.8A +12V Backplane 25mA 75mA -12V Backplane 25mA 75mA Total Power (Maximum) 15.6W 20.8W Testability and diagnostics The DDP card supports all current QPC720 testing and maintenance functions through the following procedures: •...

  • Page 84: Trunk Tip/Ring Cables

    Page 84 of 394 ISDN Primary Rate Interface equipment overview New DDP cable assemblies include: • System Trunk Tip/Ring Cables — NT5D16AA — NT5D17AA — QCAD133 • DDP to QPC471/QPC775 Clock Controller Cables — NTCG03AA — NTCG03AB — NTCG03AC — NTCG03AD •...
  • Page 85 ISDN Primary Rate Interface equipment overview Page 85 of 394 Note: On the I/O panel side, this cable is equipped with a monitor bantam plug and a 15 pin D-type trunk connector mounted on a small PCB. There are no bantam plugs on the DDP faceplate. Figure 25 NT5D16AA 8 ft.

  • Page 86: Reference Clock Cables

    Page 86 of 394 ISDN Primary Rate Interface equipment overview Table 18 NT5D16AA cable pins (Part 2 of 2) I/O Panel Cable Name Description Color pins (J5) pins (J2, J3) GND Shield Wire Bare Case P0 GND Shield Wire Bare Case P0 T-PRI1TX Trunk 1 Transmit Tip...

  • Page 87: Msdl/Dchi Cables

    ISDN Primary Rate Interface equipment overview Page 87 of 394 Figure 26 NTCG03AA, NTCG03AB, NTCG03AC, or NTCG03AD 14, 7, 4, or 2.8 ft. Connector P1 - 4 pin, male, RJ11 (DDP faceplate) Connector P2 - 9 pin, male, D-type (Clock Controller) Note: Includes an RJ11<-->9 pin D-type adaptor.

  • Page 88: Cable Diagrams

    Page 88 of 394 ISDN Primary Rate Interface equipment overview External MSDL cable The NTCK80 cable connects the DDP card to the NT6D80 MSDL card. The cable is available in four different sizes: • NTCK80AA (6 ft.) - DDP to MSDL cable •...

  • Page 89: Clock

    ISDN Primary Rate Interface equipment overview Page 89 of 394 Figure 29 DDP cable for systems with an I/O panel Switch Clock Controllers for possible Leds clock cabling options, refer NTCG03 cables clk0 to the Port 0 "Clocking clk1 configurations" clk0 chapter Port 1...
  • Page 90 Page 90 of 394 ISDN Primary Rate Interface equipment overview Tracking mode In tracking mode, the DDP loop supplies an external clock reference to a clock controller. Two DDP loops can operate in tracking mode, with one defined as the primary reference source for clock synchronization, the other defined as the secondary reference source.
  • Page 91 ISDN Primary Rate Interface equipment overview Page 91 of 394 Figure 30 Clock Controller primary and secondary tracking Clock Controller 0 Primary Primary REF 1 clocking Primary source Reference Primary REF 2 Clock Controller Backup Secondary Secondary REF 1 clocking Secondary Clock source...
  • Page 92 Page 92 of 394 ISDN Primary Rate Interface equipment overview Reference clock errors The system software checks at intervals of 1 to 15 minutes to see if a clock controller or reference-clock error has occurred. (The interval of this check can be configured in LD 73.) In tracking mode, at any one time, there is one active clock controller which is tracking on one reference clock.
  • Page 93 ISDN Primary Rate Interface equipment overview Page 93 of 394 Automatic clock switching If the EREF command is selected in LD 60, tracking on the primary or secondary reference clock is automatically switched in the following manner: • If software is unable to track on the assigned primary reference clock, it switches to the secondary reference clock and sends appropriate DTC maintenance messages.
  • Page 94 Page 94 of 394 ISDN Primary Rate Interface equipment overview Table 19 Clock Controller options- summary CC Option CPU Type Notes Option 1 Single Ref from P0 on Clk0 Ref from P1 on Clk0 Option 2 Dual Ref from P0 on Clk0 Ref from P0 on Clk1 Option 3 Dual...
  • Page 95 ISDN Primary Rate Interface equipment overview Page 95 of 394 Table 20 Clock Controller options - description (Part 1 of 2) Clock Option Notes Option 1 This option provides a single CPU system with 2 clock sources derived from the 2 ports of the DDP. Connector Clk0 provides a clock source from Port 0.
  • Page 96 Page 96 of 394 ISDN Primary Rate Interface equipment overview Table 20 Clock Controller options - description (Part 2 of 2) Clock Option Notes Option 3 This option provides a Dual CPU system with 2 references of a clock source derived from port 1 of the DDP.
  • Page 97 ISDN Primary Rate Interface equipment overview Page 97 of 394 Figure 31 Clock Controller - Option 1 CC for CPU Clk 0 Secondary Ref J1 Sec Port 0 Primary Ref Clk 1 Secondary Reference J2 Pri Clk 0 Port 1 Clk 1 Primary Reference One Reference from each port...
  • Page 98 Page 98 of 394 ISDN Primary Rate Interface equipment overview Figure 32 Clock Controller - Option 2 DDP 1 CC for CPU0 Clk 0 Port 0 J1 Sec Primary Reference Primary Ref 1 Clk 1 J2 Pri Clk 0 CC for CPU1 Port 1 Clk 1 J1 Sec...
  • Page 99 ISDN Primary Rate Interface equipment overview Page 99 of 394 Figure 33 Clock Controller - Option 3 DDP1 CC for CPU0 Clk 0 J1 Sec Port 0 Primary Ref 1 Clk 1 J2 Pri Clk 0 CC for CPU1 Primary Reference Port 1 Clk 1 J1 Sec...
  • Page 100 Page 100 of 394 ISDN Primary Rate Interface equipment overview Figure 34 Clock Controller - Option 4 CC for CPU0 Secondary Ref 1 Clk 0 J1 Sec Primary Ref 1 Port 0 J2 Pri Clk 1 Primary Reference CC for CPU1 Clk 0 Secondary Ref 2 J1 Sec...

  • Page 101: Dch Installation

    Page 101 of 394 DCH installation Contents The section contains information on the following topics: Install the NT6D11AB, NT6D11AE, NT6D11AF DCH ... Install the NT6D11AB, NT6D11AE, NT6D11AF DCH ... Set up the NT6D11AB, NT6D11AE, NT6D11AF DCHI .

  • Page 102: Set Up The Nt6D11Ab, Nt6D11Ae, Nt6D11Af Dchi

    Page 102 of 394 DCH installation Note: To configure J1, the asynchronous port on the DCHI card, refer to the documentation of the application being interfaced, and to Circuit Card: Description and Installation (553-3001-211). J1 configuration is not described in this NTP. Set up the NT6D11AB, NT6D11AE, NT6D11AF DCHI DIP switch settings The NT6D11AB/AE/AF has three sets of DIP switches.
  • Page 103 DCH installation Page 103 of 394 The DIP switches are located as shown by Figure 35. Figure 35 NT6D11 DIP switches PORT 0 PORT 1 553-7349 ISDN Primary Rate Interface Installation and Configuration...

  • Page 104: Protocol Selection

    Page 104 of 394 DCH installation Protocol selection SW3 is used to select the D-channel protocol, as shown by Table 21. Note: The setting must be 1 for ISDN applications. Table 21 Protocol selection switch settings Protocol Switch Setting SW3.1 SW3.2 DPNSS1 ISDN...

  • Page 105: Jumper Settings

    DCH installation Page 105 of 394 Port 1 The following are the only valid emulation mode combinations. If the port is configured as disabled, it will not be visible to the system CPU. Refer to Table 23. Note: The ISDN emulation must be selected. Table 23 Port 1 settings Mode...
  • Page 106 Page 106 of 394 DCH installation Figure 36 NT6D11 DCH with ISL high-speed programming jumper settings RS-232 RS-422 PORT 0 RS-232 RS-422 RS-232 RS-422 PORT 1 RS-232 RS-422 553-7350 553-3001-201 Standard 2.00 September 2004...

  • Page 107: Port Addressing Modes

    DCH installation Page 107 of 394 Figure 37 NT6D11 DCH with ISL low-speed programming jumper settings RS-232 RS-422 PORT 0 RS-232 RS-422 RS-232 RS-422 PORT 1 RS-232 RS-422 553-7351 Port addressing modes Port 0 Mode selection Port 0 is used to select whether the asynchronous ESDI port is be disabled or not.
  • Page 108 Page 108 of 394 DCH installation Table 24 (Part 2 of 2) Port 0 mode selection Not used Asynchronous ESDI Port disabled Port 1 mode selection Port 1 is used to select the standard or expanded D-channel addressing mode on the NT6D11AB/AE/AF. Refer to Table 25. Table 25 Port 1 mode selection Port Mode...

  • Page 109: Port Address Switch Settings

    DCH installation Page 109 of 394 Port address switch settings Port address switch settings in the standard mode, for ISDN Table 26 depicts the port address switch settings that apply to SW1 or SW2, the D-channel port, for ISDN mode. Table 26 Port address switch settings for ISDN (Part 1 of 2) Port Address...

  • Page 110: Install The Nt6D11Ab, Nt6D11Ae, Nt6D11Af Dchi

    Page 110 of 394 DCH installation Table 26 Port address switch settings for ISDN (Part 2 of 2) Port Address Switch Setting Half Group No. Device No. 16-31 32-47 48-63 64-79 80-95 96-111 112-127 Install the NT6D11AB, NT6D11AE, NT6D11AF DCHI Follow Procedure 1 to install the NT6D11 DCH on the Large System.

  • Page 111: Remove The Nt6D11Ab, Nt6D11Ae, Nt6D11Af Dch

    DCH installation Page 111 of 394 Set faceplate toggle switch to DISABLE. Install the DCHI card into the assigned shelf and slot. Connect DCHI port J2 to the NT8D72AB or NT8D72BA PRI port J5 with a QCAD328A cable. Set faceplate toggle switch to ENABLE. Coordinate the start-up and verification of the DCHI with the start-up of the PRI.

  • Page 112: Install The Qpc757 Dch

    Page 112 of 394 DCH installation Pack and store the card. End of Procedure Install the QPC757 DCH Installation procedures for the QPC757 DCHI card are the same for all Large Systems. These procedures apply to both primary and backup D-channels.
  • Page 113 DCH installation Page 113 of 394 10 Enable the DCHI card using LD 96, command ENL DCH x. End of Procedure Figure 38 QPC757 option and PRI/ISL high-speed programming switch settings QPC757C DCHI 1 2 3 4 Port address switch Jumper Jumpers for port RS-232...

  • Page 114: Port Address Switch Settings

    Page 114 of 394 DCH installation Figure 39 QPC757 option and PRI/ISL low-speed programming switch settings RS-232 RS-422 PORT 0 RS-232 RS-422 RS-232 RS-422 PORT 1 RS-232 RS-422 553-7351 Port address switch settings Table 27 shows the port address switch settings that apply to SW1, SW2 (the D-channel port), SW3, and SW4.

  • Page 115: D-Channel Parameter Downloading

    DCH installation Page 115 of 394 Table 27 D-channel port address switch settings for PRI (Part 2 of 2) Port Address Switch Settings Port Number D-channel parameter downloading The system software automatically downloads new parameters to each D-channel Interface (DCHI) circuit card upon SYSLOAD. When this occurs, the D-channel is temporarily disabled and then automatically reenabled.

  • Page 116: Remove The Qpc757 Dchi

    Page 116 of 394 DCH installation Remove the QPC757 DCHI Use Procedure 4 to remove the QPC757 DCHI card from Large Systems. CAUTION The QPC757 DCH must be software disabled before it is hardware disabled to prevent initialization Procedure 4 Remove the QPC757 DCH Disable the QPC757 DCHI using LD 96, command DIS DCH x.

  • Page 117: Ntbk51 Ddch Installation And Removal

    Page 117 of 394 NTBK51 DDCH installation and removal Contents This section contains information on the following topics: Introduction ..........Install NTBK51 DDCH on NT5D97 dual-port DTI2/PRI2 card .

  • Page 118: Install Ntbk51 Ddch On Nt5D97 Dual-Port Dti2/Pri2 Card

    Page 118 of 394 NTBK51 DDCH installation and removal • Remember that either the DDCH, the MSDL, or NT5D97, or NT5D12 card can be installed first. However, NT5D97 PRI2 loops, and NT5D12 PRI loops, must be configured in software before defining DCH links. Install NTBK51 DDCH on NT5D97 dual-port DTI2/PRI2 card Installation procedures for the NTBK51 DDCH are the same for all Large Systems.

  • Page 119: Remove Ntbk51 Ddch From Nt5D97 Dual-Port

    NTBK51 DDCH installation and removal Page 119 of 394 Set the DDP2 ENB/DIS faceplate switch to Enable (ON). The DDCH LED then flashes three times. End of Procedure Remove NTBK51 DDCH from NT5D97 dual-port DTI2/PRI2 card Removal procedures for the NTBK51 DDCH are the same for all Large Systems.

  • Page 120: Remove Ntbk51 Ddch From Nt5D12 Dual-Port Dti/Pri

    Page 120 of 394 NTBK51 DDCH installation and removal CAUTION A static discharge bracelet must be worn before handling circuit cards. Failure to wear the bracelet can result in damage to the circuit cards. The DDCH can be mounted on any DDP card. Follow the steps in Procedure 7 to install the NTBK51 on the NT5D12 dual-port DTI/PRI card.
  • Page 121 NTBK51 DDCH installation and removal Page 121 of 394 Procedure 8 Remove the NTBK51 from the NT5D12 dual-port DTI/PRI card Disable the faceplate switch on the DDP. Remove the DDP and DDCH. End of Procedure ISDN Primary Rate Interface Installation and Configuration...
  • Page 122 Page 122 of 394 NTBK51 DDCH installation and removal 553-3001-201 Standard 2.00 September 2004...

  • Page 123: Msdl Installation For All Systems

    Page 123 of 394 MSDL installation for all systems Contents The section contains information on the following topics: Install the MSDL......... . Replace the MSDL .
  • Page 124 Page 124 of 394 MSDL installation for all systems Insert the MSDL card into the selected card slot of the module following the card guides. Observe the red LED on the MSDL faceplate. If it turns on, flashes three times, and stays on continuously, the MSDL is operating correctly but is not yet enabled.
  • Page 125 MSDL installation for all systems Page 125 of 394 Figure 40 MSDL card layout Card Address Select Switches Ones Tens S9 S10 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 9 10 Port 0 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 9 10...
  • Page 126 Page 126 of 394 MSDL installation for all systems Table 28 MSDL switch settings (Part 2 of 2) RS-422-A RS-422-A Port 1—SW3 Port 1—SW7 RS-232-D RS-422-A RS-422-A Port 2—SW2 Port 2—SW6 RS-232-D RS-422-A RS-422-A Port 3—SW1 Port 3—SW5 RS-232-D RS-422-A RS-422-A 553-3001-201 Standard 2.00...

  • Page 127: Replace The Msdl

    MSDL installation for all systems Page 127 of 394 Replace the MSDL Replacement procedures for the MSDL card are the same for all Large Systems. Use Procedure 10 below. Procedure 10 Replace the MSDL card Disable the MSDL card in LD 96. Disconnect MSDL to PRI cables.
  • Page 128 Page 128 of 394 MSDL installation for all systems 553-3001-201 Standard 2.00 September 2004...

  • Page 129: Nt8D72 And Qpc720 Pri Card Installation

    Page 129 of 394 NT8D72 and QPC720 PRI card installation Contents The section contains information on the following topics: Introduction ..........PRI circuit pack locations .

  • Page 130: Cable Requirements

    Page 130 of 394 NT8D72 and QPC720 PRI card installation Note 1: Due to physical width, Bus Terminating Units (BTUs) and PRIs cannot fit next to each other on a shelf. Note 2: This chapter includes instructions for installing an additional network shelf on a system (when no vacant Network slots are available to install PRI packs, additional network shelves can replace Intelligent Peripheral Equipment shelves located on the rear of the Common...
  • Page 131 NT8D72 and QPC720 PRI card installation Page 131 of 394 Figure 41 NT8D72(Half Group cabling) on Half and Single Group systems without an echo canceller NT8D79AA to PRI Card (Secondary reference) NT8D72AA PRI Card (Primary reference) NT8D79AA REF1 QPC471 Clock Controller No connection REF2...
  • Page 132 Page 132 of 394 NT8D72 and QPC720 PRI card installation Figure 42 NT8D72 (Half Group cabling) for Half and Single Group systems, with an echo canceller NT8D79AA to PRI Card (Secondary reference) NT8D72 PRI Card (Primary reference) NT8D79AA REF1 QPC471 Clock Controller No connection...
  • Page 133 NT8D72 and QPC720 PRI card installation Page 133 of 394 Figure 43 NT8D72 (Single Group cabling) for Half and Single Group systems, without an echo canceller NT8D79AA to PRI Card (Secondary reference) NT8D72AA NT8D79AA PRI Card NT8D79AA (Primary reference) NT8D79AA QPC775 REF1 Clock...
  • Page 134 Page 134 of 394 NT8D72 and QPC720 PRI card installation Figure 44 NT8D72 (Single Group cabling) for Half and Single Group systems, with an echo canceller NT8D79AA to PRI Card (Secondary reference) NT8D72AA NT8D79AA NT8D79AA PRI Card (Primary reference) NT8D79AA QPC775 REF1 Clock...
  • Page 135 NT8D72 and QPC720 PRI card installation Page 135 of 394 Figure 45 NT8D72 (Multi Group cabling) for Multi Group systems without an echo canceller QCAD130 to PRI Card PRI Card (Secondary reference) (Primary reference) QCAD130 QPC471 REF1 Clock Controller SCG0 QPC417 QCAD110 Junctor...
  • Page 136 Page 136 of 394 NT8D72 and QPC720 PRI card installation Figure 46 NT8D72 (Multi Group cabling) for Multi Group systems with an echo canceller QCAD130 to PRI Card PRI Card (Secondary reference) (Primary reference) QCAD130 QPC471 REF1 Clock Controller SCG0 QPC417 QCAD110 Junctor...
  • Page 137 NT8D72 and QPC720 PRI card installation Page 137 of 394 Figure 47 QPC720 (Half Group cabling) for Multi Group systems without an echo canceller NT8D79AA or QCAD130 to PRI Card (Secondary reference) QPC720 PRI Card (Primary reference) NT8D79AA or QCAD130 REF1 QPC471 Clock...
  • Page 138 Page 138 of 394 NT8D72 and QPC720 PRI card installation Figure 48 QPC720 (Half Group cabling) for Multi Group systems with an echo canceller NT8D79AA or QCAD130 to PRI Card (Secondary reference) QPC720PRI Card (Primary NT8D79AA reference) QCAD130 REF1 QPC471 Clock Controller No connection...
  • Page 139 NT8D72 and QPC720 PRI card installation Page 139 of 394 Figure 49 QPC720 (Single Group cabling) for Multi Group systems without an echo canceller NT8D79AA to PRI Card (Secondary reference) QPC720 NT8D79AA PRI Card NT8D79AA (Primary reference) NT8D79AA QPC775 REF1 Clock Controller NT8D79AA...
  • Page 140 Page 140 of 394 NT8D72 and QPC720 PRI card installation Figure 50 QPC720 (Single Group cabling) for Multi Group systems with an echo canceller NT8D79AA to PRI Card (Secondary reference) QPC720 NT8D79AA NT8D79AA PRI Card (Primary reference) NT8D79AA QPC775 REF1 Clock Controller NT8D79AA...
  • Page 141 NT8D72 and QPC720 PRI card installation Page 141 of 394 Figure 51 QPC720 Multi Group cabling without an echo canceller QCAD130 to PRI Card PRI Card (Secondary reference) (Primary reference) QCAD130 QPC471 REF1 Clock Controller SCG0 QPC417 QCAD110 Junctor SCG1 QCAD130 QPC471 REF2...
  • Page 142 Page 142 of 394 NT8D72 and QPC720 PRI card installation Figure 52 QPC720 Multi Group cabling with an echo canceller QCAD130 to PRI Card PRI Card (Secondary reference) (Primary reference) QCAD130 QPC471 REF1 Clock Controller SCG0 QPC417 QCAD110 Junctor SCG1 QCAD130 QPC471 REF2...
  • Page 143 NT8D72 and QPC720 PRI card installation Page 143 of 394 Table 29 Cable for the NT8D72 PRI card for Half and Single Group systems (Part 1 of 2) Cable From NTND26 PRI card MSDL NT8D79AA PRI card Clock CC-0 Only when primary controller clock source.
  • Page 144 Page 144 of 394 NT8D72 and QPC720 PRI card installation Table 29 Cable for the NT8D72 PRI card for Half and Single Group systems (Part 2 of 2) Cable From NT8D7205 I/O Panel cross Run via cabinet connect I/O panel to cross-connect terminal from switch.
  • Page 145 NT8D72 and QPC720 PRI card installation Page 145 of 394 Table 30 Cable for the NT8D72 PRI card for Multi Group systems (Part 2 of 2) QCAD133 I/O Panel Patch Panel QCAD129 PRI card I/O Panel RS-232 I/O Panel Echo Canceller RS-232 PRI card...
  • Page 146 Page 146 of 394 NT8D72 and QPC720 PRI card installation Table 31 Cable for the QPC720 PRI card for Half and Multi Group systems (Part 2 of 3) Cable From Des. Con. Des. Con. Comments QCAD130 QPC720 QPC471/ CC-0 Only when secondary NT8D79xx QPC775 clock source.
  • Page 147 NT8D72 and QPC720 PRI card installation Page 147 of 394 Table 31 Cable for the QPC720 PRI card for Half and Multi Group systems (Part 3 of 3) Cable From Des. Con. Des. Con. Comments RS-232 QPC720 Echo Canceller QCAD133 QPC720 Patch Run via cabinet I/O...
  • Page 148 Page 148 of 394 NT8D72 and QPC720 PRI card installation Table 32 Cable for the QPC720 PRI card on Multi Group systems (Part 2 of 3) Cable From Des. Con. Des. Con. Notes QCAD124 QPC720 Network Run to connector NT8D85xx on network pack QCAD328 QPC720...

  • Page 149: Switch Settings

    NT8D72 and QPC720 PRI card installation Page 149 of 394 Table 32 Cable for the QPC720 PRI card on Multi Group systems (Part 3 of 3) Cable From Des. Con. Des. Con. Notes QCAD133 QPC720 Patch Run via cabinet NT8D83xx Panel I/O panel to Echo Canceller or...
  • Page 150 Page 150 of 394 NT8D72 and QPC720 PRI card installation Figure 53 NT8D72AA, NT8D72AB, NT8D72BA PRI DIP switch settings for Large Systems NT8D72AA, NT8D72AB ohm switch setting 120 ohm switch setting (default) NT8D72BA 120 ohm switch setting ohm switch setting (default) 553-7533 Note: For EuroISDN applications, use the default setting (120 ohms).
  • Page 151 NT8D72 and QPC720 PRI card installation Page 151 of 394 Figure 54 QPC720 switch settings for Half and Single Group systems 7-pole (See transmission equalization switch settings) 8-pole (All OFF except for PRI mode, see transmission equalization switch settings) 553-1503 Table 33 NT8D72 and QPC720 PRI transmission equalization switch settings for Large Systems (Part 1 of 2)

  • Page 152: Install Nt8D72 And Qpc720 Pri Cards On Large Systems

    Page 152 of 394 NT8D72 and QPC720 PRI card installation Table 33 NT8D72 and QPC720 PRI transmission equalization switch settings for Large Systems (Part 2 of 2) Switch 3 options for PRI with ESF SW3-1 on = extended superframe format (ESF) off = superframe format (SF) Note 1: All positions on S2 (location B22) are OFF except as shown under the column labeled “Switch S2 settings.”...
  • Page 153 NT8D72 and QPC720 PRI card installation Page 153 of 394 Procedure 11 Install the NT8D72 and QPC720 PRI on Large Systems Determine the cabinet and shelf location of the circuit card to be installed. The following slots can be used if they are not required for other cards. Table 34 Shelf and slot location of NT8D72 and QPC720 for Half Group and Single Group systems...

  • Page 154: Remove Nt8D72 And Qpc720 Pri Cards From Large Systems

    Page 154 of 394 NT8D72 and QPC720 PRI card installation If required, install connecting blocks at MDF or wall-mounted cross-connect terminal. If required, designate connecting blocks at MDF or wall-mounted cross-connect terminal. 10 If required, install CSU or Echo Canceller. 11 Cross-connect PRI circuits.

  • Page 155: Install An Additional Network Shelf

    NT8D72 and QPC720 PRI card installation Page 155 of 394 Pack and store circuit card. End of Procedure Install an additional network shelf Use Procedure 13 to install an additional network shelf, when additional shelf space is required for PRI cards on Half Group and Single Group systems. A QUD15 cooling unit is required for each additional shelf installed.
  • Page 156 Page 156 of 394 NT8D72 and QPC720 PRI card installation Plug the C11 or C21 connector into the single-ended connector of the QCAD172A power cable. Plug one of the two connectors at the other end of the C11 or C21 connector that was removed.

  • Page 157: Nt5D97 Dual-Port Dti2/Pri2

    Page 157 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal Contents The section contains information on the following topics: Introduction ..........NT5D97 circuit card locations .

  • Page 158: Nt5D97 Circuit Card Locations

    Page 158 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal NT5D97 circuit card locations Each NT5D97 card requires one slot on a shelf. NT5D97 cards can be placed in any card slot in the network bus. Port definitions Since the NT5D97 card is a dual-card, it equips two ports; these ports can be defined in the following combinations: Table 35 NT5D97AA/AB loops configuration...

  • Page 159: Ntck43 By A Ddp2 Card

    NT5D97 Dual-port DTI2/PRI2 installation and removal Page 159 of 394 Case Scenarios for replacing a digital trunk NT8D72BA, QPC536E, or NTCK43 by a DDP2 card The following discussion describes possible scenarios when replacing a digital trunk NT8D72BA PRI2 card or QPC536E DTI2 card or NTCK43 Dual PRI card configuration with a NT5D97 DDP2 card configuration.

  • Page 160: Nt5D97Aa/Ab Dip Switch Settings

    Page 160 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal NT5D97AA/AB DIP switch settings The NT5D97 DDP2 card is equipped with 6x2 sets of DIP switches for trunk parameters settings for port0 and port1 respectively. Additionally, the DDP2 card is equipped with one set of four DIP switches for the Ring Ground setting.
  • Page 161 NT5D97 Dual-port DTI2/PRI2 installation and removal Page 161 of 394 Figure 55 DIP switches for NT5D97AA/AB PORT 0 PORT 1 1 2 3 4 1 2 3 4 Trunk Interface 1 2 3 4 1 2 3 4 Receiver Impedence 1 2 3 4 1 2 3 4 Line...
  • Page 162 Page 162 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal The following parameters are set by DIP switches. The boldface font shows the factory set-up. Trunk interface switches for NT5D97AA/AB Impedance level and unit mode The S9/S15 switch selects the impedance level and loop operation mode on DEI2 OR PRI2.
  • Page 163 NT5D97 Dual-port DTI2/PRI2 installation and removal Page 163 of 394 Line build out A per-trunk set of three switches (S5/S11, S6/S12 and S7/S13) provides the dB value for the line build out. Refer to Table 40 on page 163. Note: Do not change this setup. Table 40 Trunk interface line build out switch settings Description...
  • Page 164 Page 164 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal Ring ground switches for NT5D97AA/AB A set of four DIP switches (S2) selects which Ring lines are connected to the ground. Refer to Table 48 on page 169. Table 42 Ring ground switch settings Switch Description...
  • Page 165 NT5D97 Dual-port DTI2/PRI2 installation and removal Page 165 of 394 Table 51 on page 170 shows the possible selections of the NTBK51AA D-channel. Table 44 NTBK51AA daughterboard address select switch settings Device Switch Setting Address Note 1: The system contains a maximum number of 16 DCHI, MSDL, and DDCH devices.

  • Page 166: Nt5D97Ad Dip Switch Settings

    Page 166 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal NT5D97AD DIP switch settings The NT5D97 DDP2 card is equipped with 6x2 sets of DIP switches for trunk parameters settings for port 0 and port 1 respectively. Additionally, the DDP2 card is equipped with one set of four DIP switches for the Ring Ground setting.
  • Page 167 NT5D97 Dual-port DTI2/PRI2 installation and removal Page 167 of 394 Figure 56 Dip switches locations for NT5D97AD 1 A B NT5D97AD Daughter Board NTBK51 1 2 3 4 5 6 7 8 9 10 1 2 3 4 5 6 7 8 9 10 1 2 3 4 1 2 3 4 S1 1...
  • Page 168 Page 168 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal The following parameters are set by DIP switches. The boldface font shows the factory set-up. Trunk interface switches for NT5D97AD Trunk 0 switches Switch S12 gives the MPU information about its environment as shown in Table 46.
  • Page 169 NT5D97 Dual-port DTI2/PRI2 installation and removal Page 169 of 394 Switch S3, S4, and S5 select LBO function as is Table 48. Table 48 LBO switches for NT5D97AD LBO setting 7.5dB 15dB Switch S6 selects the Receiver interface as in Table 49. Table 49 Receiver interface switches for NT5D97AD S6-2...
  • Page 170 Page 170 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal Table 51 Ring ground switch for NT5D97AD Switch Line S16_1 Trunk 0 Transmit S16_2 Trunk 0 Receive S16_3 Trunk 1 Transmit S16_4 Trunk 1 Receive DCH Address select switch for NTBK51AA daughter board for NT5D97AD Switch S9 selects the NTBK51AA DCH daughterboard address.
  • Page 171 NT5D97 Dual-port DTI2/PRI2 installation and removal Page 171 of 394 Table 53 Switch settings for MSDL external card Switch number Function S9_1-10 For future use S8_1-10 For future use Use Table 54 to set the card address. Table 54 Switch setting for MSDL external card (Part 1 of 2) Switch Setting DNUM (LD 17) ISDN Primary Rate Interface...

  • Page 172: Install The Nt5D97 Ddp2

    Page 172 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal Table 54 Switch setting for MSDL external card (Part 2 of 2) Switch Setting DNUM (LD 17) Install the NT5D97 DDP2 Use Procedure 14 to install the NT5D97 on Large Systems. CAUTION The static discharge bracelet located inside the cabinet must be worn before handling circuit cards.
  • Page 173 NT5D97 Dual-port DTI2/PRI2 installation and removal Page 173 of 394 Set the ENB/DIS faceplate switch to ON. If the DDCH is installed, the DDCH LED should flash three times. If required, install the I/O adapters in the I/O panel. Run and connect the NT5D97 cables. CAUTION Clock Controller cables connecting the Clock Controller and NT5D97 card must NOT be routed...

  • Page 174: Remove The Nt5D97 Ddp2

    Page 174 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal Remove the NT5D97 DDP2 Use Procedure 15 to remove the NT5D97 from Large Systems CAUTION The static discharge bracelet located inside the cabinet must be worn before handling circuit cards. Failure to wear the bracelet can result in damage to the circuit cards.

  • Page 175: Configure The Nt5D97 Ddp2

    NT5D97 Dual-port DTI2/PRI2 installation and removal Page 175 of 394 Remove the DDP2 card only if both loops are disabled. If the other circuit of a DDP2 card is in use, DO NOT remove the card. The Faceplate switch ENB/DIS must be in the OFF (DIS) position before the card is removed, otherwise the system will initialize.
  • Page 176 Page 176 of 394 NT5D97 Dual-port DTI2/PRI2 installation and removal 553-3001-201 Standard 2.00 September 2004...

  • Page 177: Nt5D12 Dual-Port Dti/Pri Card Installation

    Page 177 of 394 NT5D12 Dual-port DTI/PRI card installation Contents The section contains information on the following topics: Introduction ..........NT5D12 circuit card locations .

  • Page 178: Nt5D12 Circuit Card Locations

    Page 178 of 394 NT5D12 Dual-port DTI/PRI card installation For installation and removal procedures for the NTBK51AA Downloadable D-channel daughterboard, refer to the section “NTBK51 DDCH installation and removal” on page 117. NT5D12 circuit card locations Each NT5D12 circuit card requires one slot on a shelf. NT5D12 cards can be placed in any card slot in the network bus, subject to the cautionary note below.

  • Page 179: Nt5D12 Switch Settings

    NT5D12 Dual-port DTI/PRI card installation Page 179 of 394 Case 1 - The two ports of a QPC414 network card are connected to two digital trunks. In this case, the QPC414 and the two digital trunks are replaced by a single DDP card, which is plugged into the CE shelf in the QPC414 slot.

  • Page 180: General Purpose Switches

    Page 180 of 394 NT5D12 Dual-port DTI/PRI card installation General Purpose Switches A per-trunk set of four DIP switches provides the default setting for operational modes. Switch set S9 is used for Trunk 0. Switch set S15 is used for Trunk 1. Refer to Table 55’. Table 55 General purpose switch settings Switch...

  • Page 181: Ring Ground Switches

    NT5D12 Dual-port DTI/PRI card installation Page 181 of 394 Line Build Out A per-trunk set of three switches provides a selection between 0, 7.5 or 15 dB values. See Table 57. Table 57 Trunk interface line build out switch settings Description Switch Setting S5/S11...

  • Page 182: Dch Mode And Address Select Switches

    Page 182 of 394 NT5D12 Dual-port DTI/PRI card installation Table 59 Ring ground switch settings Switch Description S2 Switch Setting Trunk 0 Transmit OFF - Ring line is not grounded ON - Ring line is grounded Trunk 0 Receive OFF - Ring line is not grounded ON - Ring line is grounded Trunk 1 Transmit OFF - Ring line is not grounded...
  • Page 183 NT5D12 Dual-port DTI/PRI card installation Page 183 of 394 Table 61 NTBK51AA daughterboard address select switch settings Device Address Switch Setting Note 1: The maximum number of DCHI, MSDL, and DDCH devices in the system is 16. Note 1: The Device Addresses are equivalent to the MSDL DNUM designations. Note 2: Device address 0 is commonly assigned to the System Monitor.
  • Page 184 Page 184 of 394 NT5D12 Dual-port DTI/PRI card installation Figure 57 Switch functional areas on the NT5D12 NT5D12 Faceplate Port 0 Port 1 General Purpose Switches Receiver Impedance Line Build Out Switches Transmission Mode DCH Mode and Address Select Switches Functions and Areas 553-3001-201 Standard 2.00 September 2004...
  • Page 185 NT5D12 Dual-port DTI/PRI card installation Page 185 of 394 Figure 58 NT5D12 switch default settings Switch Default Setting ISDN Primary Rate Interface Installation and Configuration...

  • Page 186: Install The Nt5D12 Ddp

    Page 186 of 394 NT5D12 Dual-port DTI/PRI card installation Install the NT5D12 DDP Use Procedure 16 to install the NT5D12 on Large Systems. CAUTION The static discharge bracelet located inside the cabinet must be worn before handling circuit cards. Failure to wear the bracelet can result in damage to the circuit cards.

  • Page 187: Remove The Nt5D12 Ddp

    NT5D12 Dual-port DTI/PRI card installation Page 187 of 394 Run and connect the NT5D12 cables. CAUTION Clock Controller cables connecting the Clock Controller and NT5D12 card must NOT be routed through the center of the cabinet past the power harness. Instead, route them around the outside of the equipment shelves.

  • Page 188: Configure The Nt5D12 Ddp

    Page 188 of 394 NT5D12 Dual-port DTI/PRI card installation Procedure 17 Remove the NT5D12 DDP Determine the cabinet and shelf location of the NT5D12 card to be removed. Disable Network Loop using LD 60. The command is DISL “loop number.” The associated DCHI might have to be disabled first.
  • Page 189 NT5D12 Dual-port DTI/PRI card installation Page 189 of 394 Consider the following when configuring the NT5D12 DDP card: • The system software allows four ports to be defined for the NT6D80 MSDL. The DDCH (NTBK51AA) card has only two ports, 0 and 1; therefore, ports 2 and 3 must not be defined when using the NTBK51AA.
  • Page 190 Page 190 of 394 NT5D12 Dual-port DTI/PRI card installation 553-3001-201 Standard 2.00 September 2004...

  • Page 191: Clock Controller Description And Installation

    Page 191 of 394 Clock Controller description and installation Contents The section contains information on the following topics: Introduction ..........Description .

  • Page 192: Introduction

    Page 192 of 394 Clock Controller description and installation Introduction This chapter introduces the NTRB53 Clock Controller, and provides procedures on how to install this clock controller on Large Systems. The NTRB53 Clock Controller replaces the QPC471H and QPC775F in new systems.

  • Page 193: Supported Clock Controllers

    Clock Controller description and installation Page 193 of 394 When digital signals are being transported over a communication link, the receiving end must operate at the same frequency (data rate) as the originating end to prevent loss of information. This is referred to as link synchronization. If both ends of a communication link are not in synchronization, data bit slips occur and therefore a loss of data results.
  • Page 194 Page 194 of 394 Clock Controller description and installation hardware inventory are also included. System Initialization During system initialization, the system software will verify if the clock controllers equipped in the system are the downloadable clock controllers (NTRB53) or not. If the clock controllers are identified as the downloadable clock controller cards, then both downloadable clock controller cards will be checked for the software version number they are running with.

  • Page 195: Synchronization Methods

    Clock Controller description and installation Page 195 of 394 initiated on a single card and only that card will be allowed to perform the force download option. QPC471 and QPC775 Clock Controllers Clock Controllers QPC471 and QPC775 will continue to function with: •...

  • Page 196: Hierarchical Synchronization

    Page 196 of 394 Clock Controller description and installation Whenever possible the system uses the Mesosynchronous mode of operation by using the clock controller circuit cards to lock onto an external reference source (such as the Central Office, another PBX, and so on). This statement is true unless the system is used as a Master in an independent/private network (no digital links to a higher Node Category).
  • Page 197 Clock Controller description and installation Page 197 of 394 Figure 59 Hierarchical Synchronization Primary Reference Source Stratum 1 nodes (clock derived directly from or controlled by Cesium clock) Stratum 2 nodes (i.e. Toll Offices) Stratum 3 nodes (i.e. Digital Central or End offices) Stratum 4 nodes (i.e.

  • Page 198: Stratum Levels

    Page 198 of 394 Clock Controller description and installation Stratum levels In a digital network, nodes are synchronized using a priority master/slave method. Digital nodes are ranked in Stratum levels 1 to 5. Each node is synchronized to the highest ranking node in its neighborhood with which it has a direct link.

  • Page 199: Guidelines

    Clock Controller description and installation Page 199 of 394 When data bits are written into (added to) a buffer at a slightly higher rate than that at which they are being read (emptied), sooner or later the buffer overflows This is a slip-frame deletion. In the opposite situation, when data bits are written (added) into a buffer at slightly lower rate than that at which they are being read (emptied), eventually the buffer runs dry or underflows.
  • Page 200 Page 200 of 394 Clock Controller description and installation • The source should not be in free-run itself (providing its own clock) unless it is operating in a fully independent network where the source acts as a Master (see “Plesiosynchronous operation” on page 195.) •...
  • Page 201 Clock Controller description and installation Page 201 of 394 Figure 61 Example 2, Isolated Private Network with Secondary Reference Clock Small System Small System LD 60 LD 60 loop X loop X TRCK FRUN TRCK PCK LD 73: LD 73: loop Y loop Y PREF <cr>...
  • Page 202 Page 202 of 394 Clock Controller description and installation Figure 62 Example 3, Clocking Hierarchy referenced to a Public Network Master Clock Small System Small System LD 60 LD 60 TRCK PCK TRCK PCK Slave Slave LD 73: LD 73: PREF loop W PREF loop Z SREF <cr>...
  • Page 203 Clock Controller description and installation Page 203 of 394 Figure 63 Example 4, Alternate Clocking from the same CO Master Clock Master clock source: Non-tracking (Free-run) LD 60 TRCK FRUN Small System or LD 73: Central Office PREF <cr> SREF <cr> loop Y loop X Small System...
  • Page 204 Page 204 of 394 Clock Controller description and installation Figure 64 Example 5, digital connection to the CO Master Clock Master Clock Master Clock Central Central Central Office Office Office loop W loop X loop Y Small System Small System Small System LD 60 LD 60...
  • Page 205 Clock Controller description and installation Page 205 of 394 Figure 65 Example 6, Complex Isolated Private Network Clocking off Master: Tracking on Primary loop Y Master clock and loop W used as a Non-tracking secondary clock source (Free-run) Small System Small System LD 60 LD 60...
  • Page 206 Page 206 of 394 Clock Controller description and installation Figure 66 Example 7, Network Clocking with MUX Clocking off Master: Tracking on Primary loop Y and loop X used as a secondary clock source. Small System LD 60 Master clock TRCK PCK Slave Central...

  • Page 207: Modes Of Operation

    Clock Controller description and installation Page 207 of 394 Modes of operation There are two modes of operation, tracking mode and free run (non-tracking) mode. Tracking mode In tracking mode, the Primary Rate Interface (PRI) or Digital Trunk Interface (DTI) loop supplies an external clock reference to the on-board clock controller.

  • Page 208: Installation Procedures

    Page 208 of 394 Clock Controller description and installation Installation procedures This section provides procedures on how to install a clock controller on Large Systems. CAUTION Do not deviate from the procedures described in this section. Call processing can stop if procedural steps are not followed properly.
  • Page 209 Clock Controller description and installation Page 209 of 394 Table 65 Clock Controller switch settings for QPC471 vintage H System Half Group, Single Group Option 81 Multi Group (with the exception of Option 81) Multi Group with Fiber Network *Cable length between the J3 faceplate connectors: 0–4.3 m (0–14 ft) 4.6–6.1 m (15–20 ft)

  • Page 210: Start The Clock Controller

    Page 210 of 394 Clock Controller description and installation Table 67 Clock Controller switch settings for NTRB53 Multigroup/ Machine Faceplate Side Number Machine Single group Type # 1 Cable Length Type #2 (CC to CC) Multigroup 0-14 ft Side 0 = On 81 = Off = Off 61, 51C, 61C...

  • Page 211: Install Or Replace A Clock Controller On A Half Group And Single Group System

    Clock Controller description and installation Page 211 of 394 LD 39 commands with the NTRB53 Clock Controller Command Description DIS SCG x Disable SCG card x (0 or 1). Not applicable for NTRB53 Clock Controller. Use LD 60 instead. ENL SCG x Enable SCG x (0 or 1).
  • Page 212 Page 212 of 394 Clock Controller description and installation Replacing a clock controller, do the following: — Perform a status check on the clock with the SSCK command in LD 60. The new controller should have the same status. Note: ERR20 messages can be generated. These can usually be ignored.

  • Page 213: Install Or Replace A Clock Controller On A Single Group And Multi Group System

    Clock Controller description and installation Page 213 of 394 14 Issue the status check command, SSCK. Note: In order for the clock enhancement feature in the clock controller (NTRB53) to be fully functional, the user must issue a manual INI to activate the clock enhancement feature.
  • Page 214 Page 214 of 394 Clock Controller description and installation Set the old card’s faceplate ENL/DIS switch to DIS. Disconnect the cables from the old clock controller card and remove it from the shelf. Install the new clock controller in the selected slot. Run and connect the cables Connect the primary reference to J2.

  • Page 215: Upgrade To An Ntrb53 Clock Controller On A Single Group And Multi Group System

    Clock Controller description and installation Page 215 of 394 Upgrade to an NTRB53 Clock Controller on a Single Group and Multi Group System Follow these procedures to replace the existing clock controller with the NTRB53 Clock Controller on Large Systems. Note: The NTRB53 Clock Controller cannot be combined with a QPC775 or a QPC471 card in one system.
  • Page 216 Page 216 of 394 Clock Controller description and installation Unhook the locking devices on the card and pull it out of the card cage. End of Procedure Follow these procedures to install new equipment with Clock Controller on Large Systems. Procedure 21 Installing new equipment Set the ENB/DIS switch to DIS on the replacement card.
  • Page 217 Clock Controller description and installation Page 217 of 394 Switch to the core with the new clock. At the prompt, enter: LD 135 SCPU Switch CPU Note: Wait two minutes before proceeding to the next step. CAUTION The following procedure to faceplate disable the active clock controller could impact service.
  • Page 218 Page 218 of 394 Clock Controller description and installation 16 Insert the replacement card into the selected slot and hook the locking devices. 17 Connect the reference cables (J1 and J2) and the clock-to-clock cable (J3) to the replacement card. 18 Set the ENB/DIS switch to ENB on the replacement card.

  • Page 219: Isl Installation

    Page 219 of 394 ISL installation Contents The section contains information on the following topics: ISL configurations......... DCHI switch settings .

  • Page 220: Dchi Switch Settings

    Page 220 of 394 ISL installation Dedicated mode In this mode, the DCHI supports ISL trunks using ISDN PRI signaling. The D-channel communicates with the far end using a dedicated leased line, dial-up modem, or DTI trunk. DCHI switch settings For ISL functions, use the following switch settings for the J2 port: •...
  • Page 221 ISL installation Page 221 of 394 Figure 67 NT6D11AB, NT6D11AD DCHI with ISL high-speed programming jumper settings RS-232 RS-422 PORT 0 RS-232 RS-422 RS-232 RS-422 PORT 1 RS-232 RS-422 553-7350 ISDN Primary Rate Interface Installation and Configuration...

  • Page 222: Msdl Switch Settings

    Page 222 of 394 ISL installation Figure 68 NT6D11AB, NT6D11AD DCHI with ISL low-speed programming jumper settings RS-232 RS-422 PORT 0 RS-232 RS-422 RS-232 RS-422 PORT 1 RS-232 RS-422 553-7351 MSDL switch settings For ISL functions, use the following switch settings. •...

  • Page 223: Shared Mode

    ISL installation Page 223 of 394 Figure 69 MSDL/ISL settings Card Address Select Switches Ones Tens S9 S10 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 9 10 Port 0 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8 9 10 Port 1 Port 2...

  • Page 224: Dedicated Mode Using Leased Line

    Page 224 of 394 ISL installation Shared mode is established through service change in LD17, prompt USR, with the response SHA. In the shared mode, the DCH can share signaling for no more than 382 (T1) or 480 (E1) trunks, including digital and analog. Figure 70 ISL in shared mode Originating site...

  • Page 225: Dedicated Mode Using Dial-Up Modem

    ISL installation Page 225 of 394 Figure 71 ISL dedicated mode, using leased line Large System Large System Modem Modem QCAD42A ISL D-channel NTND27 DCHI MSDL P R I Leased line 553-AAA0063 Dedicated mode using dial-up modem In this configuration, the DCHI or MSDL is connected to a modem which is connected to a 500 set line card.
  • Page 226 Page 226 of 394 ISL installation Figure 72 ISL dedicated mode: using dial-up Hayes Smartmodem 2400 Originator Terminator Large System Large System autodial autoanswer Modem Modem QCAD42 QCAD42 DCHI DCHI Twisted pair Twisted pair 500 set 500 set card card ISL D-channel 553-AAA0065 Examples of parameters used for actual auto-answer and auto-dial sites are...
  • Page 227 ISL installation Page 227 of 394 Table 68 Active and stored profiles of the autodial or originating modem Stored profile 0: B1 E0 L2 M1 Q1 V1 X4 Y0 &C1 &D0 &G0 &J0 &L0 &P0 &Q2 &R0 &S0 &X0 S00:000 S14:ACH S18:000 S21:20H S22:76H S23:17H S25:005 S26:001 S27:42H Stored profile 1: B1 E1 L2 M1 Q0 V1 X4 Y0 &C0 &D0 &G0 &J0 &L0 &P0 &Q0 &R0 &S0 &X0...
  • Page 228 Page 228 of 394 ISL installation Table 69 Active and stored profiles of the auto answer or terminating modem Telephone numbers: &Z0= &Z1= &Z2= &Z3= Figure 73 ISL dedicated mode, using dial-up Hayes Smartmodem 2400 Originating site Terminating site Large System Large System autodial autodial...

  • Page 229: Dedicated Mode Using Pri/Dti Trunks

    To increase the reliability on this configuration, a constant power source can be used when powering the modems. Also ensure that the TIE lines meet data grade specifications. Note 2: Nortel Networks takes no responsibility for ISL D-channel outages due to modem lockup. ISDN Primary Rate Interface...

  • Page 230: Qmt11 Switch Settings

    Page 230 of 394 ISL installation Figure 74 ISL dedicated mode: using PRI/DTI trunk Large System Large System HSDM HSDM QCAD42A NTND27 DCHI MSDL P R I Twisted pair Twisted pair Data Data P R I line card line card ISL D-channel DTI or DTI or...

  • Page 231: Qmt8 Switch Settings

    ISL installation Page 231 of 394 Note 1: Set only one side of the interface to originate the hot line. Note 2: Forced Data Terminal Ready (DTR) automatically reinitiates a dropped hot line call. QMT8 switch settings If the QMT8 Asynchronous Data Module (ADM) is used, set the switches as follows: Switch 1: Switch 3:...

  • Page 232: Isl Installation

    Page 232 of 394 ISL installation • Auto Answer, On • Loopback, Off Note 1: Set only one side of the interface to originate the hot line. Note 2: Forced Data Terminal Ready (DTR) automatically reinitiates a dropped hot line call. ISL installation Use Procedure 22 to install ISL in dedicated mode.

  • Page 233: Install Isl In Shared Mode

    ISL installation Page 233 of 394 Install ISL in shared mode DTI or PRI should already be up and running. Procedure 23 Install ISL in shared mode In LD14, remove the PRI trunks. In LD17, configure ISL for dedicated mode. USR = SHA ISLM = Number of trunks handled by this D-channel (1-382) In LD16, build a PRI route data block.
  • Page 234 Page 234 of 394 ISL installation 553-3001-201 Standard 2.00 September 2004...

  • Page 235: Echo Canceller Installation

    Page 235 of 394 Echo canceller installation Contents The section contains information on the following topics: Introduction ..........Echo canceller operating parameters.

  • Page 236: Echo Canceller Initialization Procedures

    Page 236 of 394 Echo canceller installation Echo canceller initialization procedures Each of the 24 channels on the echo canceller must be initialized as shown here: • Bypass: OFF • Off-hook: ON • Canceller only: OFF • H reset: OFF •...

  • Page 237: Electromagnetic Interference

    Echo canceller installation Page 237 of 394 Table 70 PRI-to-Echo canceller – pin assignments (Part 2 of 2) Common Return (signal ground) (received line signal detector) (data terminal ready) Electromagnetic Interference The Electromagnetic Interference (EMI) filter assembly for PRI is PO643763.
  • Page 238 Page 238 of 394 Echo canceller installation Figure 75 PRI to echo canceller cabling Cross- Echo NCTE Connect I/O Filter (if required) Canceller Block XTIP XRING GRD (Shield) RTIP Port P R I RRING GRD (Shield) J1 Ref 1 (if equipped) J1 Ref 2 Network RXD (BB)

  • Page 239: 1.5 Mb Pri Implementation

    Page 239 of 394 1.5 Mb PRI implementation Contents This section contains information on the following topics: Overview ..........Hardware requirements .

  • Page 240: Hardware Requirements

    Page 240 of 394 1.5 Mb PRI implementation Hardware requirements Circuit cards To implement PRI on the system, the hardware shown in Table 71 is required. Table 71 Required circuit cards Circuit card Description NTRB21 DTI/PRI TMDI card (recommended for CS 1000S).

  • Page 241: Hardware Description

    One CSU is required per PRI. Suitable CSUs which support 64 Kbps clear and Bipolar 8 Zero Substitution (B8ZS) are available from vendors such as Verilink, Digitalink, Kentrox, and Tellabs. Note: Contact your Nortel Networks Sales representative for specific local CSU requirements. Hardware description...
  • Page 242 Page 242 of 394 1.5 Mb PRI implementation Table 72 on page 242 maps physical card slot numbers to logical card numbers for the MG 1000S and MG 1000S Expansion and reflects added support for the MG 1000S and MG 1000S Expansion physical card slot 4. Table 72 MG 1000S and MG 1000S Expansion slot assignments MG 1000S/MG 1000S Expansion...
  • Page 243 1.5 Mb PRI implementation Page 243 of 394 The NTRB21can be equipped with the NTAK09 DTI/PRI card (with the NTBK51 downloadable D-channel daughterboard) and the NTAK93 DCHI daughterboard. Note 3: A TMDI D-channel programmed as a backup D-channel against a non-TMDI primary D-channel is not supported. Backup D-channels are supported only when programmed against TMDI primary D-channels.
  • Page 244 Page 244 of 394 1.5 Mb PRI implementation Figure 76 NTRB21 TMDI card faceplate TMDI MAINT ........RS232 Monitor Port ......553-3001-201 Standard 2.00 September 2004...
  • Page 245 1.5 Mb PRI implementation Page 245 of 394 NTAK09 DTI/PRI circuit card The NTAK09 Digital Trunk Interface/Primary Rate Interface (DTI/PRI) card provides the physical interface for the DS-1 facility T-1 carrier on the system. It is required for PRI and DTI operation and is also used for ISL shared-mode applications.
  • Page 246 Page 246 of 394 1.5 Mb PRI implementation Figure 77 NTAK09 DTI/PRI circuit card Stiffeners LEDs Connector Sockets Bantam Jacks 1 2 3 4 Standoffs Switch 553-8294.EPS 553-3001-201 Standard 2.00 September 2004...
  • Page 247 1.5 Mb PRI implementation Page 247 of 394 NTAK20 Clock Controller (CC) daughterboard Digital Trunking requires synchronized clocking so a shift in one clock source results in an equivalent shift of the same size and direction in all parts of the network. Synchronization is accomplished with the NTAK20 clock controller circuit card in each Main and IP expansion cabinet/MG 1000S.
  • Page 248 Page 248 of 394 1.5 Mb PRI implementation There are two stages to clock controller tracking, as follows: • tracking a reference • locked onto a reference When tracking a reference, the clock controller uses an algorithm to match its frequency to the frequency of the incoming clock.
  • Page 249 1.5 Mb PRI implementation Page 249 of 394 Clock controller LED states The clock controller LED, on the NTAK09 or NTRB21 faceplates, is in various states depending on the status of the clock controller. Table 73 Clock controller LEDs Clock controller On (Red) NTAK20 is equipped and disabled.
  • Page 250 Page 250 of 394 1.5 Mb PRI implementation Shelf slot assignments for NTRB21, NTAK09 and NTAK20 Table 74 on page 250 provides the shelf slot assignments for the NTRB21 TMDI card, NTAK09 DTI/PRI card, and NTAK20 Clock Controller daughterboard in Small Systems and CS 1000S systems. The NTAK 93 DCH and NTBK51BA DDCH daughterboards are not included in this table since they are mounted on the NTAK09 DTI/PRI circuit card and not on a shelf.
  • Page 251 1.5 Mb PRI implementation Page 251 of 394 NTAK93 D-channel Handler Interface (DCHI) daughterboard The NTAK93 DCHI daughterboard interfaces with the system Central Processing Unit (CPU) and mounts on the NTAK09 DTI/PRI circuit card for PRI or ISL shared mode applications. The DCHI is responsible for performing the Q.921 layer 2 protocol information.

  • Page 252: Install Pri Hardware

    Page 252 of 394 1.5 Mb PRI implementation For more information on expansion daughterboards, refer to Communication Server 1000M and Meridian 1: Small System Planning and Engineering (553-3011-120). Install PRI hardware Install/remove daughterboard on the NTRB21 TMDI card Procedure 24 Mounting the NTAK20 daughterboard on the NTRB21 Work on a flat surface when mounting or removing daughterboards.
  • Page 253 1.5 Mb PRI implementation Page 253 of 394 Figure 78 NTAK20 daughterboard installation on the NTRB21 Connector Socket Stiffeners 1 2 3 4 Connector Pins LEDs NTAK20 Clock Controller Bantam Jacks Mounting Holes Standoffs 553-9024 End of Procedure Insert/remove the NTRB21 TMDI card Refer to Table 74 on page 250 to determine the slot assignment for the...
  • Page 254 Page 254 of 394 1.5 Mb PRI implementation Procedure 25 Inserting the NTRB21 TMDI card Check for available card slots in the base cabinet and print the configuration record to determine which slots can be used. To do this, enter the following command in LD 22: PRT CFN in LD 22 If in PRI mode, enter the following command in LD 96 to software disable the D-channel:...
  • Page 255 1.5 Mb PRI implementation Page 255 of 394 Procedure 26 Removing the NTRB21 TMDI card If in PRI mode, enter the following command in LD 96 to software disable the D-channel: DIS DCH x where x is the DCH port number that was assigned in LD 17. If the Clock Controller is enabled, enter the following command in LD 60 to software disable it: DIS CC 0...
  • Page 256 Page 256 of 394 1.5 Mb PRI implementation Slowly lower the daughterboard toward the NTAK09, keeping the standoffs in line with all four holes, until the holes rest on top of the four standoffs. Note: If more than a very slight amount of pressure is required at this point, the connector pins are not aligned with the connector socket.
  • Page 257 1.5 Mb PRI implementation Page 257 of 394 Figure 79 Daughterboard installation on the NTAK09 Connector Pins Connector Socket Stiffeners 1 2 3 4 NTAK20 Clock Controller Mounting Holes LEDs Bantam Jacks NTAK93 DCHI NTBK51BA DDCH Standoffs Switch 553-8295.EPS ISDN Primary Rate Interface Installation and Configuration...
  • Page 258 Page 258 of 394 1.5 Mb PRI implementation Set switches on NTAK09 DTI/PRI card Set the switches on the NTAK09 DTI/PRI card according to Table 75. Table 75 NTAK09 switch settings Distance to digital cross-connect DCH F/W (LEN 0) (LEN 1) (LEN 2) 0 - 133 feet 133 - 266 feet...
  • Page 259 1.5 Mb PRI implementation Page 259 of 394 Note 1: Refer to Table 74 on page 250 to determine the correct slot in which to insert the card. Note 2: For CS 1000S, the NTAK09 is installed only in the MG 1000S. It is not supported in the MG 1000S Expansion.
  • Page 260 Page 260 of 394 1.5 Mb PRI implementation Table 76 DS-1 line interface pinout for NTBK04 cable From 50-pin Signal MDF connector to DB-15 name Description pin 48 pin 1 transmit tip to network pin 23 pin 9 transmit ring to network pin 25 pin 2...
  • Page 261 1.5 Mb PRI implementation Page 261 of 394 The system response is: DCH N EST OPER This means that the D-channel is established and operational. End of Procedure Procedure 32 Enabling the NTAK09 DTI/PRI card Note: The DCHI and PRI cards must be configured prior to software enabling the NTAK09.
  • Page 262 Page 262 of 394 1.5 Mb PRI implementation This means that the D-channel is established and operational. End of Procedure Procedure 33 Implementing basic PRI Use this procedure to configure the PRI cards, DCHI interface, DCH link and ISDN trunk route and trunks (B-channels) that are required to implement PRI between systems.
  • Page 263 1.5 Mb PRI implementation Page 263 of 394 LD 17— Adding a PRI card Prompt Response Description Change existing data. TYPE Configuration data block. CEQU Changes to common equipment. loop x For Large Systems card x For Small Systems and CS 1000S Systems TMDI Card (Mode set to PRI OR TRK) Option 11C Cabinet TMDI (Yes)
  • Page 264 Page 264 of 394 1.5 Mb PRI implementation LD 17 — Adding a D-channel interface (Part 2 of 3) Prompt Response Description - CDNO 1-50 Card slot number to be used as the primary DDCH/DCHI. Card slots 10, 20, 30, 40, and 50 are only applicable for D-channel configuration of ISL or VNS.
  • Page 265 1.5 Mb PRI implementation Page 265 of 394 LD 17 — Adding a D-channel interface (Part 3 of 3) Prompt Response Description - - T23 1-(20)-31 Interface guard timer checks how long the interface takes to respond. In units of 0.5 seconds (default 20 = 10 seconds).
  • Page 266 Page 266 of 394 1.5 Mb PRI implementation LD 15 — Defining a PRI customer (Part 2 of 3) Prompt Response Description LDN0 xxxx Listed Directory number 0 must be defined for ISDN PRI DID service. The length of LDN0 determines the number of trailing digits translated as the dialed DN on PRI DID routes.
  • Page 267 1.5 Mb PRI implementation Page 267 of 394 LD 15 — Defining a PRI customer (Part 3 of 3) Prompt Response Description - - HLOC Home location code (NARS), prompted when PRA = YES. - - LSC 1-9999 One to four digit Local Steering Code, if required in the Coordinated Dialing Plan (CDP).
  • Page 268 Page 268 of 394 1.5 Mb PRI implementation LD 16 — Configuring an ISDN service route (Part 1 of 2) Prompt Response Description Add new data. Change existing data. TYPE Route data block. TKTP Trunk type. DTRK Digital trunk route. - DGTP 1.5 Mb PRI.
  • Page 269 1.5 Mb PRI implementation Page 269 of 394 LD 16 — Configuring an ISDN service route (Part 2 of 2) Prompt Response Description - INAC Insert ESN Access Code based on NARS/BARS call type for incoming calls on TIE routes only. If NARS is equipped, this feature inserts AC1 or AC2, depending on the responses to AC2 in LD 15 Customer Data Block.
  • Page 270 Page 270 of 394 1.5 Mb PRI implementation LD 14 — Defining service channels and PRI trunks (Part 2 of 2) Prompt Response Description RTMB Route number and Member number 0-511 1-510 Range for Large System and CS 1000E system. 0-127 1-4000 Range for CS 1000M Small System, Meridian 1 Small System, CS 1000S system, Media Gateway 1000B, and...
  • Page 271 1.5 Mb PRI implementation Page 271 of 394 LD 73 — Defining system timers and clock controller parameters (Part 2 of 2) Prompt Response Description Card number of PRI/DTI/SILC or DTI2/PRI2/SILC containing SREF CC2 the primary clock reference. Card number for Clock Controller 3. Card number of PRI/DTI/SILC or DTI2/PRI2/SILC containing PREF CC3 the primary clock reference.
  • Page 272 Page 272 of 394 1.5 Mb PRI implementation 553-3001-201 Standard 2.00 September 2004...

  • Page 273: Mb Dti Implementation

    • implementation procedures for basic call service This chapter covers the most common type of Nortel Networks DTI installation – a 24-channel Digital Trunk Interface (DTI) installation between two systems, or between a system and a central office.

  • Page 274: Hardware Requirements

    (CSUs) are required by most operating companies. One CSU is required per DTI. Suitable CSUs which support 64 Kbps clear and Bipolar 8 Zero Substitution (B8ZS) are available from vendors such as Verilink, Digitalink, Kentrox and Tellabs. Contact your Nortel Networks Sales representative for specific local CSU requirements. 553-3001-201 Standard 2.00...

  • Page 275: Hardware Description

    1.5 Mb DTI implementation Page 275 of 394 Hardware description Refer to “Hardware description” on page 241. Install DTI hardware Refer to “Install PRI hardware” for information on installing DTI hardware. Specifically: • To install the NTRB21 DTI/PRI card, see “Insert/remove the NTRB21 TMDI card”...

  • Page 276: Software Enable The Dti/Pri Cards

    Page 276 of 394 1.5 Mb DTI implementation For CS 1000S, connect the NTBK04 cable to a 50-pin amphenol connector on the rear of the Media Gateway. The amphenol connectors are labelled with the card slot numbers to which they correspond. The NTBK04 is twenty feet long.
  • Page 277 1.5 Mb DTI implementation Page 277 of 394 ENL DCH y where y is the DCH port number that was assigned in LD 17. Within about 30 seconds, the D-channel layer 3 should be established. To confirm, enter the following command in LD 60 to request the current status of the D-channel: STAT DCH (N) The system response is:...
  • Page 278 Page 278 of 394 1.5 Mb DTI implementation Within about 30 seconds, the D-channel layer 3 should be established. To confirm, enter the following command in LD 60 to request the current status of the D-channel: STAT DCH (N) The system response is: DCH N EST OPER This means that the D-channel is established and operational.
  • Page 279 1.5 Mb DTI implementation Page 279 of 394 LD 17 — Adding a DTI card Prompt Response Description Change existing data. TYPE Configuration data block. PARM PCML (MU) A System PCM law. Default is MU law. CEQU Changes to common equipment. DLOP ll dd ff Digital Trunk Interface Loop or Loops...
  • Page 280 Page 280 of 394 1.5 Mb DTI implementation LD 16 — Configuring a DTI trunk route Prompt Response Description Add new data. Change existing data. TYPE Route data block. TKTP Create a trunk route. Central Office Trunk data block WATS Trunk data block Direct Inward Dial Trunk data block TIE Trunk data block Foreign Exchange...
  • Page 281 1.5 Mb DTI implementation Page 281 of 394 LD 73 — Assigning a clock's reference source (Part 1 of 2) Prompt Response Description Change existing data. TYPE Digital Data Block. Card slot number for Clock Controller 0. Card number of PRI/DTI/SILC containing the primary PREF CCO clock reference for the main cabinet Card number of PRI/DTI/SILC containing the primary...
  • Page 282 Page 282 of 394 1.5 Mb DTI implementation LD 73 — Assigning a clock's reference source (Part 2 of 2) Prompt Response Description Card number of PRI/DTI/SILC or DTI2/PRI2/SILC PREF CC4 containing the primary clock reference. SREF CC4 Card number of PRI/DTI/SILC or DTI2/PRI2/SILC containing the primary clock reference.

  • Page 283: 1.5 Mb Isl Implementation

    Two modes of ISL are available: shared and dedicated. This chapter covers the most common type of Nortel Networks ISL installation, an ISDN Signaling Link (ISL) installation in dedicated mode using dedicated and leased lines.
  • Page 284 Page 284 of 394 1.5 Mb ISL implementation • NTAK09 Digital trunk cards (for shared mode) • NTAK02 SDI/DCH card (for dedicated mode) Shared mode In shared mode, PRI hardware plus the existing TIE line interface card is required. Dedicated mode Dedicated mode requires modems.
  • Page 285 1.5 Mb ISL implementation Page 285 of 394 Figure 80 ISL in dedicated mode using leased line MG 1000S Large System ISL D-channel leased lines modem modem DCHI DCHI DCHI ¥ ¥ Analog/Digital TIE trunks 553-AAA1984 Using dial-up modems The requirements for using a dial-up modem are: Table 81 Dial-up modem requirements (Part 1 of 2) Hardware...
  • Page 286 Page 286 of 394 1.5 Mb ISL implementation Table 81 Dial-up modem requirements (Part 2 of 2) Hardware Comments Modem Modem capable of the following: (such as Ventel 2400-33 or 2400 Plus II) - minimum of 2400 baud - synchronous operation - modems are programmed such that one modem originates the call while the other auto-answers...
  • Page 287 1.5 Mb ISL implementation Page 287 of 394 ISL hardware installation (dedicated mode) Use Procedure 37 to install hardware for an ISDN Signaling Link (ISL) in dedicated mode using dedicated leased lines. For shared mode, hardware installation is identical to the PRI installation found in “1.5 Mb PRI implementation”...
  • Page 288 Page 288 of 394 1.5 Mb ISL implementation Table 83 NTAK02 jumper settings Unit Jumper location Strap for DTE Strap for DCE Unit 0 C - B B - A Unit 1 C - B B - A C - B B - A Unit 2 C - B...

  • Page 289: Basic Isl Implementation

    1.5 Mb ISL implementation Page 289 of 394 Modems such as Ventel 2400 Plus II can be used. You must specify 4-wire operation when ordering. Otherwise, the modem is factory shipped for 2-wire operation. Note: The Hayes Smart modem 2400 cannot be used on leased lines. If the installation is a dedicated mode using dial-up modem (such as Hayes 2400, Ventel 2400 or Gandalf 2400) configuration, the DCHI is connected to a modem that is connected to a 500 set line card.
  • Page 290 Page 290 of 394 1.5 Mb ISL implementation Procedure 38 Implementing dedicated mode Configuring dedicated mode involves four major steps: Configure the D-channel for ISL (LD 17). Enable ISDN option (LD 15). Enable the ISL option on a per route basis, assigning a D-channel for each route (LD 16).
  • Page 291 1.5 Mb ISL implementation Page 291 of 394 LD 17 — Configuring the D-channel for ISL (Part 2 of 2) Prompt Response Description Software release of far-end. This is the current software release of the far-end. If the far-end has an incompatible release of software, it prevents the sending of application messages, for example, Network Ring Again.
  • Page 292 Page 292 of 394 1.5 Mb ISL implementation LD 73 — Configuring the D-channel for ISL Prompt Response Description Add new data. Change existing data. TYPE Digital data block. TRSH 0-15 Assign a threshold set or table. RALM 1-(3)-128 Yellow alarm 24-hour threshold. BIPC 1-(2)-128 24-hour bit rate violation threshold.
  • Page 293 1.5 Mb ISL implementation Page 293 of 394 LD 15 — Enabling ISDN option (Part 1 of 2) Prompt Response Description REQ: Add new data. Change existing data. TYPE: Networking data. CUST Customer number 0-99 Range for Large System, Call Server 1000E, and Media Gateway 1000E 0-31 Range for Small System, CS 1000S system,...
  • Page 294 Page 294 of 394 1.5 Mb ISL implementation LD 15 — Enabling ISDN option (Part 2 of 2) Prompt Response Description Access Code 2. Enter call types (type of number) that use access code 2. Multiple responses are permitted. This prompt only appears on NARS equipped systems. If a call type is not entered here, it is automatically defaulted to access code 1.
  • Page 295 1.5 Mb ISL implementation Page 295 of 394 LD 16 — Enabling ISL option on a per-route basis, assigning a D-channel for each route (Part 2 of 2) Prompt Response Description DTRK YES/NO Enter YES if this is a Digital Trunk Interface (DTI or PRI).
  • Page 296 Page 296 of 394 1.5 Mb ISL implementation LD 14 — Assigning a channel identification to each trunk with the ISL option Prompt Response Description l ch Loop and channel for digital trunks RTMB Route number and Member number 0-511 1-4000 Range for Large System and CS 1000E system.
  • Page 297 1.5 Mb ISL implementation Page 297 of 394 LD 16 Prompt Response Description MODE ISLD TIE route used for ISL members. DCHI 0-15 DCHI port number. LD 14 Prompt Response Description CHID 1-192 Channel identifier for ISL channels. Must be coordinated with the far-end.
  • Page 298 Page 298 of 394 1.5 Mb ISL implementation 553-3001-201 Standard 2.00 September 2004...

  • Page 299: Mb Dti Implementation

    Page 299 of 394 2.0 Mb DTI implementation Contents This section contains information on the following topics: Overview ..........Hardware requirements .
  • Page 300 Page 300 of 394 2.0 Mb DTI implementation Figure 82 2.0 Mb DTI cabling NTBKO5DA 120½ Twisted Pair (6.15 m) Small System To 2.048 PRI2 Mpbs Carrier Cross Connect DTI2 NTBKO5CA 75½ Coax Pair (6.15 m) 553-AAA1071 553-3001-201 Standard 2.00 September 2004...

  • Page 301: Ntak10 2.0 Mb Dti Card

    2.0 Mb DTI implementation Page 301 of 394 NTAK10 2.0 Mb DTI card The 2.0 Mb DTI card provides the physical interface for the digital E-1 carrier on the system. The card includes an on-board clock controller and is installed in slots 1 through 9 in the Option 11C Cabinet.
  • Page 302 Page 302 of 394 2.0 Mb DTI implementation Inspect the NTAK10 circuit card Inspect the circuit card before installing it in the Option 11C Cabinet or MG 1000S: • Locate the NTAK10 2.0 Mb circuit card and carefully remove it from its packaging.
  • Page 303 2.0 Mb DTI implementation Page 303 of 394 Switch S2 — Carrier impedance configuration This switch sets the carrier impedance to either 120¾ or 75¾. Twisted pair cable is usually associated with 120¾. Coaxial cable is usually associated with the 75¾ setting. Table 85 Switch S2 Switch...
  • Page 304 Page 304 of 394 2.0 Mb DTI implementation Switch S4 — Carrier shield grounding This switch supports selective shield grounding of the Tx and/or Rx pairs of the carrier cable. Closing the switch (down position) applies Frame Ground (FGND) to the coaxial carrier cable shield, creating a 75¾ unbalanced configuration.
  • Page 305 2.0 Mb DTI implementation Page 305 of 394 Procedure 39 Connecting the cables In the cabling area, located directly below the card cage, remove the retaining bar that secures the MDF cables. Connect the NTBK05DA/CA interface cable to the 50-pin Amphenol connector below the card slot holding the NTAK10 2.0 Mb DTI circuit card.

  • Page 306: Dti Software Implementation

    Page 306 of 394 2.0 Mb DTI implementation NTBK05CA pinouts The pinouts for the NTBK05CA cable are as follows: Table 89 NTBK05CA pinouts From: 50-pin MDF Transmit coax Receive coax 50-pin MDF connector connector connector connector pin 23 Inner conductor —...
  • Page 307 2.0 Mb DTI implementation Page 307 of 394 LD 16 — Configuring the service routes LD 14 — Defining the associated list of service trunks LD 17 — Adding a 2.0 Mb DTI card Prompt Response Description Change. TYPE CEQU Common equipment.
  • Page 308 Page 308 of 394 2.0 Mb DTI implementation LD 73 — Defining the 2.0 Mb DTI ABCD signaling bit tables (Part 2 of 8) Prompt Response Description If FALT (send) signal not required. FALT(R) abcd (Receive) bits. 2.0 Mb DTI out-of-service. If FALT (receive) signal not required.
  • Page 309 2.0 Mb DTI implementation Page 309 of 394 LD 73 — Defining the 2.0 Mb DTI ABCD signaling bit tables (Part 3 of 8) Prompt Response Description NRCV(S) abcd Number received signal (send). If NRCV(S) signal not required. P EOSF(S) abcd End of selection free (send).
  • Page 310 Page 310 of 394 2.0 Mb DTI implementation LD 73 — Defining the 2.0 Mb DTI ABCD signaling bit tables (Part 4 of 8) Prompt Response Description P BURS(R) abcd Bring up receiver (receive). Uses switch-hook flash timer for timer. If BURS(R) not required.
  • Page 311 2.0 Mb DTI implementation Page 311 of 394 LD 73 — Defining the 2.0 Mb DTI ABCD signaling bit tables (Part 5 of 8) Prompt Response Description TIME xxx yyy Minimum and maximum time range for OPRS(R) in milliseconds. xxx = 8-(48)-2040 yyy = xxx-(128)-2040 P NXFR(S) abcd...
  • Page 312 Page 312 of 394 2.0 Mb DTI implementation LD 73 — Defining the 2.0 Mb DTI ABCD signaling bit tables (Part 6 of 8) Prompt Response Description TIME xxx yyy Minimum and maximum time range for OPRS(R) in milliseconds. xxx = 8-(48)-2040 yyy = xxx-(128)-2040 If SEZV(S) not required.
  • Page 313 2.0 Mb DTI implementation Page 313 of 394 LD 73 — Defining the 2.0 Mb DTI ABCD signaling bit tables (Part 7 of 8) Prompt Response Description If BURS(R) not required. TIME 64-(128)-192 Length of BURS(R) pulse in milliseconds. If SEZV(S) not required. P CAS(R) abcd CAS Flash.
  • Page 314 Page 314 of 394 2.0 Mb DTI implementation LD 73 — Defining the 2.0 Mb DTI ABCD signaling bit tables (Part 8 of 8) Prompt Response Description TIME 800 milliseconds. Note: Prompted when the abcd bits entered in response to the CLFR(S) prompt are different from the abcd bits of the IDLE signal.
  • Page 315 2.0 Mb DTI implementation Page 315 of 394 LD 73 — Defining the 2.0 Mb DTI pad tables (Part 2 of 4) Prompt Response Description The following prompts define the pad levels. The receiving pad code is r and the transmission pad code is t. These entries have the range 0- 15.
  • Page 316 Page 316 of 394 2.0 Mb DTI implementation LD 73 — Defining the 2.0 Mb DTI pad tables (Part 3 of 4) Prompt Response Description The following prompts define the pad levels. The receiving pad code is r and the transmission pad code is t. These entries have the range 0- 15.
  • Page 317 2.0 Mb DTI implementation Page 317 of 394 LD 73 — Defining the 2.0 Mb DTI pad tables (Part 4 of 4) Prompt Response Description Analog FEX trunks. Analog DID trunks. SATT Analog satellite TIE trunks. Analog TOLL office trunks. DTI2 2.0 Mb DTI trunk (Prompted only if the 1.5/2.0 Mb Gateway feature is equipped...
  • Page 318 Page 318 of 394 2.0 Mb DTI implementation Table 90 2.0 Mb DTI pads code value (dB) +1.0 +2.0 +3.0 +4.0 +5.0 +6.0 +7.0 code value (dB) +8.0 +9.0 +10.0 +11.0 +12.0 +13.0 +14.0 code value (dB) code value (dB) idle +0.6 LD 73 —...
  • Page 319 2.0 Mb DTI implementation Page 319 of 394 LD 73 — Defining the 2.0 Mb DTI timers (Part 2 of 2) Prompt Response Description If DIGT(S) signal not required P METR(R) abcd Metering (receive). Bits P, X or U. Only two P bits allowed. COT and DID trunks only.
  • Page 320 Page 320 of 394 2.0 Mb DTI implementation Responses are interpreted as follows: • mt = Maintenance threshold time. • ct = New call suppression (hardware service removal) threshold time. • ot = Out of service threshold time. • dt = No new data calls suppression threshold time. Each of the response times are expressed as follows: •...
  • Page 321 2.0 Mb DTI implementation Page 321 of 394 • nnnM = time in minutes where nnn = 1-240 • nnH = time in hours where nn = 1-24 LD 73 — Defining the grade of service timers for the DTI card (Part 1 of 2) Prompt Response Description...
  • Page 322 Page 322 of 394 2.0 Mb DTI implementation LD 73 — Defining the grade of service timers for the DTI card (Part 2 of 2) Prompt Response Description NS mt dt ct ot Maintenance threshold slip count. NS = Error count values are in the range 1-255. mt = Maintenance threshold time (MNT).
  • Page 323 2.0 Mb DTI implementation Page 323 of 394 LD 73 — Defining the 2.0 Mb DTI system timers (Part 2 of 3) Prompt Response Description MAND 0-(15)-1440 Maintenance guard time in minutes. NCSD 0-(15)-1440 New call suppression guard time in minutes and seconds. 1S-59S OSGD 0-(15)-1440...
  • Page 324 Page 324 of 394 2.0 Mb DTI implementation LD 73 — Defining the 2.0 Mb DTI system timers (Part 3 of 3) Prompt Response Description PREF CC3 Card number of PRI/DTI/SILC or DTI2/PRI2/SILC containing the primary clock reference. SREF CC3 Card number of PRI/DTI/SILC or DTI2/PRI2/SILC containing the primary clock reference.
  • Page 325 2.0 Mb DTI implementation Page 325 of 394 LD 16 — Configuring the service routes (Part 1 of 3) Prompt Response Description Add or Change Route data block. TYPE Route data block. CUST Customer number, as defined in LD 15 ROUT Route number 0-511...
  • Page 326 Page 326 of 394 2.0 Mb DTI implementation LD 16 — Configuring the service routes (Part 2 of 3) Prompt Response Description PTYP Port type at far-end: Analog TIE trunk routes: (ATT) Analog TIE trunk. Analogue satellite system TIE trunk or ESN satellite Meridian SL-1 TIE trunk.
  • Page 327 2.0 Mb DTI implementation Page 327 of 394 LD 16 — Configuring the service routes (Part 3 of 3) Prompt Response Description Originating end control. Default for TIE, ATVN, DID, and CCSA trunk types. FEDC Far-end disconnect control. Either end. Far-end.
  • Page 328 Page 328 of 394 2.0 Mb DTI implementation LD 14 — Defining the associated list of service trunks (Part 2 of 3) Prompt Response Description TOTN New card slot and channel, where: • s = 1-9 DTI2 card slot number (Option 11C main cabinet) s = 11-19 DTI2 card slot number (IP expansion cabinet 1) s = 21-29 DTI2 card slot number (IP expansion cabinet 2) s = 31-39 DTI2 card slot number (IP expansion cabinet 3)
  • Page 329 2.0 Mb DTI implementation Page 329 of 394 LD 14 — Defining the associated list of service trunks (Part 3 of 3) Prompt Response Description 0-127 1-4000 Range for CS 1000M Small System, Meridian 1 Small System, CS 1000S system, Media Gateway 1000B, and Media Gateway 1000T.
  • Page 330 Page 330 of 394 2.0 Mb DTI implementation 553-3001-201 Standard 2.00 September 2004...

  • Page 331: 2.0 Mb Pri Implementation

    Page 331 of 394 2.0 Mb PRI implementation Contents This section contains information on the following topics: Overview ..........Hardware requirements .

  • Page 332: Overview

    Page 332 of 394 2.0 Mb PRI implementation Overview This chapter provides the information required to install 2.0 Mb PRI on a system. It includes information about hardware installation and software implementation. Hardware requirements Circuit cards To implement 2.0 Mb PRI, an NTAK79 or an NTBK50 PRI card plus associated daughterboards is required.

  • Page 333: Hardware Description

    2.0 Mb PRI implementation Page 333 of 394 Table 91 2.0 Mb PRI hardware requirement (Part 2 of 2) Circuit card Description NTAK93 D-channel-handler interface (DCHI) daughterboard. Connects to the NTBK50 PRI card. NTBK51 Downloadable D-channel daughterboard (DDCH). Connects to the NTBK50 PRI card. Cables One of the following cables is required for a PRI connection: •...
  • Page 334 Page 334 of 394 2.0 Mb PRI implementation A second difference between the NTAK79 and NTBK50 2.0 Mb PRI cards is that the NTAK79 has an on-board clock controller while the NTBK50 supports the NTAK20 clock controller daughterboard. Note: If the NTAK93 D-channel daughterboard is attached to the NTBK50 PRI card instead of the NTBK51 Downloadable D-channel daughterboard, the NTBK50 PRI card functions in the same manner as the NTAK79 PRI card.
  • Page 335 2.0 Mb PRI implementation Page 335 of 394 Note: For CS 1000S, the NTAK79 card and NTBK50 cards are installed only in the MG 1000S. They are not supported in the MG 1000S Expansion. IMPORTANT! Each MG 1000S that has a digital trunk must have a clock controller set to an external reference clock.
  • Page 336 Every Small System cabinet or MG 1000S that contains a digital trunk must contain a clock controller. If a Small System is equipped with digital trunks, Nortel Networks recommends that at least one digital trunk is placed in the Small System main cabinet.
  • Page 337 2.0 Mb PRI implementation Page 337 of 394 NTAK93 D-Channel Handler Interface (DCHI) daughterboard The NTAK93 DCHI daughterboard interfaces with the system Central Processing Unit (CPU) and mounts on the NTBK50 PRI card for PRI (but not ISL) applications. The equivalent circuit resides on-board the NTAK79 2.0 Mb PRI card.

  • Page 338: Install The Ntak79 Pri Card

    Page 338 of 394 2.0 Mb PRI implementation A minimum of one NTBK51 is required for each PRI link. If more than one PRI link connects to the same end location, a single DDCH circuit card can support up to a maximum of 16 PRI connections for the system. This enables support for 495 B-channels or PRI trunks.
  • Page 339 2.0 Mb PRI implementation Page 339 of 394 Note: The ON position for all the switches is positioned toward the bottom of the card. This is indicated by a white dot printed on the board adjacent to the bottom left corner of each individual switch. Figure 83 NTAK79 with switch locations NTAK79...
  • Page 340 Page 340 of 394 2.0 Mb PRI implementation Switch SW1 — DCHI configuration This switch enables and disables the on-board DCHI and sets the operating mode of the DCHI. For the U.K., use DPNSS1 mode. For all other countries, use Q.931 mode. Table 92 Switch SW1 Switch...
  • Page 341 2.0 Mb PRI implementation Page 341 of 394 Switch SW4 — Carrier shield grounding This switch allows for the selective grounding of the Tx/Rx pairs of the carrier cable. Closing the switch (down position) applies Frame Ground (FGND) to the coaxial carrier cable shield, creating a 75¾ unbalanced configuration.
  • Page 342 Page 342 of 394 2.0 Mb PRI implementation Procedure 40 Connecting the cables Follow the instructions below to connect cables to the NTAK79 PRI card. Also refer to Figure 84. In the cabling area, located directly below the card cage, remove the retaining bar that secures the MDF cables.
  • Page 343 2.0 Mb PRI implementation Page 343 of 394 NTBK05DA pinouts The pinouts for the NTBK05DA cable are as follows: Table 96 NTBK05DA pinouts From: 50-pin MDF 9-pin connector connector Colour Signal pin 23 pin 6 Black pin 48 pin 7 White pin 50 pin 9...

  • Page 344: Install The Ntbk50 Pri Card

    Page 344 of 394 2.0 Mb PRI implementation NTBK05CA pinouts The pinouts for the NTBK05CA cable are as follows: Table 97 NTBK05CA pinouts From: 50-pin MDF Transmit coax Receive coax 50-pin MDF connector connector connector connector pin 23 Inner conductor —...
  • Page 345 2.0 Mb PRI implementation Page 345 of 394 Procedure 41 Inspecting the NTBK50 circuit card Locate the NTBK50 2.0 Mb circuit card plus associated daughterboard(s) and carefully remove them from their packaging. Inspect the circuit cards for any visible damage that occurred during shipping.
  • Page 346 Page 346 of 394 2.0 Mb PRI implementation Figure 85 NTBK50 with switch locations NTBK50 Faceplate Switch 1 LEDs Switch 4 Jack Switch 2 553-7871.EPS Set the switches on the circuit card according to the requirements of your installation. Switch SW1 — DCHI configuration (NTAK93 only) This switch enables and disables the DCHI and sets the operating mode of the DCHI.
  • Page 347 2.0 Mb PRI implementation Page 347 of 394 For the U.K., use DPNSS1 mode. For all other countries, use Q.931 mode. Table 98 Switch SW1 Switch Down (On) Up (Off) SW 1-1 — — SW 1-2 DPNSS1/DASS2 Q.931 Switch SW2 — Carrier impedance configuration This switch sets the carrier impedance to either 120¾...
  • Page 348 Page 348 of 394 2.0 Mb PRI implementation Switch SW4 — Carrier shield grounding This switch supports the selective grounding of Tx and Rx pairs of carrier cable. Closing the switch (down position) applies Frame Ground (FGND) to the coaxial carrier cable shield, creating a 75¾ unbalanced configuration. This applies only to the NTBK05CA cable.
  • Page 349 2.0 Mb PRI implementation Page 349 of 394 Slowly lower the daughterboard toward the NTBK50, keeping the standoffs in line with all four holes, until the holes rest atop the four standoffs. If more than slight pressure is required at this point, the connector pins might not be aligned with the connector socket.
  • Page 350 Page 350 of 394 2.0 Mb PRI implementation Figure 86 Daughterboard installation Stiffeners NTAK20 Clock Controller Connector Sockets LEDs Bantam Jacks NTAK93 or NTBK51 D-Channel Interface 553-7872 Standoffs 553-7872.EPS 553-3001-201 Standard 2.00 September 2004...
  • Page 351 2.0 Mb PRI implementation Page 351 of 394 Remove the daughterboards from the NTBK50 Use these guidelines to remove the NTAK20 and NTBK51 or NTAK93 from the NTBK50 PRI card. Because of the physical layout of the mother and daughterboards, the NTAK20 should be removed before the NTAK93 or NTBK51.
  • Page 352 Page 352 of 394 2.0 Mb PRI implementation Connect the cables Follow the instructions below to connect cables to the NTBK50 PRI card. Also refer to Figure 87. • In the cabling area, located directly below the card cage, remove the retaining bar that secures the MDF cables.
  • Page 353 2.0 Mb PRI implementation Page 353 of 394 NTBK05DA pinouts The pinouts for the NTBK05DA cable are as follows: Table 101 NTBK05DA pinouts From: 50-pin MDF connector 9-pin connector Colour Signal pin 23 pin 6 Black pin 48 pin 7 White pin 50 pin 9...

  • Page 354: Pri Software Implementation

    Page 354 of 394 2.0 Mb PRI implementation PRI software implementation The following information describes the process required to program basic 2.0 Mb PRI on the system. PRI cards must be configured before defining the DCH links or PRI applications. Prompts which do not show a response are left as default.
  • Page 355 2.0 Mb PRI implementation Page 355 of 394 LD 17 — Adding a PRI card (Part 2 of 2) Prompt Response Description CEQU Changes to common equipment. PRI2 The PRI2 digital card number, where: xx = 1-9 (Option 11C main cabinet), 11-19 (IP expansion cabinet 1), 21-29 (IP expansion cabinet 2), 31-39 (IP expansion cabinet 3), 41-49 (IP expansion cabinet 4.) xx = 11-14, 21-24, 31-34, 41-44 of the first, second, third and...
  • Page 356 Page 356 of 394 2.0 Mb PRI implementation LD 17 — Adding a DCHI or DDCH (Part 2 of 3) Prompt Response Description CDNO 1-50 Card slot number used as the primary DDCH/DCHI. Card slots 10, 20, 30, 40, and 50 are only applicable for D- channel configuration of ISL or VNS.
  • Page 357 2.0 Mb PRI implementation Page 357 of 394 LD 17 — Adding a DCHI or DDCH (Part 3 of 3) Prompt Response Description Software release of far-end. This is the current software release of the far-end. If the far-end has an incompatible release of software, it prevents the sending of application messages, for example, ‘Network Ring Again.
  • Page 358 Page 358 of 394 2.0 Mb PRI implementation LD 15 — Defining a PRI customer (Part 2 of 3) Prompt Response Description CUST 0-99 Customer number Range for Large System, Call Server 1000E, and Media Gateway 1000E 0-31 Range for Small System, CS 1000S system, Media Gateway 1000B, and Media Gateway 1000T XXXX Enter the customer's Listed Directory Number.
  • Page 359 2.0 Mb PRI implementation Page 359 of 394 LD 15 — Defining a PRI customer (Part 3 of 3) Prompt Response Description HLOC Home location code (NARS) 1-9999 One to four digit Local Steering Code established in the Coordinated Dialing Plan (CDP). The LSC prompt is required for Calling Line ID and Network ACD.
  • Page 360 Page 360 of 394 2.0 Mb PRI implementation LD 16 — Defining a PRI service route (Part 2 of 2) Prompt Response Description CTYP Call Type. Enter the call type to associate with the outgoing <CR> route for direct dialing using the trunk access code (instead of NARS access code).
  • Page 361 2.0 Mb PRI implementation Page 361 of 394 LD 14 — Defining service channels and PRI trunks (Part 2 of 2) Prompt Response Description 0-127 1-4000 Range for CS 1000M Small System, Meridian 1 Small System, CS 1000S system, Media Gateway 1000B, and Media Gateway 1000T.
  • Page 362 Page 362 of 394 2.0 Mb PRI implementation LD 73 — Defining system timers and clock controller parameters (Part 2 of 2) Prompt Response Description Card number for Clock Controller 3. PREF CC3 Card number of PRI/DTI/SILC or DTI2/PRI2/SILC containing the primary clock reference.
  • Page 363 2.0 Mb PRI implementation Page 363 of 394 LD 73 — Defining PRI parameters and thresholds (Part 2 of 4) Prompt Response Description mc mt oc ot Slip error count. Where: mc = Maintenance threshold slip count, 1- (5)-255. mt = Maintenance threshold time, default 24 hours. oc = Out-of-service threshold slip count, 1-(30)-255.
  • Page 364 Page 364 of 394 2.0 Mb PRI implementation LD 73 — Defining PRI parameters and thresholds (Part 3 of 4) Prompt Response Description T2 mt dt ct ot Group 2 error thresholds. This is the maximum amount of time that can elapse before software checks the associated thresholds of 120 to 32,640 msec and rounds it to the closest multiple of 128 msec.
  • Page 365 2.0 Mb PRI implementation Page 365 of 394 LD 73 — Defining PRI parameters and thresholds (Part 4 of 4) Prompt Response Description PERS Persistence Timer for Group II problems. Enter 0-256 msec in increments of 2 msec. Default is 50 (=100ms).
  • Page 366 Page 366 of 394 2.0 Mb PRI implementation LD 73 — Changing trunk pad category values (Part 2 of 2) Prompt Response Description Nontransmission compensated. Transmission compensated. Digital COT, FEX, WAT, and DID trunks. Via Net Loss. 2.0 Mb PRI2 digital TOLL office trunks. Analog CO or WATS trunks.
  • Page 367 2.0 Mb PRI implementation Page 367 of 394 Table 103 shows the pads available to 2.0 Mb PRI. Positive dB represents loss and negative dB represents gain. Table 103 Pad values code value +1.0 +2.0 +3.0 +4.0 +5.0 +6.0 +7.0 (dB) code value...
  • Page 368 Page 368 of 394 2.0 Mb PRI implementation Configure ISDN BRI trunking with IP expansion cabinets/ MG 1000S systems For Small Systems, when configuring the MISP card slot number for ISDN BRI trunking in LD 27, the response to the LOOP prompt is: 1-9 (Option 11C Cabinet), 11-19 (IP expansion cabinet 1), 21-29 (IP expansion cabinet 2), 31-39 (IP expansion cabinet 3), 41-49 (IP expansion cabinet 4).

  • Page 369: 2.0 Mb Isl Implementation

    Page 369 of 394 2.0 Mb ISL implementation Contents This section contains information on the following topics: Overview ..........ISL hardware requirements .

  • Page 370: Isl Hardware Requirements

    Page 370 of 394 2.0 Mb ISL implementation ISL hardware requirements ISL, regardless of the operation mode, uses analog or digital TIE lines as B-channels. ISL in shared mode In shared mode, PRI hardware is required in addition to the existing TIE lines interface cards.
  • Page 371 2.0 Mb ISL implementation Page 371 of 394 • A modem capable of the following: (such as Ventel 2400-33 or 2400 Plus II) — minimum of 2400 baud — synchronous operation — must support leased line (also known as private line or point-to-point) operation •...
  • Page 372 Page 372 of 394 2.0 Mb ISL implementation • Modems such as the Ventel 2400, Hayes 2400 (the Hayes Smartmodem 2400 cannot be used on leased lines) or Gandalf 2400 that can support 2 or 4-wire leased line operation. 4-wire operation must be specified when ordering.

  • Page 373: Isl Hardware Installation

    2.0 Mb ISL implementation Page 373 of 394 ISL hardware installation Shared mode The hardware installation is identical to the PRI installation, with the addition of analogue or digital TIE trunks (or both). Dedicated mode Procedure 42 Installing the NTAK02 The NTAK02 connects to the modem through the NTAK19BA 4-port cable.

  • Page 374: Isl Software Implementation

    Page 374 of 394 2.0 Mb ISL implementation Table 105 NTAK02 jumper settings Jumper Strap for Strap for Jumper Unit location location RS422 RS232 Unit 0 C - B B - A Unit 1 C - B B - A C - B B - A C - B...
  • Page 375 2.0 Mb ISL implementation Page 375 of 394 Shared mode The NTAK79 on-board DCHI supports ISDN PRI signaling and ISL trunks. The configuration is basically the same as the PRI D-channel, with the D-channel also supporting ISL trunks. The DTI/PRI software implementation sequence can be used (refer to the appropriate chapters for more information) with the following exceptions.
  • Page 376 Page 376 of 394 2.0 Mb ISL implementation Dedicated mode The DCHI uses the NTAK02 circuit card and does not support ISDN PRI signaling. The DCHI is reserved for ISL use only. The D-channel can communicate with the far-end by means of a dedicated leased line modem or dial-up modem.
  • Page 377 2.0 Mb ISL implementation Page 377 of 394 LD 17 — Configure the D-channel for ISL (Part 2 of 3) Prompt Response Description CTYP DCHI D-channel card type. CDNO 0-15 Serial Data Interface (SDI) Card number Number the SDI cards logically with the system. MSDL application small system Card number 1-9 11-19 21-29, 31-39 41-49...
  • Page 378 Page 378 of 394 2.0 Mb ISL implementation LD 17 — Configure the D-channel for ISL (Part 3 of 3) Prompt Response Description LAPD YES,(NO) Change LAPD parameters. Simply carriage return if timers are to be left at default value. The following timers are prompted only if LAPD is set to YES.
  • Page 379 2.0 Mb ISL implementation Page 379 of 394 LD 15 — Enable the ISDN option (Part 2 of 2) Prompt Response Description 1-32700 Customer private network identifier. MUST be unique to this customer in the private network. Used as part of the setup message for feature operation such as Network Ring Again and Network ACD.
  • Page 380 Page 380 of 394 2.0 Mb ISL implementation LD 16 — Enable the ISL option (Part 1 of 2) Prompt Response Description Add new data. Change existing data. TYPE Route data block. CUST Customer number, as defined in LD 15 ROUT Route number 0-511...
  • Page 381 2.0 Mb ISL implementation Page 381 of 394 LD 16 — Enable the ISL option (Part 2 of 2) Prompt Response Description CTYP Call Type. Enter the call type to be associated with the outgoing <CR> route for direct dialing using the trunk access code (instead of NARS access code).
  • Page 382 Page 382 of 394 2.0 Mb ISL implementation 553-3001-201 Standard 2.00 September 2004...

  • Page 383: Non-Standard Cables

    Page 383 of 394 Non-standard cables Contents The section contains information on the following topics: Introduction ..........NT5K40AA, NT5K41AA, NT5K86AA .

  • Page 384: Introduction

    Page 384 of 394 Non-standard cables Introduction This section provides information required to build systems cables of non-standard lengths for ISDN PRI applications. NT5K40AA, NT5K41AA, NT5K86AA These cables are used to transport the 2Mb digital signal from the faceplate connector on the PRI card to the Line Terminating Equipment interface. •...

  • Page 385: Nt8D7206, Nt8D7207

    Non-standard cables Page 385 of 394 NT8D7206, NT8D7207 This cable is used to transport the 2Mb/s digital signal from the PRI pack to the I/O assembly located at the cabinet bulkhead. • Standard length - 3.05 m (10 ft.) for Half Group systems and Single group systems •...

  • Page 386: Qcad129

    Page 386 of 394 Non-standard cables See Table 109. Table 109 QCAD128 wire list From Signal P1-1 P2-1 XTIP (transmit tip) to telephone company P1-2 P2-2 GND (ground) P1-3 P2-3 RTIP (receive tip) from telephone company P1-4 P2-4 GND (ground) P1-5 P2-5 P1-6...

  • Page 387: Qcad133

    Non-standard cables Page 387 of 394 • P1 Connector - 15-pin, male, subminiature D, with jack-screws • P2 connector - 25-pin, male, subminiature D, with jack-screws Table 110 QCAD129 wire list Echo Canceller PRI Signal From Signal P1-1 P2-20 P1-2 P2-2 P1-4 P2-8...

  • Page 388: Nt8D7205

    Page 388 of 394 Non-standard cables • P1 Connector - 15-pin, female, subminiature D with jack-screws • P2 Connector - 15-pin, male, subminiature D, with slide-latch (optional spring-latch loose-packed with cable assembly) Table 111 QCAD133 wire list Color From PRI signal WHITE P1-1 P2-1...

  • Page 389: Qcad328

    Non-standard cables Page 389 of 394 Table 112 NT8D7205 wire list From Color (pack end) (I/O end) Signal White P1-6 P2-6 XTIP (transmit) Black P1-7 P2-7 XRING (transmit) Green Shield P1-9 GROUND P1-2 P2-2 RTIP (receive) Black P1-3 P2-3 RRING (receive) Red Shield P1-5 GROUND...

  • Page 390: Nt8D74 Clock Controller To Intergroup Cable

    Page 390 of 394 Non-standard cables Table 113 QCAD328 wire list From Signal P1-2 P2-2 SDA+ P1-13 P2-10 SDB- P1-20 P2-15 P1-15 P2-9 STA+ P1-14 P2-11 STB- P1-3 P2-4 RDA+ P1-16 P2-12 RDB- P1-17 P2-5 RTA+ P1-12 P2-13 RTB- P1-8 P2-8 P1-5 P1-8...

  • Page 391: Nt8D75 Clock Controller To Clock Controller Cable

    Non-standard cables Page 391 of 394 This cable is available in the following lengths: • NT8D74AC 1.2 m (4 ft) • NT8D74AD 1.8 m (6 ft) • NT8D74AE 2.4 m (8 ft) • NT8D74AF 3 m (10 ft) (QCAD110B) • NT8D74AJ 4.8 m (16 ft) NT8D75 Clock Controller to Clock Controller cable...

  • Page 392: Nt8D85 Network To Ipe Cable

    Page 392 of 394 Non-standard cables This cable is available in the following lengths: • NT8D83AC 1.2 m (4 ft) • NT8D83AD 1.8 m (6 ft) NT8D85 Network to IPE cable This cable connects the following: • QPC581 CMA card to QPC581 CMA card in dual CPU configuration •...

  • Page 393: Nt8D97Ax Pri/Dti I/O To Mdf Cable

    Non-standard cables Page 393 of 394 • PRI/DTI card • QPC659 Dual Loop Peripheral Buffer card • NT8D47 RPE This cable is available in the following lengths: • NT8D86AC 1.5 m (5 ft) • NT8D86AD 1.8 m (6 ft) NT8D97AX PRI/DTI I/O to MDF cable This cable connects the PRI/DTI card to the MDF through the I/O connector panel.

  • Page 394: Ntnd98 Pri To I/O Panel Cables

    Page 394 of 394 Non-standard cables NTND98 PRI to I/O panel cables These cables connect the PRI card to the I/O panel. • NTND98 6 ft 553-3001-201 Standard 2.00 September 2004...
  • Page 396 Copyright © 2003—2004 Nortel Networks All Rights Reserved Information is subject to change without notice. Nortel Networks reserves the right to make changes in design or components as progress in engineering and manufacturing may warrant. SL-1, Meridian 1, and Succession are trademarks of Nortel Networks.

This manual is also suitable for:

Communication server 1000m chassisCommunication server 1000m cabinetCommunication server 1000m half groupCommunication server 1000m single groupCommunication server 1000m multi groupCommunication server 1000e

Table of Contents
