WSM KX080-3 Service
2) Draw out the shaft [102] and ball bearing
[149] from the spindle [2].
Note : The speed reducer side shaft can be
drawn out easily after tapping the tip of
the shaft gently with a plastic hammer.
The shaft however may jump put if
struck forcefully.
3) Remove the pivots [176], parallel pins [177]
(2 each) from the spindle [2].
4) Remove the 2-speed switching piston
assembly (piston [161], shoe [162]) and
spring [185] from the spindle [2].

(16)Removal of ball bearing

Note : The ball bearing is removed only when
replacing.
1) Place the retainer (2) on the press bench,
and place the shaft [102] inside.
2) Clamp the tip of the shaft [102] with the
press and remove the ball bearing [149]
from the shaft [102].
Note : Do not reuse the ball bearing.
1)Press
2)Retainer(1)
IV-S-162
Hydraulic system
