Page 1 EXCAVATOR MODEL KX085-5 OPERATING INSTRUCTIONS W9297-8135-2 - Original - 12/2023...
Page 2 Product identification number: Shipment date: These operating instructions only apply to the KUBOTA excavator KX085-5, which complies with the fol- lowing Declaration of Conformity (page 11). In addition, the machine’s product identification number must correspond to the following scope of appli- cation.
Page 3: Table Of Contents
Hoisting the machine with a crane ...................... 39 Transport on a flat bed trailer ......................41 DESCRIPTION OF THE MACHINE....................45 Model overview............................45 Model KX085-5 ..........................45 Dimensions ............................46 Specifications ............................48 Identification of the machine........................ 50 Product identification number......................50 Engine number...........................
Page 4 Tables Description of the components of the left control console ............... 54 Drive levers and control pedals ......................55 Drive levers and control pedals - description ................... 55 Right control console .......................... 56 Description of the components of the right control console ............. 57 Keypad switch ............................
Page 5 Tables Fuel level, coolant temperature, hydraulic oil temperature, date and time - check......88 Fluid level of the wiper/washer system (cab version) - check............88 Setting up the workplace ........................88 Getting on the machine........................88 Adjusting the operator's seat ......................89 Seat belt ............................
Page 6 Tables Front window ............................ 138 Front window base ........................... 139 Side window ............................. 140 Cold weather operation........................141 Necessary preparations prior to the winter season ................141 Operation during the winter season....................141 Jump-starting the machine......................... 142 Operating in emergency situations ....................143 Engine emergency stop........................
Page 7 Tables Oil filter - change..........................181 Engine oil - fill ..........................181 Air filter element - check/clean/change .................... 182 Interior air filter (cab version) - check/clean/change ................ 183 Fuel filter - change ........................... 184 Water separator - drain ........................185 Water separator - clean........................
Page 8 KUBOTA rotary beacon ........................225 KUBOTA pipe safety valve ......................... 225 KUBOTA gravel guard......................... 226 KUBOTA auxiliary port kit ........................226 KUBOTA quick coupling systems and attachments ................ 227 KUBOTA bucket accessories ......................227 Replacing the bucket ........................227 Removing the bucket ........................228 Attaching the bucket ........................
Page 9: Abbreviations
Tables Abbreviations 1/min revolutions per minute kilowatt percent litre ° degrees l/min litres per minute °C Degrees Celsius noise level operator's place Ampere sound power level acc. according metre American Petroleum Institute m/s² metre per square second approx. approximately m³ cubic metre ASTM American Society for Testing and Materials...
Page 10: General Symbols
Tables General symbols Swivel boom (left) Warning light Swivel boom (right) Fuel indicator Dozer up Engine oil pressure indicator Dozer down Charge indicator Control lever direction Glow indicator Control lever direction Hydraulic oil Beacon Fast speed Auxiliary port enable switch Slow speed Working lights Forward travel...
Page 11 Tables Anti-theft system fault indicator Dozer in floating position Insert key indicator Overload warning indicator Pull out key indicator Raise control lever lock indicator Lower control lever lock indicator Start engine indicator Auxiliary port indicator Controller Area Network indicator Horn Return switch Please read the operating manual Acknowledge...
Page 12 Tables W9297-8135-2 12/2023...
Page 13: General Information
Keep the Declaration of Conformity in a safe place and show it, if requested, to the responsible authorities. If the Declaration of Conformity is lost, the operator must request a replacement copy from the KUBOTA dealer. The CE and UKCA conformity markings are located on the type plate. If the machine is modified or retrofitted with- out the approval of the manufacturer, the safety of the machine may be affected, thus rendering the Declaration of Conformity invalid.
Page 14 General information Content of the EC Declaration of Conformity: W9297-8135-2 12/2023...
Page 15 General information Content of the UK Declaration of Conformity: W9297-8135-2 12/2023...
Page 16: Date Of Issue Of The Operating Instructions
General information Declaration of Conformity: radio equipment manufacturer Hereby, ASAHI DENSO CO., LTD. declares that the radio equipment type [CZ106] is in compliance with the di- rectives of the following economic areas: European Union: 2014/53/EU United Kingdom: The Radio Equipment Regulation 2017 (S.I. 2017/1206) The full text of the respective Declaration of Conformity is available at the following internet address: http://en.ad-asahidenso.co.jp/euro-compliance/ Date of issue of the operating instructions...
Page 17: Location Of The Operating Instructions
The operating instructions must always be kept on the machine. If the operating instructions have become illegible due to continuous use, the owner (operator) must order a replacement from the KUBOTA dealer. The storage location (1) for the operating instructions is on the left side of the driver's seat.
Page 18: Spare Parts
When ordering spare parts, please always provide the following information: Machine’s product identification number and year of construction (see type plate) Designation/type of spare part (see original KUBOTA spare parts catalogue) Part number of the spare part (see original KUBOTA spare parts catalogue) Quantity Customer number For written orders, please provide this information exactly, or for telephone orders, please have this information ready before calling.
Page 19: Safety Rules
Safety rules SAFETY RULES Basic safety instructions The EC Use of Work Equipment Directive (2009/104/EC) from 16/09/2009 applies to the operation of the aforementioned machine. The information in these operating instructions applies for maintenance and repairs. National rules and regulations apply where applicable. Duties, liability and warranty A basic prerequisite for the safe handling and problem-free operation of the machine is the knowledge of the safety instructions and safety regulations.
Page 20: Safety Symbols
Safety rules The owner must ensure at his or her own responsibility that the safety rules are observed (page 17) unapproved use (page 19) and unauthorised operation are prevented the approved used (page 19) is ensured and the machine is operated in accordance with the contractual con- ditions of use.
Page 21: Approved Use
Safety rules Approved use The machine specified in these operating instructions may be used only for loosening the ground, excavating, picking up, handling and dumping of soil, rocks and other materials, as well as working with a dozer or hydraulic hammer.
Page 22: Restrictions With Regard To Quick Couplers And Attachments
KUBOTA. Using quick couplers or attachments that were not sold or approved by KUBOTA or that are not suited for use with the KUBOTA excavator in some other way can cause damage to the excavator and to other property. Furthermore, they pose a risk of injury to the operator and other people.
Page 23: Noise Emission And Vibration
Safety rules Noise emission and vibration The values specified in these operating instructions were identified during the test cycle on an identical machine and are valid for a machine with the standard equipment. The determined values are shown in the Technical Data (page 48).
Page 24: Safety Labels On The Machine
Clean safety labels with soap and water and dry with a soft, clean cloth. Replace damaged or missing safety labels with new ones from your KUBOTA dealer. If a component with glued-on safety labels is replaced with a new part, make sure that the new labels are affixed to the same location as the replaced component.
Page 25 Safety rules Code #: RC788-5727-0 Mortal danger by crushing! Low safe distance to the excavator and to obstacles can prevent an emergency exit from the danger zone. Crushing by excavator results in severe injury or death. Do not enter the manoeuvring area. Ensure safe distance to obstacles and sufficient freedom of move- ment.
Page 26 Safety rules Code #: RD579-5725-0 Risk of burns from hot components! Surfaces can be hot and lead to burns. Do not touch hot parts, such as exhaust muffler, etc. Code #: RD859-5778-0 Risk of being crushed or cut by rotating components! The rotating fan can cut into limbs and the rotary belt drive can pull in limbs and crush them.
Page 27 Safety rules Code #: RB456-5722-0 Mortal danger by crushing! A low safe distance to the boom can impede an emergency exit from the danger zone. Being crushed by the boom can result in severe inju- ry or death. Do not stay in the swing area of the boom. Ensure safe distance to obstacles and sufficient freedom of move- ment.
Page 28 Safety rules Code #: RB419-5796-0 Not a lifting point Code #: RD839-5739-0 Caution! Risk of component damage! When using a wider or deeper bucket, take good care when swinging or retracting the front attachments to make sure that the bucket does not hit the cab.
Page 29 Always lock front window securely. Code #: RD849-5748-0 Max. lifting load during swivel operation is 360° KX085-5 with operating weight 8467 kg W9297-8135-2 12/2023...
Page 30 Safety rules Code #: RD859-5765-0 Risk of accidents! The protection cover may break under stress. Do not enter Code #: RD809-5714-0 Emergency exit Code #: RD809-5733-0 (both sides) Tie-down eye - Only use to lash down the machine! Code #: RD579-5743-0 Risk of personal injury! Always buckle up.
Page 31 Safety rules Code #: RD579-5739-0 Mortal danger from moving excavator! When staying in the danger zone and in the case of a suddenly starting excavator, there is the danger of being run over by the excavator. Only start the machine from the operator's seat. Do not start the machine by bypassing the starter poles.
Page 32 Safety rules Code #: RD579-5783-0 Mortal danger by crushing! Low safe distance to the machine and to obstacles can prevent an emergency exit from the danger zone. Crushing by machine results in severe injury or death. Before leaving the machine, lower bucket to the ground. Lift the control lever lock, turn the starter switch to the STOP posi- tion and remove the key.
Page 33 Safety rules Code #: RD579-5755-0 Risk of being crushed due to narrow gap! The gap between the door and the counterweight is narrow. When fas- tening the cab door to the door stop or to the counterweight, there is a danger of the hands or fingers being crushed in the door crack.
Page 34: Safety Devices
Safety rules Safety devices Before starting the machine, all safety devices must be installed properly and operational. Manipulating the safety devices is prohibited. Protective devices may only be removed once the machine is standing still and the engine is stopped and secured against restarting (starter switch in STOP position and key removed).
Page 35: Cab Protective Structure
When using a hydraulic hammer or other attachment for demolition work where material (e.g. asphalt) is removed and can uncontrollably sputter away, a gravel guard is recommended for protection. If a front protective grille or a roof protective grille is required, a KUBOTA gravel guard (optional equipment) can be installed.
Page 36: Emergency Hammer
Any manipulation can result in substantial personal injuries, even death, and is therefore strictly pro- hibited. The manipulation and repair of the pipe safety valves is prohibited. They may only be replaced by your KUBOTA dealer as a kit. W9297-8135-2...
Page 37: Overload Warning System
If you cannot hear it, machine must not be used for lift- ing operation. Please contact your KUBOTA dealer immediately. An overload warning function is only available if the machine is equipped for lifting operations.
Page 38: Fire Protection
Safety rules Fire protection The machine components and attachments (in particular the engine and the exhaust system) reach high temperatures even under normal working conditions. An electric installation that is damaged or not properly serviced may lead to flashovers and/or electric arcs. The following fire protection guide- lines may help you ensure the maintenance and efficiency of your equipment and minimise fire haz- ards.
Page 39: Recovery, Loading And Transport
Recovery, loading and transport RECOVERY, LOADING AND TRANSPORT Safety rules for recovery For recovery of the machine, a towing vehicle of at least the same weight class as the machine must be used. A tow bar must be used for the recovery. If a tow rope is used, an additional vehicle to brake the machine must also be attached.
Page 40: Safety Rules For Transport
Recovery, loading and transport Safety rules for transport Risk of accidents if the load is not secured properly! The following safety rules must be observed. Risk of accidents due to unapproved use of the machine! Driving the machine onto the transport vehicle without using ramps and with the help of the boom is prohibited! Check whether the transport vehicle is designed for carrying the machine.
Page 41: Recovery
Recovery, loading and transport Recovery Adhere to the safety rules (page 17) and the safety rules for recovery (page 37). A recovery is only allowed over a short distance and at walking speed (0.5 m/s ~ 1.0 m/s). Attach the tow bar or tow rope to the towing eye (1) on the ma- chine and on the towing vehicle.
Page 42 Recovery, loading and transport Attach the lifting gear (1) on the right- and left-hand side around the dozer blade (2). Protect the dozer against damage using pieces of cloth. Do not use the tie-down eyes (3). Fasten the lifting gear (3) around the boom as illustrated in the figure.
Page 43: Transport On A Flat Bed Trailer
Recovery, loading and transport Transport on a flat bed trailer Adhere to the “Safety rules” chapter (page 17) and the “Safety rules for transport” section (page 38). Mortal danger by crushing! Nobody is allowed in the loading area or in close proximity to that area while operating the machine on the ramp and in the loading area, e.g.
Page 44 Recovery, loading and transport Secure the machine in front of and behind the chains to prevent it from slipping, e.g. using wooden beams (previous Figure/1). In order to prevent the machine from tipping on the transport vehicle, only use the approved lashing points (2) on the swivel frame.
Page 45 Recovery, loading and transport If no lashing points are available on the swivel frame, only use the lashing points on the dozer (3) and on the track frame (4) illustrated in the following figure. Tension the lashing material on the dozer (3) diagonally. Tension the lashing material on the track frame (4) towards one side.
Page 46 Recovery, loading and transport W9297-8135-2 12/2023...
Page 47: Description Of The Machine
Description of the Machine DESCRIPTION OF THE MACHINE Model overview The excavator is available as CAB model only. Model KX085-5 W9297-8135-2 12/2023...
Page 48: Dimensions
Description of the Machine Dimensions The dimensions of model KX085-5 can be found in the following illustration and table. W9297-8135-2 12/2023...
Page 49 The table row corresponding to the arm attached to the machine applies. In addition, please note the “Design of arm” table below! Arm version Name Type Arm 1750 mm** A = 1750 mm Arm 2100 mm A = 2100 mm Optional equipment All dimensions in mm with original KUBOTA bucket and rubber crawlers. Subject to technical changes. W9297-8135-2 12/2023...
Page 50: Specifications
Description of the Machine Specifications The specifications for this series are as follows. KUBOTA Excavator Model name KX085-5 Counterweight 1140 Machine weight* 8392 Operating weight** 8467 Capacity (CECE) m³ 0.21 Bucket (KUBOTA) Width with teeth Water-cooled 4-cylinder Type turbo diesel engine...
Page 51 (ISO 2631-1:1997) Idling m/s² RMS < 0.5 With original KUBOTA bucket 176.6 kg, ready for operation. Machine weight, incl. operator 75 kg. *** This CO measurement results from testing over a fixed test cycle under laboratory conditions a(n) (parent) engine representative of the engine type (engine family) and shall not imply or express any guarantee of the performance of a particular engine.
Page 52: Identification Of The Machine
Description of the Machine Identification of the machine The type plate of the machine is located at the front of the swivel frame. The owner should enter the stamped data in the field on the back of the front cover. Conformity marking Engine performance Product identification number...
Page 53: Standard Equipment
Description of the Machine Standard equipment This model includes the following standard equipment: Operating instructions with protective cover Spare parts catalogue Grease gun Spare fuses (20 A, 2x30 A, 50 A, 60 A, 100 A) Guarantee Stow the greasing gun (2) under the battery (1). The spare parts catalogue, guarantee and spare fuses can be stowed together with the operating instructions (page 15).
Page 54 Description of the Machine W9297-8135-2 12/2023...
Page 55: Assembly And Functions
Assembly and functions ASSEMBLY AND FUNCTIONS Component overview Swivel frame Bucket Track frame Bucket linkage LH outside rear view mirror Bucket cylinder Operator's place Auxiliary port connectors Cab door Drive sprocket Arm cylinder Crawler Boom Tool compartment Working light (boom) Idler RH outside rear view mirror Dozer...
Page 56: Operator's Place
Assembly and functions Operator's place The operator's place is located in the middle of the cab. It includes the following control elements: Left control console Operator's seat Drive levers and control pedals Right control console Left control console The left control console includes the following components: Control lever lock Rocker switch for the auxiliary port 2 Left control lever...
Page 57: Drive Levers And Control Pedals
Assembly and functions Left control lever The left control lever is used to move the swivel frame and the arm. The figure, in conjunction with the following table, shows the functions of the left control lever. Position of control lever Movement Arm dump Arm crowd Swivel frame to the left...
Page 58: Right Control Console
Assembly and functions Right control console The right-hand control console contains the following components: Rocker switch for the auxiliary port 1 Horn switch Auxiliary port enable switch Right control lever One way hold switch Travel speed switch Dozer control lever Heating and air-conditioner control Inhibit switch Potentiometer for the adjustment of the engine speed...
Page 59: Description Of The Components Of The Right Control Console
Assembly and functions Description of the components of the right control console Rocker switch for the auxiliary port 1 The rocker switch for auxiliary port 1 controls the oil flow to auxiliary port 1. Turning the rocker switch to the left causes the oil to flow towards the connector on the left-hand side of the arm.
Page 60: Keypad Switch
Assembly and functions Inhibit switch The inhibit switch (DPF = diesel particulate filter) is used to lock and release the automatic particle filter re- generation. The particle filter regeneration must be locked under certain working conditions. For example, when working close to people, animals, plants and/or flammable materials, the particle filter regeneration should be locked.
Page 61 Assembly and functions Washer switch Switches the washer system. Wiper switch Switches on the wiper for the front window. AUTO IDLE switch Using the switch you can switch the AUTO IDLE control on, switch the engine auto-stop control on, or switch both of them off.
Page 62: Display
Assembly and functions First, the engine speed pre-selected with the potentiometer drops down to idle speed after approx. 4 seconds - provided that no controls are being used. After the time set in auto-stop setting has passed, the engine stops automatically. The warning screen is displayed 30 seconds before the engine stops.
Page 63: Description Of The Display
Assembly and functions Description of the display The display is multifunctional. You will find detailed descriptions of the individual functions in the respective chap- ters. Warning light The warning light flashes red when a system fault or technical malfunction occurs. The warning light flashes yellow when the system issues a warning.
Page 64: Other Equipment At The Operator's Place
Assembly and functions Other equipment at the operator's place Other equipment located at and around the operator's place is described below. Heating and air-conditioning system The heating controls are on the right control console. The control panel includes the following components: Temperature control Blower switch Air-conditioner switch...
Page 65: Wiper/Washer System
Assembly and functions The air is conducted via the heat exchanger and/or the evaporator of the air-conditioner assembly to the air nozzles. Windshield Operator Leg room Side window Rear window Wiper/washer system The front window is provided with a wiper/washer system. The sys- tem is operated with the washer switch (1) and wiper switch (2).
Page 66: Interior Lighting
Assembly and functions Interior lighting An interior light (1) is located to the right of the cab roof. Use the switch (2) to turn it on and off. Fuse box The fuse box (1) is located behind the right-side cover in the cabin. Glove box The glove box (1) is located behind the operator's seat.
Page 67: Cup Holder
Assembly and functions Cup holder There is a cup holder (1) in the right control console. 12-V electrical outlet and USB outlet A 12-V electrical outlet (1) and an USB (Type-A) outlet (2) for the connection of an external electric device are located on the right- hand side control console.
Page 68: Main Battery
Assembly and functions Main battery The main battery (1) is located on the right-hand side of the vehicle under the side cover. Battery isolator The battery isolator (1) can be used to cut off the main power circuit. The battery isolator is on the right vehicle side under the side cover. Tank filler neck The tank filler neck (1) is located under the valve compartment cov- er on the right of the machine.
Page 69: Suction Pump Switch
Assembly and functions Suction pump switch The machine is equipped with a suction pump. The suction pump switch (1) is located under the valve chamber cover on the right- hand side of the vehicle. Fuel gauge The machine is equipped with an additional fuel gauge. The fuel gauge (1) is located under the valve chamber cover on the right- hand side of the vehicle.
Page 70: Return Change Valve For Direct Return Flow
Assembly and functions Return change valve for direct return flow According to the mode of operation of a given attachment, the return flow of the hydraulic oil must occur either via the control valve (indi- rect return flow) or directly to the hydraulic oil tank (direct return flow).
Page 71: Engine Compartment
Assembly and functions Engine compartment The engine compartment (figure below) is positioned at the rear of the swivel frame; it is covered by a lockable hinged cover. V-belt cover Fuel filter Alternator Oil filler opening Compressor (A/C) Diesel particle filter muffler/diesel particle filter Oil dipstick Air filter Oil separator...
Page 72: Hydraulic System
Assembly and functions Hydraulic system All controls enable the functions via a hydraulic oil pilot control circuit. An accumulator allows the boom and the arm to be lowered in case of an engine failure. The hydraulic oil tank contains the suction filter. The return filter is mounted to the outside of the hydraulic oil tank. Hydraulic oil tank Control valve Plug...
Page 73: Coolant Radiator And Oil Cooler (A/C Condenser)
Assembly and functions Coolant radiator and oil cooler (A/C condenser) The cooling circuit radiators are located on the right-hand side of the engine compartment. Coolant radiator Hydraulic oil radiator Liquid reservoir and dryer (air-conditioner) Fuel cooler The A/C condenser (1) is located under a protection cover (2) on the right-hand side of the cab.
Page 74 Assembly and functions W9297-8135-2 12/2023...
Page 75: Operation
Operation OPERATION Safety rules for operation The safety instructions (page 17) must be followed. The machine may only be operated according to its approved use (page 19). The machine may only be operated by instructed or trained personnel (page 14). Do not operate the machine when under the influence of drugs, medication or alcohol.
Page 76: Safety For Children
Operation Safety for children Children are normally attracted to machines and their operation. If children are in the vicinity of the machine and are not at a suitable distance and in the field of vision of the operator, this can lead to serious accidents or even death of the children.
Page 77: Working In The Vicinity Of Overhead Power Lines
Check fluid levels as described in the "Maintenance" section (page 165). For a description of all operation features refer to the "Operating the machine" section (page 83) as well as the following sections. If malfunctions are detected, please inform your authorised KUBOTA dealer immediately. W9297-8135-2 12/2023...
Page 78: Setting The Display Language
Operation Setting the display language Messages in the display can be shown in 11 languages. Turn the starter switch to the RUN position. Press menu switch on dial switch. The menu bar appears in the display. Rotate jog dial to the right until “Various settings” is selected in the display.
Page 79: Setting The Date/Time
Operation Setting the date/time Turn the starter switch to the RUN position. Press menu switch on dial switch. The menu bar appears in the display. Rotate jog dial to the right until “Various settings” is selected in the display. Press Jog dial (enter switch). The Various settings appears in the display.
Page 80: Date And Time Display Format
Operation Date and time display format Time can be displayed in the 12- or 24-hour format, while the date format can be changed to day, month, year. Turn the starter switch to the RUN position. Press menu switch on dial switch. The menu bar appears in the display.
Page 81: Setting The Display Brightness
Operation Setting the display brightness The display brightness is presettable in 10 levels. This brightness setting can be made separately for the working light turn-on and turn-off states. Press menu switch on dial switch. The menu bar appears in the display. Rotate jog dial to the right until “Various settings”...
Page 82: Setting The Engine Auto-Stop Function
Operation Press jog dial (enter switch) to complete “Display brightness” setting. Input can be cancelled at any time. Changes are then not saved. To cancel your input, press return switch. The display returns to its previous display mode. Setting the engine auto-stop function The time until the engine auto-stop function is activated can be set.
Page 83: Setting The Work Light Turn-Off Delay Function
Operation “Engine auto-stop setting” screen appears in the display. Rotate jog dial to the right or the left until the desired item is se- lected. Press jog dial (enter switch) to confirm the desired item. Before making a “Time” setting, enable the “Engine auto-stop”...
Page 84: Running-In Of The Machine
Operation The Various settings appears in the display. Rotate jog dial to the right until “Work light turn-off delay” is se- lected in the display. Press Jog dial (enter switch). “Work light turn-off delay” setting screen appears in the display. Rotate jog dial to the right or the left until the desired item is se- lected.
Page 85: Special Maintenance Instructions
Operation Special maintenance instructions Damage to equipment due to contaminated grease! The grease plays a particular and important role in the running-in of the machine. The movable com- ponents are not yet broken in and generate many fine particles in the initial hours of operation that drop into the grease.
Page 86: Dust Valve - Clean
Operation Dust valve - clean Empty the dust valve (1) by pressing it together several times. Engine oil level - check Pull out the oil dipstick (1) and wipe it with a clean cloth. Insert the oil dipstick completely and pull it out again. The oil level should be in the "A"...
Page 87: Coolant Radiator And Oil Cooler (A/C Condenser) - Check
Operation Coolant radiator and oil cooler (A/C condenser) - check Perform a visual inspection of the coolant radiator (1), the fuel cooler (2), and the hydraulic oil cooler (3) for leaks and accu- mulation of dirt and debris. Perform a visual inspection of the condenser (1) for tightness and soiling.
Page 88: Exhaust System Leakage - Check
Operation Exhaust system leakage - check Risk of burns! Make sure that the engine has stopped and the exhaust system has cooled down. Check the exhaust system for leaks and security (formation of cracks) If the exhaust system is leaky or loose, the machine may only be taken into operation after repair.
Page 89: Bucket Bolt And Bucket Linkage Bolt - Grease
Operation Bucket bolt and bucket linkage bolt - grease Start the engine (page 94). Position the arm and bucket as shown in the figure. See the "Excavation work (operating the controls)" section (page 115). Stop the engine (page 97). Lubricate all greasing points (see figure to the right) – see the "Operating materials"...
Page 90: Fuel Level, Coolant Temperature, Hydraulic Oil Temperature, Date And Time - Check
Operation Fuel level, coolant temperature, hydraulic oil temperature, date and time - check The following function can be carried out when the key is not in the starter switch. The display shows the fuel level (1), the date and time (4), the hy- draulic oil temperature (3) and the coolant temperature (2).
Page 91: Adjusting The Operator's Seat
Operation Adjusting the operator's seat Adjust the operator's seat so that fatigue-free and comfortable working is possible. It should be pos- sible to operate all controls safely. Horizontal seat adjustment (seat stand-off) Pull the horizontal seat adjustment lever (5) up and move the seat to the desired position by moving it forward or back, then release the lever.
Page 92: Seat Belt
Operation Adjusting the console Pull up the console adjust lever (6) vertically and move it back and forth to adjust the horizontal position of the console. Then release the lever. With the console in a desired position, make sure the adjust lever is locked.
Page 93: Field Of View
Operation Field of view When the operator is sitting in the driver’s seat, it is important to be familiar with and understand the visibility con- ditions when operating the machine. Within the machine’s immediate radius of action, this helps to detect hazards that may cause accidents early on and thus prevent them.
Page 94: Adjusting The Rear View Mirrors
Operation Adjusting the rear view mirrors Risk of accidents! Adjust the rear view mirrors while the machine is standing still and the engine is switched off. Check whether the area behind the machine is obscured from view. Check the adjustment of the rear view mirrors (1). If necessary, adjust the rear view mirrors in order to ensure a clear view of the rear and of the obscured areas.
Page 95: Safety Instructions For Starting The Engine
Operation Safety instructions for starting the engine The machine is equipped with an anti-theft system (page 153). When starting the machine for the first time on a work day, carry out the pre-operational services (page 83). Make sure that there are no persons within the machine's working area. It is essential to warn per- sons in the vicinity of the machine by briefly honking the horn.
Page 96: Starting The Engine
Operation Starting the engine Place the potentiometer (1) to the centre position between . The AUTO IDLE switch (2) is switched off. The indicator (3) does not light up. Insert the key into the starter switch and turn it to the RUN position. Before starting the engine, make sure that the dozer control lever is not at the floating position (page 125).
Page 97 Operation The display message as in the figure on the right appears for a short period of time. The engine can be started after it disappears. The engine oil pressure indicator (2) lights up, then goes out again after the engine has started. The charge indicator (3) lights up, then goes out again after the en- gine has started.
Page 98 Operation After the engine has reached its operating temperature, set the engine speed required for operation: Turn the potentiometer (1) towards until the required speed is reached. Turn on AUTO IDLE control (2). The indicator (3) lights up when the AUTO IDLE control is enabled. The AUTO IDLE control makes sure that the pre-selected engine speed drops down to idle speed after approx.
Page 99: Starting The Engine In Cold-Weather Conditions
Operation Numeric (1) displays of the engine speed show the engines current number of revolutions per minute. The time meter (2) shows the actual hours of operation of the ma- chine (independent from the engine speed). Keep an eye on the displays and indicators during operation (page 98).
Page 100: Observation Of The Displays After Starting And During Operation
Operation Observation of the displays after starting and during operation The operator must observe the display indicators and displays after starting and during operation. The warning light (1) flashes red when a system fault or technical malfunction occurs. Stop the engine im- mediately! The warning light flashes yellow when the system issues a warning.
Page 101 Operation When the machine is being operated at or close to full capacity, the temperature of the coolant can rise a little higher than normal. The display message as in the figure on the right appears. Operate the machine only with reduced loads until the operating temperature is normal again.
Page 102: Checking Error Messages
Operation If the message "Feed Fuel" appears in the display and the warning light (1) flashes yellow, there is very little fuel left in the tank. Refuel the machine (page 144). Checking error messages Press menu switch on dial switch. The menu bar appears in the display.
Page 103 Operation The detail of the message appears in the display. To rotate jog dial can be used to scroll up and down through this screen. Also stop the engine immediately if the engine speed rises or drops suddenly, abnormal noises are heard, the mechanical equipment do not respond to the control lever as expected or the exhaust fumes are black or white.
Page 104: Operating The Rear View Camera
Operation Operating the rear view camera The rear view camera is an assistance system and is only to be used to improve and monitor the view in the immediate vicinity of the rear of the construction machine during turning and operating movements.
Page 105: Diesel Particle Filter Regeneration
Operation Diesel particle filter regeneration The machine has an exhaust system that is equipped with a diesel particle filter, which filters out carcinogenic soot particles from the exhaust gases. The diesel particle filter must be regenerated regularly in order to prevent the soot particles from clogging the die- sel particle filter rendering it useless.
Page 106: Automatic Diesel Particle Filter Regeneration - Procedure
Operation Automatic diesel particle filter regeneration - Procedure The following conditions have to be met for carrying out automatic regeneration. The automatic diesel particle filter regeneration is released and the indicator in the inhibit switch (1) does not start glowing. The engine coolant should be at operating temperature.
Page 107 Inform your KUBOTA dealer immediately. If the diesel particle filter is clogged and damaged, then the particle filter needs to be replaced by the KUBOTA dealer. The display message as in the figure on the right appears. In addi- tion, the red warning light flashes and an audible signal is emitted continuously.
Page 108: Automatic Diesel Particle Filter Regeneration - Overview
“Raise engine speed” indicator and 60 seconds to protect the particle fil- message disappear. ter. Inform your KUBOTA dealer if the re- flashing If the control lever lock is lowered, the generation does not start automati- (red) engine speed is limited.
Page 109: Locking And Releasing The Diesel Particle Filter Regeneration - Procedure
Operation Locking and releasing the diesel particle filter regeneration - Procedure Press the inhibit switch (1). The automatic diesel particle filter regeneration is locked and the in- dicator in the switch lights up. The diesel particle filter regeneration must be performed in certain intervals.
Page 110 The diesel particle filter is regenerated. But the engine power is restricted to 50%. If the diesel particle filter regeneration was locked permanently, the diesel particle filter must be reconditioned by your KUBOTA dealer. The display message as in the figure on the right appears. In addi- tion, the red warning light flashes and an audible signal is emitted at intervals.
Page 111: Locking And Releasing The Diesel Particle Filter Regeneration - Overview
If the control lever lock is low- ered, then the engine is not switched off. The diesel particle filter is Inform your KUBOTA dealer clogged with soot particles and immediately. the diesel particle filter regen- eration can no longer start. The diesel particle filter must be re- paired.
Page 112: Driving The Machine
Operation Driving the machine Adhere to the general safety rules (page 17) and the safety rules for operation (page 73). Carry out the pre-operational services (page 83). Start the engine (page 94). Observe the displays and indicators (page 98). Ensure that the boom and the dozer are in the direc- tion of travel as shown in the figure.
Page 113: Driving
Operation Raise the dozer to the top position by pulling back the dozer le- ver (1). Select an appropriate engine speed. Driving Push both drive levers forward simultaneously to drive the machine straight ahead. Releasing the drive levers stops the machine immediately. To reverse the machine, pull both drive levers back simultaneously.
Page 114: Turning
Operation Two audible signals will sound and the indicator (1) will change to the icon of fast speed. Pressing the travel speed button again switches back to normal speed and only one signal will sound. Do not drive fast on muddy or uneven terrain, also if another control is operated (e.g.
Page 115 Operation From a standing position Leave the right drive lever in neutral, push the left drive lever forward. In this case, the turning radius is determined by the right track. (A) The machine makes a right turn. Turning on the spot Do not make a turn on the spot with the travel speed button actuated.
Page 116: Driving Uphill And Downhill
Operation Driving uphill and downhill Exercise extreme caution when driving up and down a slope. Do not use the travel speed button. When driving on gradients, raise the bucket approx. 200 to 400 mm (A) above the ground (see figure). When driving on gradients, let the bucket slide over the ground if the terrain allows it.
Page 117: Operating The Controls During Excavation Work
Operation Making sharp turns Do not make sharp turns on streets with a high-friction tarmac, e.g. concrete. Protecting the crawler against salt Do not work with the machine on the seashore. (The salt will cause the steel insert to corrode.) Operating the controls during excavation work Always observe the following safety instructions when working with the machine.
Page 118: Note On Using Wider And Deeper Buckets
Operation Note on using wider and deeper buckets When using a wider or deeper bucket, take good care when swinging or retracting the front attachments to make sure that the bucket does not hit the cab. Operating the dozer Lifting and lowering When working with the dozer, operate both drive le- vers with the left hand and the dozer control lever with the right hand.
Page 119: Overview Of Control Lever Functions (Standard Setting)
Operation Floating position Only use the dozer’s floating position on loose ground when driving in reverse. Otherwise, the dozer can dig itself into the ground uncontrollably. The dozer control lever is used to switch on the floating position. Enabling the floating position releases pressure from the dozer cyl- inder.
Page 120: Operating The Boom
Operation Operating the boom If the machine is overloaded, the boom must be lowered until the load rests on the ground. To prevent personal injuries and damage to equipment, do not operate any other functions (e.g. moving the swivel frame). To raise the boom, pull the right control lever back (figure/ ).
Page 121: Operating The Bucket
Operation The arm moves as shown in the figure. Operating the bucket To crowd (digging) the bucket, move the right control lever to the left (figure/ ). To dump (empty) the bucket, move the right control lever to the right (figure/ ). When crowding the bucket, take care that the teeth do not hit the dozer.
Page 122: Swivelling The Swivel Frame
Operation Swivelling the swivel frame No person is allowed to stand in the swivel area during the movement. Swivel carefully to avoid any contact of the front at- tachments with adjacent objects. To turn anticlockwise, move the left control lever to the left (figure/ ).
Page 123: Operating The Auxiliary Ports
(AP 1+2). The operation features of the right and left control levers are configured according to the equipment at- tached. Only attachments approved by KUBOTA may be used. The attachments must be operated in accord- ance with the operating instructions supplied with them.
Page 124: Auxiliary Port 1
Operation The auxiliary port function is only available when the control lever lock is lowered. If the control lever lock is raised or it is raised during the operation of the auxil- iary port, then auxiliary port operation is not possible. The message appears as in the figure on the right.
Page 125: One-Way Hold Operation
Operation Only when the auxiliary port function is enabled, the rocker switch allows the oil to flow towards the auxilia- ry port. If this function is disabled, no oil flows towards the auxiliary port. The message appears as in the figure on the right. - Press the AUX enable switch first and then han- dle the rocker switch.
Page 126 Operation Operating modes The auxiliary port connector is preset at the factory, enabling five operating modes to be selected. The operating mode can be changed on the “Mode select” screen (page 124). The icon and flow rate index in the display change accordingly. When the starter switch is turned to the RUN position the most-recently used setting is activated.
Page 127 Operation The icon and flow rate index in the display change accordingly. The electric return change valve may be interlocked with the operating mode. The flow rate set for auxiliary port 1 is shown on the right of the dis- play, that of auxiliary port 2 on the left.
Page 128 Operation Rotate jog dial to the right until “Flow volume setting” is select- ed in the display. Press Jog dial (enter switch). The “Flow volume setting” mode select screen appears in the dis- play. Rotate jog dial to the right or the left until the desired mode is selected.
Page 129 Operation The maximum flow rate can be set for each auxiliary port connector. Rotate jog dial to the right or the left until the desired bar graph is selected. Press Jog dial (enter switch). Rotate the jog dial to the right or the left until the bar graph achieves a desired level.
Page 130: Return Change Valve For Direct Return Flow
Operation Rotate jog dial to the right until (icon of acknowledge) is se- lected in the display. Press jog dial (enter switch) to complete “Flow volume setting”. Input can be cancelled at any time. Changes are then not saved. To cancel your input, press return switch. The display returns to its previous display mode.
Page 131: Depressurising The Hydraulic System
Operation Depressurising the hydraulic system Perform the pressure relief procedure immediately after stopping the engine! Lower front attachments and dozer completely. Turn the starter switch to the STOP position. Wait until the engine has come to a standstill. Turn the starter switch to the RUN position. Do not start the engine! Lower the left control console (1) and make sure that the con- trol lever lock (2) engages.
Page 132 Operation Press the auxiliary port enable switch (1) and turn on the auxil- iary port function. You will see the setting of the flow rates in the display. The bar height "A" shows the flow rate at the respective auxiliary port con- nectors (1, 2, 3 and 4).
Page 133: Placing Out Of Operation
Operation Rocker switch auxiliary port 2 (6) on the left control lever must be pushed over completely to the right and left. The auxiliary port connectors (4 and 5) are pressure relieved. Placing out of operation Park the machine in such a way that it cannot move and is secured against unauthorised use.
Page 134: Operating The Heating And Air-Conditioner System
Operation Push the release lever (1) all the way forward and open the door. If the cab door is not closed again right away, lock the door at the cab wall. Close and lock the cab door. The key must remain with the op- erator.
Page 135: Heating The Cab
Operation Heating the cab Set the temperature control (1) to the "Warm" position. Blue Cold Warm Set the blower switch (2) to position 1, 2 or 3. Set the air nozzles to the desired position. To avoid accumulated heat and damage to the ventilation system, do not cover air nozzles with ob- jects (e.g.
Page 136: De-Icing Or Demisting The Windows
Operation To cool the cab faster, set the air supply lever (1) to the recir- culated air (B) position. Lasting circulating air mode leads to overtiring of the operator! A lasting use of the circulating air mode may cause a lack of oxygen inside the cab. No cool fresh air flows in from the outside.
Page 137: Operating The Wiper/Washer System
Operation Operating the wiper/washer system Risk of damage to components! When you turn on the wiper while the windscreen is opened, the wiper can hit the adjacent cab com- ponents causing damage to the wiper. - Do not turn on the wiper switch while the windscreen is open. Switching on the windscreen wiper The starter switch is in the RUN position.
Page 138: Operating The Room Light
Operation Operating the room light Press the switch (2) to the ON (A) position. The interior light (1) is illuminated as long as the switch remains in this position. To switch off, press the switch (2) to the OFF position (B). Operating the working light The starter switch is in the RUN position.
Page 139: Operating The 12 V Plug
Operation Operating the 12 V plug Open the cover cap (1) and put the load into the 12 V plug. The rated current of the connected load must not ex- ceed 10 A. Operating the USB outlet Open the cover cap (1) and put the load into the USB (Type-A) outlet.
Page 140: Opening And Closing The Windows
Operation Closing the cab door Press down the release lever (2) and pull the cab door into the lock. Opening the cab door from the inside Push the release lever (1) all the way forward and open the door. If the cab door is not closed again right away, lock the door at the cab wall.
Page 141: Front Window Base
Operation Opening Press the right and left lock bars (figure above/1) inwards simultaneously and push the front window upward at both grips (figure above/2) in the guide rails as far as the stopper. Lock the front window at the endpoint. Check that the front window is locked.
Page 142: Side Window
Operation Installing Check that the front window is opened before install- ing. Firmly hold the front window base (1) against the cab back wall with one hand. Loosen the locking mechanism (2) and carefully remove the front window base from the cab back wall. Note that the glass pane may fall down - risk of in- jury! Running into something can cause the glass pane to...
Page 143: Cold Weather Operation
Operation Cold weather operation Operating the machine at an ambient temperature below 5 °C is considered cold weather operation. Necessary preparations prior to the winter season If necessary, replace the engine oil and hydraulic oil with those of the viscosities specified for winter. Only use regular diesel fuel with winter additives.
Page 144: Jump-Starting The Machine
Operation Jump-starting the machine Only a vehicle or starting device with a 12 V power supply may be used. The operator must remain seated on the operator's place, the battery jumper cables must be con- nected by a second person. Make the battery accessible, and remove the positive terminal cover.
Page 145: Operating In Emergency Situations
Operation Operating in emergency situations In case of emergency, you can switch off the engine and lower the boom and the arm manually. Engine emergency stop If the engine cannot be stopped with the key, it can be stopped man- ually.
Page 146: Filling Up The Washer System (Cab Version)
Operation Filling up the washer system (cab version) Open the cap (1) of the washer system reservoir (2) and add water or a cleaning agent. In winter, use a cleaning agent with antifreeze. Refuelling the machine When refuelling the machine, smoking, an open flame, or other sources of ignition are not allowed. The danger zone has to be clearly marked with signs.
Page 147: Refuelling The Machine Using The Suction Pump
Operation Refuelling the machine using the suction pump If the machine is equipped with a suction pump, you can refuel it directly from a barrel or a jerrycan. The same safety rules apply as for refuelling the machine. Use the suction pump only for pumping diesel fuel. Do not use for any other liquids! Stop the engine.
Page 148: Bleeding The Fuel System
Operation Bleeding the fuel system If the fuel tank was run empty or if work was performed on the fuel system, then the fuel system has to be bled. To bleed the fuel system, move the starter switch to the RUN position. The electrical fuel pump will bleed the fuel system automatically within approx.
Page 149: Fuse Layout Of The Fuse Box
Operation Remove the cap (1) from the fuse box (2). Remove the blown fuse from the fuse box and replace it. The fuse layout is shown in the figure below. Fuse layout of the fuse box ECU Main (AC) Front Work Light Control lever lock Beacon 2 Alternator...
Page 150: Main Fuses
Operation Main fuses Remove the blown main fuse from the main fuse box (1) and replace it. Fuse layout: Alternator (100 A) Engine control unit (30 A) Main fuse (60 A) Engine cut-off switch (50 A) Electric blower fuse Remove the blown fuse from the fuse box (2) and replace it. Fuse layout: Electric blower (20 A) Fuel system and engine control fuses...
Page 151: Operating The Battery Isolator
Operation Operating the battery isolator In order for the machine to be operated, the battery isolator (1) must be in the ON position. If the battery isolator is in the OFF position, most of the electrically powered functions will be turned off (e.g. horn, working lights, etc.).
Page 152: Opening And Closing The Valve Chamber Cover
Operation Opening and closing the valve chamber cover Insert the ignition key (1) into the lock of the valve compartment cover (2), turn it clockwise and then push in the lock cylinder. Pull the handle (3) and swing the valve compartment cover all the way up.
Page 153: Opening/Closing The Tool Compartment
Operation Swing side cover (2) aside until the locking device (1) engages. Make sure that the catch has snapped into place prop- erly. If the cover is unexpectedly slammed shut, for ex- ample by another person or by the wind, this could lead to serious injury.
Page 154: Replacing The Bucket
Operation Replacing the bucket When replacing the bucket, make sure to wear eye protection, a helmet and protective gloves. During attaching and detaching, chippings and burrs may appear on the bolts or bushings. These may cause severe injuries. Never use your fingers for the alignment of the components (linkage, bucket, arm). The components may sever your fingers by uncontrolled movements.
Page 155: Anti-Theft System
Operation Anti-theft system The machine is equipped with an anti-theft system that restricts the engine to be started using a registered key only. If a registered key gets lost or stolen, you can invalidate it. This will prevent the engine from being started with this key, thus protecting the vehicle against theft.
Page 156: The Key System
Use only the special KUBOTA key ring. Other key rings can lead to signal failures between the key and starter switch, and the engine can possibly not start or a key registration cannot be performed.
Page 157: Registering A Black Key For The Machine
Operation If you attempt to register a fifth black key, the display will show the "No more keys" message and registration cannot be carried out. Registering a black key for the machine Register a black key only under the following conditions: Make sure that there are no persons within the machine’s working area.
Page 158 Operation Pull out the red key. The display shows the "Insert black key" message. Insert black key into the starter switch. Do not turn the key at this point. If the key is in the RUN position, turn it back to the STOP position. After a brief moment, the display shows the "Pull out black key"...
Page 159: Troubleshooting
In the POSSIBLE CAUSE column you will find the possible causes for the malfunction. The REPAIR column indicates the required remedial measure. If the failure cannot be remedied by the measure indicated in the REPAIR column, please consult your KUBOTA dealer. Safety rules for troubleshooting Adhere to the general safety rules (page 17) and the safety rules for operation (page 73).
Page 160: Troubleshooting: Operation
Troubleshooting Troubleshooting: Operation MALFUNCTION POSSIBLE CAUSE REPAIR Operation Insufficient engine power Air filter restricted Check, clean and replace the air fil- ter (page 182). Fuel filter contaminated or water in Check the water content of the water fuel system separator (page 87), drain if neces- sary (page 185).
Page 161 Fuel filter clogged Replace the fuel filter if necessary. Coolant temperature is too high. Water pump seal is damaged Replace it; consult your KUBOTA dealer if necessary. V-belt is damaged or very loose Replace and/or tension it (page 177).
Page 162: Troubleshooting: Display Indications
It is essential to take prompt action to rectify any incorrect operation, use or maintenance of the emis- sion control system in accordance with rectification as specified in the solution column. You can view detailed information by pressing the Jog dial (enter switch). Inform your KUBOTA deal- er which messages appeared in the display.
Page 163 Troubleshooting No. indicator Problem/Error Preliminary Measure Solution Problem with AUX2 / If systems other than Inform your KUBOTA dealer Thumb system. AUX2 / Thumb system immediately. function, work can be continued. Charging voltage is too Switch the engine off im- If the indicator lights up again high.
Page 164 (e.g. exca- vating) by pressing the overload warning switch. 10 hours until periodic Operate the machine as Ask your KUBOTA dealer for check interval. usual. relevant parts and use them to replace existing parts. Periodic check interval...
Page 165 Inform your KUBOTA dealer Common Rail System. immediately. Malfunctions in the par- Engine control is not Immediately contact your ticulate control device working properly. KUBOTA dealer of the emer- (PCD) / NOx control de- gency repair. vice (NCD). W9297-8135-2 12/2023...
Page 166 Troubleshooting W9297-8135-2 12/2023...
Page 167: Maintenance
Careful maintenance of the machine will guarantee functional safety and a longer service life. Failure to perform the servicing will void the warranty and any liability by KUBOTA. Only use spare parts that are recommended by the manufacturer. Non-approved spare parts of inferior quality or wrong classification result in an increased risk of accidents.
Page 168: Repair Work On The Machine
Maintenance Repair work on the machine Repairs on the machine may only be carried out by trained personnel. If repairs are carried out on load-bearing parts, for example welding on frame parts, the work has to be checked by a qualified person. After repairs, the machine should be operated only if it is functioning properly.
Page 169 Maintenance The list of “Periodic check” check points appears in the display. To rotate jog dial can be used to scroll up and down through the list of maintenance points. The maintenance points illustrated in the following table are set in the service period indicator. Elapsed hours of operation* Maintenance point Task...
Page 170: General Maintenance Chart: 50 To 500 Hours Of Operation
Maintenance General maintenance chart: 50 to 500 hours of operation Operator servicing Elapsed hours of operation Servicing Tasks Interval Page 50 100 150 200 250 300 350 400 450 500 Walk-around inspection Check Daily Dust valve Clean Daily Engine oil level Check Daily Coolant level...
Page 171: General Maintenance Chart: 550 To 1000 Hours Of Operation
Maintenance General maintenance chart: 550 to 1000 hours of operation Operator servicing Elapsed hours of operation Servicing Tasks Interval Page 550 600 650 700 750 800 850 900 950 1000 Walk-around inspection Check Daily Dust valve Clean Daily Engine oil level Check Daily Coolant level...
Page 172: Servicing Maintenance Chart: 50 To 500 Hours Of Operation
Maintenance Servicing maintenance chart: 50 to 500 hours of operation Servicing by skilled personnel or KUBOTA dealer Elapsed hours of operation* Servicing Tasks Interval Page 50 100 150 200 250 300 350 400 450 500 V-belt Adjust 250 h Pilot valve linkage...
Page 173 Elapsed hours of operation* Servicing Tasks Interval Page 50 100 150 200 250 300 350 400 450 500 Every 2 Fuel lines Change Please contact your KUBOTA dealer. years Every 2 Hydraulic hoses Change Please contact your KUBOTA dealer. years Every 2 Coolant...
Page 174: Servicing Maintenance Chart: 550 To 1000 Hours Of Operation
Maintenance Servicing maintenance chart: 550 to 1000 hours of operation Servicing by skilled personnel or KUBOTA dealer Elapsed hours of operation Servicing Tasks Interval Page 550 600 650 700 750 800 850 900 950 1000 V-belt Adjust 250 h Pilot valve linkage...
Page 175 Elapsed hours of operation Servicing Tasks Interval Page 550 600 650 700 750 800 850 900 950 1000 Every 2 Fuel lines Change Please contact your KUBOTA dealer. years Every 2 Hydraulic hoses Change Please contact your KUBOTA dealer. years Every 2 Coolant...
Page 176: Cleaning The Machine
Maintenance Cleaning the machine Before cleaning, shut down the engine and secure it against starting. If a steam cleaner is used for cleaning the machine, do not direct the steam jet at electric compo- nents. Do not direct a water jet into the intake opening of the air filter. Do not clean the machine with inflammable liquids.
Page 177: Servicing
Maintenance Servicing Adhere to the instructions for regular servicing to keep the machine in good condition. Pilot valve linkage - grease Pull rubber boot (3) on the control lever upward. Lubricate the linkage (1) underneath the disc (2) with grease. See "Operating materials"...
Page 178: Radiator - Clean
Maintenance Radiator - clean Do not touch the hot radiators: risk of burning. Open the side cover (page 150). Clean the coolant radiator (1), hydraulic oil radiator (2), and fuel cooler (3) from the engine side with a water jet or a compressed air pistol.
Page 179: V-Belts - Check/Adjust/Change
Maintenance V-belts - check/adjust/change Removing and Installing the V-belt cover Risk of injury by rotating components! The V-belt cover must be removed before performing any work with the V-belt. If the engine is running during these works, there is a risk of being caught and injured by rotating components.
Page 180 Maintenance Remove the mounting screws (1 & 2). Tighten the V-belt by swinging the alternator (3). Press in the V-belt at position "B". The V-belt must give way for approx. 10 mm (pressure: 10 kg). Tighten the fastening screws. After adjusting, check the V-belt. Install the V-belt cover.
Page 181: Coolant Hoses And Hose Clamps - Check
Maintenance Coolant hoses and hose clamps - check Only carry out inspections when engine is cold, other- wise there is a risk of burns! Open the engine compartment cover (page 149). Open the side cover (page 150). Inspect the condition of all hose connections (1) on the engine and to the radiator or to the heater fan (cracks, bulges, hard spots), check for leaks and verify tightness of the clamps.
Page 182: Engine Oil And Oil Filter - Change
Maintenance Remove the coolant expansion reservoir (1) and drain it, clean- ing it if necessary. Refit the reservoir. Fill the premixed coolant into the radiator and expansion reser- voir. Do not operate the cooling system with pure water (even in summer). The antifreeze also contains a cor- rosion inhibitor.
Page 183: Oil Filter - Change
Maintenance Oil filter - change Place an oil pan under the oil filter (1). Remove the oil filter us- ing a filter wrench (turn anticlockwise). Coat the sealing ring of the new oil filter with engine oil. Install and tighten the oil filter by hand. Do not use the filter wrench.
Page 184: Air Filter Element - Check/Clean/Change
Maintenance Air filter element - check/clean/change Risk of engine damage! The interior filter element (1) must remain installed while cleaning the air filter case (6). Otherwise, particles of dirt could enter the air intake duct while cleaning and damage parts of the injection sys- tem and engine.
Page 185: Interior Air Filter (Cab Version) - Check/Clean/Change
Maintenance Interior air filter (cab version) - check/clean/change If the machine is operated in a particularly dusty envi- ronment, the interior air filter must be checked more of- ten. Open the heating and air-conditioner unit service cover (page 151). Remove the screw (2). Open the cover plate (1).
Page 186: Fuel Filter - Change
Maintenance Set the filter with the cushion (A) facing upward and with the V-flap (B) facing outwards. Wrong setting shortens the filter’s service life. Replace the interior air filter (3). Close the cover (1). Tighten the screw (2). Close the heating and air-conditioner unit service cover. Fuel filter - change Users must take appropriate actions to insure fuel is not contaminated during operation.
Page 187: Water Separator - Drain
Maintenance Place cleaning cloths under the fuel filter (1) to prevent fuel from spilling onto the ground. Loosen and unscrew the filter using a filter key. Wet the rubber seal of the new filter with fuel. Do not add any fuel into the new filter cartridge before installing it.
Page 188 Maintenance Open the side cover (page 150). Visual inspection of the water separator for water and sedi- ments. Place a cleaning cloth under the water separator (1) to prevent fuel from running onto the ground. Turn the cock (2) to the “OFF” position. Loosen the venting screw (3).
Page 189: Water Separator - Clean
Maintenance Water separator - clean While changing the fuel filter, be careful not to allow dust or dirt into the fuel line and the fuel filter. Keep the water separator away from dust and dirt during assembly. Always remove spilled fuel immediately. Open the side cover (page 150).
Page 190: Water Separator Filter - Change
Maintenance Water separator filter - change While changing the fuel filter, be careful not to allow dust or dirt into the fuel line and the fuel filter. Keep the water separator away from dust and dirt during assembly. Always remove spilled fuel immediately. Open the side cover (page 150).
Page 191: Fuel Tank - Drain
Maintenance Fuel tank - drain Open the side cover (page 150). Place a container with a minimum capacity of 12 litres under the fuel drain valve (1). Open drain valve (A) and drain the water. Close the drain valve (B). Dispose of fluid in the container according to the appli- cable environmental protection regulations.
Page 192: Return Filter In The Hydraulic Oil Tank - Change
Maintenance Return filter in the hydraulic oil tank - change Pay attention to utmost cleanliness when servicing the hydraulic system. Users must take appropriate actions to insure hydraulic oil is not contaminated during oper- ation. Risk of injury by hot and pressurized hydraulic oil! This service may only be carried out after the hydraulic oil has cooled down.
Page 193: Suction Filter In The Hydraulic Oil Tank - Change
Maintenance Open the engine compartment cover (page 149). Remove the LH side cover (1). Remove the filter cup (4) from the filter head (1). Remove the filter element (2) from the filter head. Install new filter and new sealing ring (3). Screw in the filter cup and tighten it by hand.
Page 194 Maintenance Drain the hydraulic oil (page 193). Unscrew the hex bolts (3) and remove the cover (1). Remove the breather hose (2). Unscrew the hex bolts (2) and remove the hydraulic tank cover (1) with the seal. Remove the suction filter (2) with the rod (1) [suction filter as- sembly].
Page 195: Hydraulic Oil - Refill/Change
Maintenance Hydraulic oil - refill/change Pay attention to utmost cleanliness when servicing the hydraulic system. This service may only be carried out after the hydraulic oil has cooled down. The suction filter must be changed along with the hydraulic oil. Operate the boom, arm, bucket and boom swing mechanism so that all hydraulic cylinders are extended half- way.
Page 196: Filling The Hydraulic Oil
Maintenance Filling the hydraulic oil Before filling in a different brand of hydraulic oil, drain the hydraulic oil system completely. Filling quantity with oil change: approx. 75 l Total hydraulic system capacity: 155.5 l Remove the filler plug (1) from the hydraulic oil tank. Insert a clean funnel with a strainer into the filler plug opening.
Page 197: Battery Service
Maintenance Battery service The battery can become damaged or may explode if the following instructions are not observed. Reg- ular maintenance can extend the life cycle of the battery considerably. - For refillable-type batteries, never charge or use when the electrolyte level is below the [LOW- ER] (lower limit level) mark.
Page 198: Battery - Charge
Maintenance Battery - charge Battery acid is very caustic. Avoid contact with battery acid under all circumstances. If clothing, skin or eyes have come into contact with battery acid, rinse the affected parts immediately with water. If the eyes are affected, immediately seek medical attention! Neutralise spilled battery acid immediate- When servicing a battery, always wear suitable protective gloves and eye protection.
Page 199: Battery - Change
Maintenance Battery - change When disconnecting and connecting the battery, always observe the specified order Risk of short circuit. Make the battery accessible. Remove the negative terminal cover and take off the cable clamp. Move the clamp to the side so as to avoid contact with the negative terminal.
Page 200: Swivel Bearing - Grease
Maintenance Swivel bearing - grease Fill grease through the grease nipple (1) with a grease gun. Grease at each 90° position of the swivel bearing. Us- ing the grease gun, apply 5 shots at every position. Refer to the "Operating materials" section (page 210). When moving the swivel frame, make sure no person or material is in the swivel area.
Page 201: Other Greasing Points
Maintenance Other greasing points Start the engine (page 94). Position the boom, arm and dozer as shown in the figure. Stop the engine, remove the key. Refer to the “Ex- cavation work (operating the controls)” section (page 115). Lubricate all greasing points with grease – see the “Operating materials” section (page 210) – until fresh grease oozes out.
Page 202: Crawler Tension - Check/Adjust
Maintenance Crawler tension - check/adjust If the crawlers are too tight, wear is increased. If the crawlers are too loose, wear is increased and the crawlers may come off. When parking a machine with rubber crawlers, ensure that the seam ( ) is on top, halfway between the two sliders (see figure/1, Crawler tension (rubber) - check, page 201).
Page 203: Crawler Tension (Rubber) - Check
Maintenance Crawler tension (rubber) - check The crawler seam (1) is half way between the idler and sprock- Crawlers with an SP mark can be checked and ten- sioned in any position. Check the crawler sag as shown in the figure. Crawler sag "A"...
Page 204: Crawler Tension (Steel) - Check
Maintenance Crawler tension (steel) - check Check the crawler sag as shown in the figure. Crawler sag "A" 40-55 mm If the crawler sag is more than 55 mm, adjust the crawler. If necessary, tighten or loosen the crawler. Start the machine and rotate the lifted crawler briefly. Caution: The area around the rotating crawler must be free of persons.
Page 205: Drive Unit Oil - Change
Check that all the pipes and hoses of the heating and air-conditioner systems are in serviceable condition (no cracks, bulges or hard spots) and are firmly seated. If any damage is found, consult your KUBOTA dealer. Only trained personnel may work on the heating and air-conditioner systems.
Page 206: In Line Filter - Change
Maintenance In line filter - change The replacement procedures are explained with the LH control lever as an example; the RH control lever filter replacement should be performed in the same manner. Release the pilot circuit pressure. Raise the LH control console (1). Remove the lower trim panels.
Page 207: Refrigerant Content (Air-Conditioner Only) - Check
A low refrigerant level affects the performance of the equipment and the air-conditioner will eventually automati- cally switch off. If you find out that the refrigerant level is too low, please contact your KUBOTA dealer. Open the side cover (page 150).
Page 208: Viewing The Operations Log
Maintenance Viewing the operations log The operations log enables the operation of the machine over the previous three months to be checked. Turn the starter switch to the RUN position. Press menu switch on dial switch. The menu bar appears in the display. Rotate jog dial to the right until “Log record”...
Page 209: Bolted Joints - Check
Maintenance Bolted joints - check The table below contains the torques for nuts and bolts. These may only be tightened with a torque wrench. Miss- ing torques can be requested from KUBOTA. Tightening torque for screws Nm ( kgf m 7 T (8.8)
Page 210: Tightening Torque For Hydraulic Hoses
Maintenance Tightening torque for hydraulic hoses Nm ( kgf m Nut type Nut type Dimension (ORS) (Metal seal) (ORS) 7.8~11.8 1/8 ( - ) (0.8~1.2) 24.5~29.4 35.2~43.1 1/4 (9/16-18) (2.5~3.0) (3.6~4.4) 37.2~42.1 60.0~73.5 3/8 (11/16-16) (3.8~4.3) (6.1~7.5) 58.8~63.7 70.6~86.2 1/2 (13/16-16) (6.0~6.5) (7.2~8.8) 117.6~127.4...
Page 211: Tightening Torque For Hydraulic Adapters
Maintenance Tightening torque for hydraulic adapters Tightening torque Comments Thread size Wrench size Steel pipe kgf m (Pipe union) (guide number) (OD) R (conical thread) G (round thread) 19.6~29.4 17 mm 8 mm 1/8" 2.0~3.0 0.67 in. 0.31 in. With O-ring Tightening torque for 36.3~44.1 19 mm...
Page 212: Operating Materials
Always use distilled water to SAE J1034 mix with antifreeze. LLC-N-50F MB 325.0 Always follow the recommen- Coolant KUBOTA Mixing ratio ASTM D3306 dations of the coolant manufac- ASTM D4985 turer for the mixing ratio. Do not mix with other coolants.
Page 213: Requirements Regarding Fuel Use And Maintenance Of Crs Diesel Engines
4. The following cases are not covered by the warranty. If the engine fails because of the use of any fuel and/or fuel filter not recommended by KUBOTA or because of the negligence of specified instructions, KUBOTA will not accept any refunds.
Page 214 Maintenance W9297-8135-2 12/2023...
Page 215: Safety Inspection
Safety inspection SAFETY INSPECTION All safety inspections are based on the national worker's protection regulations, safety regulations and technical specifications applicable to the country in which the machine is operated. The operator (page 20) should arrange for the safety inspections to be performed at specified intervals in accord- ance with national laws and regulations.
Page 216 Safety inspection W9297-8135-2 12/2023...
Page 217: Taking Out Of Service And Storage
Taking out of service and storage TAKING OUT OF SERVICE AND STORAGE If the machine is taken out of service for up to six months, the measures before, during and after taking it out of service must be carried out as described below. If the vehicle is to be taken out of service for a period of over six months, contact the manufacturer for additional measures.
Page 218: Start-Up After Taking Out Of Service
Taking out of service and storage Start-up after taking out of service If necessary, clean the machine thoroughly (page 174). Check the hydraulic oil for condensate water. Replace the oil if necessary (page 193). Remove the grease from the piston rods of the hydraulic cylinders. Install the battery (page 197).
Page 219: Lifting Capacity Of The Excavator
Lifting capacity of the excavator LIFTING CAPACITY OF THE EXCAVATOR Constructive calculation of lifting capacity The lifting capacity of the excavator is based on ISO 10567 and does not exceed 75 % of the static tipping load or 87 % of the hydraulic lifting capacity of the machine. The lifting capacity is measured at the front bolt of the arm with the arm fully extended.
Page 220: Lifting Attachment
Load suspensions (e.g. hooks) may only be welded on by suitably skilled personnel. For this type of work, please contact your KUBOTA dealer. At every point of the implement or the boom, the lifting attachment must withstand a load of two-and-a-half- times its rated lifting load.
Page 221: Load Suspension Device
Lifting capacity of the excavator Load suspension device A load suspension device with all the characteristics listed below is required: The system must withstand a load two-and-a-half times its rated lifting load, regardless of the point at which that load is applied. The system must be designed in such a way as to practically prevent any objects that have been lifted from falling from the lifting attachment, for example by means of a protective attachment designed for this purpose.
Page 222 Information on inspecting lifting equipment in France The test coefficients determined by KUBOTA and to be applied for the commissioning or recommissioning of ma- chines equipped for lifting (article 10 et 11 de l'arrêté du 1 mars 2004 relatif aux vérifications des appareils et ac- cessoires de levage) are 1.0 for static testing and 1.0 for dynamic testing.
Page 223: Max. Lifting Load During Swivel Operation Is 360
Lifting capacity of the excavator Max. lifting load during swivel operation is 360° KX085-5 / arm 1750 mm and arm 2100 mm / operating weight 8467 kg W9297-8135-2 12/2023...
Page 224 Lifting capacity of the excavator Lifting capacity over front end, dozer down, only with pipe safety valve on the dozer cylinder MODEL KX085-5 SPECIFICATION OPERATING WEIGHT 8467 kg ARM 1750 mm kN (t) LIFT POINT RADIUS (mm) LIFT POINT HEIGHT...
Page 225 Lifting capacity of the excavator Lifting capacity over front end, dozer down, only with pipe safety valve on the dozer cylinder MODEL KX085-5 SPECIFICATION OPERATING WEIGHT 8467 kg ARM 2100 mm kN (t) LIFT POINT RADIUS (mm) LIFT POINT HEIGHT...
Page 226 Lifting capacity of the excavator W9297-8135-2 12/2023...
Page 227: Optional Equipment
Any manipulation can result in substantial personal injuries, even death, and is therefore strictly pro- hibited. The manipulation and repair of the pipe safety valves is prohibited. They may only be replaced by your KUBOTA dealer as a kit. W9297-8135-2...
Page 228: Kubota Gravel Guard
It is bolted onto the mounting points (see arrows) on the cab. KUBOTA auxiliary port kit The Auxiliary port kit is a set of pipe extensions (1) with quick re- lease couplings (2) and mountings (3) for the existing standard ports (4) at the arm.
Page 229: Kubota Quick Coupling Systems And Attachments
When attaching the bucket or other attachments, O-rings and spacers are required. They are sup- plied with the machine. Please contact your KUBOTA dealer if spacers with different dimensions are required. W9297-8135-2 12/2023...
Page 230: Removing The Bucket
Optional equipment Removing the bucket Lower the bucket onto a flat, even surface. Stop the engine. Ensure that the components indicated below remain free of dirt and dust. Unscrew the safety pins on bolts (2) and (3). The bucket is stored with bolts (2) and (3) in a total of four bearing eyes.
Page 231: Attaching The Bucket
Optional equipment Attaching the bucket Ensure that the components indicated below are free of dirt and dust. Ensure that an O-ring (6) is attached to each bearing eye (5). Check the O-rings and dust protection seals (7) for damage, re- place them if necessary.
Page 232 Optional equipment W9297-8135-2 12/2023...
Page 233: Software Information
This product includes "Open Source Software", which is provided "as is". KUBOTA and any third party that has the right to use OSS shall not be liable for any damages arising out of this software and its use or the inability to use it.
Page 234 Software information W9297-8135-2 12/2023...
Page 235 Software information W9297-8135-2 12/2023...
