Kubota KX080-3 Workshop Manual page 564

WSM KX080-3 Service
6) Remove the spring [230] (2 springs), valve
[227] (2 valves) from the rear flange [201].
(10) Disassembly of SRV mounted into the rear
flange
1) Loosen and remove the plug [282] (2 plugs)
from the rear flange [201].
2) Remove the O-ring [238] from the plug
[282],
Note : Do not reusethe O-ring [238] which has
been removed.
3) Remove the piston [286] from the rear
flange [201].
Note : The rear flange [201] and the piston
[286] are watched as a set. keep them
so you will know the combination.
Note : If the piston [286] is difficult to remove,
screw the bolt of M3 to the screw hole
for the disassembly of the piston [286].
Be careful not to do damaged the
piston hole.
IV-S-156
Hydraulic system
