Parameter
Gateway Registration Name
[GWRegistrationName]
First Redundant Proxy IP
Address
[ProxyIP]
Second Redundant Proxy IP
Address
[ProxyIP]
Third Redundant Proxy IP
Address
[ProxyIP]
76
Description
Defines the user name that is used in From and To headers of REGISTER
messages. Applicable only to single registration per gateway
(AuthenticationMode = 1).
If GWRegistrationName is not specified (default), the Username parameter
is used instead.
If AuthenticationMode=0, all the gateways endpoints are
registered with a user name that equals to the endpoints phone
number.
IP addresses of the first redundant Proxy you are using.
Enter the IP address as FQDN or in dotted format notation (for example
192.10.1.255). You can also specify the selected port in the format: <IP
Address>:<port>.
This parameter is available only if you select Use Proxy in the
Enable Proxy field.
When port number is specified, DNS NAPTR/SRV queries are not
performed, even if ProxyDNSQueryType is set to 1.
ini file note: The IP address of the first redundant Proxy is
defined by the second repetition of the ini file parameter ProxyIP.
IP addresses of the second redundant Proxy you are using.
Enter the IP address as FQDN or in dotted format notation (for example
192.10.1.255). You can also specify the selected port in the format: <IP
Address>:<port>.
This parameter is available only if you select Use Proxy in the
Enable Proxy field.
When port number is specified, DNS NAPTR/SR queries are not
performed, even if ProxyDNSQueryType is set to 1.
ini file note: The IP address of the second redundant Proxy is
defined by the third repetition of the ini file parameter ProxyIP.
IP addresses of the third redundant Proxy you are using.
Enter the IP address as FQDN or in dotted format notation (for example
192.10.1.255). You can also specify the selected port in the format: <IP
Address>:<port>.
This parameter is available only if you select Use Proxy in the
Enable Proxy field.
When port number is specified, DNS NAPTR/SR queries are not
performed, even if ProxyDNSQueryType is set to 1.
ini file note: The IP address of the second redundant Proxy is
defined by the third repetition of the ini file parameter ProxyIP.
3Com
®
VCX V7111 VoIP Gateway User Guide
