Parameter
Enable SIPS
[EnableSIPS]
Enable TCP Connection Reuse
[EnableTCPConnectionReuse]
SIP Destination Port
[ SIPDestinationPort ]
Use "user=phone" in SIP URL
[ IsUserPhone ]
Use "user=phone" in From Header
[IsUserPhoneInFrom]
Use Tel URI for Asserted Identity
[UseTelURIForAssertedID]
Tel to IP No Answer Timeout
[IPAlertTimeout]
Enable Remote Party ID
[EnableRPIheader]
68
Description
Enables secured SIP (SIPS) connections over multiple hops.
Disable [0] (default).
Enable [1].
When SIPTransportType = 2 (TLS) and EnableSIPS is disabled, TLS
is used for the next network hop only.
When SIPTransportType = 2 (TLS) or 1 (TCP) and EnableSIPS is
enabled, TLS is used through the entire connection (over multiple
hops).
If SIPS is enabled and SIPTransportType = UDP, the
connection fails.
Enables the reuse of the same TCP connection for all calls to the
same destination. Valid options include:
[0] = Use a separate TCP connection for each call (default)
[1] = Use the same TCP connection for all calls
SIP destination port for sending initial SIP requests.
The valid range is 1 to 65534. The default port is 5060.
SIP responses are sent to the port specified in the Via
header.
No [0] = user=phone string is not used in SIP URI.
Yes [1] = user=phone string is part of the SIP URI (default).
No [0] = Does not use ;user=phone string in From header (default).
Yes [1] = ;user=phone string is part of the From header.
Determines the format of the URI in the P-Asserted and P-Preferred
headers.
0 = 'sip:' (default).
1 = 'tel:'.
Defines the time (in seconds) the gateway waits for a 200 OK
response from the called party (IP side) after sending an INVITE
message. If the timer expires, the call is released.
The valid range is 0 to 3600. The default value is 180.
Enable Remote-Party-ID (RPI) headers for calling and called
numbers for Tel IP calls.
Disable [0] (default).
Enable [1] = RPI headers are generated in SIP INVITE messages
for both called and calling numbers.
®
