Configure the multiple IP parameters by completing the following steps:
4
Open the IP Settings screen (Advanced Configuration menu > Network Settings > IP
Settings option); the IP Settings screen is displayed.
Modify the IP parameters to correspond to the values shown in
OAM, Control and Media Network Settings parameters appear only after you select the
options Multiple IP Networks or Dual IP in the field IP Networking Mode.
Configure the OAM parameters only if the OAM networking parameters are different
from the networking parameters used in the Single IP Network mode.
Figure 107 Example of the IP Settings Screen
Click the Submit button to save your changes.
Configure the IP Routing table by completing the following steps (the IP Routing table is
5
required to define static routing rules for the OAM and Control networks since a default
gateway is not supported for these networks):
Open the IP Routing Table screen (Advanced Configuration menu > Network Settings >
IP Routing Table option); the IP Routing Table screen is displayed.
®
3Com VCX V7111 VoIP Gateway User Guide
Figure 107. Note that the
