NFS ini File Example
Figure 58
[ NFSServers ]
FORMAT NFSServers_Index = NFSServers_HostOrIP, NFSServers_RootPath,
NFSServers_NfsVersion, NFSServers_AuthType, NFSServers_UID, NFSServers_GID,
NFSServers_VlanType;
NFSServers 1 = 101.1.13, /audio1, 3, 1, 0, 1, 1;
[ \NFSServers ]

Configuring the IP Routing Table

The IP routing table is used by the gateway to determine IP routing rules. It can be used, for
example, to define static routing rules for the OAM and Control networks since a default
gateway is not supported for these networks (see
the gateway searches this table for an entry that matches the requested destination host /
network. If such entry is found, the gateway sends the packet to the indicated router. If no
explicit entry is found, the packet is sent to the default gateway (configured in Network
Settings > IP Settings screen). Up to 50 routing entries are available.
To configure the IP Routing table:
Open the IP Routing Table screen (Advanced Configuration menu > Network Settings >
1
Routing Table option); the IP Routing Table screen is displayed.
IP Routing Table Screen
Figure 59
Use the Add a new table entry pane to add a new routing rule. Each field in the IP routing
2
table is described in
Click the button Add New Entry; the new routing rule is added to the IP routing table.
3
166
Table 53.
Multiple IPs). Before sending an IP packet,
®
3Com VCX V7111 VoIP Gateway User Guide
