Management Settings Screen
Figure 72
Configure the Management Settings according to
2
Click Submit to save your changes.
3
To save the changes so they are available after a power fail,
4
Management Settings Parameters
Table 65
Parameter
Syslog Settings
Syslog Server IP address
[SyslogServerIP]
Syslog Server Port
[SyslogServerPort]
®
3Com VCX V7111 VoIP Gateway User Guide
Description
IP address (in dotted format notation) of the computer you are using to
run the Syslog Server.
The Syslog Server is an application designed to collect the logs and error
messages generated by the VoIP gateway. For information on the
Syslog, see V7111 Gateway Line
Defines the UDP port of the Syslog server.
The default value (that is, port) is 514.
Table 65.
Saving Configuration.
Testing.
199
