The Ini File Example - 3Com VCX v7111 User Manual

Syntax errors in the parameter value field can cause unexpected errors (because
parameters may be set to the wrong values).
Sub-section names are optional.
String parameters, representing file names, for example CallProgressTonesFileName,
must be placed between two inverted commas (...).
The parameter name is NOT case-sensitive; the parameter value is not case-sensitive
except for coder names.
The ini file should be ended with one or more carriage returns.

The ini File Example

Figure 97 shows an example of an ini file for the VoIP gateway.
SIP ini File Example
Figure 97
[Channel Params]
DJBufMinDelay = 75
RTPRedundancyDepth = 1
DefaultNumber = 101
MaxDigits = 3
CoderName = g7231,90
; Phone of each endpoint
EnableSyslog = 0
[Files]
CallProgressTonesFilename = 'CPUSA.dat'
FXSLoopCharacteristicsFileName = 'coeff.dat'
SaveConfiguration = 1
®
3Com VCX V7111 VoIP Gateway User Guide
239
