3Com VCX v7111 User Manual page 206

ini File Parameter Name
HeartBeatDestPort
HeartBeatIntervalmsec
RADIUSRetransmission
RADIUSTo
HTTPS Parameters
HTTPSPort
HTTPSRequireClientCertificate
HTTPSRootFileName
HTTPSPkeyFileName
[Security Settings > Certificates]
HTTPSCertFileName
BootP and TFTP Parameters
The BootP parameters are special Hidden parameters. Once defined and saved in the flash memory, they
are used even if they don't appear in the ini file.
206
Valid Range and Description
Destination UDP port to which the heartbeat packets are sent.
The range is 0 to 64000.
The default is 0.
Delay (in msec) between consecutive heartbeat packets.
10 = 100000.
-1 = disabled (default).
Determines the number of RADIUS retransmission retries for the
same request.
The valid range is 1 to 10.
The default value is 3.
Determines the time interval (measured in seconds) the gateway
waits for a response before a RADIUS retransmission is issued.
The valid range is 1 to 30.
The default value is 10.
Determine the local Secured HTTPS port of the device.
The valid range is 1 to 65535 (other restrictions may apply within this
range).
The default port is 443.
Requires client certificates for HTTPS connection. The client
certificate must be preloaded to the gateway, and its matching private
key must be installed on the managing PC. Time and date must be
correctly set on the gateway, for the client certificate to be verified.
0 = Client certificates are not required (default).
1 = Client certificates are required.
Defines the name of the HTTPS trusted root certificate file to be
loaded using TFTP. The file must be in base64-encoded PEM
(Privacy Enhanced Mail) format.
The valid range is a 47-character string.
This parameter is only relevant when the gateway is loaded
using BootP/TFTP. For information on loading this file using
the Embedded Web Server, see the Security section in the
Users Manual.
Defines the name of a private key file (in unencrypted PEM format) to
be loaded from the TFTP server.
Defines the name of the HTTPS server certificate file to be loaded
using TFTP. The file must be in base64-encoded PEM format.
The valid range is a 47-character string.
This parameter is only relevant when the gateway is loaded
using BootP/TFTP. For information on loading this file using
the Embedded Web Server, see the Security section in the
Users Manual.
®
3Com VCX V7111 VoIP Gateway User Guide
