To modify an existing remote NFS file system:
Click the Edit radio button for the row to be modified.
1
Change the values on the selected row according to your requirements.
2
Click Apply New Settings; the remote NFS file system is mounted using the new settings.
3
Check the Syslog server for the NFS mount was successful message.
To save the changes so they are available after a power fail, see
4
Network Settings, NFS Settings Parameters
Table 52
Parameter
Line Number
[NFSServers_Index]
Host / IP
[NFSServers_HostOrIP]
Root Path
[NFSServers_RootPath]
The combination of Host / IP and Root Path must be unique for each row in the table. For example, there
must be only one row in the table with a Host / IP of 192.168.1.1 and Root Path of /audio.
NFS Version
[NFSServers_NfsVersion]
Auth Type
[NFSServers_AuthType]
UID
[NFSServers_UID]
GID
[NFSServers_GID]
VLAN Type
[NFSServers_VlanType]
Figure 58
shows an example of an NFS table definition using ini file using parameter tables
(for information on parameter tables, see
®
3Com
VCX V7111 VoIP Gateway User Guide
Description
The row index of the remote file system.
The valid range is 0 to 4.
The domain name or IP address of the NFS server. If a domain
name is provided, a DNS server must be configured.
Path to the root of the remote file system.
In the format: / + [path]
For example, /audio
NFS version to use with the remote file system, 2 or 3 (default).
Identifies the authentication method used with the remote file
system.
AUTH_NULL [0] .
AUTH_UNIX [1] (default).
User ID used in authentication if using AUTH_UNIX.
The valid range is 0 to 65537. The default is 0.
Group ID used in authentication if using AUTH_UNIX.
The valid range is 0 to 65537. The default is 1
The VLAN, OAM [0] or Media [1] , to use when accessing the
remote file system. The default is to use the media VLAN.
This parameter applies only if VLANs are enabled or if Multiple IPs
is configured (see
IP QoS via Differentiated Services
Using Parameter
Saving
Configuration.
(DiffServ)).
Tables).
165
