Parameter
Any telephone number whose destination number matches the prefix defined in the Destination Phone
Prefix field and its source number matches the prefix defined in the adjacent Source Phone Prefix field, is
sent to the IP address entered in the IP Address field.
Note that Tel to IP routing can be performed according to a combination of source and destination phone
prefixes, or using each independently.
An additional entry of the same prefixes can be assigned to enable alternative routing.
For available notations that represent multiple numbers, see
Destination IP Address
Profile ID
Status
Charge Code
Parameter Name in ini File Parameter Format
Prefix
IP to Hunt Group Routing
The IP to Hunt Group Routing Table is used to route incoming IP calls to groups of channels
called hunt groups. Calls are assigned to hunt groups according to any combination of the
following three options (or using each independently):
Destination phone prefix
120
Description
In each of the IP Address fields, enter the IP address (and optionally port
number) that is assigned to these prefixes. Domain names, such as
domain.com, can be used instead of IP addresses.
For example: <IP Address>:<Port>
To discard outgoing IP calls, enter 0.0.0.0 in this field.
When using domain names, you must enter a DNS server IP address,
or alternatively define these names in the Internal DNS Table.
Enter the number of the IP profile that is assigned to the destination IP address
defined in the Destination IP Address field.
A read only field representing the quality of service of the destination IP
address.
N/A = Alternative Routing feature is disabled.
OK = IP route is available
Ping Error = No ping to IP destination, route is not available
QoS Low = Bad QoS of IP destination, route is not available
DNS Error = No DNS resolution (only when domain name is used instead of an
IP address).
An optional Charge Code (1 to 25) can be applied to each routing rule to
associate it with an entry in the Charge Code table (see
Prefix = <Destination Phone Prefix>, <IP Address>,<Src Phone Prefix>,<IP
Profile ID>,<Charge Code>
For example:
Prefix = 20,10.2.10.2,202,1,15
Prefix = 10[340-451]xxx#,10.2.10.6,*,1,1
Prefix = *,gateway.domain.com,*,20
<destination / source phone prefix> can be single number or a range
of numbers. For available notations, see to
This parameter can appear up to 50 times.
Parameters can be skipped by using the sign $$, for example:
Prefix = $$,10.2.10.2,202,1
An optional IP ProfileID (1 to 9) can be applied to each routing rule.
Dialing Plan
Dialing Plan
®
3Com VCX V7111 VoIP Gateway User Guide
Notation.
Charge Codes Table).
Notation.
