3Com VCX v7111 User Manual page 125

Internal SRV Table Screen
Figure 39
In the Domain Name field, enter the hostname to be translated. You can enter a string up
2
to 31 characters long.
From the Transport Type drop-down list, select a transport type.
3
In the DNS Name 1 field, enter the first DNS A-Record to which the hostname is
4
translated.
In the Priority, Weight and Port fields, enter the relevant values
5
Repeat steps 4 to 5, for the second and third DNS names, if required.
6
Repeat steps 2 to 6, for each Internal SRV Table entry.
7
Click Submit to save your changes.
8
To save the changes so they are available after a hardware reset or power fail, see to
9
Saving Configuration.
Internal SRV ini File Parameter
Figure 40
Parameter Name in ini File
SRV2IP
®
3Com VCX V7111 VoIP Gateway User Guide
Parameter Format
SRV2IP = <Internal Domain Name>, <Transport Type>, <DNS
Name 1>, <Priority 1>, <Weight 1>, <Port 1>, <DNS Name 2>,
<Priority 2>, <Weight 2>, <Port 2>, <DNS Name 3>, <Priority 3>,
<Weight 3>, <Port 3>
If the internal SRV table is configured, the gateway first
tries to resolve a domain name using this table. If the
domain name isn't found, the gateway performs an SRV
resolution using an external DNS server.
This parameter can appear up to 10 times.
125
