Retain any diskettes or CDs.
6

Package Contents

Ensure that in addition to the V7111 1x PORT, the package contains:
AC power cable.
Small plastic bag containing four anti-slide bumpers for desktop installation.
A CD with software and documentation may be included.
The V7111 Fast Track Installation Guide.

19-inch Rack Installation Package (Optional)

An additional option is available for installing the V7111 1x PORT in a 19-inch rack. The 19-
inch rack installation package contains a single shelf (shown in
device screws.
The 19-inch rack shelf is not supplied in the standard package kit, but can be
ordered separately: Bulk Pack package (MCMK00015) containing 10 rack
mounting shelves for V7111 1x PORT. For ordering and pricing, please contact
your 3Com' distributor.
19-inch Rack Shelf
Figure 6

Mounting the V7111 1x PORT

The V7111 1x PORT can be mounted on a desktop (see
Desktop), on a wall (see
19-inch rack (Installing the V7111 1x PORT in a 19-inch
Figure 7 describes the V7111 1x PORT base.
32
Mounting the V7111 1x PORT on a
Figure
Mounting the V7111 1x PORT on a
Wall) or installed in a standard
Rack).
®
3Com VCX V7111 VoIP Gateway User Guide
6) and eight shelf-to-
