A F: SNMP T
PPENDIX RAPS
This section provides information on proprietary SNMP traps currently supported by the
gateway. There is a separation between traps that are alarms and traps that are not (logs).
Currently all have the same structure made up of the same 11 varbinds (Variable Binding)
(1.3.6.1.4.1.5003.9.10.1.21.1).
The source varbind is composed of a string that details the component from which the trap is
being sent (forwarded by the hierarchy in which it resides). For example, an alarm from an
SS7 link has the following string in its source varbind:
acBoard#1/SS7#0/SS7Link#6
In this example, the SS7 link number is specified as 6 and is part of the only SS7 module in
the device that is placed in slot number 1 (in a chassis) and is the module to which this trap
relates. For devices where there are no chassis options the slot number of the gateway is
always 1.

Alarm Traps

The following tables provide information on alarms that are raised as a result of a generated
SNMP trap. The component name (described in each of the following headings) refers to the
string that is provided in the acBoardTrapGlobalsSource trap varbind. To clear a generated
alarm the same notification type is sent but with the severity set to cleared.
®
441
3Com VCX V7111 VoIP Gateway User Guide
