To configure the Tel to IP Routing table:
Open the Tel to IP Routing screen (Protocol Management menu > Routing Tables
1
submenu > Tel to IP Routing option); the Tel to IP Routing screen is displayed (shown in
Figure 37).
In the Tel to IP Routing Mode field, select the Tel to IP routing mode (see
2
In the Routing Index drop-down list, select the range of entries that you want to edit.
3
Configure the Tel to IP Routing table according to
4
Click Submit to save your changes.
5
To save the changes so they are available after a power fail,
6
Tel to IP Routing Table Screen
Figure 37
Tel to IP Routing Table
Table 32
Parameter
Tel to IP Routing Mode
[RouteModeTel2IP]
Destination Phone Prefix
Source Phone Prefix
®
3Com VCX V7111 VoIP Gateway User Guide
Description
Route calls before manipulation [0] = Tel IP calls are routed before the
number manipulation rules are applied (default).
Route calls after manipulation [1] = Tel IP calls are routed after the number
manipulation rules are applied.
Not applicable if Proxy routing is used.
Each entry in the Destination Phone Prefix fields represents a called telephone
number prefix. The prefix can be 1 to 19 digits long. An asterisk (*) represents
all numbers.
Each entry in the Source Phone Prefix fields represents a calling telephone
number prefix. The prefix can be 1 to 19 digits long. An asterisk (*) represents
all numbers.
Table 32.
Saving Configuration.
Table 32 ).
