Data line(s): Contain the actual values of the parameters. The values are interpreted
according to the Format line. The first word of the Data line must be the table's string
name followed by the Index fields.
Items must be separated by a comma ','.
A Data line must end with a semicolon ';'.
End-of-Table-Mark: Indicates the end of the table. The same string used for the table's
title, preceded by a backslash '\' (for example, [\MY_TABLE_NAME]).
Figure 113 displays an example of the structure of a parameter table in the ini file.
Figure 113 Structure of a Parameter Table in the ini File
; Table: Items Table.
; Fields: Item_Name, Item_Serial_Number, Item_Color, Item_weight.
; NOTE: Item_Color is not specified. It will be given default value.
[Items_Table]
; Fields declaration
Format Item_Index =
Items_Table 0 = Computer, 678678, 6;
Items_Table 6 = Computer-screen, 127979, 9;
Items_Table 2 = Computer-pad, 111111, $$;
[\Items_Table]
Refer to these notes:
Indices (in both the Format and the Data lines) must appear in the same order
determined by the specific table's documentation. The Index field must never be omitted.
The Format line can include a sub-set of the configurable fields in a table. In this case, all
other fields are assigned with the pre-defined default values for each configured line.
The order of the fields in the Format line is not significant (as opposed to the Index-
fields). The fields in the Data lines are interpreted according to the order specified in the
Format line.
The sign '$$' in a Data line indicates that the user wants to assign the pre-defined default
value to it.
The order of the Data lines is insignificant.
Data lines must match the Format line, that is, it must contain exactly the same number
of Indices and Data fields and must be in exactly the same order.
A line in a table is identified by its table-name and Index fields. Each such line may
appear only once in the ini file.
Table dependencies:
Certain tables may depend on other tables. For example, one table may include a field
that specifies an entry in another table. This method is used to specify additional
attributes of an entity, or to specify that a given entity is part of a larger entity. The tables
308
Item_Name, Item_Serial_Number, Item_weight;
