RADIUS Parameters Screen
Figure 52
Configure the RADIUS accounting parameters according to
2
Click Submit to save your changes.
3
To save the changes so they are available after a power fail, see
4
RADIUS Parameters
Table 46
Parameter
Enable RADIUS
EnableRADIUS
RADIUS Accounting Server
IP Address
[RADIUSAccServerIP]
RADIUS Accounting Port
[RADIUSAccPort]
RADIUS Accounting Type
[RADIUSAccountingType]
AAA Indications
[ AAAIndications ]

Configuring the FXO Parameters

Use this screen to configure the gateways specific FXO parameters.
To configure the FXO parameters:
Open the FXO Settings screen (Protocol Management menu > FXO Settings > FXO
1
Settings option); the FXO Settings screen is displayed.
®
3Com VCX V7111 VoIP Gateway User Guide
Description
Enables or disables the RADIUS application.
Valid options include:
Disables [0] = disables RADIUS application (default)
Enable [1] = enables RADIUS application
IP address of the RADIUS accounting server.
Port of the RADIUS accounting server.
The default value is 1646.
Determines when the RADIUS accounting messages are sent to the RADIUS
accounting server.
Valid options include:
At Call Release [0] = At the release of the call only (default).
At Connect and Release [1] = At the connect and release of the call.
At Setup and Release [2] = At the setup and release of the call.
Determines which Authentication, Authorization and Accounting (AAA) indications
to use.
Valid options include:
None [0] = No indications (default)
Accounting Only [3] = Only accounting indications are used.
Table 46.
Saving Configuration.
